1
RM5501K/RM6501K/RM7501K/RM8601K
RS232/LAN Protocol Installation Guide

2
Table of Contents
Introduction...........................................................................................................................3
Wire arrangement.........................................................................................................................................................3
RS232 pin assignment...................................................................................................................................................3
Communicationsetting...................................................................................................................................... 4
Command message reference............................................................................................................................ 4
Connections and communication settings..............................................................................4
RS232 serial port with a straight cable .....................................................................................................................4
RS232 via LAN...............................................................................................................................................................5
RS232 via HDBaseT......................................................................................................................................................5
Protocol Command Description .............................................................................................5
Set-function listing.........................................................................................................................................................6
Set-function description...............................................................................................................................................6
Set-function format ........................................................................................................................................... 6
Set-function table .............................................................................................................................................. 8
Get-function listing......................................................................................................................................................10
Get-function description............................................................................................................................................10
Get-function format ........................................................................................................................................10
PC Get-function command to LCD Monitor .................................................................................................15
Date: 2019/03/20

3
Introduction
This document describes the hardware interface spec and software protocols of RS232 interface
communication between Commercial Display and PC or other control unit with RS232 protocol.
This set protocol allow users to assign the ID in the command to control the specify ID monitor.
The set protocol contains two sections command: Set-Function and Get-Function
In this document, "PC" represents all the control units that can send or receive the RS232 protocol command.
Wire arrangement
Wire Arrangement
P1
Color
P2
1
Black
1
2
Brown
3
3
Red
2
4
Orange
4
5
Yellow
5
6
Green
6
7
Blue
7
8
Purple
8
9
Gray
9
Case
Drain wire
Case
RS232 pin assignment
Pin
Description
Pin
Description
1
NC
2
RXD
3
TXD
4
NC
5
GND
6
NC
7
RTS
8
CTS
9
NC
Use of crossover (null modem) cable requires use with PC.

4
Communication setting
Baud rate select: 38400bps (fixed)/ Data bits: 8 bits (fixed)
Parity: None (fixed)/ Stop Bits: 1(fixed)
Command message reference
PC sends to Monitor command packet followed by "CR". Every time PC sends control command to the
Monitor, the Monitor shall response as follows:
1. If the message is received correctly, it will send "+" (02Bh) followed by "CR" (00Dh).
2. If the message is received incorrectly, it will send "-" (02Dh) followed by "CR" (00Dh).
Connections and communication settings
Choose one of the connections and set up properly before RS232 control.
RS232 serial port with a straight cable
PC or laptop
D-Sub port (male or female)
on a display
D-Sub 9 pin
(female)
D-Sub 9 pin
(male)
Communication cable (straight)
D-Sub 9 pin

5
RS232 via LAN
Find the Wired LAN IP address of the connected display from the OSD menu and make sure the display and the computer
are within the same network.
IP Procotol Port: 4660
RS232 via HDBaseT
Protocol Command Description
Item
Description
Length
Total Bytes of Message excluding "CR"
TV ID
Identification for each of TV
Command Type
Identify command type, "s"
(0x73h): Set Command
"g" (0x67h): Get Command
"r" (0x72h): Reply Command
"+" (0x2Bh): Valid command Reply
"-" (0x2Dh): Invalid command Reply
Command
Function command code: One byte ASCII code
Value [1~3]
Three bytes ASCII that defines the value
CR
0x0D
PC or laptop
LAN cable
RJ45 port on a display
HDBaseT compatible device
D-Sub 9 pin
RJ45
RJ45 port on a display
LAN cable
D-Sub 9 pin
PC or laptop

6
Set-function listing
The PC can control the LCD Monitor for specific actions. The Set-Function command allows you to
control the LCD monitor behavior in a remote sit through the RS232 port. The
Set-Function packet format consists of 11 bytes.
Set-function description
Item
Description
Length
Total Bytes of Message excluding "CR"
TV ID
Identification for each of TV
TV ID is “01”for LAN control
Command Type
Identify command type, "s"
(0x73h): Set Command
Command
Function command code: One byte ASCII code
Value [1~3]
Three bytes ASCII that defines the value
CR
0x0D
Set-function format
Send: (Command Type="s")
Name
Length
ID
Command
type
Command
Value1
Value2
Value3
CR
Byte count
1 Byte
2 Byte
1 Byte
1 Byte
1 Byte
1 Byte
1 Byte
1 Byte
Bytes
order
1
2~3
4
5
6
7
8
9
Reply: (Command Type="+" or "-")
Name
Length
ID
Command
type
CR
Bytecount
1 Byte
2 Byte
1 Byte
1 Byte
Bytes
order
1
2~3
4
5
Example 1: Set Brightness as 76 for TV-02 and this command is valid.
Send (Hex Format)
Name
Length
ID
Command
type
Command
Value1
Value2
Value3
CR

7
Hex
0x38
0x30
0x32
0x73
0x24
0x30
0x37
0x36
0x0D
Reply (Hex Format)
Name
Length
ID
Command
type
CR
Hex
0x34
0x30
0x31
0x2B
0x0D
Example 2: Set Brightness as 176 for TV-02 and this command is NOT valid.
Send (Hex Format)
Name
Length
ID
Command
type
Command
Value1
Value2
Value3
CR
Hex
0x38
0x30
0x32
0x73
0x24
0x31
0x37
0x36
0x0D
Reply (Hex Format)
Name
Length
ID
Command
type
CR
Hex
0x34
0x30
0x31
0x2D
0x0D
Example 3: Set Tint as 32 for TV-03 and this command is valid.
Send (Hex Format)
Name
Length
ID
Command
type
Command
Value1
Value2
Value3
CR
Hex
0x38
0x30
0x33
0x73
0x27
0x30
0x33
0x32
0x0D
Reply (Hex Format)
Name
Length
ID
Command
type
CR

8
Hex
0x34
0x30
0x31
0x2B
0x0D
Example 4: Set Tint as 75 for TV-03 and this command is NOT valid.
Send (Hex Format)
Name
Length
ID
Command
type
Command
Value1
Value2
Value3
CR
Hex
0x38
0x30
0x33
0x73
0x27
0x30
0x37
0x35
0x0D
Reply (Hex Format)
Name
Length
ID
Command
type
CR
Hex
0x34
0x30
0x31
0x2D
0x0D
Example 5: Set Brightness as 76 for all TV and this command is valid.
Send (Hex Format)
Name
Length
ID
Command
type
Command
Value1
Value2
Value3
CR
Hex
0x38
0x39
0x39
0x73
0x24
0x30
0x37
0x36
0x0D
No Reply.
Set-function table
Value Range (ASCII Bytes)
Set Function
Len
ID
Cmd Type
Cmd Code
(Hex)
RS232 Control
LAN Control
Power
8
s
21
000 : ------- / Monitor
Off
000 : Monitor Off
001 : Android On / Monitor On
001 : Monitor On
002 : Android Off / -------
Video Source
8
s
22
000 : VGA
000 : VGA
001 : HDMI1
001 : HDMI1

9
002: HDMI2
002: HDMI2
021 : HDMI3
021 : HDMI3
022 : HDMI4
022 : HDMI4
101 : android
101 : android
102 : OPS
102 : OPS
Aspect Ratio
8
s
31
000: Default
001: 16:9
002: 4:3
003: Auto
004 : Panorama Mode
005 : Just Scan
006 : 14:9
007 : PC Mode
Language
8
s
32
000: English
001: Français
002: Español
003: 繁中
004: 简中
005: Português
006: German
007: Dutch
008: Polish
009: Russia
010:Czech
011:Danish
012:Swedish
013:Italian
014:Romanian
015:Norwegian
016:Finnish
017:Greek
019:Arabic
020: Japanse
021: Thailand
023 : Hungarian
024 : Persian
025 : Vietnamese
Volume
8
s
35
200 Volume -
200 Volume -
300 Volume +
300 Volume +

10
Mute
8
s
36
002: turn (State change)
002: turn (State change)
Remote control
8
s
40
010 : Remote Up
011 : Remote Down
012 : Remote Left
013 : Remote Right
014 : Remote OK
020 : Remote OSD Menu
021 : Remote Source
023 : Remote Back (Android Back
key)
031 : Blank
032 : Freeze
Button&IR Control
8
s
43
000: Disable
001: Enable
All Reset
8
s
7E
000
Monitor ID default : 01 (30 31)
Get-function listing
The PC can interrogate the LCD Monitor for specific information. The Get-Function packet format
consists of 5 bytes which are similar to the Set-Function packet structure. Note that the "Value" byte is
always = 00.
Get-function description
Item
Description
Length
Total Bytes of messages excluding "CR"
TV ID
Identification for each of TV
Command Type
Identify command type,
"g" (0x67h): Get Command
Command
Function command code: One byte ASCII code
Value [1~3]
Three bytes ASCII that defines the value
NOTE: To get backlight senor, thermal sensor, and ambient sensor,
you need four bytes ASCII that defines the value and the length is 9.
CR
0x0D
Get-function format
Send: (Command Type="g")

11
Name
Length
ID
Command
type
Command
Value1
Value2
Value3
CR
Byte count
1 Byte
2 Byte
1 Byte
1 Byte
1 Byte
1 Byte
1 Byte
1 Byte
Bytes
order
1
2~3
4
5
6
7
8
9
Reply: (Command Type="r" or "-")
If the Command is valid, Command Type ="r"
Name
Length
ID
Command
type
Command
Value1
Value2
Value3
CR
Byte count
1 Byte
2 Byte
1 Byte
1 Byte
1 Byte
1 Byte
1 Byte
1 Byte
Bytes
order
1
2~3
4
5
6
7
8
9
If the Command is Not valid, Command Type="-"
Name
Length
ID
Command
type
CR
Bytecount
1 Byte
2 Byte
1 Byte
1 Byte
Bytes
order
1
2~3
4
5
Example 1: Get Brightness from TV-05 and this command is valid.
The Brightness value is 67.
Send (Hex Format)
Name
Length
ID
Command
type
Command
Value1
Value2
Value3
CR
Hex
0x38
0x30
0x35
0x67
0x62
0x30
0x30
0x30
0x0D
Reply (Hex Format)
Name
Length
ID
Command
type
Command
Value1
Value2
Value3
CR

12
Hex
0x38
0x30
0x35
0x72
0x62
0x30
0x36
0x37
0x0D
Example 3: Get Tint from TV-0007 and this command is valid.
The Tint value is 32.
Send (Hex Format)
Name
Length
ID
Command
type
Command
Value1
Value2
Value3
CR
Hex
0x38
0x30
0x37
0x67
0X65
0x30
0x30
0x30
0x0D
Reply (Hex Format)
Name
Length
ID
Command
type
Command
Value1
Value2
Value3
CR
Hex
0x38
0x30
0x37
0x72
0x65
0x30
0x33
0x32
0x0D
Example 4: Get Tint from TV-07, but the Brightness command ID is error and it is NOT in the command
table.
Send (Hex Format)
Name
Length
ID
Command
type
Command
Value1
Value2
Value3
CR
Hex
0x38
0x30
0x37
0x67
0XD7
0x30
0x30
0x30
0x0D
Reply (Hex Format)
Name
Length
ID
Command
type
CR

13
Hex
0x34
0x30
0x31
0x2D
0x0D
Example 5: Get backlight sensor from TV-0007 and this command is valid.
The lux value is 1786 (ASCII code).
Send (Hex Format)
Name
Length
ID
Command
type
Command
Value1
Value2
Value3
Value4
CR
Hex
0x39
0x30
0x37
0x67
0X6F
0x30
0x30
0x30
0x30
0x0D
Reply (Hex Format)
Name
Length
ID
Command
type
Command
Value1
Value2
Value3
Value4
CR
Hex
0x39
0x30
0x37
0x72
0X6F
0x31
0x37
0x38
0x36
0x0D
Example 6: Get ambient sensor from TV-0007 and this command is valid.
The lux value is 1568 (ASCII code).
Send (Hex Format)
Name
Length
ID
Command
type
Command
Value1
Value2
Value3
Value4
CR
Hex
0x39
0x30
0x37
0x67
0X70
0x30
0x30
0x30
0x30
0x0D
Reply (Hex Format)
Name
Length
ID
Command
type
Command
Value1
Value2
Value3
Value4
CR
Hex
0x39
0x30
0x37
0x72
0X70
0x31
0x35
0x36
0x38
0x0D
Example 7: Get thermal sensor from TV-0007 and this command is valid.

14
The value is +075 degree (ASCII code).
NOTE: Positive degree is "+"ASCII code and negative degree is "-"ASCII code.
Send (Hex Format)
Name
Length
ID
Command
type
Command
Value1
Value2
Value3
Value4
CR
Hex
0x39
0x30
0x37
0x67
0X71
0x30
0x30
0x30
0x30
0x0D
Reply (Hex Format)
Name
Length
ID
Command
type
Command
Value1
Value2
Value3
Value4
CR
Hex
0x39
0x30
0x37
0x72
0X71
0x2B
0x30
0x37
0x35
0x0D
Example 8: Get Running Hours from TV-0007 and this command is valid. The value is 21,356 hours (ASCII
code).
Send (Hex Format)
Name
Length
ID
Command
type
Command
Value1
Value2
Value3
Value4
Value5
CR
Hex
0x3A
0x30
0x37
0x67
0X76
0x30
0x30
0x30
0x30
0x30
0x0D
Reply (Hex Format)
Name
Length
ID
Command
type
Command
Value1
Value2
Value3
Value4
Value5
CR
Hex
0x3A
0x30
0x37
0x72
0X76
0x32
0x31
0x33
0x35
0x36
0x0D

15
PC Get-function command to LCD Monitor
Value Range (ASCII Bytes)
Get Function
Len
ID
Cmd
Type
Cmd Code
(Hex)
RS232
LAN
Model Info
20
g
20
(1) Input value: Byte1 - Byte2 - Byte3…Byte15
Byte2~Byte11=0x00
Byte1=0x01: Get Customer Name
Byte1=0x02: Get Customer Model Name
Byte1=0x04: Get Scaler Firmware Version
Byte1=0x06: Get Serial Number
(2) Return value: Byte1 - Byte2 - Byte3…Byte15
The Byte1 value at the return value should be the same as the
value of Byte1 at input value.
Byte2~Byte15 should be ASCII format.
Ex: If Customer=Generic, Byte1=0x01, Byte2='G',
Byte3='e',...Byte8='c', Byte9~Byte11=0x00.
Ex: If the Scaler Firmware Version=1.02, Byte1=0x03, Byte2='1',
Byte3='.', Byte4='0', Byte5='2', Byte6~Byte11=0x00.
Signal Status
8
g
22
000: Signal unstable
001: Signal stable (Active Sync exists)
Volume
8
g
66
000 ~ 100
000 ~ 100
Mute
8
g
67
000: Off
000: Off
001: On
001: On
Button&IR Control
8
g
69
000: Disable
001: Enable
Video Source
8
g
6A
000 : VGA
001 : HDMI1
002: HDMI2
021 : HDMI3
022 : HDMI4
101 : android
102 : OPS
Power
8
g
6C
000 : Monitor Off
001 : Android
On
001 : Monitor On
002 : Android

16
Off
Aspect Ratio
8
g
77
000: Default
001: 16:9
002: 4:3
003: Auto
004 : Panorama Mode
005 : Just Scan
006 : 14:9
007 : PC Mode
Language
8
g
78
000: English
001: Français
002: Español
003: 繁中
004: 简中
005: Português
006: German
007: Dutch
008: Polish
009: Russia
010:Czech
011:Danish
012:Swedish
013:Italian
014:Romanian
015:Norwegian
016:Finnish
017:Greek
019:Arabic
020:Japanse
021: Thailand
023 : Hungarian
024 : Persian
025 : Vietnamese
Network Setting
14
g
E1
Input Value: Byte1 - Byte2 - Byte3…Byte9
(1) Byte1=0x00: IP Setup Mode
Byte1=0x01: IP Address
Byte1=0x02: Get Subnet Mask
Byte1=0x03: Default Gateway
Byte1=0x04: Primary DNS

17
Byte1=0x05: Secondary DNS
Byte1=0x06: MAC Address
(2) Byte2~9 are reserved, should be 0x00.
Return value: Byte1 - Byte2 - Byte3…Byte9
The Byte1 at the return value should be the same as the value of
Byte1 at Input value. Byte2~Byte15 should be hex value format
(1) If Byte1=0x00(IP Setup Mode) at Input value, the return value
should be
Byte1=0x00
Byte2=0x00: Manual
0x01: DHCP
Byte3~9 are reserved, should be 0x00.
(2) If Byte1=0x01(IP Address) at Input value, the return value
should be
Ex: IP address=169.254.81.38
Byte1=0x01 (same as Byte1 at Input value)
Byte2=0xA9 (=169), Byte3=0xFE (=254),
Byte4=0x51(=81), Byte5=0x26 (=38)
Byte6~9 are reserved, should be 0x00.
(3) If Byte1=0x02~0x05 at Input value, refer to (2)
(4) If Byte1=0x06(MAC Address) at Input value, the return value
should be
Ex: MAC address=00:22:64:7E:2C:82
Byte1=0x06 (same as Byte1 at Input value)
Byte2=0x00, Byte3=0x22, Byte4=0x64, Byte5=0x7E,
Byte6=0x2C, Byte7=0x82
Byte8~9 are reserved, should be 0x00.
Monitor ID default : 01 (30 31)
