Belkin F5U402-03IN-KIT User manual

Belkin Tech Support
US: 310-898-1100, ext. 2263
800-223-5546, ext. 2263
UK: 0845 607 77 87
Australia: 1800 235 546
New Zealand: 0800 235 546
Singapore: 800 616 1790
Europe: www.belkin.com/support
Belkin International, Inc.
501 West Walnut Street
Los Angeles, CA 90220, USA
310-898-1100
310-898-1111 fax
Belkin Ltd.
Express Business Park, Shipton Way
Rushden, NN10 6GL, United Kingdom
[phone]
[phone] fax
© 2007 Belkin International, Inc. All rights reserved. All trade names are registered trademarks of
respective manufacturers listed. Windows and Windows Vista are either registered trademarks or
trademarks of Microsoft Corporation in the United States and/or other countries. P75358-B
Belkin B.V.
Boeing Avenue 333
1119 PH Schiphol-Rijk, The Netherlands
[phone]
[phone] fax
Belkin Ltd.
4 Pioneer Avenue
Tuggerah Business Park
Tuggerah, NSW 2259, Australia
[phone]
[phone] fax
In-Desk
USB Hub

In-Desk
USB Hub
User Manual
F5U402-02IN/F5U402-03IN

1. Introduction ...................................................................... 1
Features ........................................................................ 2
Package Contents ......................................................... 2
Technical Specifications ................................................ 3
2. Installation ....................................................................... 4
3. Information ...................................................................... 5
Table of Contents

1
2
3
1
Congratulations and thank you for purchasing the In-Desk
USB Hub. The Hub provides four downstream USB ports
that offer backward-compatible, Plug-and-Play connectivity
with all USB devices, including USB 1.1 (low- and full-speed)
and USB 2.0 (high-speed) devices. This includes such
peripherals as scanners, printers, mass-storage devices, and
high-resolution cameras. The Hub is self-powered, which
allows the cascading of devices with additional hubs so that
up to 127 USB devices may be connected to a single port.
The Hub fits into an included 2- or 3-inch mounting ring, for
discreet placement into your desk.
Note: If your desk does not have a pre-drilled hole in it, you
can drill one yourself using a 2- or 3-inch hole saw (requires
separate purchase, not from Belkin).
Note: When the Hub is connected to a USB 1.1 host
controller, the maximum USB 1.1 bandwidth of 12Mbps
must be shared by all four ports.
Introduction
1
2
3

2
2
Introduction
1
2
3
Features
• USB specification 2.0 (data rate 1.5/12/480Mbps)
• Backward-compatible with USB Specification 1.1 (data rate
1.5/12Mbps)
• Compatibility with Windows® 98SE, Me, 2000, XP,
and VistaTM
• Approved by USB Implementers Forum (USB-IF)
• Plug-and-Play connectivity
• Hot-swapping capability
• Over-current detection and protection
• Multiple mounting-ring sizes for different desks (3" and 2")
Package Includes
• In-Desk USB Hub
• Mounting Ring
• Power Adapter
• USB 2.0 Cable
• User Manual
Note: Mount Ring (Grommet) Caps, Belkin part numbers
F5U402-02IN-GRC and F5U402-03IN-GRC, may be used for cable
management and to cover mounting-ring opening when Hub is not
present (not included).

3
3
Technical Specifications
Upstream Ports: 1
Downstream Ports: 4
Per-Port Voltage: DC +5V
Per-Port Current: 500mA (max) (self-powered mode)
Power Mode: Self-powered/bus-powered
Operating Temperature: 5° C ~ 40° C
Storage Temperature: -20° C ~ 60° C
Enclosure: ABS
Power Supply: Output: DC 5V, 2.5A
Plug Size: 3.5mm (outer)
1.0mm (center)
Plug Polarity: Center positive
Main-Power LED
Color Definitions Off: Not operational
Green: Operational
Port-Status LED
Color Definitions Off: Not operational
Green: Operational
Introduction
1
2
3

4
4
1
2
3
IMPORTANT NOTE: Please do not connect any USB devices to
the Hub until instructed to do so in step 5 of this installation
procedure.
1. Insert the mounting ring into the desk.
2. Plug the included power adapter into a wall outlet or surge
suppressor, running its cable through the mounting ring. Do not
plug it into the Hub yet.
3. Plug the flat end of the USB device cable into the downstream
port of your computer or another hub; and run the USB cable
through the mounting ring.
4. Now, plug in the power cable’s connector to the power jack on the
rear of the Hub.
Note: You can use the Hub without the power supply when
connecting low-power devices such as keyboards and mice.
5. Plug the square end of the USB device cable into the upstream
port on the rear of the Hub.
6. Place the Hub into the mounting ring.
Important Note: The Hub must be connected to a USB 2.0-
compliant host in order to function in high-speed mode (480Mbps
data rate). If the Hub is connected to a USB 1.1-compliant host, it will
operate only in low- or full-speed mode (1.5Mbps/12Mbps).
7. Windows will now detect your Hub and install the required driver.
(The Windows “Install New Hardware Wizard” may prompt you to
provide your Windows Installation CD to complete the
driver-installation process.)
Important Note: Hi-Speed USB 2.0 hub drivers are included with
most USB 2.0 PCI upgrade cards and are pre-installed along with
the PCI-card drivers. If you purchased an upgrade card prior to the
advent of Hi-Speed USB 2.0 hub support, please check with your
PCI-card vendor for an updated USB 2.0 driver.
8. Plug the USB-A connector of the USB device or additional hub
into any of the In-Desk USB Hub’s downstream ports.
Important Note: When moving a device from one port to another, it
may be necessary to reinstall the USB drivers for that device.
Installation

5
5
Information
CE Declaration of Conformity
We, Belkin International, Inc., declare under our sole responsibility
that the F5U402-02IN/F5U402-03IN, to which this declaration relates,
are in conformity with Generic Emissions Standard EN55022:1998
Class B, EN50081-1, and with Generic Immunity Standard
EN50082-1:1992.
Belkin International, Inc., Limited Lifetime Product Warranty
What this warranty covers.
Belkin International, Inc., warrants to the original purchaser of this
Belkin product that the product shall be free of defects in design,
assembly, material, or workmanship.
What the period of coverage is.
Belkin International, Inc., warrants the Belkin product for the lifetime
of the product.
What will we do to correct problems?
Product Warranty.
Belkin will repair or replace, at its option, any defective product free
of charge (except for shipping charges for the product).
1
2
3
FCC Statement
DECLARATION OF CONFORMITY WITH FCC RULES FOR
ELECTROMAGNETIC COMPATIBILITY
We, Belkin International, Inc., of 501 West Walnut Street, Compton, CA
90220, declare under our sole responsibility that the products:
F5U402-02IN/F5U402-03IN
to which this declaration relates:
Comply with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference
that may cause undesired operation. This equipment may only be operated
indoors. Operation outdoors is in violation of 47 U.S.C. 301 and could subject
the operator to serious legal penalties.

66
Information
1
2
3
What is not covered by this warranty?
All above warranties are null and void if the Belkin product is not
provided to Belkin International, Inc., for inspection upon Belkin’s
request at the sole expense of the purchaser, or if Belkin International,
Inc., determines that the Belkin product has been improperly installed,
altered in any way, or tampered with. The Belkin Product Warranty
does not protect against acts of God (other than lightning) such as
flood, earthquake, war, vandalism, theft, normal-use wear and tear,
erosion, depletion, obsolescence, abuse, damage due to low voltage
disturbances (i.e. brownouts or sags), non-authorized program, or
system equipment modification or alteration.
How to get service.
To get service for your Belkin product you must take the
following steps:
1. Contact Belkin International, Inc., at 501 W. Walnut St.,
Compton CA 90220, Attn: Customer Service, or call
(800)-223-5546, within 15 days of the Occurrence.
Be prepared to provide the following information:
a. The part number of the Belkin product.
b. Where you purchased the product.
c. When you purchased the product.
d. Copy of original receipt.
2. Your Belkin Customer Service Representative will then instruct
you on how to forward your receipt and Belkin product and how
to proceed with your claim.
Belkin International, Inc., reserves the right to review the damaged
Belkin product. All costs of shipping the Belkin product to Belkin
International, Inc., for inspection shall be borne solely by the
purchaser. If Belkin determines, in its sole discretion, that it is
impractical to ship the damaged equipment to Belkin International,
Inc., Belkin may designate, in its sole discretion, an equipment repair
facility to inspect and estimate the cost to repair such equipment.
The cost, if any, of shipping the equipment to and from such repair
facility and of such estimate shall be borne solely by the purchaser.
Damaged equipment must remain available for inspection until the
claim is finalized. Whenever claims are settled, Belkin International,
Inc., reserves the right to be subrogated under any existing insurance
policies the purchaser may have.

7
How state law relates to the warranty.
THIS WARRANTY CONTAINS THE SOLE WARRANTY OF BELKIN
INTERNATIONAL, INC., THERE ARE NO OTHER WARRANTIES,
EXPRESSED OR, EXCEPT AS REQUIRED BY LAW, IMPLIED,
INCLUDING THE IMPLIED WARRANTY OR CONDITION OF
QUALITY, MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE, AND SUCH IMPLIED WARRANTIES, IF ANY, ARE
LIMITED IN DURATION TO THE TERM OF THIS WARRANTY.
Some states do not allow limitations on how long an implied
warranty lasts, so the above limitations may not apply to you.
IN NO EVENT SHALL BELKIN INTERNATIONAL, INC., BE LIABLE
FOR INCIDENTAL, SPECIAL, DIRECT, INDIRECT, CONSEQUENTIAL
OR MULTIPLE DAMAGES SUCH AS, BUT NOT LIMITED TO, LOST
BUSINESS OR PROFITS ARISING OUT OF THE SALE OR USE OF
ANY BELKIN PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY
OF SUCH DAMAGES.
This warranty gives you specific legal rights, and you may also have
other rights, which may vary from state to state. Some states do not
allow the exclusion or limitation of incidental, consequential, or other
damages, so the above limitations may not apply to you.
