Bentley Designs OPEN DISPLAY UNIT User manual

Page: 1
Stocknumber: 2003-27
Thankyou for purchasingthisproduct.Pleaseread theinstructionscarefullybeforeusetoensuresafeand
satisfactoryoperation ofthis product.
Pleasecheckthepackcontentsbeforeattemptingtoassemblethis product.A full checklist ofcomponentsis
given in thisleaflet.Ifanycomponentsaremissing,pleasecontact theretailerfromwhomyou bought this
product.
This product takesapproximately 30 MINUTES toassemblewith 2PEOPLE.
All assemblyshould beperformed on aflat,stable,clean and soft surface.
This product is HEAVY,it should beassembled asnearaspossibletothepoint ofuse. TAKECARE
WHENLIFTING toavoid personalinjuryand (or)damagetotheproduct
Thefittingpackcontains SMALL ITEMS which should be KEPTAWAYFROMYOUNGCHILDREN.
IMPORTANT: Retain theseinstructionsforfuturereference.
Pre-assemblypreparation
Pleaseensureinstructionsareread in full beforeattemptingtoassemblethis product.
IW-17-2003-29-5-R2
Necessary Tools:Necessary Tools:
OPENDISPLAYUNIT
(Included)

x 1
x 1
x 1
Page :2
1x 1
Metallegframeleft
C
Fittings and parts checklist
Ax 10
Item Description Qty. Item Description Qty.
5
Fixed shelfB
DB x 15
Longhex head bolt
2
3
4
6
7
8
x 32
x 1
Allen key
Fixed shelfA
x 1
x 1
x 1
1
2
7
65
43
8x5
Metallegframeright
Fixed shelfC
Fixed shelfD
Fixed shelfE
Fixed shelfrail back x 5
x 1
x 1
x 1
Wooden dowel Short hex head bolt
IW-17-2003-29-5-R2

Page :3
Fitting
A x 10
StepByStepAssemblyInstructions
Step11.1 :Lay all partson aflat,stable,clean and soft surface.
1.2 :Insert 10x wooden dowels (A)intothepre-drilled holeson fixed shelfA (3)&fixed
shelfB(4),fixed shelfC(5),fixed shelfD(6),fixed shelfE (7)asshown.
3
4
6
A
5
7
IW-17-2003-29-5-R2

Page :4
Fitting
Bx 15
StepByStepAssemblyInstructions
Step22.1 :Attach fixed shelfrail back(8)ontofixed shelfA (3),fixed shelfB(4),fixed shelfC(5),
fixed shelfD(6),fixed shelfE (7)asshown.Ensurewooden dowels (A)arealigned
correctlywith theholesofmatingpartsbeforeattaching.
2.2 :Secureparts(8)topart (4),(5),(6),(7)using 15x longhex head bolts(B)asshown.
Useallen key(D)toturn fittings(B)clockwisetofix.
3
4
6
7
5
8
8
8
8
8
B
D
Dx 1
Step 2.1
Step 2.1
Step 2.1
Step 2.1
Step 2.1
Step 2.2
IW-17-2003-29-5-R2

Page :5
Fitting
Cx 16
StepByStepAssemblyInstructions
Step33.1 :Attach thestructureassembled in Step 2ontometallegframeright (2)asshown.
3.2 :Secureparts(3),(4),(5),(6),(7)topart (2)using 6x short hex head bolts(C)asshown.
Useallen key(D)toturn fittings(C)clockwisetofix.
3.3 :Secureparts(8)topart (2)using 10x short hex head bolts(C)asshown.Useallen key(D)
toturn fittings(C)clockwisetofix
Dx 1
7
6
5
4
3
C
C
D
Step 3.1
Step 3.1
Step 3.1
Step 3.1
Step 3.1
2
Step 3.3
8
8
8
8
8
Step 3.2
C
D
Step 3.2
C
D
C
Step 3.2
IW-17-2003-29-5-R2

Page :6
Fitting
Cx 16
StepByStepAssemblyInstructions
Step44.1 :Attach metallegframeleft (1)ontothestructureassembled in Step 3asshown.
4.2 :Securepart (1)toparts(3),(4),(5),(6),(7)using 6x short hex head bolts(C)asshown.
Useallen key(D)toturn fittings(C)clockwisetofix.
4.3 :Securepart (1)toparts(8) using 10x short hex head bolts(C)asshown.Useallen key(D)
toturn fittings(C)clockwisetofix
Dx 1
C
D
Step 4.1
7
6
5
4
3
1
Step 4.3
8
8
8
8
8
C
D
Step 4.2
Step 4.2
D
C
IW-17-2003-29-5-R2

Page :7
StepByStepAssemblyInstructions
Step5Stand theunit upright.
Assembly iscomplete
IW-17-2003-29-5-R2

Page: 8
PLEASE KEEP THESE INSTRUCTIONSFORFUTUREREFERENCE
Howtocareforyourwoodfurniture
Dustwith a clean,damp,lintfree cloth.Frequentdusting will remove abrasive buildup,which can damage the
finish overtime.
Do notuse a verywetcloth orallowanyliquid to contactwith the veneersfora long period oftime as this can
permanentlydamage the surface.Wipe up spillsimmediately.
Do notuse anyabrasive cleanerorharsh detergentasthiscan damage the surface ofthe furniture.
Spraypolishesare bestavoided astheycontain siliconeswhich mayspoil the furniture's surface when building up
overtime.
Make sure all surfacesare protected fromheatand liquids by mats and coasters.
Ensure thata matorpad isplacedunderpaperwhen you are writing on the furniture surface.
Do notplace rubber,cork,vinylorplasticmaterialson the wood finish as chemicals within may reactwith the
finish if leftin contactforan extended period oftime.
Ourfurniture will endure mosttemperaturesin the home butitisbest toavoidplacing furniture nexttoheat
sourcessuch asradiators orfires.Be particularlycarefulwith solid wood asthe lackofhumidity causedby home
heating can cause damage such aswarping,cracking orsplitting.
Excessive exposure to sunlightcan cause fading ofyourfurniture.
Avoid exposing yourfurniture to anyliquids.All liquidsshould be wiped up immediately with a soft,slightly
damp cloth in the direction ofthe wood grain.If stickyliquid residuesdo occur,they may be removedwith a
dilute solution ofwarmsoapywaterfollowed bya clean,damp sponge.The area shouldthen be wiped
immediatelyin the direction ofthe wood grain with a clean,softwhite cloth until completely dry.
Nail polish remover,hairspray,perfume,potpourri&anyotherproducts thatcontains solvents can damage
wood upholsteryfinishes.
SafetyInstructions:
Neverdrag furniturewhen moving it.Always liftit.
Periodicallycheckall fixings toensurenone have comeloose.Re-tighten whennecessary.
Please take carewhen handlingormovingthe furnitureas careless handling may causedamage orinjury.
Furniturecanbe dangerousif incorrectlyassembled. Assemblyshould be carried outby a competentperson.
Noliabilitywill be accepted fordamage orinjurycaused byincorrectly installed orassembled furniture.
Heavyitemwarning:
Itisrecommended toseek assistancewhenmoving aheavy object.Take carewhen liftingtoavoid personal
injuryand (or)damage tothe product.
Itisrecommended thatbeforemovingaheavy objecttoa newlocation itis completelydis-assembled to
avoid personalinjuryordamage tothe furniture.Please be careful toretain all fittings when doing this.
Care and Maintenance
WoodFurniture
Wood displaysdifferentgrain patternsdependingon whichway theyarecut-forexample, the 'medullary ray'
whichcanappearon oak furnitureisamarkof good qualitytimber-thesearejustcharacteristics of the natural
beautyof thewood.
Somefurnitureisalsodeliberately aged and rustic.
Wood veneersalsoallowdistinctivepatterns tobe created onsomesurfaces,suchas table tops and drawer
frontsbytheway slivers arearranged.
Alltimberand veneersurfaceswill change colourand mellowovertime.Newfurniturewill initially vary in shade
fromitemsthathave been previously purchased.
