Bentone BF1 Series Technical specifications

Providing sustainable energy solutions worldwide
178 135 35-1 2019-08–15
Installation- and maintenance instruction
BF1

example Beispielexempel
Manuels dans d'autres langues.
www.bentone.com\download
ou scannez le code QR
Saisir le numéro d'article du brûleur
sur votre plaque signalétique (consultez l'illustration)
et sélectionnez la langue.

3Bentone BF1
General
Table of contents
GENERAL
1. General Information_____________________________________________________4
Burner servicing schedule ___________________________________________6
Component replacement intervals________________________________6
Delivery check____________________________________________________________6
2. Technical data _____________________________________________________________7
1.1 Dimensions BF1_______________________________________________________7
2.1.1 Dimensions, flanges_______________________________________7
2.1 Model BF1 FU/FUV 63-16_________________________________________8
2.1.1 Burner output/ Basic settings_________________________8
2.1.2 Electric Specification______________________________________8
2.2 Model BF1 KS/KSV 76-24 ________________________________________9
2.2.1 Burner output/ Basic settings_________________________9
2.3 Model BF1 M1V 87-20 ___________________________________________10
2.3.1 Burner output _____________________________________________10
2.4 Model BF1 N1V 56-14/BF1 N1 56-14 ______________________11
2.4.1 Burner output _____________________________________________11
2.5 Modell BF1 NU1V 60-14_________________________________________12
2.5.1 Burner output _____________________________________________12
2.5.2 Basic settings ____________________________________________12
2.6 Modell BF1 R 69-16/BF1 RV 69-16 _________________________13
2.6.1 Burner output _____________________________________________13
2.6.2 Basic settings ____________________________________________13
2.7 Recommended nozzles and pressures _____________________ 14
2.8 Nozzle table, 8-15 bar ____________________________________________14
2.8.1 Burner with preheater __________________________________14
2.9 Description____________________________________________________________15
2.9.1 Components_______________________________________________16
3. Installation ________________________________________________________________17
3.1 Delivery checks______________________________________________________17
3.2 Preparations for installation _____________________________________17
3.3 Oil supply ______________________________________________________________17
3.4 Electrical connection_______________________________________________17
3.5 Choice of nozzle ____________________________________________________17
3.6 Brake plate and airflow setting_________________________________17
3.7 Burner installation___________________________________________________ 18
3.7.1 Hole pattern________________________________________________ 18
3.7.2 Burner installation________________________________________ 18
3.7.3 Oil pipes_____________________________________________________18
3.7.4 Electrical connection____________________________________18
4. Basic settings ___________________________________________________________ 19
4.1 Example of basic setting _________________________________________ 19
4.1.1 Choice of nozzle__________________________________________ 19
4.1.2 Basic setting_______________________________________________19
4.1.3 Nozzle assembly adjustment ________________________20
4.1.4 Air intake adjustment ___________________________________20
4.1.5 Method of adjusting air quantity ____________________ 20
4.1.6 Inlet cone, air adjustment _____________________________ 20
4.1.7 Air intake rotation ________________________________________ 21
4.1.8 Air duct ______________________________________________________21
5. Burner servicing ________________________________________________________ 22
5.1 Warning ________________________________________________________________22
5.1.1 Service position___________________________________________ 22
5.1.2 Combustion assembly service ______________________23
5.1.3 Preheater replacement_________________________________24
5.1.4 Oil pump replacement__________________________________24
5.1.5 Fan motor replacement________________________________25
5.1.6 Air intake and intake cone service _________________ 26
5.1.7 Fan wheel checks________________________________________26
5.1.8 Electrical module_________________________________________ 28
6. Instructions Pump ____________________________________________________30
6.1 SUNTEC AS _________________________________________________________30
6.1.1 Suction line tables _______________________________________32
6.1.3 Check oil line seals ______________________________________ 34
6.1.2 Replacement of pump filter___________________________ 34
6.1.4 Replacing the solenoid valve (pump)______________ 35
6.1.5 Replacing the gasket seal (pump)__________________ 35
6.2 Danfoss BFP 11 and BFP 21___________________________________36
6.2.1 Technical data_____________________________________________ 36
6.2.2 Components_______________________________________________36
6.2.3 Filter replacement BFP 11 ____________________________ 36
6.2.4 Filter replacement BFP 21 ____________________________ 36
6.2.5 Function BFP 11 and BFP 21 _______________________37
6.2.6 LE-S System______________________________________________ 38
6.2.7 Purging ______________________________________________________38
6.2.8 Suction pipe tables BFP11 and BFP21 __________ 39
7. Preheater __________________________________________________________________40
7.2.1 Function FPHE 5 _________________________________________ 40
7.2.2 Function FPHE 5-LE ____________________________________ 40
8. Replacement of electrical components______________________41
9. Electrical equipment LMO1..2..4.. ______________________________ 42
9.1 Wiring diagram ______________________________________________________ 42
9.1.1 Component list____________________________________________43
9.1.2 Function LMO1..2..4..__________________________________ 43
9.1.3 Technical data_____________________________________________ 44
9.1.4 Colour codes LMO14/24______________________________45
9.1.5 Fault codes LMO14/24 ________________________________ 45
10. Fault Location ___________________________________________________________ 46
10.1 Burner will not start ________________________________________________ 46
10.2 Burner will not start after normal use ________________________46
10.3 Delayed ignition______________________________________________________47
10.4 Noise in pump _______________________________________________________47
10.5 Pump pressure ______________________________________________________ 47
11. Log of flue gas analysis _____________________________________________ 48
12. Oil burners maintenance instructions ________________________ 49
13. DECLARATION OF CONFORMITY _____________________________ 50

4Bentone BF1
General
1. General Information
This Installation and Maintenance manual:
• is to be regarded as part of the burner and must always be kept near
the installation site
• is intended for use by authorised personnel
• must be read prior to installation
• must be observed by all who work with the burner and associated
system components
• work with the burner may only be carried out by certified installers/
personnel
• Enertech AB is not liable for any typographical errors and reserves the
right to make design changes without prior notice.
• The burner may only be used for its intended purpose in accordance
with the product’s technical data.
• The burner may only be installed and operated by authorised
personnel.
• The product is packaged to prevent damage from occurring during
handling. Handle the product with care. Lifting equipment must be
used to lift larger packages.
• The products must be transported/stored on a level surface in a dry
environment, max. 80% relative humidity, no condensation.
Temperature -20 to +60 °C.
• Check that the burner is compatible with the boiler’s output range.
• The label information on the rating plate refers to the burner’s minimum
and maximum power.
• The power data on the type sign refers to the burner’s min. and max.
power.
• All components must be installed without being bent, twisted or
subjected to mechanical or thermal forces which can affect the
components.
• The burner must be installed so that it complies with local regulations
for fire safety, electrical safety, and fuel distribution.
• Make sure when installing the equipment that there is enough space to
service the burner.
• Permitted ambient temperature during operation -0 to +60 °C. Max
80% relative humidity, no condensation.
• The installer must ensure that the room has adequate air supply.
• The room must comply with local regulations pertaining to its intended
use.
• The installation site must be free of chemicals.
165 105 01

5Bentone BF1
General
• Burner pipes, fan wheels and air dampers may contain sharp edges.
• The surface temperature of the burner’s components can exceed 60 °C.
• Caution: The burner has moving parts, and there is risk of crushing
injuries.
• The electrical installation must be professionally carried out in
accordance with applicable high voltage regulations, as per Enertech’s
recommendations.
• Before servicing, shut off the fuel supply and turn off the power to the
burner.
• Leak checks must be performed during installation and servicing to
prevent fuel leakage.
• Care should be taken by the installer to ensure that no electrical cables
or fuel lines are crushed or otherwise damaged during installation or
servicing.
• If the boiler is equipped with an access hatch, this must be equipped
with a hatch opening switch connected to the burner's safety system.
• When in operation, the burner’s noise level can exceed 85 dBA.
Use hearing protection.
• The burner must not be put into operation without proper safety and
protection devices.
• A Class BE fire extinguisher is recommended.
• It is forbidden to alter thedesign or use accessories which have not
been approved by Enertech in writing.
• Prior to operation, the following points must be checked:
-fitting and installation work has been completed and approved
-electrical installation has been correctly performed
-flue gas ducts and combustion air ducts are not blocked
-all actuators and control and safety devices are in working order and
correctly set

6Bentone BF1
General
Detailed ecodesign information can be downloaded at:
www.bentone.com/ecodesign
Components Service life – Recommended
replacement
Service life – Recommended
replacement Operating cycles
Control system 10 years 250,000 cycles
Pressure switch 10 years 250,000 cycles
Flame guard 10 years 250,000 cycles
UV flame sensor 10000 hrs N/A
Damper motor 500 000 cycles
Contaktor 10 years 500,000 cycles
Burner 1 year 3000 hrs
Filter 1 year 3000 h Change
Oilhose 1 year control/change
Nozzle 1 year change 3000h Change
Electrods 1 Year Change /cleaning 3000h Change /cleaning
Brake plate 1 Year Change /cleaning 3000h Change /cleaning
Motor 1 year 3000 hrs
Cuppling chaft 1 year control/change 3000h control/change
Fan wheel “1 Year Change when dirty /
unbalance”
“3000h Change when dirty /
unbalance”
The burner and its components must be recycled according to applicable regulations.
Burner servicing schedule
Servicing must be carried out once a year or after 3000 hours of operation
Component replacement intervals
Delivery check
• Make sure everything is delivered and the goods have not been
damaged during transit.
• If something is wrong with a delivery, report it to the supplier.
• Transport damage must be reported to the shipping company.

7Bentone BF1
General
ø89
172
B
190
226
278
145
1.1 Dimensions BF1
2. Technical data
The burner is intended for:
• Light oil, B10 heating oil/biofuel blend (as defined in DIN V51603-6)
and is used for:
• Water heating generators
• Hot air generators (these require LMO 24 255 C2E)
2.1.1 Dimensions, flanges
Flange 2
10,3
25
130–150
ø89,7
Flange 1
125–150
ø90 5
10,3
Type Motor Complete
burner
Complete
burner with
Preheater
Sound
BF1 110W 0,9A 230V
50/60Hz 4µF 230V 1,0A 50Hz 230V 1,2A 50Hz 70dBA ± 0,5
dBA
2.1.2 Electric Specification
Burner correspond to IP 20

8Bentone BF1
General
ø63
ø67
ø16
7,0–8,0
1,6–2,0 (-0,1)+0,5
-0,5
0,0
0,5
1,0
1,5
2,0
2,5
3,0
3,5
4,0
10 15 20 25 30 35 40 45 50 55 60
Burner output, kW
Boiler overpressure, mbar
0,0
2,0
4,0
6,0
8,0
10,0
12,0
14,0
16,0
18,0
20,0
22,0
15 20 25 30 35 40 45 50 55
Burner output, kW
Scale
Air settings
Nozzle assembly
!Scale value applies to 0 mbar furnace pressure.
2.1 Model BF1 FU/FUV 63-16
2.1.1 Burner output/ Basic settings
1,3 - 4,6 kg/h
15 - 55 kW
Length of blast tube
Protrusion from flange,
measurement B
Flange
1 2
102 85 69
132 115 99

9Bentone BF1
General
Length of blast tube
Protrusion from flange,
measurement B
Flange
1 2
147 130 114
224 207 191
!Scale value applies to 0 mbar furnace pressure.
ø73
ø24
ø76
10,0-11,0
2,3-3,1 0,5-1,5
Burner output, kW
Boiler overpressure, mbar
-0,5
0,0
0,5
1,0
1,5
2,0
2,5
3,0
3,5
4,0
30 35 40 45 50 55 60 65 70 75 80 85 90 95
0,0
2,0
4,0
6,0
8,0
10,0
12,0
14,0
16,0
18,0
20,0
22,0
35 40 45 50 55 60 65 70 75 80 85 90
Burner output, kW
Scale
Air settings
Nozzle assembly
2.2 Model BF1 KS/KSV 76-24
2.2.1 Burner output/ Basic settings
3,0 - 7,6 kg/h
35 - 90 kW

10 Bentone BF1
General
ø87
2.3 Model BF1 M1V 87-20
2.3.1 Burner output
0,9 - 2,2 kg/h
11 - 25 kW
Boiler overpressure, mbar
Burner output, kW
3-4


14-16
19-21
ø20
Length of blast tube Protrusion from flange, measurement B
Flange
1 2
247 230 214
!Scale value applies to 0 mbar furnace pressure.
-0,5
0,0
0,5
1,0
1,5
2,0
10 15 20 25 30

11Bentone BF1
General
2.4 Model BF1 N1V 56-14/BF1 N1 56-14
2.4.1 Burner output
1,3 - 5,1 kg/h
15 - 60 kW
ø56
5,5–6,5
2,0–3,0 -05–0,5
ø61,5
ø14
-0,5
0,0
0,5
1,0
1,5
2,0
2,5
3,0
3,5
10 15 20 25 30 35 40 45 50 55 60 65
Boiler overpressure, mbar
Burner output, kW
!Scale value applies to 0 mbar furnace pressure.
Length of blast tube Protrusion from flange, measurement B
Flange
1 2
131 114 98

12 Bentone BF1
General
2.5 Modell BF1 NU1V 60-14
ø60
ø61,5
ø14
5,5–6,5
2,0–3,0 -0,5–0,5
Length of blast tube Protrusion from flange, measurement B
Flange
1 2
131 114 98
181 164 148
0,0
2,0
4,0
6,0
8,0
1
0,0
1
2,0
1
4,0
1
6,0
1
8,0
2
0,0
2
2,0
15 20 25 30 35 40 45 50 55 60
2.5.1 Burner output
1,3 - 5,5 kg/h
15 - 65 kW
-0,5
0,0
0,5
1,0
1,5
2,0
2,5
3,0
3,5
4,0
10 15 20 25 30 35 40 45 50 55 60 65 70
Boiler overpressure, mbar
Burner output, kW
Air settings
Nozzle assembly
Scale
2.5.2 Basic settings
Nozzle assembly
Air settings
Air settings
!Scale value applies to 0 mbar furnace pressure.

13Bentone BF1
General
ø89
!Scale value applies to 0 mbar furnace pressure.
2.6 Modell BF1 R 69-16/BF1 RV 69-16
6,0–7,0
1,8–2,2 1,2–1,6
ø72,8
ø16
2.6.1 Burner output
1,3 - 5,5 kg/h
15 - 65 kW
-0,5
0,0
0,5
1,0
1,5
2,0
2,5
3,0
3,5
4,0
10 15 20 25 30 35 40 45 50 55 60 65 70
0,0
2,0
4,0
6,0
8,0
10 ,0
12 ,0
14 ,0
16 ,0
18 ,0
20 ,0
22 ,0
15 2 0 25 3 0 3 5 40 4 5 5 0 5 5 6 0 6 5
Boiler overpressure, mbar
Burner output, kW Burner output, kW
2.6.2 Basic settings
Nozzle assembly
Air settings
Scale
Length of blast tube Protrusion from flange, measurement B
Flange
1 2
131 114 98

14 Bentone BF1
General
2.7 Recommended nozzles and pressures
Because of the different types of boiler in existence, with varying furnace
geometries and furnace loads, it is not possible to commit to any given spray
angle or spay pattern. Note that spray angles and spray patterns change
with pump pressures.
Nozzle 60° Solid/Hollow cone
80° Solid/Hollow conel
Pump pressure 10 bar (8–14 bar) Fuel oil 1
10 bar (7–12 bar) Kerosene
2.8 Nozzle table, 8-15 bar
Pump pressure, bar
Gph 8 9 10 11 12 13 14 15
kg/h kW kg/h kW kg/h kW kg/h kW kg/h kW kg/h kW kg/h kW kg/h kW
0,40 1,33 16 1,41 17 1,49 18 1,56 18 1,63 19 1,70 20 1,76 21 1,82 21
0,50 1,66 20 1,76 21 1,86 22 1,95 23 2,04 24 2,12 25 2,20 26 2,28 27
0,60 2,00 24 2,12 25 2,23 26 2,34 28 2,45 29 2,55 30 2,64 31 2,73 32
0,65 2,16 26 2,29 27 2,42 29 2,54 30 2,65 31 2,75 33 2,86 34 2,96 35
0,75 2,49 29 2,65 31 2,79 33 2,93 35 3,08 36 3,18 38 3,30 39 3,42 40
0,85 2,83 33 3,00 36 3,16 37 3,32 39 3,47 41 3,61 43 3,74 44 3,87 46
1,00 3,33 39 3,53 42 3,72 44 3,90 46 4,08 48 4,24 50 4,40 52 4,56 54
1,10 3,66 43 3,88 46 4,09 48 4,29 51 4,48 53 4,67 55 4,84 57 5,01 59
1,20 3,99 47 4,24 50 4,47 53 4,68 55 4,89 58 5,09 60 5,29 63 5,47 65
1,25 4,16 49 4,40 52 4,65 55 4,88 58 5,10 60 5,30 63 5,51 65 5,70 68
1,35 4,49 53 4,76 56 5,02 59 5,27 62 5,50 65 5,73 68 5,95 70 6,15 73
1,50 4,98 59 5,29 63 5,58 66 5,85 69 6,11 72 6,36 75 6,60 78 6,83 81
1,65 5,49 65 5,82 69 6,14 73 6,44 76 6,73 80 7,00 83 7,27 86 7,52 89
1,75 5,82 69 6,18 73 6,51 77 6,83 81 7,14 85 7,42 88 7,71 91 7,97 94
2,00 6,65 79 7,06 84 7,45 88 7,81 93 8,18 97 8,49 101 8,81 104 9,12 108
2,25 7,49 89 7,94 94 8,38 99 8,78 104 9,18 109 9,55 113 9,91 117 10,26 122
The table applies to oils with a viscosity of 4.4 mm2/s (cSt) at a density of 830 kg/m3.
2.8.1 Burner with preheater
Allow for a reduction in oil quantity of 5–20% with preheating owing to:
• Temperature increases at the nozzle.
• Nozzle design.
• Capacity (the higher the capacity the lower the difference).

15Bentone BF1
General
23 4
7
1
10
5
6
8
9
17
7
6
53
18
20
19
23 21
24 22
16
2.9 Description

16 Bentone BF1
General
211 12 1
10
15
14
13 5
2.9.1 Components
1. Brake plate
2. Nozzle
3. Fan housing, front
4. Ignition transformer
5. Separating screw
6. Oil burner control
7. Electrical contact X1 (refer to wiring diagram)
8. Motor
9. Capacitor
10. Preheater, where fitted
11. Ignition electrode
12. Ignition cable
13. Photoresistor
14. Inspection glass
15. Nozzle assembly adjustment
16. Cover plate
17. Blast tube
18. Grid
19. Solenoid valve
20. Oil pump
21. Air regulator
22. Air intake
23. Air flow indicator
24. Fan housing, rear

17Bentone BF1
General
3. Installation
3.1 Delivery checks
Check that everything has been delivered and that the goods are not
transport damaged. Any delivery faults must be reported to the supplier.
Transport damage must be reported to the forwarder.
3.2 Preparations for installation
Check that the burner’s measurements and capacity range is suitable for
the boiler in question. The power information on the data plate refers to the
burner’s max. and min. power.
3.3 Oil supply
In order to achieve good operational reliability it is important that the oil
supply system is laid out correctly.
Observe the following:
• Choice of pipe diameters, pipe lengths and height differences (refer to
pump instructions).
• Piping should be run with a minimum of joints/compression fittings.
• Pipework must be laid out so that oil hoses are not subjected to
tension or overbending when the burner is swung out or removed for
service.
• The oil filter should be installed so that the filter cartridge can easily be
replaced
3.4 Electrical connection
Before electrical installation is begun, electricity must be switched off at
the main switch. If the boiler has a 7-pole or a 4-pole Eurostecker (only on
2-stage burners), these often fit directly to the burner. Otherwise use the
connectors supplied. The operating thermostat, the max. thermostat and the
inspection hatch (where fitted) interlock can then be wired in series on the
incoming phase connected to L1 or connected between T1 and T2. In the
first mentioned case a jumper is installed between T1 and T2.
(Refer to connection in the section Electrical equipment).
3.5 Choice of nozzle
(Technical data): Recommended nozzle and nozzle table.
3.6 Brake plate and airflow setting
Before operations basic burner setting may be made according to the
diagram. (Refer to basic settings). Note that this only refers to the basic
setting; the setting must be adjusted after the burner has been started.
At this time flue gas analysis and soot measurement must be carried out.
!If any electrical connection is used other than that recommended
by Enertech, there may be a risk of equipment damage and personal injury.

18 Bentone BF1
General
E
Return Inlet
E
X1
X2
3.7 Burner installation
3.7.1 Hole pattern
Check that the hole pattern matches the flange supplied.
(Refer to Technical data.)
3.7.2 Burner installation
1. Install the flange and the gasket on the boiler.
2. Attach the front piece to the flange.
3. Insulate between the burner register and the boiler cover for reduced
heat radiation.
4. Install the selected nozzle. (Refer to Technical data.)
5. Install the brake plate and check the ignition electrodes (refer to Burner
service.).
6. Install the burner body to the front piece and lock with screw (E).
3.7.3 Oil pipes
1. Check the oil pipe dimensions. (Refer to Pump Instructions.)
2. The oil filter should be installed in the oil supply line. If an air separator is
fitted, the oil filter should be installed before the air filter to increase the
life span of the filter.
3. For one-pipe systems the return plug must be removed. (Refer to
Pump Instructions.)
4. When installing oil hoses, check that the supply and return hoses are
connected to the correct connections on the oil pump. The hoses
must be run so that they are not bent or tensioned.
5. Purge the oil system. The oil pump will be damaged if it is run dry.
6. The vacuum should not be lower than 0.3 bar depression in the suction
line at start up.
3.7.4 Electrical connection
If the boiler lacks ready-connected plugs, connect using the supplied plug,
X2 in accordance with the wiring diagram.
1. Disconnect the power at the main switch.
2. Wire the Eurostecker X2 as in alt. 1–3 (refer to Electrical equipment).
3. Connect the Eurostecker X2 to the burner.
4. Switch on the power at the main switch.

19Bentone BF1
General
4. Basic settings
4.1 Example of basic setting
4.1.1 Choice of nozzle
BF1 FU 63-16
Burner output 30 kW
Estimated nozzle output: 30 / 11,86* = 2,53 kg/h
Choice of nozzle according to table. (Refer to Technical data.)
According to the nozzle table, the following nozzle is indicated:
Nozzle: 0,65 Gph
Pump pressure: 11,0 bar
BF1 FU 63-16/FUV 63-16
Burner output 30 kW
Because of preheater, output is adjusted upward for choice of nozzle
according to table.
Estimated nozzle output: 30 x 1,06 = 31,8 kW
31,8 / 11,86* = 2,68 kg/h
Choice of nozzle according to table. (Refer to Technical data).
According to the nozzle table, the following nozzle is indicate
Nozzle: 0,75 Gph
Pump pressure: 9,5 bar
* Calorfic value Light oil = 11,86 kWh/kg
4.1.2 Basic setting
Setting values for 30 kW according to basic settings tables.
(Refer to Technical data FU 63-16).
Air setting = 11,0
Insert setting = 4,0

20 Bentone BF1
General
Ι
Π
M
4.1.3 Nozzle assembly adjustment
The burner is fitted with a regulator which changes the brake plate position
in the blast tube. This is used to set the correct pressure drop across the
combustion assembly and thereby achieve good combustion without
pulsation.
The setting to be chosen is dependent among other things on set output
and furnace pressure.
Brake plate setting
• Less diffusion: turn screw to left.
• More diffusion: turn to right.
Setting brake plate position affects air flow. It is therefore always
necessary to adjust the air with the burner air regulator afterwards.
4.1.4 Air intake adjustment
Air settings are very important for achieving good combustion with neither
too much, nor too little, air. Adjustment of combustion airflow is carried out
by turning the air regulator with an Allen key. How far open the air regulator
must be is determined by output, furnace pressure and other burner settings
such as blast tube position.
4.1.5 Method of adjusting air quantity
Setting the air regulator is dependent on how the screw (with which air
regulation is adjusted) is installed. If the air intake is installed underneath
as shown in illustration Ι, turning the screw clockwise will reduce airflow,
and anticlockwise increase it. If the air intake is installed on top as shown
in illustration Π, clockwise adjustment increases airflow, and anticlockwise
reduces it.
4.1.6 Inlet cone, air adjustment
Airflow is also affected by the position of the inlet cone. However, it is
extremely rare that this needs to be adjusted; it should be left in the
standard STD position to achieve good starts and operations. (A cast-in
arrow on the fan housing indicates the position of the inlet cone. In addition
to the scale on the inlet cone casting, there is also a mark (M) indicating the
factory setting.)
