Ameriwood Basics 7391015COM User manual

7391015COM
pantry
‐Unitcantipovercausingsevereinjuryordeath.
‐Anchorunittostudinwall(ifinstructedto).
‐DoNotallowchildrentoclimbonunit.
‐Putheavyitemsonlowershelvesordrawers.
B347391015COM0
THISINSTRUCTIONBOOKLETCONTAINS IMPORTANT SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.
WARNING
FollowAmeriwoodHome
Tube
You
DateofPurchase___/___/___
LotNumber:
DoNotReturnThisProduct!
Contactourcustomerserviceteamforhelpfirst.
Call:1‐800‐489‐3351(tollfree)
Monday‐Friday9am‐5pmCST
Visit:www.ameriwoodhome.com
AssemblyDifficultyMeter
Easy Tough

ContactUs!
HelpfulHints
2
ameriwoodhome.com
DoNOTreturnthisproduct!
Contactourfriendlycustomerserviceteamfirstforhelp.
Callus!
1‐800‐489‐3351
Monday‐Friday
9am‐5pmCST
Visitameriwoodhome.comtoviewthe
limitedwarrantyvalidintheU.S.andCanada.
AssemblyTips
‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.

‐Identify,sortandcountthepartsbeforeattemptingassembly.

‐Compressiondowelsarelightlytappedinwithahammer.

‐Slidesarelabeledwitha
R (right)and L (left)forproperplacement.

‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe
outeredge.

‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.

‐Backpanelmustbeusedtomakesureyourunitissturdy.

‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.

‐Neverpush,pull,ordragyourfurniture.
Tube
You
Tube
You
PEOPLENEEDEDFORASSEMBLY:1‐2
ESTIMATEDASSEMBLYTIME:1HOUR

3
ameriwoodhome.com
BeforeYouStart

Quick
Tip
Assembly



Tube
You
Readthrougheachstepcarefullyandfollowtheproperorder

Separateandcountallyourpartsandhardware

Giveyourselfenoughroomfortheassemblyprocess

Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead
ScrewdriverandHammer
Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,
pleasebeawaretoslowdownandstopwhenscrewistight.
Failuretodosomayresultinstrippingthescrew.


4
ameriwoodhome.com
BoardIdentification
Notactualsize
Tube
You
LeftPanel
37391015010 RightPanel
37391015020 Top
37391015030 BottomShelf
37391015040
FixedShelf
37391015050 AdjustableShelf(2)
37391015060
KickPanel
37391015070
LeftDoor
37391015080
RightDoor
37391015090
BackPanel
K739101500
This piece is paperboard construction.
It is not made from wood, but is
required for the assembly of your unit.
AB
CD
EFG
HI

5
ameriwoodhome.com
BoardIdentification
Notactualsize
Tube
You
A
B
C
D
E
F
G
HI
F
This piece is paperboard construction.
It is not made from wood, but is
required for the assembly of your unit.

6
ameriwoodhome.com
PartList
ActualSize
Tube
You
NotActualSize
(x14)
#A13410
1-3/4" screw
(x1)
#A53600
angle bracket
(x26)
#A12105
7/16" screw
(x4)
#A12700
7/8" screw
(x8)
#A80250
shelf support
(x14)
#A24000
cover cap
(x1)
#A25400
washer
9a 9b
9c
9d
11a 11b
(x2)
#A50695
handle
(x1)
#A60010
hinge
(x1)
#A84050
safety bracket kit
(x40)
#A21110
nail
12
(x2)
#A30030
plastic catch
34
56
78
10
12

7
ameriwoodhome.com
STEP1
Tube
You
(x4)
#A12105
33
11a
9a
9b
C
D
8
9a 9b 11a
8
3
(x1)
#A25400
(x1)
#A84050
(x2)
#A30030
finishededge
finishededge

8
ameriwoodhome.com
STEP2
Tube
You
1(x14)
#A13410
1
1
A
B
C
D
E
G
1
1
1
11
1
1
1
1
1
x7
x7
Caution:Assurethatallholespropertylineupwhenassembling.
All finished edges are facing upwards.
rawsurface
rawsurface
finishedsurface

9
ameriwoodhome.com
STEP3
Tube
You
(x38)
#A21110
IMPORTANT! THEBACKPANELISASTRUCTURALPARTOFTHISUNIT
ANDMUSTBEINSTALLEDPROPERLY.
6
6
2
3
3
2
67
3
(x14)
#A24000
(x1)
#A53600
(x2)
#A12105
x7
x7
7
6
6
6
6
6
6
Carefullyplacetheunitonitsfront.
PositiontheBackPanelasshown.FlushwiththebottomedgeoftheBottom(D).Align
squarelywithouteredgesandnailstraightintotherawedgeofthePanels(A&B),
Bottom(D),andTop(C).
B
D
G
raw
surface

10
ameriwoodhome.com
STEP4
Tube
You
10
33
34
4
11b
3
410 12
(x12)
#A12105
(x4)
#A12700
(x4)
#A60010
(x2)
#A30030
(x2)
#A50695
11b
3
12
I
Repeat the procedure for the Left Door (H)
