Bell HP250 AP User manual
Read carefully this manual before installing and using the pump.
Vor Installation und Inbetriebnahme der Pumpe muß dieses Handbuch aufmerksam durchgelesen werden.
s.r.l.
HP250 - HP500
HP700 - HP1000
(AP & RC)
112
45
280
295,5
33
14,7 4580,845
54
117
100
127,5
70,4
146
190
113
218
233,5
358
112
34,5
280
180
366,5
Fig.2a
Fig.2b
Fig.1a
Fig.1b (AP Type - XL Tank)
264
ø 5
96
200
198
ø 6
Fig.4Fig.3
Fig.5
ITALIANO
ENGLISH
DEUTSCH
FRANÇAIS
Fig.6
(pompa con serbatoio da 1,4 litri)
ISTRUZIONI ORIGINALI
Pressione ingresso aria (bar•) 5 ÷ 8
Pressione massima di utilizzo (bar•) 250 500 700 1000
Portata max. nominale (l/min)• 2,0 1,3 0,7 0,6
Attacco aria (standard*) 1/4" GAS
Attacco olio (standard*) 3/8" - 18 NPTF
Peso max. (kg) ~ 5,3
Contenuto olio / quantità utilizzabile (l) ~ 1,4 / 1,1
Dimensioni (mm) Le dimensioni delle pompe sono indicate in gura 1a, pag.2
Rumore 80 dB(A) / 1m
Tipi di olio da usare SHELL TELLUS S2 V22/32 - MOBIL DTE 22/24 - CASTROL HYSPIN AWS 22/32 - o equivalenti
Pressione ingresso aria (bar•) 5 ÷ 8
Pressione massima di utilizzo (bar•) 250 500 700 1000
Portata max. nominale (l/min)• 2,0 1,3 0,7 0,6
Attacco aria (standard*) 1/4" GAS
Attacco olio (standard*) 3/8" - 18 NPTF
Peso max. (kg) ~ 8,8
Contenuto olio / quantità utilizzabile (l) ~ 4 / 3,5
Dimensioni (mm) Le dimensioni delle pompe sono indicate in gura 1b, pag.2
Rumore 80 dB(A) / 1m
Tipi di olio da usare SHELL TELLUS S2 V22/32 - MOBIL DTE 22/24 - CASTROL HYSPIN AWS 22/32 - o equivalenti
TRANSLATION OF ORIGINAL INSTRUCTIONS
Fig.6
(1.4 litres model)
Air inlet pressure (bar•) 5 ÷ 8
Maximum working pressure (bar•) 250 500 700 1000
Maximum rated ow (l/min)• 2,0 1,3 0,7 0,6
Air connection (standard*) 1/4" GAS
Oil connection (standard*) 3/8" - 18 NPTF
Max. weight (kg) ~ 5,3
Reservoir capacity / usable capacity (l) ~ 1,4 / 1,1
Dimensions (mm) Pump dimensions are shown on page 2, gure 1a
Noise level 80 dB(A) / 1m
Recommended oil types SHELL TELLUS S2 V22/32 - MOBIL DTE 22/24 - CASTROL HYSPIN AWS 22/32 - or equivalent
Air inlet pressure (bar•) 5 ÷ 8
Maximum working pressure (bar•) 250 500 700 1000
Maximum rated ow (l/min)• 2,0 1,3 0,7 0,6
Air connection (standard*) 1/4" GAS
Oil connection (standard*) 3/8" - 18 NPTF
Max. weight (kg) ~ 8,8
Reservoir capacity / usable capacity (l) ~ 4 / 3,5
Dimensions (mm) Pump dimensions are shown on page 2, gure 1c
Noise level 80 dB(A) / 1m
Recommended oil types SHELL TELLUS S2 V22/32 - MOBIL DTE 22/24 - CASTROL HYSPIN AWS 22/32 - or equivalent
A B
