BELLATERRA HOME
ASSEMBLY INSTALLATION
INSTRUCTIONS
&
804357
INTRODUCTION
read these instructions carefully before you begin also review the recommended tools and
materials section carefullyunpack and examine yournew plumbing fixture
. ,
..
ALL INSTALLATION PROCEDURES MUST COMPLY IN STRICT ACCORDANCE WITH
APPLICABLE LOCAL PLUMBING AND BUILDING CODES
Tools and materials Required
,
.
Most of the procedures require
the use of availabie from hard
ware and piumbing supply stores
it is essential that the tools and
matenals be on hand before work
is begun
.""*Dimensions shown for location of supplies and P trap are suggested
Roughing in Dimensions
Adjustable wrench Saber Saw
Basin Wrench Plumbers Putty or
Ca ulking
'
Ch annel Locks
Pipe Wre chnPutty Knife
Tape
Measure Tubing Cutter
Ha cksaw
Drill
Re gular Screwdriver
Phillips Screwdriver
Leve l
804357
-1-
915mm
36

804357
-2-
Step One:Use the track level bar,tape measure and pencil to mark holes in desired location.Having established
the position,use drill to make holes.Use the hammer to insert anchors into the hole and screw in the screws.Finally
put the mirror in place.
Step Two:Place the vanity in position.Level vanity ensuring it is level with water outlets and piping.If the doors are
out of alignment they can be fixed by adjusting the hinges.
Step Three:Fix the vanity to the wall through the back rail of the cabinet (for wall hung units).The fixings should be
placed on a wall stud.Werecommend that you use a toggle or toggle type system if you can't located a strong solid
surface.
Step Four:(For undermount sink unit) Glue the undermount sink to the Stone Top in suitable place, put them on
the cabinet after the glue is dry. Make sure the sink and stone stick to each other strong enough.
(For semi recessed basin unit) Put the basin on the cabinet in suitable place. Glue the basin to the
cabinet if necessary.
(For above counter basin unit) Put the stone top on the cabinet and place the basin on stone in suitable
place.
Step Five: (If has board shelf) Use the track level bar,tape measure and pencil to mark holes in desired
location.Having established the position,use drill to make holes.Use the hammer to insert anchors into the hole and
screw in the screws.Finally put the board shelf in place.

A
B
Install faucet and drain in accordance with
manufacturer s instructions Ensure all water supply
and drain connections are tightened Turn on water
supply valves and water test installation
' .
.
- .
Typical Drain Assembly
Connect the trap to the drain assembly hand tight to check
alignment It may be necessary to cut off part of the tailpiece
area A or part horizontal leg of the trap area B
Trap joints for watertight assembly
Connect hot and cold supply lines to the shut off valves Tighten
.
.)""()""(
.
.
-3- 804357
