Bellezza 014-HG-20067 User manual

Owner’s Manual
Garden Bench / Item# 014-HG-20067
www.bellezzafurniture.com
[phone]
FOLLOW US: CONTACT INFO: NOTE:
Read the instructions and precautions before use of this product
Please keep this instruction manual for future reference
Model No: 50140721
Rose Bloom Bench
Instruction Manual
For warranty information, please refer to the back page of
this instruction manual.
Due to ongoing product development
the actual product or products may vary from
the illustrations or photos shown within this manual.
NOTE: This product is intended for residential, non-commercial use.
Made in China
©2014 World Factory, Inc.
Distributed by:
World Factory, Inc.
Southlake, TX 76092
070813rev1
For Manuals, Replacement Parts or Customer Service visit:
www.ezreplacement.com
Astonica Limited Warranty
World Factory, Inc. Products for Home Use
World Factory, Inc. (Seller) warrants to the original Buyer only, that each Astonica Product will be free
from defects in material and workmanship for a period of one (1) year from date of purchase.
SELLER’S SOLE OBLIGATION AND BUYER’S EXCLUSIVE REMEDY UNDER THIS LIMITED
WARRANTY SHALL BE THE REPAIR OR REPLACEMENT OF PARTS, WITHOUT CHARGE, WHICH
ARE DEFECTIVE IN MATERIAL OR WORKMANSHIP. ANY PARTS AS DETERMINED BY THE SELLER
WHICH HAVE BEEN MISUSED; ABUSED OR DAMAGED EITHER DIRECTLY OR INDIRECTLY FROM
REPAIRS OR ALTERATIONS ATTEMPTED BY UNAUTHORIZED PERSONS; IMPROPER
MAINTENANCE, NEGLECT OR ACCIDENT ARE NOT COVERED BY THIS LIMITED WARRANTY. This
warranty does not apply to damage, heat-induced coloration changes, scratching or alteration due to
normal use or weathering. To make a claim under this Limited Warranty, you must return the complete
product with proof of purchase, transportation prepaid, to any World Factory, Inc. authorized service
center. Email us at [email protected] or visit www.ezreplacement.com to initiate a warranty
claim.
Additional Limitations
THIS LIMITED WARRANTY DOES NOT APPLY TO ACCESSORY OR CONSUMABLE ITEMS RELATED
TO THIS PRODUCT. ALL IMPLIED WARRANTIES SHALL BE LIMITED IN DURATION TO ONE (1)
YEAR FROM DATE OF PURCHASE. IN NO EVENT SHALL SELLER BE LIABLE FOR ANY INCIDENTAL
OR CONSEQUENTIAL DAMAGES, INCLUDING BUT NOT LIMITED TO LIABILITY FOR LOSS OF
PROFITS, ARISING FROM THE SALE OR USE OF THIS PRODUCT.
If any provision of this Limited Warranty is for any reason held to be invalid or unenforceable, such
provision shall not affect any other provision herein, this Limited Warranty shall be construed as if
such invalid and/or unenforceable provision had never been contained herein.
This warranty gives you special legal rights, and you may also have other rights which vary from state
to state.
This Warranty contains the entire agreement between Seller and Buyer and supersedes any and all
prior agreements, arrangements, or understandings between the parties relating to product warranty.
For warranty information, please refer to the back page of this
instruction manual.

www.bellezzafurniture.com
2
TABLE OF CONTENTS
OUR BRAND
PARTS & HARDWARE LIST
ASSEMBLY INSTRUCTIONS
WARRANTY
02
03
04
06
OUR BRAND
Bellezza is one of the nation’s largest direct sellers of home decor. We offer an extensive selection of high-quality
indoor and outdoor furniture, appliances, and accessories. We are committed to making decorating your home easy,
affordable and fun. Everything you need to make your house into a beautiful home can be found at Bellezza. So
whether you shop by website or catalog, you can be sure you will always find top-quality merchandise for
your home.
PLEASE LIKE, COMMENT AND SUBSCRIBE.

www.bellezzafurniture.com 3
AE
EFG
FG
Figure 1
C
Carefully remove the contents from the package. If any parts are missing do not
attempt to use the product until they have been obtained and correctly installed.
ASSEMBLY INSTRUCTIONS
CAUTION: Do not over tighten fasteners.
2. (SEE FIGURE 2) Attach the wood slats (B)
to leg and arm support (C) as shown.
Repeat on the other side, but do not
tighten bolts until all wood slats (B) are in
place and bench is upright on the floor.
1. (SEE FIGURE 1) Using bolts (E), washers (F)
and nuts (G) attach one end of the straight
back (A) to the leg & arm frame (C).
Attach the other end of the back to the
second leg & arm brace (C).
BC
F
G
E
Figure 2
12
NOTE: This product is intended for residential, non-commercial use.
5. (SEE FIGURE 4) Add plastic nut cover (I)
to nut (G) located on backside of straight
back (A).
3. (SEE FIGURE 3) Turn the bench over on a
non-scratch surface and attach middle
seat brace (J) to the slats (B) at the midway
point between legs (C) using wood screws (H).
Work from the front to back, as necessary to
fit the contour of the bench.
Attach side seat brace (D) to the leg (C) using
bolt (K), washers (F) and nut (G), connect side
seat brace (D) to the slats (B) at the sideway
point between legs (C) using wood screws (H).
4. Ensure all fasteners are securely tightened.
Figure 3 J
D
D
H
G
G
F
F
K
K
H
H
PARTS & HARDWARE LIST
PART # DESCRIPTION QUANTITY
A Straight Back 1
B Wood Seat Slats 5
C Leg & Arm Frame 2
D Side Seat Brace 2
E 6mm x 32mm Bolt 14
F 6mm Washer 16
G 6mm Nut 16
H Screw 4mm x 16mm 7
I Plastic Nut Cover 4
J Middle Seat Brace 1
K 6mm x 25 mm Bolt 2
EK
J
F
A
B
C
I
DGH
Figure 4
(I) Plastic Nut Cover
Four places backside
Parts Detail
PARTS & HARDWARE LIST
PART # DESCRIPTION QUANTITY
A Straight Back 1
B Wood Seat Slats 5
C Leg & Arm Frame 2
D Side Seat Brace 2
E 6mm x 32mm Bolt 14
F 6mm Washer 16
G 6mm Nut 16
H Screw 4mm x 16mm 7
I Plastic Nut Cover 4
J Middle Seat Brace 1
K 6mm x 25 mm Bolt 2
PARTS DETAIL
**Carefully remove the contents from the package. If any parts are missing do not attempt to use the product
until they have been obtained and correctly installed.
NOTE: This product is intended for residential, non-commercial use.

4
INSTRUCTIONS MANUAL
AE
EFG
FG
Figure 1
C
Carefully remove the contents from the package. If any parts are missing do not
attempt to use the product until they have been obtained and correctly installed.
ASSEMBLY INSTRUCTIONS
CAUTION: Do not over tighten fasteners.
2. (SEE FIGURE 2) Attach the wood slats (B)
to leg and arm support (C) as shown.
Repeat on the other side, but do not
tighten bolts until all wood slats (B) are in
place and bench is upright on the floor.
1. (SEE FIGURE 1) Using bolts (E), washers (F)
and nuts (G) attach one end of the straight
back (A) to the leg & arm frame (C).
Attach the other end of the back to the
second leg & arm brace (C).
BC
F
G
E
Figure 2
12
NOTE: This product is intended for residential, non-commercial use.
5. (SEE FIGURE 4) Add plastic nut cover (I)
to nut (G) located on backside of straight
back (A).
3. (SEE FIGURE 3) Turn the bench over on a
non-scratch surface and attach middle
seat brace (J) to the slats (B) at the midway
point between legs (C) using wood screws (H).
Work from the front to back, as necessary to
fit the contour of the bench.
Attach side seat brace (D) to the leg (C) using
bolt (K), washers (F) and nut (G), connect side
seat brace (D) to the slats (B) at the sideway
point between legs (C) using wood screws (H).
4. Ensure all fasteners are securely tightened.
Figure 3 J
D
D
H
G
G
F
F
K
K
H
H
PARTS & HARDWARE LIST
PART # DESCRIPTION QUANTITY
A Straight Back 1
B Wood Seat Slats 5
C Leg & Arm Frame 2
D Side Seat Brace 2
E 6mm x 32mm Bolt 14
F 6mm Washer 16
G 6mm Nut 16
H Screw 4mm x 16mm 7
I Plastic Nut Cover 4
J Middle Seat Brace 1
K 6mm x 25 mm Bolt 2
EK
J
F
A
B
C
I
DGH
Figure 4
(I) Plastic Nut Cover
Four places backside
Parts Detail
AE
EFG
FG
Figure 1
C
Carefully remove the contents from the package. If any parts are missing do not
attempt to use the product until they have been obtained and correctly installed.
ASSEMBLY INSTRUCTIONS
CAUTION: Do not over tighten fasteners.
2. (SEE FIGURE 2) Attach the wood slats (B)
to leg and arm support (C) as shown.
Repeat on the other side, but do not
tighten bolts until all wood slats (B) are in
place and bench is upright on the floor.
1. (SEE FIGURE 1) Using bolts (E), washers (F)
and nuts (G) attach one end of the straight
back (A) to the leg & arm frame (C).
Attach the other end of the back to the
second leg & arm brace (C).
BC
F
G
E
Figure 2
12
NOTE: This product is intended for residential, non-commercial use.
5. (SEE FIGURE 4) Add plastic nut cover (I)
to nut (G) located on backside of straight
back (A).
3. (SEE FIGURE 3) Turn the bench over on a
non-scratch surface and attach middle
seat brace (J) to the slats (B) at the midway
point between legs (C) using wood screws (H).
Work from the front to back, as necessary to
fit the contour of the bench.
Attach side seat brace (D) to the leg (C) using
bolt (K), washers (F) and nut (G), connect side
seat brace (D) to the slats (B) at the sideway
point between legs (C) using wood screws (H).
4. Ensure all fasteners are securely tightened.
Figure 3 J
D
D
H
G
G
F
F
K
K
H
H
PARTS & HARDWARE LIST
PART # DESCRIPTION QUANTITY
A Straight Back 1
B Wood Seat Slats 5
C Leg & Arm Frame 2
D Side Seat Brace 2
E 6mm x 32mm Bolt 14
F 6mm Washer 16
G 6mm Nut 16
H Screw 4mm x 16mm 7
I Plastic Nut Cover 4
J Middle Seat Brace 1
K 6mm x 25 mm Bolt 2
EK
J
F
A
B
C
I
DGH
Figure 4
(I) Plastic Nut Cover
Four places backside
Parts Detail
**CAUTION: Do not over tighten fasteners.
1. (SEE FIGURE 1) Using bolts (E), washers (F) and nuts
(G) attach one end of the straight back (A) to the leg &
arm frame (C).
Attach the other end of the back to the second leg & arm
brace (C).
2. (SEE FIGURE 2) Attach the wood slats (B) to leg and
arm support (C) as shown. Repeat on the other side, but
do not tighten bolts until all wood slats (B) are in place
and bench is upright on the oor.

www.bellezzafurniture.com 5
INSTRUCTIONS MANUAL
AE
EFG
FG
Figure 1
C
Carefully remove the contents from the package. If any parts are missing do not
attempt to use the product until they have been obtained and correctly installed.
ASSEMBLY INSTRUCTIONS
CAUTION: Do not over tighten fasteners.
2. (SEE FIGURE 2) Attach the wood slats (B)
to leg and arm support (C) as shown.
Repeat on the other side, but do not
tighten bolts until all wood slats (B) are in
place and bench is upright on the floor.
1. (SEE FIGURE 1) Using bolts (E), washers (F)
and nuts (G) attach one end of the straight
back (A) to the leg & arm frame (C).
Attach the other end of the back to the
second leg & arm brace (C).
BC
F
G
E
Figure 2
12
NOTE: This product is intended for residential, non-commercial use.
5. (SEE FIGURE 4) Add plastic nut cover (I)
to nut (G) located on backside of straight
back (A).
3. (SEE FIGURE 3) Turn the bench over on a
non-scratch surface and attach middle
seat brace (J) to the slats (B) at the midway
point between legs (C) using wood screws (H).
Work from the front to back, as necessary to
fit the contour of the bench.
Attach side seat brace (D) to the leg (C) using
bolt (K), washers (F) and nut (G), connect side
seat brace (D) to the slats (B) at the sideway
point between legs (C) using wood screws (H).
4. Ensure all fasteners are securely tightened.
Figure 3 J
D
D
H
G
G
F
F
K
K
H
H
PARTS & HARDWARE LIST
PART # DESCRIPTION QUANTITY
A Straight Back 1
B Wood Seat Slats 5
C Leg & Arm Frame 2
D Side Seat Brace 2
E 6mm x 32mm Bolt 14
F 6mm Washer 16
G 6mm Nut 16
H Screw 4mm x 16mm 7
I Plastic Nut Cover 4
J Middle Seat Brace 1
K 6mm x 25 mm Bolt 2
EK
J
F
A
B
C
I
DGH
Figure 4
(I) Plastic Nut Cover
Four places backside
Parts Detail
3. (SEE FIGURE 3) Turn the bench over on a non-
scratch surface and attach middle
seat brace (J) to the slats (B) at the midway point
between legs (C) using wood screws (H). Work from the
front to back, as necessary to t the contour of the bench.
Attach side seat brace (D) to the leg (C) using bolt (K),
washers (F) and nut (G), connect side seat brace (D) to
the slats (B) at the sideway point between legs (C) using
wood screws (H).
4. Ensure all fasteners are securely tightened.
5. (SEE FIGURE 4) Add plastic nut cover (I) to nut (G)
located on backside of straight back (A).

www.bellezzafurniture.com
6
LIMITED TERM WARRANTY
ONE (1) YEAR FROM DATE OF PURCHASE
WARRANTY TERMS ADDITIONAL CONDITIONS
ADDITIONAL CONDITIONS
Bellezza warrants that its merchandise are free from manufac-
turing defects (workmanship and/or material) and will either give
credit or replace defective parts for a period of up to one (1) year
from the date of purchase in accordance with the conditions set
forth below. If a manufacturing defect is found, Bellezza should
be notied promptly of the defect and supplied a copy of the
invoice and delivery ticket. Inspection by a Bellezza employee
or representative may be necessary to verify that a manufactur-
ing defect exists, or you may be required to submit samples to
Bellezza along with a digital image of the defects. If replacement
is required in accordance with this warranty and the defective
material or merchandise has been discontinued or unavailable,
Bellezza reserves the right to select and supply similar mer-
chandise or offer full credit for the merchandise; otherwise the
same material or merchandise will be supplied for replacement
purposes. This warranty is made solely to the retailer and is
not transferable under any circumstances. It is the retailer’s re-
sponsibility to contact Bellezza with a claim. We will not handle
claims from consumers directly; all requests must go through
the retailer who sold the merchandise to the consumer. We ad-
vise all retailers to retain invoices for a minimum of one (1) year
for warranty purposes. This warranty supersedes and replaces
all implied warranties of merchantability and use for particular
purpose. No representative, employee, or agent of Bellezza
or any other person is authorized to assume for Bellezza any
additional liability or responsibility in connection with Bellezza’s
merchandise except as described above. Implied warranties or
merchantability and tness of the merchandise are limited to a
period of one (1) year from the date of purchase. In no event
shall Bellezza be liable for indirect, consequential or incidental
damages of any kind
The following examples are not manufacturer’s defects:
• Colors may vary slightly from the photo because of
photography and printing tolerances.
• Foam will soften slightly.
• Sizes are stated in U.S. standard measurements while the ac
tual sizes are manufactured using the metric system.
Therefore the sizes may vary slightly.
• There are no exchanges or refunds on any pillows or
toppers sold.
• No returns for buyer’s remorse.
*No returns - other than stated above - will be accepted
Warranty is void for any of the following conditions:
1 Improper maintenance or improper use resulting in damage.
2 Any product modications by dealer, consumer, or other
parties not authorized by Bellezza will void this warranty.
3 Floor samples sold or products designated “AS IS” at the
time of purchase are not covered by the warranty.
4 Warranty does not cover minor variations or differences be
tween oor samples or printed illustrations and your furniture.
5 Cost of packaging and shipping to and from Bellezza is not
covered by the warranty unless expressly arranged
by Bellezza.
6 This warranty covers only articles of furniture intended for
residential use only, does not cover any industrial,
commercial, institutional, or rental use.
7 Dissatisfaction due to buyer’s remorse.
8 Normal wear and tear.
9 Damages incurred during transportation.
10 Damages incurred during assembling or maintenance.
11 Damages incurred by accidents or abuse.
Additional conditions for warranty on upholstery are listed on
the attached addendum.

www.bellezzafurniture.com
[phone]
FOLLOW US: CONTACT INFO:
