BenQ PV270 User manual

PV Series
LCD Monitor
User Manual
Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per BenQ PV270 o
cerca il tuo prodotto tra le migliori offerte di Monitor

2
Copyright
Copyright © 2016 by BenQ Corporation. All rights reserved. No part of this publication may
be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any
language or computer language, in any form or by any means, electronic, mechanical, magnetic,
optical, chemical, manual or otherwise, without the prior written permission of BenQ
Corporation.
Disclaimer
BenQ Corporation makes no representations or warranties, either expressed or implied, with
respect to the contents hereof and specifically disclaims any warranties, merchantability or
fitness for any particular purpose. Further, BenQ Corporation reserves the right to revise this
publication and to make changes from time to time in the contents hereof without obligation of
BenQ Corporation to notify any person of such revision or changes.
Power Safety
• The AC plug isolates this equipment from the AC supply.
• The power supply cord serves as a power disconnect device for pluggable equipment. The
socket outlet should be installed near the equipment and be easily accessible.
• This product should be operated from the type of power indicated on the marked label. If you
are not sure of the type of power available, consult your dealer or local power company.
• An approved power cord greater or equal to H03VV-F or H05VV-F, 2G or 3G, 0.75mm2 must
be used.
Care And Cleaning
• Cleaning. Always unplug your monitor from the wall outlet before cleaning. Clean the LCD
monitor surface with a lint-free, non-abrasive cloth. Avoid using any liquid, aerosol or glass
cleaners.
• Slots and openings on the back or top of the cabinet are for ventilation. They must not be
blocked or covered. Your monitor should never be placed near or over a radiator or heat
source, or in a built-in installation unless proper ventilation is provided.
• Never push objects or spill liquid of any kind into this product.
Safety warning and precautions
• The warranty may be void if any of the instructions in this user manual are not followed.
Improper use will invalidate the guarantee. These safety instructions also apply to original
accessories.
Please follow these safety instructions for best performance, and long life for your monitor.

3
• It is the sole responsibility of the user if problems (such as data loss and system failure)
occurred due to non-factory provided software, parts, and/or non-original accessories.
• Please use the original accessories (e.g. power cable) only with the device to avoid possible
dangers such as electric shock and fire.
• It takes about 30 minutes (under BenQ standard testing condition) for the system to reach to
a stable state. For works that involve critical color judgment or image enhancement, please
wait for 30 minutes after the monitor is powered on.
• It is recommended to set the monitor to a lower brightness for long-term use to reduce your
eye strain, and maintain a stable display in order to extend the display’s lifetime. Yet you should
always adjust the monitor brightness according to the light condition around the monitor. See
Adjusting the backlight on page 33 for more information.
Servicing
Do not attempt to service this product yourself, as opening or removing covers may expose
you to dangerous voltages or other risks. If any of the above mentioned misuse or other
accident such as dropping or mishandling occurs, contact qualified service personnel for
servicing.
BenQ ecoFACTS
BenQ has been dedicated to the design and development of greener product as part of its
aspiration to realize the ideal of the "Bringing Enjoyment 'N Quality to Life" corporate vision
with the ultimate goal to achieve a low-carbon society. Besides meeting international regulatory
requirement and standards pertaining to environmental management, BenQ has spared no
efforts in pushing our initiatives further to incorporate life cycle design in the aspects of
material selection, manufacturing, packaging, transportation, using and disposal of the products.
BenQ ecoFACTS label lists key eco-friendly design highlights of each product, hoping to ensure
that consumers make informed green choices at purchase. Check out BenQ's CSR Website at
http://csr.BenQ.com/ for more details on BenQ's environmental commitments and
achievements.

4
Table of Contents
Copyright ......................................................................................................................................2
Getting started .............................................................................................................................5
Getting to know your monitor ................................................................................................7
Front view.................................................................................................................................................... 7
Back view ..................................................................................................................................................... 7
Connection ...................................................................................................................................................9
How to assemble your monitor hardware ........................................................................ 10
How to detach the stand and the base ............................................................................................... 15
Installing shading hood ............................................................................................................ 17
Adjusting the monitor height ................................................................................................................ 20
Rotating the monitor .............................................................................................................................. 21
Viewing angle adjustment ....................................................................................................................... 22
Using the monitor wall mounting kit ................................................................................................... 23
Getting the most from your BenQ monitor ...................................................................... 24
How to install the monitor on a new computer .............................................................................. 25
How to upgrade the monitor on an existing computer ................................................................. 26
How to install on Windows 10 system .............................................................................................. 27
How to install on Windows 8 (8.1) system .......................................................................................28
How to install on Windows 7 system ................................................................................................ 29
How to adjust your monitor ................................................................................................. 30
The control panel..................................................................................................................................... 30
Basic menu operation ............................................................................................................................. 31
Customizing the hot keys....................................................................................................................... 32
Adjusting the display color..................................................................................................................... 32
Adjusting color temperature automatically........................................................................................ 33
Adjusting the backlight............................................................................................................................ 33
Using PIP/PBP mode ................................................................................................................................ 33
Navigating the main menu ...................................................................................................... 35
Display menu ............................................................................................................................................. 36
Color Adjustment menu ........................................................................................................................ 38
ERGONOMICS menu ............................................................................................................................ 43
Eco menu ................................................................................................................................................... 45
PIP/PBP menu ............................................................................................................................................ 47
System menu ............................................................................................................................................. 50
Troubleshooting ....................................................................................................................... 54
Frequently asked questions (FAQ) ...................................................................................................... 54
Need more help?...................................................................................................................................... 56

5Getting started
Getting started
When unpacking please check you have the following items. If any are missing or damaged,
please contact the place of purchase for a replacement.
BenQ LCD Monitor
Monitor Stand
Monitor Base
Quick Start Guide
DVD-ROM
Power Cord
(Picture may differ from product supplied
for your region.)
Video Cable: DVI-DL

6 Getting started
Video Cable: DP to mini DP
Video Cable: HDMI
(Optional accessory, sold separately)
USB Cable
Shading hood
• Available accessories and the pictures shown here may differ from the actual contents and the product supplied
for your region. For cables that are not supplied with your product, you can purchase them separately.
• Consider keeping the box and packaging in storage for use in the future when you may need to transport the
monitor. The fitted foam packing is ideal for protecting the monitor during transport.
Always keep the product and accessories out of reach of small children.

7Getting to know your monitor
Getting to know your monitor
Front view
Back view
1. Color temperature sensor (see
Adjusting color temperature
automatically on page 33)
2. Light sensor / ECO sensor
3. Control buttons
4. Power button
234
1
5. Power switch
6. AC power input jack
7. Cable management hole
8. HDMI socket
9. DisplayPort socket
10. Mini DisplayPort socket
11. Service port (Service only. Do
not remove the seal or the
warranty is void.)
12. USB port (upstream; connecting
to the PC)
13. Kensington lock slot
6751389
10 12
11

8 Getting to know your monitor
14. SD card slot
15. USB port x 2 (downstream;
connecting to USB devices)
16. Quick release button
17. DVI-DL socket
• Above diagram may vary depending on the model.
• Picture may differ from product supplied for your region.
16
17
14
15

9Getting to know your monitor
Connection
The following connection illustrations are for your reference only. For cables that are not
supplied with your product, you can purchase them separately.
For detailed connection methods, see page 11 - 13.
PC/Notebook
SD card(*)
USB peripherals
Colorimeter
*: Requires card reader driver for Windows 8 (8.1) and Windows 10 operating systems. Install the driver from
the supplied DVD.

10 How to assemble your monitor hardware
How to assemble your monitor hardware
• If the computer is turned on you must turn it off before continuing.
Do not plug-in or turn-on the power to the monitor until instructed to do so.
• The following illustrations are for your reference only. Available input and output jacks may vary depending on
the purchased model.
1. Attach the monitor base.
Please be careful to prevent damage to the monitor. Placing the screen surface on an object like a stapler or a
mouse will crack the glass or damage the LCD substrate voiding your warranty. Sliding or scraping the monitor
around on your desk will scratch or damage the monitor surround and controls.
Protect the monitor and screen by clearing a flat open
area on your desk and placing a soft item like the
monitor packaging bag on the desk for padding.
Gently lay the screen face down on a flat clean padded
surface.
Attach the monitor stand to the monitor base as
illustrated. Make sure to align the arrow on the end of
the stand to the one on the monitor base.
Turn the stand clockwise until you cannot go further.
