BERGHOF B-PRIMIS ET-PRIME ET2115WUX CS Instruction Manual

USER HANDBOOK 1.2
B-PRIMIS DC/ET PRIME 2110W X C,
2115WUX C

Copyright © Berghof Automation GmbH
Reproduction and duplication of this document and utilisation and communication of its content is pro-
hibited unless with our express permission. All rights reserved.
Infringements will result in compensation for damages.
Legal disclaimer
The content of this document has been verified for conformity with the hardware and software de-
scribed therein. It is, however, impossible to rule out all variations. As a result, we cannot be held re-
sponsible if the content is not fully compliant. The information given in this document is updated regu-
larly and any corrections will be reflected in future versions. We are always willing to receive sugges-
tions for improvements. Subject to technical modifications.
Trademarks
CANtrol®// is a registered trademark belonging to Berghof Automationstechnik GmbH.
Microsoft®, Windows® and the Windows® logo are registered trademarks belonging to the Mi-
crosoft Corp. in the USA and in other countries.
EtherCAT® is a registered trademark and patented technology licensed from Beckhoff Automa-
tion GmbH, Germany.
CiA® and CANopen® are registered trademarks belonging to CAN in Automation e. V.
ARM ® and Cortex ® are registered trademarks belonging to ARM Limited.
PROFINET® is a registered trademark belonging to PROFIBUS Nutzerorganisation e. V.
Modbus® is a registered trademark belonging to the Modbus-IDA Organisation.
i.MX6 is a registered trademark belonging to Freescale.
The rights of all companies and company names as well as products and product names mentioned in
this website belong to the respective companies.
Notes on this handbook
This device handbook contains information which is specific to the product and which is valid at the
time of printing.
This equipment manual is only complete in conjunction with the product-related hardware and software
user manuals required for the individual application.
You can reach us at:
Berghof Automation GmbH
Harretstr. 1
72800 Eningen
Germany
T +49.7121.894-0
F +49.7121.894-100
E-mail: [email protected]om
www.berghof-automation.com
Berghof Automation GmbH is certified to DIN EN ISO 9001:2015.

USER HANDBOOK 1.2 | B-PRIMIS DC/ET PRIME 2110W X C, 2115WUX C
Berghof Automation GmbH | Harretstraße 1 | 72800 Eningen | www.berghof-automation.com
270011X00_B-PRIMIS_ET-DC-PRIME 2110W-2115W_EN.docx
3
Change log
Version
Date
Description
0.2
10/04/2018
HB first draft
0.8
12/06/2018
Addition of graphics. Corrections, change to new layout
0.9
18/06/2018
Corrections, chapter added: Counter and web interface
1.0
26/06/2018
First version
1.1
05/12/2018
Modification to the mechanism, new group names
1.2
14/12/2018
Corrections after review
1.3
21/12/2018
Corrections (IP protection)

USER HANDBOOK 1.2 | B-PRIMIS DC/ET PRIME 2110W X C, 2115WUX C
Berghof Automation GmbH | Harretstraße 1 | 72800 Eningen | www.berghof-automation.com
270011X00_B-PRIMIS_ET-DC-PRIME 2110W-2115W_EN.docx
4
Table of contents
1. GENERAL INFORMATION .................................................................................................................7
1.1. Notes on the handbook .....................................................................................................................7
1.2. Symbols and visual depictions .........................................................................................................7
1.3. Hazard categories and indications ...................................................................................................8
1.4. Qualified personnel............................................................................................................................9
1.5. Duty of care.........................................................................................................................................9
1.5.1. General ................................................................................................................................................9
1.6. Intended Use.....................................................................................................................................10
1.7. Transport and storage .....................................................................................................................11
Transport and storage ........................................................................................................................11
Devices with batteries/rechargeable batteries....................................................................................11
Operation ...........................................................................................................................................11
1.8. Unpacking.........................................................................................................................................11
2. SAFETY.............................................................................................................................................12
Safety-related systems.......................................................................................................................12
2.1. Safety instructions ...........................................................................................................................12
Working on the device........................................................................................................................12
3. PRODUCT DESCRIPTION................................................................................................................13
3.1. Overview ...........................................................................................................................................14
3.1.1. Overview DC2115WUX CM................................................................................................................14
3.1.2. Overview DC2110W X CM .................................................................................................................15
3.1.3. Overview ET2115WUX CS.................................................................................................................16
3.1.4. Overview ET2110W X CS ..................................................................................................................17
3.2. Scope of delivery and accessories.................................................................................................18
Scope of delivery................................................................................................................................18
Accessories........................................................................................................................................18
3.3. Product features...............................................................................................................................18
4. INSTALLATION.................................................................................................................................20
4.1. Preparation for installation Front installation DC/ET2115WUX C ................................................20
4.2. Preparation for installation from the front DC/ET2110W XC........................................................22
4.3. Installation ........................................................................................................................................24
5. CONNECTION...................................................................................................................................26
5.1. Power supply....................................................................................................................................26
5.1.1. Connecting the power supply .............................................................................................................27
5.2. Data connections .............................................................................................................................29
5.2.1. Block circuit diagram DC2115WUX CM / DC2110W X CM ................................................................29
5.2.2. Block circuit diagram ET2115WUX CS / ET2110W X CS...................................................................30
5.2.3. Digital inputs and outputs (DC2115WUX CM / DC2110W X CM) .......................................................31
5.2.4. Counting inputs (C) ............................................................................................................................35

USER HANDBOOK 1.2 | B-PRIMIS DC/ET PRIME 2110W X C, 2115WUX C
Berghof Automation GmbH | Harretstraße 1 | 72800 Eningen | www.berghof-automation.com
270011X00_B-PRIMIS_ET-DC-PRIME 2110W-2115W_EN.docx
5
5.2.5. Analogue inputs (DC2115WUX CM / DC2110W X CM) .....................................................................37
5.2.6. Ethernet..............................................................................................................................................43
5.2.7. EtherCAT (DC2115WUX CM / DC2110W X CM)................................................................................44
5.2.8. USB....................................................................................................................................................45
5.2.9. CAN Bus (DC2115WUX CM / DC2110W X CM) ................................................................................46
5.2.10. Serial interfaces (DC2115WUX CM / DC2110W X CM) .....................................................................47
6. OPERATION......................................................................................................................................49
6.1. Switching on and off ........................................................................................................................49
6.2. Commissioning the network ...........................................................................................................50
6.2.1. DC2115WUX CM / DC2110W X CM web interface ............................................................................50
6.2.2. DC2115WUX CM / DC2110W X CM on-screen config.......................................................................52
6.2.3. ET2115WUX CS / ET2110W X CS Configuration ..............................................................................54
6.2.4. ET2115WUX CS / ET2110W X CS web-terminal configuration..........................................................56
6.3. Operation ..........................................................................................................................................58
6.3.1. Status displays (only DC-PRIME).......................................................................................................58
6.3.2. Function key S1 (only DC-PRIME) .....................................................................................................59
6.3.3. Real-time clock with buffer battery DC2115WUX CM / DC2110W X CM............................................59
6.3.4. microSD card......................................................................................................................................60
6.4. Troubleshooting ...............................................................................................................................61
6.4.1. No network connection.......................................................................................................................61
6.4.2. In error stop mode DC2115WUX CM / DC2110W X CM ....................................................................61
7. MAINTENANCE/UPKEEP.................................................................................................................62
7.1. Maintenance......................................................................................................................................62
7.2. Cleaning ............................................................................................................................................62
8. UNINSTALLATION............................................................................................................................63
9. DISPOSAL.........................................................................................................................................65
10. TECHNICAL DATA............................................................................................................................66
10.1. DC2115WUX CM / DC2110W X CM Dialog Controller ....................................................................66
10.2. ET2115 Ethernet TerminalWUX CS / ET2110W X CS .....................................................................69
10.3. Identification plate............................................................................................................................71
10.4. Identification .....................................................................................................................................72
11. STANDARDS AND CERTIFICATES.................................................................................................73
11.1. Standards..........................................................................................................................................73
11.2. Declaration of conformity................................................................................................................74
12. CUSTOMER SERVICES / ADDRESSES ..........................................................................................75
12.1. Customer service .............................................................................................................................75
12.2. Addresses.........................................................................................................................................75
13. APPENDIX.........................................................................................................................................76

USER HANDBOOK 1.2 | B-PRIMIS DC/ET PRIME 2110W X C, 2115WUX C
Berghof Automation GmbH | Harretstraße 1 | 72800 Eningen | www.berghof-automation.com
270011X00_B-PRIMIS_ET-DC-PRIME 2110W-2115W_EN.docx
6
13.1. Information on copyright and software licence.............................................................................76
13.2. List of figures....................................................................................................................................76

USER HANDBOOK 1.2 | B-PRIMIS DC/ET PRIME 2110W X C, 2115WUX C
Berghof Automation GmbH | Harretstraße 1 | 72800 Eningen | www.berghof-automation.com
270011X00_B-PRIMIS_ET-DC-PRIME 2110W-2115W_EN.docx
7
1. General information
This user handbook is intended for use by qualified professionals and contains information on the as-
sembly, installation, start-up and maintenance of the device.
1.1. Notes on the handbook
This user handbook is a component of the product and applies to the following devices:
B-PRIMIS DC-PRIME DC2110W Dialog Controller X CM and DC2115WUX CM
B-PRIMIS ET-PRIME Ethernet Terminal ET2110W X CS and ET2115WUX CS
It contains information on the following topics:
Applications
Safety
Mechanical design
Electrical design
Connections
Start-up
Upkeep and maintenance
Decommissioning
Disposal
Always keep this user handbook available alongside the product.
1.2. Symbols and visual depictions
The following symbols and visual depictions are used in this handbook:
Symbol
Meaning
…
List entry
…
Individual instruction or list of instructions which can be carried out in any or-
der.
1. …
2. …
List of instructions which must be carried out in the order given.
Additional product information

USER HANDBOOK 1.2 | B-PRIMIS DC/ET PRIME 2110W X C, 2115WUX C
Berghof Automation GmbH | Harretstraße 1 | 72800 Eningen | www.berghof-automation.com
270011X00_B-PRIMIS_ET-DC-PRIME 2110W-2115W_EN.docx
8
Design of warnings:
WARNING
Optional:
Other
Symbols
Hazard type and source
Short description and consequences
Preventive measures
1.3. Hazard categories and indications
The following indications are used in the case of warning messages so as to ensure your personal
safety and avoid any damage to property.
The indications have the following meanings:
DANGER
Serious injury or death
Non-compliance with the safety features will result in death or serious injury.
Take preventive measures.
WARNING
Possible serious injury or death
Non-compliance with the safety features may result in death or serious injury.
Take preventive measures.
CAUTION
Possible minor injuries
Non-compliance with the safety features may result in minor injuries.
Take preventive measures.
NOTE
Possible damage to property
Non-compliance with the safety features may result in damage to property.
Take preventive measures.

USER HANDBOOK 1.2 | B-PRIMIS DC/ET PRIME 2110W X C, 2115WUX C
Berghof Automation GmbH | Harretstraße 1 | 72800 Eningen | www.berghof-automation.com
270011X00_B-PRIMIS_ET-DC-PRIME 2110W-2115W_EN.docx
9
1.4. Qualified personnel
The installation, start-up and maintenance of the device must be carried out by qualified personnel.
For the purposes of this documentation and the safety instructions contained therein, “qualified per-
sonnel” means trained staff who are familiar with safety concepts in automation engineering and who
are authorised to assemble, install, start up, earth and identify devices, systems and electrical circuits
in accordance with standards set in safety engineering.
1.5. Duty of care
1.5.1. General
The user or processor (OEM) must ensure the following:
The device must only be used according to regulations.
The device must only be used in good working order.
The user handbook must always be kept legible and fully available.
Only sufficiently qualified and authorised personnel may carry out the assembly, installation,
start-up and maintenance of the device.
These authorised personnel must receive regular training on all relevant occupational health and
safety and environmental protection issues and must be fully familiar with the contents of this us-
er handbook, particularly the sections regarding safety features.
Any markings or identification labels and safety and warning signs on the device must not be re-
moved and must be kept legible at all times.
The national and international regulations regarding the operating of machinery and facilities
where the device is being used must be observed at all times.
The user must always be kept abreast of any current relevant information regarding the device
and its use or operation.
The user takes direct responsibility for agreeing with the competent authorities the use of safety-
related control components, and for compliance with their instructions.

USER HANDBOOK 1.2 | B-PRIMIS DC/ET PRIME 2110W X C, 2115WUX C
Berghof Automation GmbH | Harretstraße 1 | 72800 Eningen | www.berghof-automation.com
270011X00_B-PRIMIS_ET-DC-PRIME 2110W-2115W_EN.docx
10
1.6. Intended Use
The device is part of a modular automation system for industrial control applications within the medium
to high performance range. It extends the communications capabilities to include EtherCAT, Profinet,
Modbus and others.
The automation system is designed for use within overvoltage category I (IEC 364 4 443) systems for
controlling and regulating machinery and industrial processes in low-voltage installations in accordance
with the following general parameters:
maximum rated supply voltage of 1,000 V AC (50/60 Hz) or 1,500 V DC
Environment with maximum category 2 pollution (EN 61010-1)
for use up to a maximum altitude of 2,000 m above msn.
for indoor use only in areas not exposed to direct UV radiation
Max. ambient temperature inside and outside the control cabinet in accordance with the technical
data (see “Technical data“)
Qualified project planning and design, proper transport, storage, installation, use and careful mainte-
nance are essential to the flawless and safe operation of the automation system.
The automation system may only be used within the scope of the data and applications specified in this
documentation and associated user manuals.
The automation system must only be used:
as intended
in a technically perfect condition
without any unauthorised modifications
by qualified users
Observe the rules of the employer’s liability insurance association, the technical inspectorate,
and the VDE (Association of German Electrical Engineers) or corresponding country regulations.
The device is intended for installation into a suitable cut-out on industrial machines and systems in in-
door areas.
When installing the device, check that the seal profiles are undamaged.
For operation, refer to the applicable statement of ambient conditions (see "Technical data").

USER HANDBOOK 1.2 | B-PRIMIS DC/ET PRIME 2110W X C, 2115WUX C
Berghof Automation GmbH | Harretstraße 1 | 72800 Eningen | www.berghof-automation.com
270011X00_B-PRIMIS_ET-DC-PRIME 2110W-2115W_EN.docx
11
1.7. Transport and storage
The device is susceptible to impacts, heavy vibration, moisture and extreme temperatures.
Transport and storage
Protect the device against major mechanical stresses during transport.
Always pack the device in its original packaging for transport.
For storage, refer to the applicable statement of ambient conditions (see "Technical data").
Protect the device against condensation and damp.
Devices with batteries/rechargeable batteries
Lithium metal batteries are hazardous items. The manufacturer’s information specifies that they are
subject to UN 3091 (must be permanently installed within the device).
The ADR 188 special regulations can be applied for transport.
Operation
If the device has been stored or transported in cold weather or under conditions or large fluctua-
tions in temperature, do not start to operate it until it has acclimatised to room temperature for the
place it is used.
If condensation is present, wait at least 12 hours before starting to operate the device.
1.8. Unpacking
Or receipt of the device, a check must be made that it is complete and undamaged.
Check the packaging for external damage.
If the packaging is seriously damaged or if damage to the contents is evident: Do not proceed
further with opening the packaging, instead immediately inform the transport company and your
supplier.
Remove the packaging and keep it safe for subsequent transport.
Check the contents for evidence of damage in transport.
Check the contents for completeness against the order documentation and keep all the delivery
documentation for future reference. The delivery documentation contains important information
about the device and is part of the product.
If you discover damage in transport, or if the equipment delivered does not match the order: In-
form the supplier immediately.

USER HANDBOOK 1.2 | B-PRIMIS DC/ET PRIME 2110W X C, 2115WUX C
Berghof Automation GmbH | Harretstraße 1 | 72800 Eningen | www.berghof-automation.com
270011X00_B-PRIMIS_ET-DC-PRIME 2110W-2115W_EN.docx
12
2. Safety
Safety-related systems
The use of PLCs in safety-related systems requires specific measures. Wherever a PLC is to be used
in a safety-related system, the user must be given comprehensive advice by the PLC manufacturer in
addition to information on any available standards or regulations regarding safety installations.
Before starting any work on devices, switch off all power feeds, including to peripherals.
Keep all ventilation holes unobstructed.
Failure in certain components in an electronic control system may result in uncontrolled and/or unpre-
dictable operational behaviour.
All types of failure must be considered at the system level and the associated preventative
measures identified.
If necessary, request information from your automation system provider.
2.1. Safety instructions
The device may be operated only when it is in good working order. Exposed sharp edges pose an inju-
ry risk.
If you discover damage to the front glass of the device, do not continue to operate the device.
Immediately disconnect it from the power supply.
Working on the device
Do not start work on the device until all necessary safety precautions have been taken. Take precau-
tions to avoid unforeseeable functional events and movements of the system.
Bring the system into a safe condition.
Switch the system and the device off.
Secure the system against being switched on again.
Disconnect the device from the system.
The casing of the device must not be opened.
If work on the internal parts of the device is necessary, contact the manufacturer (see
"Addresses").

USER HANDBOOK 1.2 | B-PRIMIS DC/ET PRIME 2110W X C, 2115WUX C
Berghof Automation GmbH | Harretstraße 1 | 72800 Eningen | www.berghof-automation.com
270011X00_B-PRIMIS_ET-DC-PRIME 2110W-2115W_EN.docx
13
3. Product description
The Dialog Controllers of the B-PRIMIS DC-PRIME product group (DC2110W X CM and
DC2115WUX CM) are control modules with a display for the control and regulation of automation and
industrial processes in low-voltage installations in real time.
The CODESYS 3.5 (IEC 61131-3) development environment from 3S-Smart Software Solutions is
used for programming the device.
The Ethernet Terminals of the B-PRIMIS ET-PRIME product group (ET2110W X CS and ET2115WUX
CS) are input devices with a display for connection to a control system for machines or systems. The
terminal shows the CODESYS Web visualisation or CODESYS Target visualisation, irrespective of
whether the visualisation originates from a Berghof PLC control unit or some other CODESYS control
unit.
ET211x Ethernet Terminals can be connected via Ethernet interfaces; DC211x Controllers can be con-
nected via various different interfaces and in addition have their own digital and analogue in-
puts/outputs.
The device connection area for all external connections is located at the rear of the devices. These de-
vices are intended for installation on a flat surface in a pre-prepared installation cut-out.
All connections are of the plug-in type.

USER HANDBOOK 1.2 | B-PRIMIS DC/ET PRIME 2110W X C, 2115WUX C
Berghof Automation GmbH | Harretstraße 1 | 72800 Eningen | www.berghof-automation.com
270011X00_B-PRIMIS_ET-DC-PRIME 2110W-2115W_EN.docx
14
3.1. Overview
3.1.1. Overview DC2115WUX CM
Fig. 1: Overview DC2115WUX CM (rear view)
Item
Designation
Item
Designation
1
Display 15.6 inch
X6
EtherCAT (ETH1)
2
LEDs: PWR, Run/Stop, Error
X8
CAN bus
3
LEDs: Power, digital I/O
X9
RS-232 / RS-485
4
Earth connection
X11
Debug interface (do not use this - it is for
use only by Berghof Service Engineers)
X1
Power supply,
digital inputs/outputs
S1
Function key
X2
Analogue inputs
S2
Terminating resistor CAN (120 Ohm)
X3
USB 2.0
S3
Terminating resistor RS-485 (120 Ohm)
X4
Ethernet (ETH0)
µSD
MicroSD card slot (for memory extension)
X5
USB 2.0

USER HANDBOOK 1.2 | B-PRIMIS DC/ET PRIME 2110W X C, 2115WUX C
Berghof Automation GmbH | Harretstraße 1 | 72800 Eningen | www.berghof-automation.com
270011X00_B-PRIMIS_ET-DC-PRIME 2110W-2115W_EN.docx
15
3.1.2. Overview DC2110W X CM
Fig. 2: Overview DC2110W X CM (rear view)
Item
Designation
Item
Designation
1
Display 10.1 inch
X6
EtherCAT (ETH1)
2
LEDs: PWR, Run/Stop, Error
X8
CAN bus
3
LEDs: Power, digital I/O
X9
RS-232 / RS-485
4
Earth connection
X11
Debug interface (do not use this - it is for
use only by Berghof Service Engineers)
X1
Power supply,
digital inputs/outputs
S1
Function key
X2
Analogue inputs
S2
Terminating resistor CAN (120 Ohm)
X3
USB 2.0
S3
Terminating resistor RS-485 (120 Ohm)
X4
Ethernet (ETH0)
µSD
MicroSD card slot (for memory extension)
X5
USB 2.0

USER HANDBOOK 1.2 | B-PRIMIS DC/ET PRIME 2110W X C, 2115WUX C
Berghof Automation GmbH | Harretstraße 1 | 72800 Eningen | www.berghof-automation.com
270011X00_B-PRIMIS_ET-DC-PRIME 2110W-2115W_EN.docx
16
3.1.3. Overview ET2115WUX CS
Fig. 3: Overview ET2115WUX CS (rear view)
Item
Designation
Item
Designation
1
Display 15.6 inch
X8
Debug interface (do not use this - it is for
use only by Berghof Service Engineers)
2
Earth connection
X100
Power supply
X3
USB 2.0
S1
Function button (do not use this - it is for
use only by Berghof Service Engineers)
X4
Ethernet (ETH0)
LED
LEDs: PWR, Run/Stop, Error

USER HANDBOOK 1.2 | B-PRIMIS DC/ET PRIME 2110W X C, 2115WUX C
Berghof Automation GmbH | Harretstraße 1 | 72800 Eningen | www.berghof-automation.com
270011X00_B-PRIMIS_ET-DC-PRIME 2110W-2115W_EN.docx
17
3.1.4. Overview ET2110W X CS
Fig. 4: Overview ET2110W X CS (rear view)
Item
Designation
Item
Designation
1
Display 10.1 inch
X8
Debug interface (do not use this - it is for
use only by Berghof Service Engineers)
2
Earth connection
X100
Power supply
X3
USB 2.0
S1
Function button (do not use this - it is for
use only by Berghof Service Engineers)
X4
Ethernet (ETH0)
LED
LEDs: PWR, Run/Stop, Error

USER HANDBOOK 1.2 | B-PRIMIS DC/ET PRIME 2110W X C, 2115WUX C
Berghof Automation GmbH | Harretstraße 1 | 72800 Eningen | www.berghof-automation.com
270011X00_B-PRIMIS_ET-DC-PRIME 2110W-2115W_EN.docx
18
3.2. Scope of delivery and accessories
Scope of delivery
DC2110W X CM / DC2115WUX CM:
Device
E-I/O plug, 6-pin, black (order no. 204803900)
E-I/O connector, 12-pin, black (order no. 15838)
Securing clip SMALL (8/14)
ET2110W X CS / ET2115WUX CS:
Device
E-I/O plug, 2-pin, black (order no. 204801800)
Securing clip SMALL (8/14)
Accessories
DC2110W X CM / DC2115WUX CM:
E-I/O plug, 6-pin, black (order no. 204803900)
E-I/O connector, 12-pin, black (order no. 15838)
Securing clip SMALL (8/14)
ET2110W X CS / ET2115WUX CS:
E-I/O plug, 2-pin, black (order no. 204801800)
Securing clip SMALL (8/14)
3.3. Product features
Installation
The device is designed for installation in a front panel or in a control panel in a rough industrial envi-
ronment.
Processor
In its the basic configuration the device is equipped with an 800 MHz ARM® CPU with a Cortex™-A9
core.
Ethernet
1 Ethernet interface with 10/100 Mbit/s
The Ethernet interface is used for standard Ethernet connections. TCP/IP and UDP/IP protocols permit
flexible connections to visualisation software, higher-level control units and to the IT infrastructure.
EtherCAT (DC2110W X CM / DC2115WUX CM)
The second Ethernet interface is used as an EtherCAT master interface.
Other protocols available for the Ethernet interfaces: PROFINET, Ethernet/IP, OPC UA, BACnet and
Modbus.

USER HANDBOOK 1.2 | B-PRIMIS DC/ET PRIME 2110W X C, 2115WUX C
Berghof Automation GmbH | Harretstraße 1 | 72800 Eningen | www.berghof-automation.com
270011X00_B-PRIMIS_ET-DC-PRIME 2110W-2115W_EN.docx
19
USB
The USB host interface allows a wide range of peripherals to be connected to the device. This allows a
USB stick to be used for updating the application or for downloading data directly.
USB sticks with FAT/FAT32 formatting are supported.
If you require support for other USB formats, please contact our Technical Support.
CAN interface (DC2110W X CM / DC2115WUX CM)
The device has one standard CAN interface which can be used at speeds up to 1 Mbit/s.
Serial interface (DC2110W X CM / DC2115WUX CM)
The device has 2 serial ports (1x RS-485; 1x RS-232).
Onboard inputs / outputs (DC2110W X CM / DC2115WUX CM)
The device incorporates digital inputs / outputs and analogue inputs.
Real-time clock (DC2110W X CM / DC2115WUX CM)
A software interface permits the current time and date to be set and read on a real-time clock with bat-
tery back-up.
microSD card (DC2110W X CM / DC2115WUX CM)
The standard commercial microSD card interface (SDHC up to max. 32 GB) allows data to be written
to memory cards or read from memory cards.
Summary of features
DC2110W X CM / DC2115WUX CM:
ARM® CPU with CortexTM-A9 single-core (800 MHz; optional dual or quad core)
Program memory and data memory (RAM): 512 MB onboard
Program memory (flash): 2048 MB on-board
2 USB host interfaces (USB 2.0)
Non-volatile memory 100 kB
2 Ethernet 10/100 Base T interfaces (2nd Interface: EtherCAT master interface)
1 CAN interface
2 serial interfaces (1x RS-485; 1x RS-232)
1 µSD card slot
Onboard I/O
Real-time clock
ET2110W X CS / ET2115WUX CS:
ARM® CPU with CortexTM-A9 single-core (800 MHz)
1 USB host interface (USB 2.0)
1 Ethernet 10/100 Base T interface

USER HANDBOOK 1.2 | B-PRIMIS DC/ET PRIME 2110W X C, 2115WUX C
Berghof Automation GmbH | Harretstraße 1 | 72800 Eningen | www.berghof-automation.com
270011X00_B-PRIMIS_ET-DC-PRIME 2110W-2115W_EN.docx
20
4. Installation
4.1. Preparation for installation Front installation
DC/ET2115WUX C
The device is intended for installation from the front into a rectangular cut-out on a panel. The support
material must be rigid and be from 1 to 3 mm thick.
Fig. 5: Dimensions DC2115WUX CM / ET2115WUX CS
Requirements:
To allow sufficient air circulation, it must be ensured that the device has a clear space of at least
20 mm all round at the rear.
The max. ambient temperature inside the control cabinet must not exceed 55 °C in operation.
The support material for the installation cut-out must be flat, sufficiently stable, and be from 1 to 3
mm thick.
