Teknion HNBLSF Operating and maintenance instructions

Section:
Date: Sept 2019
SCREENS AND GABLES
height-adjustable bench
Installation Guides
Rev.
Page: 1 of 8
HAB_224
1.5.3
1.5.1
1.5.2
Navigate Single-Sided Corridor Screen – Fabric (HNBLSF), Navigate Single-Sided Corridor Screen – Solid (HNBLSS)

Section:
Date: Sept 2019
SCREENS AND GABLES
height-adjustable bench
Installation Guides
Page: 2 of 8
HAB_224
ITEM
NO.
PREVIEW DESCRIPTION
PART
NUMBER
QTY.
1. NAVIGATE SINGLE SIDED CORRIDOR SCREEN - FABRIC (HNBLSF)
1.1
FRAME ASSY
FRAMED FABRIC
FLOOR SCREEN SS
HAB CORRIDOR
N03-
3067\42\54
1
1.2
TOP TRIM CUT
SIZES - FABRIC
SCREEN
A23-6540-X 1
1.3
VERTICAL TRIM
CUT SIZES -
NAVIGATE END OF
RUN SCREEN
A23-7431-X 2
1.4
FABRIC &
SUBSTRATE ASSY -
NAVIGATE FLOOR
SCREEN
N03-
3045\42\54
2
ITEM
NO.
PREVIEW DESCRIPTION
PART
NUMBER
QTY.
1.5. FABRIC CORRIDOR SCREEN MOUNTING BRKT KIT, HAB (X06-0619) 2
1.5.1
CORRIDOR SCREEN
BRKT, HAB
A16-7801 1
1.5.2 MOUNTING NUT A25-0386 1
1.5.3
5/16"-18 x 1"
SOCKET BUTTON
HEAD SCREW
E01-0651 1
1.5.4
1/4-20X5/8" MACH
SCR, BLACK,
QUAD,TRUSS
E01-0113 2
Part & Product Identification

Section:
Date: Sept 2019
SCREENS AND GABLES
height-adjustable bench
Installation Guides
Page: 3 of 8
HAB_224
ITEM
NO.
PREVIEW DESCRIPTION
PART
NUMBER
QTY.
2.3. SOLID CORRIDOR SCREEN MOUNTING BRKT KIT, HAB (X06-0610) 2 or 3
2.3.1
CORRIDOR SCREEN
BRKT, HAB
A16-7801 1
2.3.2 MOUNTING NUT A25-0386 1
2.3.3
5/16"-18 x 1"
SOCKET BUTTON
HEAD SCREW
E01-0651 1
2.3.4
1/4-20X5/8" MACH
SCR, BLACK,
QUAD,TRUSS
E01-0113 4
ITEM
NO.
PREVIEW DESCRIPTION
PART
NUMBER
QTY.
2. NAVIGATE SINGLE SIDED CORRIDOR SCREEN - SOLID (HNBLSS)
2.1
CORRIDOR
SCREEN, HAB
C07-5199\51\96 1
2.2
LEVELLER
BOLT
D03-0037 2
Part & Product Identification

Section:
Date: Sept 2019
SCREENS AND GABLES
height-adjustable bench
Installation Guides
Page: 4 of 8
HAB_224
1.5.1
NOTE: HNBLSF Shown
1.5.4
1.5.2
1.5.3
ATTACH BRACKETS
STEP 1a: Attach Brackets as shown above with screws provided. STEP 2a: Assemble T-Nuts as shown above.
ASSEMBLE T-NUTS

Section:
Date: Sept 2019
SCREENS AND GABLES
height-adjustable bench
Installation Guides
Page: 5 of 8
HAB_224
NOTE: HNBLSS Shown
2.3.1
2.3.4
2.3.3
2.3.2
ATTACH BRACKETS
STEP 1b: Attach Brackets as shown above with screws provided. STEP 2b: Assemble T-Nuts as shown above.
ASSEMBLE T-NUTS

Section:
Date: Sept 2019
SCREENS AND GABLES
height-adjustable bench
Installation Guides
Page: 6 of 8
HAB_224
NOTE: Frame and Worksurface Assmbly is not shown for illustration purpose.
STEP 3: Align T-Nuts parallel to the wire channel.
ALIGN T-NUTS

Section:
Date: Sept 2019
SCREENS AND GABLES
height-adjustable bench
Installation Guides
Page: 7 of 8
HAB_224
NOTE: Worksurface not shown for illustration purpose.
STEP 4: Fasten T-Nuts with an Allen Key. Make sure the screen is perpendicular to the ground.
FASTEN SCREWS

Section:
Date: Sept 2019
SCREENS AND GABLES
height-adjustable bench
Installation Guides
Page: 8 of 8
HAB_224
STEP 5: Using a wrench, adjust Levellers to achieve stability.
ADJUST LEVERLLERS (OPTIONAL)
