Flash receiver
BE1442/BE1444
2
BE1444_005MAN002-433-Visit-Flashreceiver.indb 4 2017-09-06 09:33:54

Overview
1 Rotatable reector
2 Flash
3 Visit LED, orange
4 Visit LED, green
5 Visit LED, yellow
6 Visit LED, red
7 Connector for power supply
8 Telephone input for
analogue telephone
9 Mute / test button
10 Bed shaker output
11 Cable holder
12 Table stand/battery compartment
13 External socket
14 Power LED
Overview
1 Rotatable reector
2 Flash
3 Visit LED, orange
4 Visit LED, green
5 Visit LED, yellow
6 Visit LED, red
7 Connector for power supply
8 Telephone input for
analogue telephone
9 Mute / test button
10 Bed shaker output
11 Cable holder
12 Table stand/battery compartment
13 Smoke alarm menu button
14 Power LED
15 Smoke alarm supervision LED
Flash receiver
BE1442
Flash receiver
BE1444
EN
3
BE1444_005MAN002-433-Visit-Flashreceiver.indb 5 2017-09-06 09:33:54

Bellman Visit ash receiver, BE1442/BE1444
General
The ash receiver is part of the Visit smart home system that helps you to keep tabs on your
home. It alerts you with bright ashes when the doorbell or telephone rings, when your
baby needs you or if a re should occur.
It is activated via radio signals from the Visit transmitters and features colored LED’s to dif-
ferentiate the alarms. You can also connect a bed shaker (optional accessory) and wake up
to vibrations if something should happen while you are asleep. For indoor use.
Getting started
Unpacking, installing and testing the unit
1 Connect the power supply to the receiver and the mains power. Pull the battery tab
at the bottom. Place the receiver on a level surface or mount it on the wall using the
BE9075 wall bracket accessory. The receiver should be placed where it best can be seen.
2To test the radio link you need a Visit transmitter. Press the test button/s on the transmitter.
3The receiver starts to ash and lights up the corresponding Visit LED. If a bed shaker is
connected, it will vibrate. A short press on the test button repeats the last indication. If
nothing happens, see Troubleshooting.
4You can connect a Bellman bed shaker, BE1271 (optional accessory) to the bed shaker
output (10) . When the ash receiver is activated, the bed shaker will vibrate.
5You can connect the ash receiver to the landline phone jack via the telephone input (8)
with the BE9105 Telephone Flex (optional accessory) and an adapter plug (optional
accessory). When the phone rings, the ash receiver will alert with ashes and the yellow
LED (5) will light up.
Function
Radio key
All Bellman Visit units are set to the same radio key as factory default. If you have a neighbour
with a similar system, you can change the radio key so that you do not aect each other’s
systems. Please refer to Installer’s guide in page 10. If you want to change the radio keys.
All units in a Bellman Visit System must have the same radio key in order to operate as a group.
4
BE1444_005MAN002-433-Visit-Flashreceiver.indb 6 2017-09-06 09:33:54

Indicators and Signals
It is generally the transmitters in the Visit smart home system that determine how the
receivers will indicate an alarm. See the description in the relevant transmitter user manual
for further information.
The Visit ash receiver has a function which allows you to easily check which alarm was
the last one detected. Give a short press on the test button (9) and the last alarm will be
repeated.
System indicators
The LEDs that indicate which transmitter has activated the Bellman Visit Flash
Receiver normally have the following meanings.
Orange LED indicates a baby monitor.
Green LED indicates a door transmitter.
Yellow LED indicates a telephone transmitter.
Red LED indicates a re alarm.
If the green and yellow LEDs blink alternately, this indicates that the Visit ash receiver
is in radio key selection mode. The ash receiver will then wait for a radio signal from a
transmitter in the Visit system which will adjust the receiver to the same radio key as the
transmitter is set to.
Flash light
When the Visit ash receiver is activated, the ash (2) will show a sharp white light.
The ash head (1) can be rotated to point in the direction required The reector can, for
example, be pointed towards a wall to prevent dazzle. A silicone slip-on top is also available
in a variety of colours (art. no. BE9164-BE9167).
Vibration
The Bellman Visit Flash Receiver can power a BE1271 Bellman Bed shaker (optional accessory)
connected to the socket (10) . The bed shaker is placed under the pillow to wake the
user up when the Visit ash receiver is activated.
Refer to the user manual for the relevant Bellman Visit transmitter for more information
about vibration patterns.
5
EN
BE1444_005MAN002-433-Visit-Flashreceiver.indb 7 2017-09-06 09:33:54

Power LED indications
When the ash receiver is connected to mains power, the power LED lights up in green.
The BE1442/BE1444 ash receiver is also equipped with battery backup and the power LED
indicates the following:
6
Power LED Status
Green light Connected to mains power. Backup batteries installed.
Green blinks Connected to mains power. No backup batteries detected.
Red light Running on battery backup.
Red blinks Backup batteries nearly depleted.
For further instruction about replacing the batteries, please refer to Installer’s guide “Battery
backup” section in Page 11.
BE1444_005MAN002-433-Visit-Flashreceiver.indb 8 2017-09-06 09:33:54

7
For further information, please refer to the Installer’s guide.
Troubleshooting in brief
If Try this
Nothing happens. Check that the power supply unit is connected correctly.
Check that there is current in the wall socket.
The receiver is not activated. Check the battery in the transmitters.
Check that the receiver is not placed too far away from the
transmitters by moving it closer to the transmitters.
Check that the receiver is set to the correct radio key. For
further information see Function/Radio key.
The receiver signals when no
transmitter is activated.
Change the Radio Key on all units in the system. For further
information see Appendix/Radio key.
EN
BE1444_005MAN002-433-Visit-Flashreceiver.indb 9 2017-09-06 09:33:54

8
BE1444_005MAN002-433-Visit-Flashreceiver.indb 10 2017-09-06 09:33:54

10 Introduction
11 Battery backup
12 Smoke alarm supervision
14 Smoke alarm supervision indication
16 Technical information
Installer’s guide
EN
9
BE1444_005MAN002-433-Visit-Flashreceiver.indb 11 2017-09-06 09:33:54

Introduction
Settings
No adjustments are required for normal use. The relevant descriptions are provided below,
if you wish to change a setting for some reason.
Changing the radio key
In order to use several Visit systems close to one another without interference, different
radio keys can be set on the dierent systems. All Visit units from the factory are set to the
same radio key, channel 0. This means that all radio key switches on the transmitters are set
to the OFF position.
Here is how you change the radio key:
 Open the transmitter cover and move any radio key switch to the up=on position to
change the radio key. See Changing the radio key for the relevant transmitter.
 Press and hold the mute/test button on the top of the receiver until the green and yel-
low Visit LED’s blink alternately. Release the button.
 Press the test button/s on the transmitter within 30 seconds to send the new radio key.
 All Visit LEDs on the receiver blink 4 times to show that the radio key has
been changed. It then returns to normal mode.
Please note: All Visit units must be set to the same radio key in order to operate as a group.
Signal pattern
A signal pattern decides how the receiver in the Visit system indicates during the activa-
tion. Changing the transmitter signal switch changes the signal pattern which the receivers
display when the transmitter is activated.
See the transmitter user manual for further information.
10
BE1444_005MAN002-433-Visit-Flashreceiver.indb 12 2017-09-06 09:33:54

11
Battery backup BE1442/BE1444
Getting started
• Remove the battery tab at the bottom
of the unit before use.
• Please charge the unit for 24 hours to
ensure full backup time.
Replacing batteries
• Remove the screw at the bottom of the
unit to exchange the batteries.
How to get batterys
• You can contact your local dealer or direct contact the Bellman & Symfon AB.
• Use only 4x1.2VNiMH 600AAA/900AAA
Lexel rechargeable batteries to ensure
full backup time.
• Battery Model NO.:
BE1442: 600AAA: LH060-3AH45 or
900AAA: LH095-3AH45
BE1444: 900AAA: LH095-3AH45
CAUTION
RISK OF EXPLOSION IF BATTERY IS
REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS.
EN
BE1444_005MAN002-433-Visit-Flashreceiver.indb 13 2017-09-06 09:33:54

12
1 2
5s
3s
1 2
5s
3s
Smoke alarm supervision (BE1444 only)
BE1444 has an unique feature when working with smoke alarm transmitter BE1281, which
is called smoke alarm supervision function.
To activate the smoke alarm supervision function on the flash receiver, you need to
manually pair the smoke alarm transmitter BE1281 by allowing the ash receiver to store
the hardware ID of the smoke alarm.
Press and hold the mute/test button on
the top of the receiver until the green
and yellow Visit LEDs blink alternately.
Release the button.
Press and hold the test button on the
smoke alarm for more than 3 seconds
until it alarms.
Release the button.
The ash receiver will indicate that pair-
ing was successful by switching between
the LED lights four times.
BE1444_005MAN002-433-Visit-Flashreceiver.indb 14 2017-09-06 09:33:54

13
When successfully paired, the corresponding LED will light up to indicate the smoke
alarm hardware ID sequence in BE1444 memory. (Sequence indication: please refer to
the Information above. )
Attach the corresponding label (provided with each smoke alarm transmitter) on the smoke
alarm transmitter unit so you can easily identify it later.
Indication of smoke alarm ID
sequence in BE1444
Sequence
smoke alarm 1
smoke alarm 2
smoke alarm 3
smoke alarm 4
smoke alarm 5
smoke alarm 6
smoke alarm 7
smoke alarm 8
LED lights up LED ashes
BE1444 can maximum store 8 smoke alarm hardware ID. When manually paring the 9th
smoke alarm to BE1444, the four LED orange, green yellow and red will blink
at the same time for 30 seconds, to indicate the hardware ID storage failure which means
the smoke alarm supervision function is not available.
EN
BE1444_005MAN002-433-Visit-Flashreceiver.indb 14 2017-09-06 09:33:54

14
Smoke alarm supervision indication
In case there is faulty on the BE1281 smoke alarm which is manually paired to the BE1444
as per mentioned in Page 12, the Visit LED ( 6 ) on the BE1444 will blink in red.
To identify the faulty, please refer to the indication on Smoke alarm supervision LED (15)
and the table below.
If there are multiple BE1281 smoke alam manually paired, just enter the Smoke alarm menu
to nd the faulty unit.
Status Indication Try this
Smoke alarm
supervision LED (15)
Low battery orange, blinking Replace the battery using the correct
batteries stated at the smoke alarm label.
Lost connection red, blinking Check if the battery in the smoke alarm
transmitter is still OK.
Move the units to their original position
and verify that the error message
disappears.
Hardware failure red Clean the smoke alarm transmitter
according to the smoke alarm transmitter
manual.
If it is still faulty, replace the smoke alarm
transmitter.
BE1444_005MAN002-433-Visit-Flashreceiver.indb 15 2017-09-06 09:33:54

15
Removing one smoke alarm transmitter from the system
Removing all smoke alarm transmitters from the system
5s
5s
Menu
button
Menu
button
Menu
button
Menu
button
Smoke alarm
supervision
LED
Smoke alarm
supervision
LED
Press and hold the Smoke alarm transmitter
Menu button (13) for more than 5 seconds.
Release the button.
The ash receiver will indicate the
successful removal of the smoke
alarm transmitter by swithing between
the LED lights four times.
Press and hold the Smoke alarm transmitter
Menu button (13) for more than 5 seconds.
Release the button.
The ash receiver will indicate the successful
removal of the smoke alarm transmitter
by swithing between the LED
lights four times.
Press the Menu button (13) on the backside
of the unit.
The Smoke alarm supervision LED (15) will
light up green to indicate you are entering
the menu system.
Press the Menu button (13) until the LED
(3) switches to the corresponding smoke
alarm transmitter as per page 13.
Press the Smoke alarm transmitter Menu
button (13) on the backside of the unit.
The Smoke alarm supervision LED (15) will
light up green to indicate you are entering
the menu system.
EN
BE1444_005MAN002-433-Visit-Flashreceiver.indb 16 2017-09-06 09:33:55

16
Technical information
Power supply
Mains power: 7.5 V DC / 1500 mA.
This product is also designed for IT power distribution
system with phase to phase voltage of up to 230V. The
socket-outlet shall be installed near the equipment and
shall be easily accessible.
Battery back-up: 4x1.2V Lexel 600mAh/900mAh
Please dispose used batteries at municipal collecting points or dispense them to local stores
free of charge.
Radio function
Power consumption: Active: 1500 mA
Radio frequency: 433.92 MHz depending on region
Number of Radio Keys: 64 Radio Keys as standard. Special software can be used to
increase these to 256 Radio Keys in increments of 64 per
software purchase. Contact the nearest supplier for further
information.
Coverage: The normal coverage between a transmitter and receiver in
the Bellman Visit System is up to 80 metres with clear line of
sight. Coverage is reduced if walls and large objects screen
off the signals. Any thick walls constructed of reinforced
concrete will greatly affect coverage. The system may also
be affected by radio transmitters such as TV transmitters,
computers, mobile phones, etc. This means that a unit may
work perfectly in one part of the room but not at all in another.
BE1444_005MAN002-433-Visit-Flashreceiver.indb 17 2017-09-06 09:33:55

17
Technical information
Power supply
Mains power: 7.5 V DC / 1500 mA.
This product is also designed for IT power distribution
system with phase to phase voltage of up to 230V. The
socket-outlet shall be installed near the equipment and
shall be easily accessible.
Battery back-up: 4x1.2V Lexel 600mAh/900mAh
Please dispose used batteries at municipal collecting points or dispense them to local stores
free of charge.
Additional information
Programming pin (16): For service personal only (Output: 3.3V/max. 150mA)
CAUTION: Do not use, unit will be damaged when used.
Activation
Radio: Bellman Visit system
Via analogue
telephone network: 26 - 120 V RMS, 15 - 100 Hz.
Self-Maintenance
Information: Test this device once a month
WARNING: The telephone port of the Flasher Receiver must be connected using 26
AWG or greater telecommunications wire.
Output signals
Output signals Built-in ash light signal >10 Candela
Warning! Flashes can cause epileptic attacks.
Vibrator power 2.0 – 4.0 VDC (max. 500mA)
For indoor use only Temperature range 0°C – 40°C
Dimensions Ø x H: 70 x 140 mm
Weight: 320 g
Colour: White
Optional accessories (sold seperately)
Wall Mount Bracket BE9075
Bellman Bed-shaker BE1271
Telephone Flex BE9105
Adapter plug for the appropriate country
EN
BE1444_005MAN002-433-Visit-Flashreceiver.indb 18 2017-09-06 09:33:55

18
FCC ID: WMSBE144X
FCC compliance statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Warning: Changes or modications to this unit not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
IC compliance statement
Industry Canada
This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions:
(1)This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
BE1444_005MAN002-433-Visit-Flashreceiver.indb 19 2017-09-06 09:33:55
