BenQ LU9915 User manual

LU9915
Digital Projector
Installation Guide
Guide d'installation
Installationsanleitung
Guida all'installazione
Guía de instalación
설치 설명서
安裝指南
安装指南
V1.00
4J.JHG01.001
BenQ_LU9915_Installation Guide.indb 1 2017/10/20 下午 03:47:19

2
English
Table of Contents
Notice..................................................................................................... 3
Ventilation illustration .................................................................................................3
Exhaust vent requirements .........................................................................................3
Voltage switcher ...........................................................................................................4
Product information ............................................................................. 5
Packing contents...........................................................................................................5
Projector specifications................................................................................................5
Terminals.......................................................................................................................6
Remote control.............................................................................................................7
Remote control ID setting...........................................................................................7
Installation ............................................................................................. 8
Lens specifications ........................................................................................................8
Projection table.............................................................................................................9
Lens shift........................................................................................................................11
Installation positioning .................................................................................................12
Dimensions ............................................................................................ 13
Cabinet dimensions ......................................................................................................13
Ceiling mount hole dimensions...................................................................................13
Ceiling mount dimensions (CMG6) ............................................................................14
Optional lens dimensions.............................................................................................15
LED indication....................................................................................... 16
10/20/17
Please visit below website for latest version of User Manual / Installation Guide.
http://business-display.benq.com/
BenQ_LU9915_Installation Guide.indb 2 2017/10/20 下午 03:47:19

3
English
Notice
Ventilation illustration
Air inlet
Air inlet
Air outlet
Exhaust vent requirements
For proper ventilation of the projector, make sure to leave some space around the projector as
shown in the illustration below:
11.8 in / 30 cm
or greater
11.8 in / 30 cm
or greater
R/Pr G/Y B/Pb
HDBaseT / LAN
3D Sync Out
RGB IN
RS-232 USBTRIGGER
HV
Display Port
DVI-D
WIRE
RGB OUT
HDMI
MENU EXIT
POWER INPUT
AUTO
SYNC ASPECT
FOCUS
LENS
SHIFT
ZOOM
SHUTTER
CENTER
LENS
19.7 in / 50 cm
or greater
19.7 in / 50 cm
or greater
BenQ_LU9915_Installation Guide.indb 3 2017/10/20 下午 03:47:19

4
English
R/Pr G/YB/Pb
HDBaseT/ LAN
3DSync Out
RGBIN
RS-232 USBTRIGGER
HV
DisplayPortDVI-D
WIRE
RGBOUT
HDMI
MENU EXIT
POWER INPUT
AUTO
SYNC ASPECT
FOCUS
LENS
SHIFT
ZOOM
SHUTTER
CENTER
LENS
Minimum
19.7 in / 50 cm
Minimum
11.8 in / 30 cm
Minimum
39.3 in / 100 cm
Voltage switcher
Please make sure the Voltage Switch is selected at the right voltage in the region where projector
is being used.
Note:
Default setting is 230V.
BenQ_LU9915_Installation Guide.indb 4 2017/10/20 下午 03:47:19

5
English
Product information
Packing contents
Carefully unpack and verify that you have the items below. Some of the items may not be available
depending on your region of purchase. Please check with your place of purchase.
Projector
without lens Installation guide
Anti-Theft screw Lens hole cap
Power cable
VGA cable Wired remote cable
MENU
EXIT
ENTER
1
4
7
0
89
6
3
5
2
Remote
without AA batteries
Projector specifications
Specifications LU9915
Projection system DLP Single 0.67 WUXGA DMD Chip
Native resolution WUXGA (1920 x 1200)
Brightness 10,000 Lumens
Aspect ratio 16:10
Light source Laser Light Source
Power consumption 1290W@100V, 1215W@240V
Dimensions 583mm (L) x 500mm (W) x 211mm (H)
Weight 28kg / 61.7 lbs (Lens excluded)
Operation Temperature 32ºF to 104ºF (0ºC to 40ºC )
Note:
• Brightness is supplied by standard lens. The value will vary depending on lenses being installed.
• Brightness output will vary depending on each unit and actual usage.
• Please visit the local website from http://www.benq.com for the latest User Manual.
BenQ_LU9915_Installation Guide.indb 5 2017/10/20 下午 03:47:20

6
English
Terminals
3D SYNC OUT
3D SYNC IN
MONITOR OUTCOMPUTER 1
COMPUTER 2
RS-232TRIGGER
WIRED
REMOTE HDBaseT/LANDVI-D DISPLAYPORT IN OUT HDMI
R/PrG/YB/PbHV
3G-SDI
TRIGGER
• HDBaseT/LAN
For connection to RJ45 Cat5/Cat6 Ethernet cable to input uncompressed high-definition video
(HD), control signals.
• 3D Sync Out
Connection to 3D IR sync signal transmitter.
• 3D Sync In
Connection to 3D sync signal input.
• DVI-D
Connection to DVI-D source.
• HDMI
Connection to HDMI source.
• DisplayPort
Connection to device or PC featuring DisplayPort.
• 3G-SDI
Connection to 3G-SDI source.
• Computer 1
15-pin VGA port for connection to RGB, component HD source, or PC.
• Computer 2 (V, H, B/Pb, G/Y, R/Pr)
Connection to RGB or YPbPr/YCbCr output signal with BNC type input terminal.
• Monitor Out
Connection to other display equipment for concurrent playback display.
• RS-232
Standard 9-pin D-sub interface for connection to PC control system and projector maintenance.
• TRIGGER
3.5mm mini earphone jack, employs 350mA display relay to provide 12(+/-1.5)V output and
short circuit protection.
• Wired Remote
Connection to input Niles or Xantech compatible IR repeater system.
Note:
Make sure the port is valid before inserting a wired remote controller. The remote controller may be damaged in
case of an invalid port, e.g. a wired remote controller is connected to trigger output.
BenQ_LU9915_Installation Guide.indb 6 2017/10/20 下午 03:47:20

7
English
Remote control
MENU
EXIT
ENTER
1
4
7
0
89
6
3
5
2
ON OFF
FOCUS +/-
ZOOM +/-
TEST PATTERN
LENS-SHIFT
ENTER
Up
Left
MENU
AUTO PC
COMPUTER 1
HDMI 1
3G-SDI
CLEAR
COMPUTER 2
Right
Down
EXIT
STATUS
BLANK
ASPECT
DVI
HDMI 2
DisplayPort
HDBaseT
ID SET
FREEZE
Numeric buttons
Remote control ID setting
You can set the remote control ID to control the specific projector.
Please set projector ID (from 01 to 99) by using the OSD menus. After setup different ID, the
remote control will only control the matched projector .
Press ID SET + MENU keys together for 5 seconds, the remote control backlight will flash one
time, then into the ID Set mode.
Again click ID SET + MENU keys for 5 seconds (backlight will flash 1 time) to release ID SET
Mode.
After into the ID Set Mode, press ID SET key for 3 seconds.
The remote control LED light will flash and backlight will light. In the meantime, press number to
set the remote control ID.
For example, for setting remote control ID to “01”, please press 0 key for 1 second (LED light
will flash 3 times then back light off), then press 1 key for 1 second (LED light flash 3 times then
backlight off).
For setting remote control ID to “19”, please press 1 key for 1 second, then press 9 key for 1
second.
BenQ_LU9915_Installation Guide.indb 7 2017/10/20 下午 03:47:20

8
English
Installation
Lens specifications
Model
Name Lens Type BenQ Part Number Optical spec Throw Ratio Zoom Ratio Weight*
LS1ST4 Ultra Short
Throw 5J.JCY37.002 F=2.0, f=5.64 mm 0.38:1 Fixed 2,710g
LS1ST3 Wide fix 5J.JAM37.011 F=1.85, f=11.6mm 0.76:1 Fixed 910g
LS1ST2 Ultra Wide 5J.JAM37.061 F=1.96~2.3,
f=11.3~14.1mm 0.75~0.93:1 1.25:1 1,280g
LS1ST1 Wide Zoom 5J.JAM37.021 F=1.85~2.5,
f=18.7~26.5mm 1.25~1.79:1 1.41:1 1,090g
LS1SD Standard 5J.JAM37.001 F=1.7~1.9,
f=26~34mm 1.73~2.27:1 1.3:1 820g
LS1LT1 Semi Long 5J.JAM37.051 F=1.86~2.48,
f=32.9~54.2mm 2.22~3.67:1 1.65:1 950g
LS1LT2 Long Zoom1 5J.JAM37.031 F=1.85~2.41,
f=52.8~79.1mm 3.58~5.38:1 1.5:1 1,020g
LS1LT3 Long Zoom2 5J.JAM37.041 F=1.85~2.48,
f=78.5~121.9mm 5.31~8.26:1 1.55:1 1,350g
Note:
The values listed in the table above are average and may vary by model.
BenQ_LU9915_Installation Guide.indb 8 2017/10/20 下午 03:47:20

9
English
Projection table
Wide Fix Lens, Wide Zoom Lens, STD Lens, Semi Long Zoom1,
Long Zoom 1 Lens, Long Zoom 2 Lens, Ultra Wide Zoom Lens
Distance (A)
Height (B)
Lens center
SCREEN
LU9915
Screen Size 5J.JAM37.011 5J.JAM37.021 5J.JAM37.001 5J.JAM37.051
Wide Fix Lens Wide Zoom Lens STD Lens Semi long Zoom1
Diagonal Width Height (B) Distance (A)
Fixed Wide Tele Wide Tele Wide Tele
(inch) (m) (inch) (m) (inch) (m) (inch) (m) (inch) (m) (inch) (m) (inch) (m) (inch) (m) (inch) (m) (inch) (m)
40 1.02 34 0.86 21 0.54 25.1 0.64 41.4 1.05 59.9 1.52 57.2 1.45 75.8 1.93 73.6 1.87 124.1 3.15
50 1.27 42 1.08 26 0.67 31.8 0.81 52.3 1.33 75.4 1.92 72.1 1.83 95.5 2.42 92.9 2.36 155.9 3.96
60 1.52 51 1.29 32 0.81 38.5 0.98 63.1 1.60 90.9 2.31 87.1 2.21 115.1 2.92 112.1 2.85 187.8 4.77
80 2.03 68 1.72 42 1.08 52.0 1.32 84.9 2.16 121.8 3.09 117.0 2.97 154.3 3.92 150.5 3.82 251.4 6.39
100 2.54 85 2.15 53 1.35 65.5 1.66 106.6 2.71 152.7 3.88 147.0 3.73 193.5 4.92 188.9 4.80 315.0 8.00
120 3.05 102 2.58 64 1.62 78.9 2.01 128.4 3.26 183.6 4.66 176.9 4.49 232.8 5.91 227.6 5.78 378.6 9.62
150 3.81 127 3.23 79 2.02 99.1 2.52 161.0 4.09 230.0 5.84 221.8 5.63 291.6 7.41 285.0 7.24 474.1 12.04
180 4.57 153 3.88 95 2.42 119.3 3.03 193.6 4.92 276.4 7.02 266.7 6.77 350.5 8.90 342.6 8.70 569.5 14.47
200 5.08 170 4.31 106 2.69 132.8 3.37 215.3 5.47 307.3 7.81 296.6 7.53 389.7 9.90 381.0 9.68 633.1 16.08
300 7.62 254 6.46 159 4.04 200.1 5.08 324.0 8.23 461.9 11.73 446.3 11.34 585.9 14.9 573.2 14.56 951.2 24.16
400 10.16 339 8.62 212 5.38 267.4 6.79 432.7 10.99 616.6 15.66 595.9 15.14 782.3 19.87 765.3 19.44 1269.7 32.25
500 12.70 424 10.77 265 6.73 334.8 8.50 541.5 13.75 771.2 19.59 745.6 18.94 978.3 24.85 957.4 24.32 1587.8 40.33
Screen Size 5J.JAM37.031 5J.JAM37.041 5J.JAM37.061
Long Zoom 1 Lens Long zoom 2 Lens Ultra Wide zoom Lens
Diagonal Width Height (B) Distance (A)
Wide Tele Wide Tele Wide Tele
(inch) (m) (inch) (m) (inch) (m) (inch) (m) (inch) (m) (inch) (m) (inch) (m) (inch) (m) (inch) (m)
40 1.02 34 0.86 21 0.54 118.7 3.01 181.0 4.60 173.9 4.42 277.7 7.05 24.5 0.62 31.1 0.79
50 1.27 42 1.08 26 0.67 149.7 3.80 227.6 5.78 220.2 5.59 350.0 8.89 31.1 0.79 39.2 1.00
60 1.52 51 1.29 32 0.81 180.7 4.59 274.1 6.96 266.6 6.77 422.3 10.73 37.6 0.96 47.4 1.20
80 2.03 68 1.72 42 1.08 242.7 6.16 367.3 9.33 359.4 9.13 567.0 14.40 50.8 1.29 63.8 1.62
100 2.54 85 2.15 53 1.35 304.3 7.73 460.4 11.70 452.1 11.48 711.6 18.07 63.9 1.62 80.2 2.04
120 3.05 102 2.58 64 1.62 366.7 9.31 553.6 14.06 544.9 13.84 856.2 21.75 77.1 1.96 96.6 2.45
150 3.81 127 3.23 79 2.02 459.4 11.67 693.3 17.61 684.0 17.37 1073.1 27.26 96.8 2.46 121.1 3.08
180 4.57 153 3.88 95 2.42 552.4 14.03 833.0 21.16 823.1 20.91 1290.1 32.77 116.5 2.96 145.7 3.70
200 5.08 170 4.31 106 2.69 614.7 15.6 926.4 23.53 915.9 23.26 1434.7 36.44 129.7 3.29 162.1 4.12
300 7.62 254 6.46 159 4.04 924.0 23.47 1392.1 35.36 1379.6 35.04 2157.8 54.81 195.4 4.96 244.0 6.20
400 10.16 339 8.62 212 5.38 1233.9 31.34 1857.9 47.19 1843.3 46.82 2880.9 73.18 261.2 6.63 325.9 8.28
500 12.70 424 10.77 265 6.73 1543.7 39.21 2323.6 59.02 2307.1 58.60 3604.0 91.54 326.9 8.30 407.7 10.36
BenQ_LU9915_Installation Guide.indb 9 2017/10/20 下午 03:47:20

10
English
Ultra Short Reflection
120
873
285
216
㻸㻟
L1
L2
H2
H1
Screen
L1: Screen to the point of mirror
L2: Screen to projector front
L3: Screen to project back
H1: Screen bottom to projector top side
H2: Screen bottom to projector bottom
Screen size 5J.JCY37.001
Ultra Short Reflection
Diagonal Width Height H1 H2 L1 L2 L3
inch mm inch mm inch mm inch mm inch mm inch mm inch mm inch mm
100 2540 85 2166 53 1355 19 485 28 701 33 849 22 564 -1 -24
120 3048 102 2599 64 1627 23 596 32 812 39 1000 28 715 5 127
150 3810 128 3247 80 2032 30 763 39 979 48 1227 37 942 14 354
200 5080 170 4330 107 2711 41 1041 49 1257 63 1606 52 1321 29 733
250 6350 213 5415 133 3391 52 1320 60 1536 78 1984 67 1699 44 1111
300 7620 256 6500 160 4071 63 1598 71 1814 93 2362 82 2077 59 1489
350 8890 299 7585 187 4752 74 1877 82 2093 108 2741 97 2456 74 1868
Note:
• For more visualized instructions, please go to BenQ calculator website http://projectorcalculator.benq.com/.
• Precise installation is prefered to be done by professionals. Contact your dealer for more information.
• When UST lens is installed to the projector, it is recommended to loosen the screw on the support kit and make
the arm movable before adjustment.
• The User Manual for UST Lens installation is available from local BenQ website.
BenQ_LU9915_Installation Guide.indb 10 2017/10/20 下午 03:47:20

11
English
Lens shift
Lens shift adjustable range
The adjustable range for lens shift is tabulated below and subject to the conditions listed.
Model Name Lens Type BenQ Part Number Lens Shift Range
LS1ST4 Ultra Short Throw 5J.JCY37.001 -3% ~ +7% Vertical; -5% ~ +5% Horizontal
(Central position at 56.5%)
LS1ST3 Wide fix 5J.JAM37.011 NA
LS1ST2 Ultra Wide 5J.JAM37.061 0 ~ +50% Vertical; -6.7% ~ +6.7% Horizontal
LS1ST1 Wide Zoom 5J.JAM37.021 0 ~ +50% Vertical; -10% ~ +10% Horizontal
LS1SD Standard 5J.JAM37.001 0 ~ +50% Vertical; -10% ~ +10% Horizontal
LS1LT1 Semi Long 5J.JAM37.051 0 ~ +50% Vertical; -10% ~ +10% Horizontal
LS1LT2 Long Zoom1 5J.JAM37.031 0 ~ +50% Vertical; -10% ~ +10% Horizontal
LS1LT3 Long Zoom2 5J.JAM37.041 0 ~ +50% Vertical; -10% ~ +10% Horizontal
Desktop-front projection
Vertical Shift
Max
0.5V
1V
1V
0.1H
Horizontal Shift
to Left
Horizontal Shift
to Right
0.1H
Max
0.5V
Height of projected image
Height of projected image
Width of projected image
1H
Vertical Shift
Ceiling mount-front projection
Vertical Shift area
Note:
The drawings above apply to the standard lens only.
BenQ_LU9915_Installation Guide.indb 11 2017/10/20 下午 03:47:20

12
English
Installation positioning
Ceiling mount installation
Screen Top
H
CX
0.1H
Shift Range
Screen Center
Desktop installation
C
H
0.1H
Shift Range
Screen Center
Note:
• Lens Shift function is not available to LS1ST3 (Fixed Lens). This lens should be used for "zero degree"/"no-offset"
applications. See below:
C
117.4 Screen Center
FOR USE WITH LS1ST3 (FIXED LENS) ONLY
BenQ_LU9915_Installation Guide.indb 12 2017/10/20 下午 03:47:21

13
English
Dimensions
Cabinet dimensions
ADJ. FOOT
AC IN
R SIDECOVER
ADJ. FOOT
L SIDE COVER
AIR IN
547.26
216
582.80
FRONT RING
FRONT COVER
RELEASE BUTTON
AIR IN
300
AIR IN
BASE COVER
28
152.50
300
150
95
100
220
REAR COVER
AIR OUT
MODEL LOGO
TOP COVER
REAR IR WINDOW
FRONT IR
NAME PLATE
LED STATUS
500
Unit: mm
Ceiling mount hole dimensions
100
150
300
152.5
150
6-CEILING MOUNT HOLE
M4*0.7 SCREW L=16 mm (MAX.)
BenQ_LU9915_Installation Guide.indb 13 2017/10/20 下午 03:47:23

14
English
Ceiling mount dimensions (CMG6)
302.5
582.8
633.50 648.50
150
150
300
300
483.60
710.70
483.60
498.60
BenQ_LU9915_Installation Guide.indb 14 2017/10/20 下午 03:47:23

15
English
Optional lens dimensions
872.5
500
582.80
UST LENS
WIDE FIX LENS
610.16
582.80
Optional Lens (UST: LSIST4) Optional Lens (WIDE FIX: LSIST3)
UWZ LENS
639.4
582.80
Optional Lens (UWZ: LSIST2)
WIDE LENS
616.5
582.8
Optional Lens (WIDE: LSIST1)
STD LENS
582.80
590.7
Optional Lens (STD: LSISD)
609.90
582.80
SEMI LONG LENS
Optional Lens (SEMI: LSILT1)
LONG 1 LENS
626.7
582.80
Optional Lens (LONG1: LSILT2)
LONG2 LENS
667.3
582.80
Optional Lens (LONG2: LSILT3)
BenQ_LU9915_Installation Guide.indb 15 2017/10/20 下午 03:47:24

16
English
LED indication
Indicator messages
Several indicator messages are used by the projector to alert users about problems with setup or
system error. The LEDs on top cover of the projector illustrated below.
TEMP LED
LED display Projector status Operation tips
Off Normal status
Flashing Red Over temperature error Contact with your nearest authorized dealer or service
center.
LIGHT SOURCE LED
LED display Projector status Operation tips
Off Light source is off
Flashing
Green Projector is turning on
Red (Cycles of
6) Light source is end-of-life Please call the local service center.
On Red Light source problem Please call the local service center.
Green Light source is on
STATUS LED indicator
LED display Projector status Operation tips
Close Normal
Flashing
Red (once) Safety switch error
Please check whether the top cover is well assembled
or lens is well installed or not. If the problem persists,
call the local service center.
Red
(quadruple) Fan error Call the local service center.
Lights up Red System error Call the local service center.
BenQ_LU9915_Installation Guide.indb 16 2017/10/20 下午 03:47:24

17
English
POWER LED indicator
LED display Projector status Operation tips
Close AC power turned off Check AC power source and power on the projector.
Flashing
Green Ready to power on the
projector Wait until the projector starts projecting.
Orange The projector is cooling
down
Lights up Red Standby mode
To power on the projector, press the ON key on the
remote controller or the Power key on the control
panel.
Green Projector powered on
BenQ_LU9915_Installation Guide.indb 17 2017/10/20 下午 03:47:24

18
Français
Table des matières
Avis ......................................................................................................... 19
Illustration de la ventilation.........................................................................................19
Exigences pour la sortie de la ventilation...................................................................19
Commutateur de tension ............................................................................................20
Informations sur le produit.................................................................. 21
Contenu du colis ...........................................................................................................21
Caractéristiques du projecteur ...................................................................................21
Prises..............................................................................................................................22
Télécommande .............................................................................................................23
Paramètre d’ID de la télécommande.........................................................................23
Installation ............................................................................................. 24
Caractéristiques de l’objectif.......................................................................................24
Table de projection.......................................................................................................25
Décalage de l’objectif ...................................................................................................27
Positionnement de l’installation..................................................................................28
Dimensions ............................................................................................ 29
Dimensions du boîtier ..................................................................................................29
Dimension des trous de montage au plafond ............................................................29
Dimension de montage au plafond (CMG6) ..............................................................30
Dimensions de l’objectif en option..............................................................................31
Indication de la diode............................................................................ 32
10/20/17
Veuillez visiter le site Web ci-dessous la dernière version du Manuel d’utilisation /
Guide d’installation.
http://business-display.benq.com/
BenQ_LU9915_Installation Guide.indb 18 2017/10/20 下午 03:47:24

19
Français
Avis
Illustration de la ventilation
Entrée d’air
Entrée d’air
Sortie d’air
Exigences pour la sortie de la ventilation
Pour une bonne ventilation du projecteur, veillez à laisser un peu d'espace autour du projecteur,
comme indiqué dans l'illustration ci-dessous :
11,8 pouce/30 cm
ou plus
11,8 pouce/30 cm
ou plus
R/Pr G/Y B/Pb
HDBaseT / LAN
3D Sync Out
RGB IN
RS-232 USBTRIGGER
HV
Display Port
DVI-D
WIRE
RGB OUT
HDMI
MENU EXIT
POWER INPUT
AUTO
SYNC ASPECT
FOCUS
LENS
SHIFT
ZOOM
SHUTTER
CENTER
LENS
19,7 pouce/50 cm
ou plus
19,7 pouce/50 cm
ou plus
BenQ_LU9915_Installation Guide.indb 19 2017/10/20 下午 03:47:24

20
Français
R/Pr G/YB/Pb
HDBaseT/ LAN
3DSync Out
RGBIN
RS-232 USBTRIGGER
HV
DisplayPortDVI-D
WIRE
RGBOUT
HDMI
MENU EXIT
POWER INPUT
AUTO
SYNC ASPECT
FOCUS
LENS
SHIFT
ZOOM
SHUTTER
CENTER
LENS
Minimum
19,7 pouce/50 cm
Minimum
11,8 pouce/30 cm
Minimum
39,3 pouce/100 cm
Commutateur de tension
Veuillez vous assurer que le commutateur de tension est réglé sur la bonne tension dans la région
où le projecteur est utilisé.
Remarque :
Le réglage par défaut est de 230 V.
BenQ_LU9915_Installation Guide.indb 20 2017/10/20 下午 03:47:25
