Bentley Designs 4207-90 User manual

Stocknumber: 4207-90
Thankyou for purchasingthis product.Pleasereadtheinstructionscarefullybeforeusetoensuresafeand
satisfactoryoperation ofthis product.
DRESSINGTABLE
Page: 1Page: 1
Pre-assemblypreparation
Pleaseensureinstructionsareread in full beforeattemptingtoassemblethis product.
Pleasecheckthepackcontentsbeforeattemptingtoassemblethis product.A full checklist ofcomponentsis
given in this leaflet.Ifanycomponentsaremissing,pleasecontact theretailerfromwhomyou bought this
product.
This product takesapproximately 30 MINUTES toassemblewith 2 PEOPLE.
All assemblyshould beperformed on aflat,stable,clean and soft surface.
This product is HEAVY,it should beassembled asnearaspossibletothepoint ofuse. TAKECARE
WHENLIFTING toavoid personalinjuryand (or)damagetotheproduct
Thefittingpackcontains SMALL ITEMS which should be KEPTAWAYFROMYOUNGCHILDREN.
IMPORTANT: Retain theseinstructionsforfuturereference.
Necessary Tools: Pozi screwdriver (Included )
Pz2 or Pz3
IW-17-4206-06-9-R1

Page: 2
Fittings and parts checklist
3
21
Item Description Qty.
1Top unit x 1
2Backpanel
3Legframe left x 1
x 1
A
B
x 2
C
"O"ring Grub screw
Ø8 x 8.5mm
E
F
G
x 8
x 2
x 2
x 12
D H x 1
x 4
Allen key
M4 x 30 x 110mm
Felt
Item Description Qty.
4
4Legframeright x 1
IW-17-4206-06-9-R1

Page: 3
Stepbystepassemblyinstructions
1.1:Lay all partsontoaflat,stable,clean and soft surface.
1.2 :Attach 2x steeldowels (A) ontolegframes(3),(4) byscrewingfittings(A)intotheinset
fittingsthat arelocated onparts(3),(4) asshown.Useapozi screwdrivertoturn fittings(A)
clockwisetofix.Ensurethedirection oftheholeson fittings(A)arefacingcorrectlyasper
diagram.
1.3 : Removetheplasticfrom4x felts(B)and stickfelts(B)ontounderofparts(3),(4)asshown.
Step1
Fitting
A x 2
Bx 4Inset fitting A
B
B
Step2 :Insert 8x wooden dowels (C)intothepre-drilled holeson rearbackpanel(2)asshown.
Fitting
Cx 8
3
Step 1.2
2
CC
4
Step 1.3
IW-17-4206-06-9-R1

Page: 4
Stepbystepassemblyinstructions
:Attach 2x cam screws (D)intothepre-drilled holeson top unit (1)asshown.Useapozi
screwdrivertoturn fittings(D)clockwisetofix.
Step3
Step4
Fitting
Dx2
D
1
:Attach legframes(3),(4)tobackpanel(2)asshown.Ensuresteeldowels (A)and wooden
dowels (C)arealigned correctlywith theholesofmatingpartsbeforeattaching.
3
4
2
IW-17-4206-06-9-R1

Page: 5
Stepbystepassemblyinstructions
5.1 :Attach thestructureassembled in Step4 ontotableframe (1) asshown.Ensuresteeldowels
(A),wooden dowels (C)and cam screws (D)arealigned correctlywith theholesofmating
partsbeforeattaching.
5.2 :Secureparts(3),(4)topart (1)using 12x hex head bolts(F) asshown.Useallen key(H)to
turn fittings(F) clockwisetofix.
5.3 :Securepart (2)topart (1)using2x cam locks(G)asshown.Useapozi screwdrivertoturn
fittings(G) clockwisetofix.
5.4 :Secureparts(3),(4)topart (2)using2x grub screws (E)asshown.Useapozi screwdriverto
turn fittings(E)clockwisetofix.
5.5: Stand theunit upright.
Step5
E x 2
Assemply iscomplete
Fitting
Fx 12
Gx 2
Hx 1F
H
Step 5.2
Step 5.3
G
E
Step 5.4
Step 5.1
Step 5.1
Step 5.5
4
3
2
1
IW-17-4206-06-9-R1

REMOVE
VERTICALADJUSTMENT(±2.5mm)
Removedrawerbox
TANDEMRUNNERADJUSTMENT INSTRUCTION
Extend therunner all theway out.
Unlockbypullingtheblack plasticpegon therunnerout.
Holdrunnerswithbothofyour hands.
Carefullyliftthedrawer frontupfrom thefrontmetal pin, thenslideforwardtoremove from back hooks.
Back hook
Frontmetal pin
Page: 6
IW-17-4206-06-9-R1

TANDEMRUNNERADJUSTMENT INSTRUCTION
ASSEMBLE
Once theback hookisconnectedgentlylowerthedrawer
ontothefrontmetal pin.
Extend therunnerall theway out.Putthedrawerontothem thenholdboth
therunnerswithyour hands, lift thedrawerupwithyour thumbsand push
tohookthedrawerattheendoftherunner.
Back hook
Hole/ plasticpeg
Hole/ Frontmetal pin
Lock itbypushing
theblack plasticpegon therunner in.
Black plasticpeg
Page: 7
IW-17-4206-06-9-R1

PLEASE KEEP THESE INSTRUCTIONSFORFUTUREREFERENCE Page:8
CareandMaintenance
WoodFurniture
Wood displaysdifferent grain patternsdependingon which way theyarecut -for example,the'medullaryray' which
can appearon oakfurnitureis amarkofgood qualitytimber-thesearejust characteristicsofthenaturalbeautyof
thewood.
Somefurnitureis also deliberatelyaged and rustic.
Wood veneers also allow distinctivepatternstobecreated on somesurfaces, such astabletopsand drawer
frontsbytheway slivers arearranged.
All timberand veneersurfaceswill changecolourand mellow overtime.Newfurniturewill initiallyvaryin shade
fromitemsthat havebeen previouslypurchased.
How tocarefor yourwoodfurniture
Dust with aclean,damp,lint free cloth.Frequent dustingwill removeabrasivebuild up,which can damagethefinish
overtime.
Donot useaverywet cloth or allow anyliquid tocontact with theveneers for alongperiod oftimeasthis can
permanentlydamagethesurface.Wipeup spills immediately.
Donot useanyabrasivecleaneror harsh detergent asthis can damagethesurfaceofthefurniture.
Spray polishesarebest avoided astheycontain siliconeswhich may spoil thefurniture'ssurfacewhen buildingup
overtime.
Make sureall surfacesareprotected fromheat and liquidsbymatsand coasters.
Ensurethat amat or pad is placed underpaperwhen you arewritingon thefurnituresurface.
Donot placerubber, cork,vinylor plasticmaterials on thewood finish aschemicals within may react with thefinish
ifleft in contact for an extended period oftime.
Ourfurniturewill enduremost temperaturesin thehomebut it is best toavoid placingfurniturenext toheat
sourcessuch asradiators or fires. Beparticularlycarefulwith solid wood asthelackofhumiditycaused byhome
heatingcan causedamagesuch aswarping,crackingor splitting.
Excessiveexposuretosunlight can causefadingofyourfurniture.
Avoid exposingyourfurnituretoanyliquids. All liquidsshould bewiped up immediatelywith asoft,slightlydamp
cloth in thedirection ofthewood grain.If stickyliquid residuesdooccur, theymay beremoved with adilutesolution
ofwarmsoapywaterfollowed byaclean,damp sponge.Theareashouldthen bewiped immediatelyin thedirection
ofthewood grain with aclean,soft whitecloth until completelydry.
Nail polish remover, hairspray,perfume,potpourri &anyotherproductsthat containssolventscan damagewood
upholsteryfinishes.
SafetyInstructions:
Neverdrag furniturewhen movingit.Alwayslift it.
Periodicallycheckall fixingstoensurenonehavecomeloose.Re-tighten when necessary.
Pleasetake carewhen handlingor movingthefurnitureascareless handlingmay causedamageor injury.
Furniturecan bedangerousifincorrectlyassembled.Assemblyshould becarried out byacompetent person.
Noliabilitywill beaccepted for damageor injurycaused byincorrectlyinstalled or assembled furniture.
Heavy itemwarning:
It is recommended toseek assistancewhen movingaheavy object.Take carewhen liftingtoavoid personal
injuryand (or)damagetotheproduct.
It is recommended that beforemovingaheavy object toanewlocation it is completelydis-assembled to
avoid personalinjuryor damagetothefurniture.Pleasebecarefultoretain all fittingswhen doingthis.
Mirror warning:
Useglass cleaneror soapywaterfor cleaning.Donot useanythingabrasiveasthis may damagethesurfaceof
theproduct.
IW-17-4206-06-9-R1
