Mainstays FULTON MS16-D4-1007-17 User manual

1PB
model# MS16-D4-1007-17
model# MS16-D4-1007-18
model# MS16-D4-1007-19
model# MS16-D4-1007-20
model# MS16-D4-1007-21
Lot#_________Date________
Customer Service:
1.877.436.7290
[email protected]
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
gray
blue
green
orange
black
Manufactured By:
BDDMI
1321 Tyler St NE, Minneapolis, MN 55413
Assembly Instructions
FULTON LOUNGE CHAIR

2
PARTS LIST
CHAIR BACK
CUSHION
LEG [X2]
UPPER TUBE
A
B
C
D
Before you begin:
1. Check for damaged or missing parts.
2. Use the carton as a working surface to prevent product damage during assembly.

2 3
HARDWARE LIST
CAUTION:
1. Make sure the screws go through the pre-drilled holes properly.
2. Do not over tighten bolts.
5. Washer
x4
3. M6x25mm Bolt
x8
4. Lock Washer
x4
1. M8x50mm Bolt
x4
2. M6x40mm Bolt
x6
6. Large Allen Wrench
x1
7. Small Allen Wrench
x1

4
x4 x4 x1x4
STEP 1
1. Make sure the bolts go through the pre-drilled holes properly.
2. Do not over tighten bolts.
1. M8x50mm
Bolt
4. Lock
Washer
5. Washer 6. Large
Allen Wrench
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.

4 5
STEP 2

6
x6 x1
STEP 3
1. Make sure the bolts go through the pre-drilled holes properly.
2. Tighten bolts half way.
2. M6x40mm
Bolt 7. Small Allen Wrench
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.

6 7
x1x8
STEP 4
1. Make sure the bolts go through the pre-drilled holes properly.
2. Do not over tighten bolts.
7. Small
Allen Wrench
3. M6x25mm
Bolt
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.

8
x1
STEP 5
1. Tighten bolts the rest of the way.
2. Do not over tighten bolts.
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.
7. Small
Allen Wrench

8 9
250 lbs. / 113.4 kg.
WARNING: Do not exceed the maximum load capacity. Exceeding the maximum load capacity may result in
collapse and possible injury.
Furniture Care Instructions:
Dust with clean, lint-free cloth.
Use furniture spray polish as needed.
Customer Service:
877.436.7290
[email protected]
Your complete satisfaction is our number 1 priority. Our product is designed and manufactured to meet the
highest quality of standards. In the event that you have assembly questions, or parts are missing or damaged,
our customer service department would appreciate the opportunity to assist you.
This product carries a one (1) year warranty against defects in workmanship and materials. Defective product
will be replaced free of charge within the stated warranty period, when returned by the original purchaser with
proof of purchase. This product is not guaranteed against wear or breakage due to misuse and/or abuse. Please
contact our Customer Service at 1-877-436-7290 to obtain information on warranty performance. This warranty
gives you specic legal rights and you may also have other rights which vary from State to State.

1PB
model# MS16-D4-1007-17
model# MS16-D4-1007-18
model# MS16-D4-1007-19
model# MS16-D4-1007-20
model# MS16-D4-1007-21
Lot#_________Fecha_______
Servicio al Cliente:
1.877.436.7290
[email protected]
ESTE MANUAL DE INSTRUCCIONES CONTIENE INFORMACIÓN IMPORTANTE DE SEGURIDAD.
POR FAVOR LEA Y GUARDE PARA REFERENCIA FUTURA.
gris
azul
verde
color naranja
negro
Fabricado Por :
BDDMI
1321 Tyler St NE, Minneapolis, MN 55413
SILLA LOUNGE FULTON
Instrucciones de Ensamble
