BenQ DCP10 User manual

BenQ America Corp.
15375 Barranca Parkway. Suite A-205. Irvine, CA 92618 Tel: [phone] www.BenQ.us
BenQ is a registered trademark of BenQ Corp. All rights reserved.
Product names, logos, brands, and other trademarks featured or referred to in this materials are the property of their respective trademark holders.
Specifications subject to change without notice.
One-Touch Audiovisual Recording
The DCP10 allows you to create live audiovisual videos effortlessly
by pressing the one-touch recording button on the control panel.
It will then save everything recorded to your USB drive or SDHC
card. With your lessons turned into video clips, you can help
absent students catch up missed work quickly and have more to
share at parent-teacher conferences.
5M Sensor
Capture sharp and vivid images of just about any object with the
5-megapixel CMOS sensor – It doesn’t get any higher than this!
1080p Native Output Resolution
With HD 1080p native output resolution, you can offer your class
much more details in everything, whether it’s a book, a photo or
a video clip of your recent eld trip. Pair the DCP10 with BenQ’s
high quality projector to get the best visual result!
QBOX
Draw students’ attention to a particular part of the lesson with
QBOX. You can access this convenient feature directly on the
remote control.
Qvision Software Tool
All it takes is a USB cable to connect your computer to the
DCP10. Start sharing instantly and do editing together live as
a class through Qvision! Be sure to test out all the enhanced
drawing and annotation tools! You can also turn your lesson into
video clips through the recording feature.
5X Optical True Zoom and 80X Total Zoom
This is a practical tool for doing lab work together as a class. Being
able to zoom in closely to observe tiny details helps students stay
focused, understand better and learn more.
USB & SDHC Extended Storage
Capture and save your lessons onto a USB drive or an
SDHC card for future! You can save up to 32GB of images
and videoclips with SDHC and 64GB with a USB drive.
With the DCP10, there’s plenty of room to document every
great lesson!
PC/Camera Switch
The PC/Camera Switch gives you the extra teaching exibility
switching between the DCP10 and your computer. Without
reconnecting the cables, you get to save more time for class!
Instant Sharing, Easy Learning
Highlights Specications
Image Sensor
Total Pixels
Frame Rate
Lens
Focus
Shooting Area
Zoom
Image Rotation
Internal Image Storage
External Image Storage
Image Effective
Image Adjustment
(White Balance/Exposure/Night View)
Presenter Function
Split Screen
Picture-in-Picture
Display Mode
Capture mode
User Proles
Flicker lter Control
Video + Audio Recording
External Storage
Lighting System
Interface
Dimensions (Operating)
Dimensions (Folded)
Net Weight
Power source
Power Consumption
Compatible Operating System
(Qvision Software)
EMC Certications
Safty Certications
Accessories (Standard)
Accessories (Optional)
Limited warranty
1/2” CMOS color sensor
5M Pixels
30 fps (max)
f6.26~30.75mm; f3.2 (wide) f6.8 (tele)
Auto/Manual
11.81”x15.75” (300x400mm)
80X (5X optical Zoom +16X digital Zoom)
0, 90, 180, 270 degrees
Built-in Memory 128MB
Max 80 images (5M); 240 images (XGA)
SDHC (32GB Max) / USB Drive (64GB Max)
Color / B&W / Negative / Mirror / Freeze
Auto/Manual
QBOX / QVISOR / Timer
Horizontal & Vertical
Yes
Text / Graphics / High Frame / Marco
Marco / Innite / Microscope
Single & Continuous
Up to 3
Yes - 2 levels
Saved at SDHC Card or USB Drive
SDHC slot / USB Drive Slot
Embedded LED Lamp with Laser Guide
RGB In, RGB Out
Microphone In, Audio In, Audio Out
Compostie Video, DVI,
DV12V/Light Box Port
RS232 with CVBS/RS-232 adapter cable
Mini USB2.0 for PC Camera or Image Download
18.5” x 6.8” x 21.4” (471.3 x 173.5 x 542.7mm)
14.4” x 6.8” x 2.5” (366.7 x 173.5 x 63.2mm)
4.63 lbs (2.1 Kgs)
AC 100 to 240V, 50/60 Hz
20W (Max)
Windows XP(SP2), Vista(32-bit,64-bit)
Win 7(32-bit, 64-bit)
MAC OS 10.4(Tiger), OS 10.5 (Leopard)
FCC, CE, C-Tick, IC
FDA/CB/NOM/Energy Label/SASD
RS232/CVBS Cable, USB Cable, RGB Cable,
RCA Cable, Power Cord, Carrying Bag,
Remote Control, Anti-glare sheet x 1
Microscope adapters (34mm & 28mm)
Light Box
3 years parts/labor
DCP10 12-09-11-BQus
DCP10
DOCUMENT
CAMERA

Interface
Control Panel
DCP10 Document Camera
(1)
(2)
(3)
(4)
(5)
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
(12)
(1) Camera head
(2) LED light switch
(3) Camera lens
(4) Control panel
(5) Built-in MIC
(6) Arm
(7) Left panel
(8) IR sensor
(9) Rear panel
(10) Right panel
(1) Menu
(2) Recording
(3) Cap/Del
(4) Payback
(5) Freeze/Stop
(6) Camera/PC
(7) , , , &
(8) Zoom in
(9) Zoom out
(10) Enter
(11) Auto focus
(12) Built-in MAC
(6)
(7)
(8)
(9)
(10)
