BenQ DCP10 User manual

Document Camera
User Manual
DCP10

ENGLISH
Table of Contents
Package Contents ........................... 1
Optional Accessories...................... 1
Get Familiar with the DCP10 .......... 2
Right Panel........................................... 2
Rear Panel ........................................... 3
Left Panel ............................................. 3
Control Panel........................................ 4
Remote Control .................................... 5
Making the Connections................. 7
Set the TV-RGB Switch Setting ............ 7
Connect to a Monitor or Projector......... 7
Connect to a Monitor or Projector with
DVI-I interface ...................................... 8
Connect to a TV.................................... 8
Connecting the Power .......................... 9
Connect to a Computer ........................ 9
Connect to a Computer via USB ........ 10
Connect an External Microphone ....... 10
Connect an Amplified Speaker ............11
Connect to a Microscope.....................11
Setting Up DCP10.......................... 12
Camera Head ..................................... 12
Mechanical Arm.................................. 12
LED Light Switch ................................ 13
Infrared Sensor................................... 13
Anti-glare Sheet.................................. 13
External Memory Storage ................... 14
Insert
an SD Card............................ 14 Insert an SD Card
Insert
a USB Flash Drive ................. 14Insert a USB Flash Drive
OSD MENU ..................................... 15
Select Menu and Settings................... 16
Basic................................................... 16
Brightness........................................ 16
Contrast ........................................... 16
Auto Image ...................................... 16
MODE.............................................. 17
Focus............................................... 17
Effect ............................................... 17
Default ............................................. 17
Advanced ........................................... 18
Exposure ......................................... 18
White Balance ................................. 18
Flicker .............................................. 18
Night View ....................................... 19
Presentation ....................................... 19
QBOX On/Off ...................................19
QBOX Shade....................................19
QBOX Resize...................................20
QVISOR ...........................................20
QVISOR Shade ................................20
PIP ...................................................20
Split Screen ......................................21
Timer ................................................21
Timer Set..........................................21
Setting.................................................21
Capture Resolution...........................21
Capture Quality ................................22
Capture Type....................................22
Capture Interval................................22
Recording Format.............................22
Recording Quality.............................22
Current Storage ................................23
Format Storage.................................23
System ................................................23
Language .........................................23
Output Resolution.............................23
USB State.........................................24
Backup .............................................24
Profile Save ......................................24
Profile Recall ....................................24
Information .......................................25
Playback..............................................25
Slide Show .......................................25
Slide Show Interval...........................25
Slide Show Effect .............................25
Current Storage ................................26
Delete All ..........................................26
Transfer Captured Images/Videos to a
computer..........................................26
Technical Specifications...............27
Image ...............................................27
Optics ...............................................27
Power ...............................................27
Lighting.............................................27
Input/Output......................................27
Dimension ........................................28
External Storage...............................28
Troubleshooting ............................28
Limited Warranty ...........................29

ENGLISH
1
P
Pa ac ck ka ag ge e C Co on nt te en nt ts s
Make sure the following items are included in the package.
DCP10
RS-232/CVBS Cable
Power Adapter
Software & Manual CD
USB Cable
RGB Cable
RCA Cable
Power Cord
* The power cord will vary
depending on the standard
power outlet of the country
where it is sold.
Carrying Bag
Remote Control
(batteries included)
Anti-glare Sheet
O
Op pt ti io on na al l A Ac cc ce es ss so or ri ie es s
34mm Microscope Adapter
28mm Microscope Adapter
Light Box

ENGLISH
2
G
Ge et t F Fa am mi il li ia ar r w wi it th h t th he e D DC CP P1 10 0
(9)
(6)
(8)
(7)
(1)
(
2
)
(
3
)
(
4
)
(
5
)(10)
(fig. 1.1)
Name Function
(1) Camera head Contain the camera sensor.
(2) LED light switch Turn on & off among 3 different light settings.
(3) Camera lens Focus the image in the camera.
(4) Control panel Easy access to various functions.
(5) Built-in MIC Record audio when recording video clip. The recorded sound will be
in monophonic.
(6) Arm Extendable for viewing coverage.
(7) Left panel Connections for microphone, speaker, and computer, SD card, and
TV-RGB display output switch.
(8) IR sensor Receive remote control commands.
(9) Rear panel Connections for power and external display device.
(10) Right panel On off switch for USB flash drive port.
Right Panel
(3)
(2)
(1)
(fig. 1.2)
Name Function
(1) USB Flash Drive switch Switch to right (►) for audio video recording directly to a
USB flash drive and left (◄) when connecting DCP10 to a
computer using a USB cable.

ENGLISH
3
Name Function
(2) USB Flash Drive port Insert a USB flash drive for audio video recording.
(3) Power button Turn the unit on/standby mode.
Rear Panel
(3)
(1)
(2)
(fig. 1.3)
Name Function
(1) DC12V / LIGHTBOX port Connect the power adapter into this port.
(2) DVI-I OUTPUT port Connect the DCP10 to any display device with DVI cable.
If the display device does not support DVI-I, you can only
view in Camera and Playback mode.
(3) RGB OUTPUT port Connect the DCP10 to any display device with RGB cable
Left Panel
(1) (7)
(
5
)
(6)
(4)
(3)
(2)
(fig. 1.4)
Name Function
(1) Mini USB port Connect to a USB port of a computer with a USB cable and use
DCP10 as a USB Camera or transfer the captured images/videos
either from the memory source to computer.
(2) RGB INPUT port Input the signal from a computer or other sources and pass it
through to the RGB OUTPUT port only. Connect this port to the
RGB/VGA output port of a computer.
(3) MIC port Connect a 3.5mm plug microphone. The built-in mic will be
disabled when an external MIC is connected to this port.
(4) Speaker port Connect to an amplified speaker to playback recorded audio &
video clip.
(5) RS-232/CVBS port Connect the supplied RS-232/CVBS cable into this port. The RCA
jack outputs the video signal from the camera to a TV or video
equipment. The RS-232 jack is used to connect to computer serial
port or to any control panel or for centralized control if desire.
(6) TV-RGB switch TV switch to output display video from RS232/CVBS (via RCA
connection), and RGB to RGB and DVI-I OUTPUT ports.

ENGLISH
4
Name Function
(7) SD card slot Insert the SD card with the label facing up.
Control Panel
(6)
(7)
(9)
(10)
(11)
(1)
(
2
)
(
3
)
(
4
)
(12)
(8)
(
5
)
(fig. 1.5)
Name Function
(1) MENU Open and exit the OSD menu.
(2) RECORDING Start/Stop audio & video recording. Audio and video recording can be
saved on a SD card or an USB Flash drive only. See External
Memory Storage.
(3) CAP/DEL - Capture picture in Camera mode. In continuous capture mode,
press this button again to stop.
- Delete the selected picture/video in Playback mode.
(4) PLAYBACK View & playback captured still images and audio video files.
(5) FREEZE / STOP - Pause or resume image display in Camera mode.
- Stop audio & video playback in Playback mode.
(6) CAMERA / PC Switch between Camera and Computer.
(7) ▲,▼,◄, & ►
- Pan and zoom-in image (above 10x zoom level) in both live and
playback mode.
- Select options in OSD menu.
- Use ▲&▼to increase and decrease the video playback volume.
- Use ◄&►to play the video backward and forward.
- Move the QBOX frame and QVISOR screen cover.
(8) ZOOM IN Increase the image magnification in camera and picture playback
mode.
(9) ZOOM OUT Decrease the image magnification in camera and picture playback
mode.
(10) ENTER - Make a selection in Playback mode and OSD menu.
- Start/Pause video playback.
(11) AUTO FOCUS Adjust the focus automatically.
(12) Built-in MIC Record audio automatically when recording video clip

ENGLISH
5
Remote Control
The remote control requires two (2) “AAA” size batteries (supplied), make sure batteries
are installed properly before use. You can access all the features of DCP10 with the
remote.
Name Function
(11)
(6)
(17)
(22)
(21)
(19)
(20)
(23)
(26)
(1)
(9)
(13)
(15)
(5)
(24)
(25) (7)
(2)
(4)
(3)
(8)
(10)
(16)
(14)
(12)
(18)
(fig. 1.6)
(1) POWER Turn the unit on/standby.
(2) CAMERA / PC Switch between Camera and
computer mode.
- Camera mode displays the video
signal from the built-in camera.
- PC mode displays the video signal
from the RGB INPUT port of
DCP10.
(3) PLAYBACK View the captured picture/video from
the memory in 16-thumbnail images.
(4) QBOX Overlay a box frame on the
presentation screen, you can move it
around and adjust the box size
(5) QVISOR Cover part of the presentation screen
and allow presenter to reveal the
material as desire.
(6) SPLIT SCREEN Divide the screen into two. One side
displays the live image from the built-
in camera and the other side displays
8-thumbnail size picture/video from
the memory.
(7) PIP Show a thumbnail size captured
picture/video from the memory at the
corner of the screen in Camera
mode.
(8) SLIDE SHOW Start/Stop automatically showing the
captured picture/video one-by-one.
(9) EFFECT Convert and display the image in
BW, Negative or Color in Camera
and Playback mode only.
(10) CAPTURE Capture still image in Camera mode.
In continuous capture mode, press
this button again to stop.
(11) RECORDING Start/Stop audio & video recording.
Video recording can only be saved
either in a SD memory card or a USB
flash drive.
(12) DEL Delete the selected picture/video in
Playback mode.
(13) AUTO IMAGE Automatically adjust and set the
white balance and exposure setting.
(14) BRIGHTNESS
+/-
Adjust the brightness.

ENGLISH
6
Name Function
(11)
(6)
(17)
(22)
(21)
(19)
(20)
(23)
(26)
(1)
(9)
(13)
(15)
(5)
(24)
(25) (7)
(
2
)
(4)
(3)
(8)
(10)
(16)
(14)
(12)
(18)
(fig. 1.6)
(15) DEFAULT Reset at factory default setting.
(16) NEAR / FAR Adjust the focus manually.
(17) ZOOM RESET Reset zoom level to 100%.
(18) ZOOM +/- Increase/decrease the image
magnification in camera and picture
playback mode.
(19) ENTER - Make a selection in Playback mode
and OSD menu.
- Start/Pause video playback.
(20) ▲,▼,◄, & ►- Pan the image when image is
above 10X zoom in live mode or in
playback captured image mode.
- Move the selection in Playback
mode and in OSD menu.
- Use ▲&▼to increase and
decrease the video playback
volume.
- Use ◄&►to play the video
backward and forward.
- Move the QBOX frame and
QVISOR screen cover.
(21) MENU Open and exit the OSD menu.
(22) AUTO FOCUS Adjust the focus automatically.
(23) FREEZE / STOP - Freeze live images.
- Stop video playback.
(24) ROTATE Rotate the image by 90° in Camera
mode and Playback mode.
(25) MIRROR Flip the image in Camera mode.
(26) TIMER Start/Pause timer countdown.

ENGLISH
7
M
Ma ak ki in ng g t th he e C Co on nn ne ec ct ti io on ns s
Before making the connection, make sure the power of all devices are turned off. If you
are not sure on where to connect, simply follow the illustrated connections below and also
refer to the user manual of the device you are connecting the DCP10 with.
S
Se et t t th he e T TV V- -R RG GB B S Sw wi it tc ch h S Se et tt ti in ng g
The TV-RGB switch determines the display output selection. Switch it to RGB (right) to
output signal using RGB/DVI-I connection and TV (left) to output signal using RCA
connection. (see fig. 1.4 # 6)
Switch DCP10 Port Display Device Port
RGB
RGB OUTPUT
To
RGB INPUT
DVI-I OUTPUT DVI-I INPUT
TV
RS232/CVBS
(use RS-232/CVBS cable)
VIDEO IN
C
Co on nn ne ec ct t t to o a a M Mo on ni it to or r o or r P Pr ro oj je ec ct to or r
Locate the RGB (VGA) input port of the graphics display device and connect it to RGB
OUTPUT port of DCP10.
Make sure the TV/RGB switch is set to RGB.
RGB cable
Projector
LCD monitor
CRT monitor

ENGLISH
8
C
Co on nn ne ec ct t t to o a a M Mo on ni it to or r o or r P Pr ro oj je ec ct to or r w wi it th h D DV VI I- -I I
i
in nt te er rf fa ac ce e
Locate the DVI-I input port of the display device and connect it to DVI-I OUTPUT port of
DCP10.
Make sure the TV/RGB switch is set to RGB.
Projector
LCD Monitor
with DVI interface
DVI cable
(not supplied)
C
Co on nn ne ec ct t t to o a a T TV V
Locate the VIDEO or SCART RGB (if applicable) input port of the TV or Video equipment
(i.e., VCR) to record your presentation and connect it to RCA jack of RS-232/CVBS cable.
RS-232/CVBS cable
RCA to SCART cable
(not supplied)
RCA cable
VIDEO
SCART
INPUT
Projector
Television
VCR

ENGLISH
9
C
Co on nn ne ec ct ti in ng g t th he e P Po ow we er r
Connect the power adapter to a standard 100V~240V AC power outlet. The unit
automatically turns on once the power is connected.
Power adapter
Power cord
Wall outlet
C
Co on nn ne ec ct t t to o a a C Co om mp pu ut te er r
Locate the RGB (VGA) output port of the computer or laptop and connect it to RGB INPUT
port of DCP10. The video signal from the RGB INPUT port is streamed to RGB and DVI-I
OUTPUT port.
- To display computer image, press Camera/PC button on the control panel
or remote control to switch DCP10 to computer mode.
- For laptop to output display image, use the keyboard command (FN+F5)
to switch between the display modes. For different command, please refer
to your laptop manual.
RGB cable
Desktop
Laptop

ENGLISH
10
C
Co on nn ne ec ct t t to o a a C Co om mp pu ut te er r v vi ia a U US SB B
Locate the USB port of the computer or laptop and connect it to USB port of DCP10. This
enables you to use DCP10 as a USB Camera or to transfer the captured pictures/videos
from the memory and to computer. Also see “Transfer File from DCP10 to PC”.
Make sure the USB Flash Drive switch (see fig. 1.2 #1) is set to the
left .
USB cable
Desktop
Laptop
C
Co on nn ne ec ct t a an n E Ex xt te er rn na al l M Mi ic cr ro op ph ho on ne e
Plug a 3.5mm mono microphone to port. The built-in microphone on the control panel
will be disabled when an external microphone is connected. The recorded audio will be in
monophonic sound.
Microphone

ENGLISH
11
C
Co on nn ne ec ct t a an n A Am mp pl li if fi ie ed d S Sp pe ea ak ke er r
Plug a 3.5mm plug amplified speaker to port. Only the audio from the video playback is
supported.
We recommend connecting an amplified speaker to the Audio output port.
Take caution when using earphones. Adjust the volume down on the
remote to prevent hearing damage due to loudness.
Amplified Speaker
C
Co on nn ne ec ct t t to o a a M Mi ic cr ro os sc co op pe e
Connect the DCP10 to a microscope enables you to examine microscopic objects on a big
screen.
1. Change the image display mode to Microscope. Press MENU > select MODE > select
MICROSCOPE and press ENTER.
2. Adjust the microscope and focus first. Then select the appropriate adapter size for the
microscope eyepiece.
3. Remove the microscope eyepiece from the microscope and connect it with the
microscope adapter. Fasten the 3 bolts until the adapter secures the eyepiece.
4. Attach the microscope adapter to the DCP10 camera head.
- Make sure to connect the longer hook to the front latch hole of the
camera head.
- For the eyepiece, we suggest using 15.5mm eye relief or higher.
Microscope
eyepiece
Microscope
Adapter
Microscope
2.5cm 2.2cm

ENGLISH
12
S
Se et tt ti in ng g U Up p D DC CP P1 10 0
This section provides useful tips on how to adjust the DCP10 to meet your needs.
C
Ca am me er ra a H He ea ad d
The camera head can turn freely at 90° to the left and right and up and down.
90°
90°
90°
90°
If the camera head is in upright position, you can also press ROTATE on the remote
control twice to rotate the image in 180°.
M
Me ec ch ha an ni ic ca al l A Ar rm m
The mechanical arm design can extend for a full A4 paper viewing.
122mm (4.8 in)
180°
195°

ENGLISH
13
L
LE ED D L Li ig gh ht t S Sw wi it tc ch h
DCP10 has patented four (4) laser positioning pointers feature that define the viewing
area. This allows user quickly center the object underneath the camera. The three (3)
various light and laser positioning pointers settings are indicated in the illustration below.
OffOff
White LED and
Document
Positioning
Pointers
Document
Positioning
Pointers
White LED
Only
I
In nf fr ra ar re ed d S Se en ns so or r
Aim the remote control at the infrared sensor to operate the unit.
A
An nt ti i- -g gl la ar re e S Sh he ee et t
The anti-glare sheet is a special coated film that helps eliminate any glare that maybe
encountered while displaying very shiny objects or glossy surfaces such as magazines
and pictures. To use, simply place the anti-glare sheet on top of the shiny document to
reduce reflected light.

ENGLISH
14
E
Ex xt te er rn na al l M Me em mo or ry y S St to or ra ag ge e
DCP10 supports both SD memory card and USB flash drive for more image capture and
audio & video recordings. DCP10 can detect when there is an external storage media and
automatically switch to the last detected storage. If no external storage is connected, all
captured still images will be saved in the built-in memory.
I
In ns se er rt t a an n S SD D C Ca ar rd d
Insert the card with the contact facing down until it reaches the end. To remove
the card, push to eject and pull the card out. The supported SD card capacity is
from 1GB to 32GB.
SD Card
I
In ns se er rt t a a U US SB B F Fl la as sh h D Dr ri iv ve e
Make sure to set the USB Flash Drive switch (see fig. 1.2 #1) to the right before
inserting a USB flash drive. DCP10 can support USB flash drive from 2GB to
64GB.
USB Flash Drive

ENGLISH
15
O
OS SD D M ME EN NU U
There are 5 tabs on the OSD menu: BASIC, ADVANCED, PRESENTATION, SETTING
and SYSTEM. In Playback mode, you can access PLAYBACK OSD menu to enable the
Slide Show feature and modify Slide Show interval and transition setting if desire.
For TV output, the RESOLUTION will be disabled in SETTING menu list.
BASIC ADVANCED
PRESENTATION
SETTING
SYSTEM
PLAYBACK

ENGLISH
16
S
Se el le ec ct t M Me en nu u a an nd d S Se et tt ti in ng gs s
1. Press MENU button on the remote or control panel.
2. Press ►and ◄to toggle between tabs
3. Press ▼and ▲to select a menu option.
4. Press ENTER to make a selection and display the
setting selection on the right.
5. Use ►and ◄to adjust the setting or ▼and ▲to make
a selection.
6. Press ENTER to make the new setting take effect.
7. Press MENU to close the OSD menu.
B
Ba as si ic c
Menu Screen Function
Brightness
Adjust brightness level manually between 0 and 63.
Contrast
Adjust the contrast level manually between 0 and 255
under bright and dark environments.
Auto Image
Automatically adjust the white balance and exposure
setting and correct the color and exposure compensation.

ENGLISH
17
Menu Screen Function
MODE
Select various image display settings.
Sharp - adjust the contrast along the edges making text
appear more visible.
Graphics - adjust the gradient of image.
Motion - increase frame rate. Sufficient lighting is
required when using this mode.
Microscope - automatically adjust optical zoom for
microscopic viewing.
Macro - set to view when object is only 5 – 20 cm away
from the camera.
Infinite - set to view when subject is at least 55cm away
from the camera.
Focus
Manually adjust the focus.
Effect
Convert the image into positive (true color), monochrome
(black and white) or negative.
Default
Restore all the settings into original factory default setting.

ENGLISH
18
A
Ad dv va an nc ce ed d
Menu Screen Function
Exposure
Select the exposure setting.
AUTO - automatically adjust the camera exposure and
amount of light required.
MANUAL - manually adjust the exposure level. The
exposure can be adjusted up to 100.
White Balance
Select the White Balance setting for various light
conditions or color temperature.
AUTO - automatically adjust the white balance.
MANUAL - manually adjust the red and blue color level.
The color level can be adjusted up to 255.
Flicker
Select between 50Hz or 60Hz. Some display devices
cannot handle high refresh rates. The image will flicker a
couple of times as the output is switched to another
refresh rate.
