BEST EXPERIENCE SPRINGS WINDOW FASHIONS BUDGET BLINDS SMART HOME MOTORIZED... User manual

MOTORIZED
SHADES

Getting to Know Your Remotes
Motor Program Button and Charging the Battery ..........................3
Single-Channel Remote .............................................................. 4-5
Multi-Channel Remote................................................................... 6
Five-Channel Wall Switch............................................................... 7
Smart Home Hub and App .............................................................8
Quick Start Guide
Knowing Your Shade’s Limits and Home Position ....................... 10
Controlling Your Shade................................................................ 11
Assigning Shades to Channels (Multi-Channel Only)................... 12
Adjusting Your Shade’s Limits and Favorite Position
Adjusting the Upper Limit....................................................... 14-15
Adjusting the Lower Limit ............................................................ 16
Adjusting the Favorite Position.................................................... 17
Pairing Your Remotes and Shades
Pair a New Remote Using an Existing Remote ............................ 19
Pairing a New Remote Using the Motor Program Button............ 20
Remove a Remote Pairing.............................................................21
Adjusting Motor Speed ...........................................................22-23
Integrating Your Shades with a Home Automation System
Setting Up Smart Home Collection App...................................... 24
Troubleshooting ........................................................................... 25-27
Glossary........................................................................................ 28-30
Channel Assignment Worksheet ..................................................... 31
TABLE OF CONTENTS
TABLE OF CONTENTS

3
Getting to Know Your Remotes
Motor Program Button
The program button on the shade’s motor end lets you move
your shade without a remote. It’s also used to perform various
programming functions, discussed later in this manual.
MOTOR FOR CELLULAR
AND PLEATED SHADES
ROLLEASE ACMEDA Automate™ Programming Instructions | Li-ion Tubular Motors | 7
.
Pair motor with controller
Check motor direction
5.1
5.2
Consult user manual for your
controller for information on
selecting channel.
Damage to shade may occur when operating motor prior to
setting limits. Attention should be given.
Reversing motor direction using this method is only possible
during initial set-up
Hold P1 button on
motor head.
To check travel direction of shade, press UP or
DOWN on controller.
Quick Press = Step
Long Press = Continuous Travel
To reverse shade direction, hold both UP and
DOWN.
Until the motor responds.
Select channel on
controller.
Hold STOP on
controller.
Approx.
Approx.
Motor Response
Motor Response
Motor Response
Motor is now in step mode and ready for setting limits
IMPORTANT
IMPORTANT
IMPORTANT
5 INITIAL SET UP
OR
Approx.
MOTOR FOR SOLAR
AND ROLLER SHADES
P1 Button
Charging the Battery
Only use the charger supplied with the shades.
Solar/Roller: Motor will beep 10 times when in use to indicate
that the battery needs to be charged. LED light in motor head
will blink green when charging and turn solid green when
charging is complete.
Cellular/Pleated: LED light in battery pack will be solid red
when charging and turn solid green when charging is complete.
P1 Button
IMPORTANT INFORMATION BEFORE YOU BEGIN
You must charge the batteries for your product ordered.
You should only use the charger ordered with the shades.
Charge time can vary and could take up to 4 hours for a
complete charge.

4Getting to Know Your Remotes
GETTING TO KNOW
YOUR REMOTES
Single-Channel Remote
UP button
DOWN button
STOP button
LED indicator

5
Getting to Know Your Remotes
Single-Channel Remote
The single-channel remote has 1 available channel. This channel
can include a single shade or multiple shades, and can control
an unlimited number of shades at once. However, each shade
can be added to a maximum of 10 different remote channels.
FRONT
BACK
6 | Automate Programming Instructions | Paradigm Remotes ROLLEASE ACMEDA
4 FUNCTIONAL OVERVIEW
4.1 Buttons
4.2 Levelling control
UP
STOP
DOWN
CHANNEL
LEVEL CONTROL
SETTING (P2)
The levelling control bar can be used to visualize and accurately set your preferred shade position. When
used to control a group of shades, they will all perfectly align to the same position.
.
6 | Automate Programming Instructions | Paradigm Remotes ROLLEASE ACMEDA
4 FUNCTIONAL OVERVIEW
4.1 Buttons
4.2 Levelling control
UP
STOP
DOWN
CHANNEL
LEVEL CONTROL
SETTING (P2)
The levelling control bar can be used to visualize and accurately set your preferred shade position. When
used to control a group of shades, they will all perfectly align to the same position.
.
STOP button
UP button
DOWN button
LED indicator
Setting (P2)

6Getting to Know Your Remotes
Multi-Channel Remote
The multi-channel remote has 15 available channels. Each channel
can include a single shade or multiple shades, and can control an
unlimited number of shades at once. However, each shade can be
added to a maximum of 10 different remote channels.
LEARN HOW
to assign shades to
channels on page 12.
BACK
FRONT
STOP button
DOWN button
Channel
UP button
P2 Button
USER GUIDEUSER GUIDE
QUICK START GUIDE
ADVANCED PROGRAMMING
BUTTON OVERVIEW GROUP CONTROL
REPLACE BATTERY WALL MOUNTING
HIDE SPARE CHANNELS
SELECTING A CHANNEL CONTROLLING A SHADE
Install battery CR2430 with positive (+)
side facing up.
Remove cover from remote
press gently in and down to
disengage cover.
Use supplied fasteners and anchors
to attach the base to wall.
Press and hold both channel scroll
buttons together until the c appears
on the screen.
scroll with the left arrow from ch 13 until
you reach the last channel that you want
to see (example 5) confirm by pressing stop
Ch 1 -5 will only be visible
CONTROL SHADE UP OR DOWN
STOPPING THE SHADE
Press the stop button to stop shade
at any point
While the channel is displayed press
up or down to move shade accordingly
UP BUTTON
LOCK BUTTON
P2 BUTTON
CHANNEL
STOP BUTTON
DOWN BUTTON
DISABLE LIMIT SETTING
This mode is intended to be used after all shade
programming is completed. User Mode will prevent
accidental or unintended changing of limits.
Push switch to lock or
unlocked position
CREATE CUSTOM GROUPS
It is possible to copy one channel to another
channel to create custom groups
Repeating these steps after creating a
favorite position will delet it.
SET A FAVORITE POSITION
Move shade to desired position by
pressing UP or DOWN on the remote.
Press P2 on controller
Press STOP on controller
Press STOP on controller
BEEP
x1
JOG
x1
MOTOR RESPONSE
Press P2 again on existing
controller
Press P2 on existing controller
Select the channel
you want to transfer
Select the channel
on the new controller
Press P2 on new controller
BEEP
x1
JOG
x1
MOTOR RESPONSE
BEEP
x1
JOG
x1
MOTOR RESPONSE
BEEP
x1
JOG
x1
MOTOR RESPONSE
BEEP
x1
JOG
x1
MOTOR RESPONSE
BEEP
x3
JOG
x2
MOTOR RESPONSE
STEP 1.
STEP 2. STEP 2.
STEP 3.
STEP 1.
STEP 3.
Step 3 to be completed
within
4 seconds of Step 2
LCD displays “L” when locked
LCD displays “U” when locked
Press left and right arrow; to scroll
through channels as required.
READY FOR CONTROL
Now while the channel is active
follow the control instructions.
if no button is pressed within 4 seconds,
the channel slection will automatically
be confirmed.
STEP 1
STEP 2
OR OR
OR
L
55
U
Channel "0" is pre-set to control
ALL shades paired to your
Muli-channel remote.
0
C
USER GUIDEUSER GUIDE
QUICK START GUIDE
ADVANCED PROGRAMMING
BUTTON OVERVIEW GROUP CONTROL
REPLACE BATTERY WALL MOUNTING
HIDE SPARE CHANNELS
SELECTING A CHANNEL CONTROLLING A SHADE
Install battery CR2430 with positive (+)
side facing up.
Remove cover from remote
press gently in and down to
disengage cover.
Use supplied fasteners and anchors
to attach the base to wall.
Press and hold both channel scroll
buttons together until the c appears
on the screen.
scroll with the left arrow from ch 13 until
you reach the last channel that you want
to see (example 5) confirm by pressing stop
Ch 1 -5 will only be visible
CONTROL SHADE UP OR DOWN
STOPPING THE SHADE
Press the stop button to stop shade
at any point
While the channel is displayed press
up or down to move shade accordingly
UP BUTTON
LOCK BUTTON
P2 BUTTON
CHANNEL
STOP BUTTON
DOWN BUTTON
DISABLE LIMIT SETTING
This mode is intended to be used after all shade
programming is completed. User Mode will prevent
accidental or unintended changing of limits.
Push switch to lock or
unlocked position
CREATE CUSTOM GROUPS
It is possible to copy one channel to another
channel to create custom groups
Repeating these steps after creating a
favorite position will delet it.
SET A FAVORITE POSITION
Move shade to desired position by
pressing UP or DOWN on the remote.
Press P2 on controller
Press STOP on controller
Press STOP on controller
BEEP
x1
JOG
x1
MOTOR RESPONSE
Press P2 again on existing
controller
Press P2 on existing controller
Select the channel
you want to transfer
Select the channel
on the new controller
Press P2 on new controller
BEEP
x1
JOG
x1
MOTOR RESPONSE
BEEP
x1
JOG
x1
MOTOR RESPONSE
BEEP
x1
JOG
x1
MOTOR RESPONSE
BEEP
x1
JOG
x1
MOTOR RESPONSE
BEEP
x3
JOG
x2
MOTOR RESPONSE
STEP 1.
STEP 2. STEP 2.
STEP 3.
STEP 1.
STEP 3.
Step 3 to be completed
within
4 seconds of Step 2
LCD displays “L” when locked
LCD displays “U” when locked
Press left and right arrow; to scroll
through channels as required.
READY FOR CONTROL
Now while the channel is active
follow the control instructions.
if no button is pressed within 4 seconds,
the channel slection will automatically
be confirmed.
STEP 1
STEP 2
OR OR
OR
L
55
U
Channel "0" is pre-set to control
ALL shades paired to your
Muli-channel remote.
0
C
LOCK Button

7
Getting to Know Your Remotes
Five-Channel Wall Switch
The ve-channel wall switch has 5 available channels. Each
channel can include a single shade or multiple shades, and can
control an unlimited number of shades at once. However, each
shade can be added to a maximum of 10 different
remote channels.
BACK
FRONT
Channels 1-5
ROLLEASE ACMEDA Automate™ Programming Instructions | Flush Wall Switch | 7
Press desired channel button(s) To deselect channel, press channel button
until LED turns off
Buttons
Selecting a channel
4.1
4.2
4 FUNCTIONAL OVERVIEW
CHANNELS 1-5
STOP
P2
UP DOWN
Motor Response
Switch requires that at least one channel be selected at
all times. First select an additional channel, then deselect
channel you don't want to operate.
Blue LEDs will illuminate indicating channel selection.
IMPORTANT
ROLLEASE ACMEDA Automate™ Programming Instructions | Flush Wall Switch | 7
Press desired channel button(s) To deselect channel, press channel button
until LED turns off
Buttons
Selecting a channel
4.1
4.2
4 FUNCTIONAL OVERVIEW
CHANNELS 1-5
STOP
P2
UP DOWN
Motor Response
Switch requires that at least one channel be selected at
all times. First select an additional channel, then deselect
channel you don't want to operate.
Blue LEDs will illuminate indicating channel selection.
IMPORTANT
STOP Button
UP Button DOWN Button
P2 Button

8Getting to Know Your Remotes
Smart Home Hub and App
LED Indicator
Locations
Devices
Menu
Rooms
Home
Favorites
Scenes
Timers

9
Quick Start Guide
QUICK START GUIDE

10 Quick Start Guide
Knowing Your Shade’s Limits and
Favorite Position
To help you get started quickly and easily, we set your
shade up with predened positions.
You can adjust each of these positions to t the needs of
your home—just follow the instructions in the Adjusting Your
Shade’s Limits and Favorite Position section on page 13.
Upper Limit: The highest
position your shade can reach.
We pick a position that gives you
the best view and also protects
your shade from damage.
Lower Limit: The lowest
position your shade can
reach. This matches the shade
length you ordered.
Favorite Position: We set this
to the midpoint of your shade,
but you can adjust it to any
point between the upper
and lower limits.

11
Quick Start Guide
Controlling Your Shade
We preprogrammed your remotes
to operate your shades.
Stop Your Shade While
It’s Moving
While your shade is moving,
press and release the
STOP button.
Open Your Shade
Press and release the
UP button.
Close Your Shade
Press and release the
DOWN button.
Move Your Shade to the
Favorite Position
Press and hold the STOP button
for approximately two seconds.
ROLLEASE ACMEDA Automate™ Programming Instructions | Li-ion Tubular Motors | 7
.
Pair motor with controller
Check motor direction
5.1
5.2
Consult user manual for your
controller for information on
selecting channel.
Damage to shade may occur when operating motor prior to
setting limits. Attention should be given.
Reversing motor direction using this method is only possible
during initial set-up
Hold P1 button on
motor head.
To check travel direction of shade, press UP or
DOWN on controller.
Quick Press = Step
Long Press = Continuous Travel
To reverse shade direction, hold both UP and
DOWN.
Until the motor responds.
Select channel on
controller.
Hold STOP on
controller.
Approx.
Approx.
Motor Response
Motor Response
Motor Response
Motor is now in step mode and ready for setting limits
IMPORTANT
IMPORTANT
IMPORTANT
5 INITIAL SET UP
OR
Approx.

12 Quick Start Guide
Assigning Shades to Channels
(Multi-Channel Remote Only)
If you bought your shades and multi-channel remote at
the same time, your shades arrive already paired with your
multi-channel remote. Channel “0” is preset to control all
shades paired to your multi-channel remote.
1. Hold the P1 button on the motor
head until the shade jogs one time.
ROLLEASE ACMEDA Automate™ Programming Instructions | Li-ion Tubular Motors | 7
.
Pair motor with controller
Check motor direction
5.1
5.2
Consult user manual for your
controller for information on
selecting channel.
Damage to shade may occur when operating motor prior to
setting limits. Attention should be given.
Reversing motor direction using this method is only possible
during initial set-up
Hold P1 button on
motor head.
To check travel direction of shade, press UP or
DOWN on controller.
Quick Press = Step
Long Press = Continuous Travel
To reverse shade direction, hold both UP and
DOWN.
Until the motor responds.
Select channel on
controller.
Hold STOP on
controller.
Approx.
Approx.
Motor Response
Motor Response
Motor Response
Motor is now in step mode and ready for setting limits
IMPORTANT
IMPORTANT
IMPORTANT
5 INITIAL SET UP
OR
Approx.
ROLLEASE ACMEDA Automate™ Programming Instructions | Li-ion Tubular Motors | 7
.
Pair motor with controller
Check motor direction
5.1
5.2
Consult user manual for your
controller for information on
selecting channel.
Damage to shade may occur when operating motor prior to
setting limits. Attention should be given.
Reversing motor direction using this method is only possible
during initial set-up
Hold P1 button on
motor head.
To check travel direction of shade, press UP or
DOWN on controller.
Quick Press = Step
Long Press = Continuous Travel
To reverse shade direction, hold both UP and
DOWN.
Until the motor responds.
Select channel on
controller.
Hold STOP on
controller.
Approx.
Approx.
Motor Response
Motor Response
Motor Response
Motor is now in step mode and ready for setting limits
IMPORTANT
IMPORTANT
IMPORTANT
5 INITIAL SET UP
OR
Approx.
2. Select the channel you want to
assign the shade to and hold
STOP on the controller for
approximately two seconds
until the shade jogs two times.
3. Repeat steps 1–2 for
each shade.
Assign a Shade to a Channel
ROLLEASE ACMEDA Automate™ Programming Instructions | Li-ion Tubular Motors | 7
.
Pair motor with controller
Check motor direction
5.1
5.2
Consult user manual for your
controller for information on
selecting channel.
Damage to shade may occur when operating motor prior to
setting limits. Attention should be given.
Reversing motor direction using this method is only possible
during initial set-up
Hold P1 button on
motor head.
To check travel direction of shade, press UP or
DOWN on controller.
Quick Press = Step
Long Press = Continuous Travel
To reverse shade direction, hold both UP and
DOWN.
Until the motor responds.
Select channel on
controller.
Hold STOP on
controller.
Approx.
Approx.
Motor Response
Motor Response
Motor Response
Motor is now in step mode and ready for setting limits
IMPORTANT
IMPORTANT
IMPORTANT
5 INITIAL SET UP
OR
Approx.
MOTOR FOR SOLAR
AND ROLLER SHADES
P1 Button
P1 Button
MOTOR FOR CELLULAR
AND PLEATED SHADES

13
Adjusting Your Shade’s Limits and Favorite Position
ADJUSTING YOUR SHADE’S
LIMITS AND FAVORITE POSITION
Use the instructions in this section to adjust your shade’s upper
and lower limits or favorite position.

14 Adjusting Your Shade’s Limits and Favorite Position
Adjusting the Upper Limit
Before You Start
If your remote currently controls a group of shades, you’ll first need
to put the shades you do not wish to program into Sleep Mode. To
do that, perform the following steps first.
1. To enter Sleep Mode, hold the P1 button on
the motor head for approximately 6 seconds
until the shade jogs twice.
Don’t attempt to move the upper limit to a position higher
than the preset limit—that could damage your shade or
prematurely drain the batteries.
16 | Automate™ Programming Instructions | Li-ion Tubular Motors ROLLEASE ACMEDA
9 SLEEP MODE
Enter Sleep Mode
Sleep mode is utilized to
prevent a motor from incorrect
configuration during other
motor setup.
Hold P1 button on the motor
head
If multiple motors are grouped on a single channel, Sleep Mode may be used to put all but 1 motor to sleep,
allowing programming of just the one motor that remains “Awake”. See page 6 for detailed P1 functions.
Exit Sleep Mode: Method 1
Exit sleep mode once the shade
is ready.
Press and release P1 button on
the motor head
Exit Sleep Mode: Method 2
Remove power and then
re-power the motor.
Motor Response
Motor Response
14 SLEEP MODE
Approx.
ROLLEASE ACMEDA | AUSTRALIA
110 Northcorp Boulevard,
Broadmeadows VIC 3047, AUS
T [phone] | F [phone]
ROLLEASE ACMEDA | USA
Level 7 / 750 East Main Street
Stamford, CT 06902, USA
T [phone] | F [phone]
ROLLEASE ACMEDA | EUROPE
Via Conca Del Naviglio 18,
Milan (Lombardia) Italy
T [phone] | F [phone]
G
15 TROUBLE SHOOTING
Problem Cause Remedy
Motor is not responding Battery in motor is depleted Recharge with a compatible
charger
Insufficient charging from solar
PV panel
Check connection and orientation
of PV panel
Transmitter battery is discharged Replace battery
Battery is inserted incorrectly
into transmitter
Check battery polarity
Radio interference/shielding Ensure transmitter is positioned
away from metal objects and
the aerial on motor or receiver
is kept straight and away from
metal
Receiver distance is too far from
transmitter
Move transmitter to a closer
position
Charging failure Check power supply to motor is
connected and active
Motor beeps x10 when in use Battery voltage is low Recharge with a compatible
charger
Cannot program a single motor
(multiple motors respond)
Multiple motors are paired to the
same channel
Always reserve an individual
channel for programming
functions. Use Sleep Mode to
program individual motors.
rolleaseacmeda.com
2. Repeat step 1 for each shade you want
to put into Sleep Mode.
Shades that are in Sleep Mode will retain their current programming.
MOTOR FOR CELLULAR
AND PLEATED SHADES
ROLLEASE ACMEDA Automate™ Programming Instructions | Li-ion Tubular Motors | 7
.
Pair motor with controller
Check motor direction
5.1
5.2
Consult user manual for your
controller for information on
selecting channel.
Damage to shade may occur when operating motor prior to
setting limits. Attention should be given.
Reversing motor direction using this method is only possible
during initial set-up
Hold P1 button on
motor head.
To check travel direction of shade, press UP or
DOWN on controller.
Quick Press = Step
Long Press = Continuous Travel
To reverse shade direction, hold both UP and
DOWN.
Until the motor responds.
Select channel on
controller.
Hold STOP on
controller.
Approx.
Approx.
Motor Response
Motor Response
Motor Response
Motor is now in step mode and ready for setting limits
IMPORTANT
IMPORTANT
IMPORTANT
5 INITIAL SET UP
OR
Approx.
MOTOR FOR SOLAR
AND ROLLER SHADES
P1 Button
P1 Button

15
Adjusting Your Shade’s Limits and Favorite Position
1. On the remote, hold
UP and STOP for
approximately 5 seconds
until the shade jogs once.
2. Move shade to the desired
highest position by pressing
the UP button.
4. To exit Sleep Mode, press and hold
the P1 button on each applicable
motor until the shade jogs once.
3. To save upper limit, hold UP
and STOP for approximately
5 seconds until the shade
jogs twice.
ROLLEASE ACMEDA Automate™ Programming Instructions | Li-ion Tubular Motors | 9
SEC
SEC
S
S
5
5
Adjust upper limit
Adjust lower limit
6.1
6.2
Hold UP and STOP on
controller.
Hold DOWN and STOP
on controller.
Move shade to the desired
lowest position by pressing
the UP or DOWN button.
Move shade to the desired
highest position by pressing
the UP or DOWN button.
To save upper limit, hold UP
and STOP.
To save lower limit, hold
DOWN and STOP.
Approx.
Approx.
Motor Response
Motor Response Motor Response
Motor Response
6 ADJUSTING LIMITS
SEC SECS S
5 5
Approx. Approx.
The bottom limit should be set ~ 1.38 in. (35mm) below the Ultra-Lock to disengage the auto lock mechanism when the shade is raised.
IMPORTANT
OR
OR
ROLLEASE ACMEDA Automate™ Programming Instructions | Li-ion Tubular Motors | 9
SEC
SEC
S
S
5
5
Adjust upper limit
Adjust lower limit
6.1
6.2
Hold UP and STOP on
controller.
Hold DOWN and STOP
on controller.
Move shade to the desired
lowest position by pressing
the UP or DOWN button.
Move shade to the desired
highest position by pressing
the UP or DOWN button.
To save upper limit, hold UP
and STOP.
To save lower limit, hold
DOWN and STOP.
Approx.
Approx.
Motor Response
Motor Response Motor Response
Motor Response
6 ADJUSTING LIMITS
SEC SECS S
5 5
Approx. Approx.
The bottom limit should be set ~ 1.38 in. (35mm) below the Ultra-Lock to disengage the auto lock mechanism when the shade is raised.
IMPORTANT
OR
OR
16 | Automate™ Programming Instructions | Li-ion Tubular Motors ROLLEASE ACMEDA
9 SLEEP MODE
Enter Sleep Mode
Sleep mode is utilized to
prevent a motor from incorrect
configuration during other
motor setup.
Hold P1 button on the motor
head
If multiple motors are grouped on a single channel, Sleep Mode may be used to put all but 1 motor to sleep,
allowing programming of just the one motor that remains “Awake”. See page 6 for detailed P1 functions.
Exit Sleep Mode: Method 1
Exit sleep mode once the shade
is ready.
Press and release P1 button on
the motor head
Exit Sleep Mode: Method 2
Remove power and then
re-power the motor.
Motor Response
Motor Response
14 SLEEP MODE
Approx.
ROLLEASE ACMEDA | AUSTRALIA
110 Northcorp Boulevard,
Broadmeadows VIC 3047, AUS
T [phone] | F [phone]
ROLLEASE ACMEDA | USA
Level 7 / 750 East Main Street
Stamford, CT 06902, USA
T [phone] | F [phone]
ROLLEASE ACMEDA | EUROPE
Via Conca Del Naviglio 18,
Milan (Lombardia) Italy
T [phone] | F [phone]
G
15 TROUBLE SHOOTING
Problem Cause Remedy
Motor is not responding Battery in motor is depleted Recharge with a compatible
charger
Insufficient charging from solar
PV panel
Check connection and orientation
of PV panel
Transmitter battery is discharged Replace battery
Battery is inserted incorrectly
into transmitter
Check battery polarity
Radio interference/shielding Ensure transmitter is positioned
away from metal objects and
the aerial on motor or receiver
is kept straight and away from
metal
Receiver distance is too far from
transmitter
Move transmitter to a closer
position
Charging failure Check power supply to motor is
connected and active
Motor beeps x10 when in use Battery voltage is low Recharge with a compatible
charger
Cannot program a single motor
(multiple motors respond)
Multiple motors are paired to the
same channel
Always reserve an individual
channel for programming
functions. Use Sleep Mode to
program individual motors.
rolleaseacmeda.com
Adjust the Upper Limit
5. If you need to adjust another shade’s
upper limit, go back to the Before You
Start section and repeat the steps
for each shade.
MOTOR FOR CELLULAR
AND PLEATED SHADES
ROLLEASE ACMEDA Automate™ Programming Instructions | Li-ion Tubular Motors | 7
.
Pair motor with controller
Check motor direction
5.1
5.2
Consult user manual for your
controller for information on
selecting channel.
Damage to shade may occur when operating motor prior to
setting limits. Attention should be given.
Reversing motor direction using this method is only possible
during initial set-up
Hold P1 button on
motor head.
To check travel direction of shade, press UP or
DOWN on controller.
Quick Press = Step
Long Press = Continuous Travel
To reverse shade direction, hold both UP and
DOWN.
Until the motor responds.
Select channel on
controller.
Hold STOP on
controller.
Approx.
Approx.
Motor Response
Motor Response
Motor Response
Motor is now in step mode and ready for setting limits
IMPORTANT
IMPORTANT
IMPORTANT
5 INITIAL SET UP
OR
Approx.
MOTOR FOR SOLAR
AND ROLLER SHADES
P1 Button
P1 Button
ROLLEASE ACMEDA Automate™ Programming Instructions | Li-ion Tubular Motors | 9
SEC
SEC
S
S
5
5
Adjust upper limit
Adjust lower limit
6.1
6.2
Hold UP and STOP on
controller.
Hold DOWN and STOP
on controller.
Move shade to the desired
lowest position by pressing
the UP or DOWN button.
Move shade to the desired
highest position by pressing
the UP or DOWN button.
To save upper limit, hold UP
and STOP.
To save lower limit, hold
DOWN and STOP.
Approx.
Approx.
Motor Response
Motor Response Motor Response
Motor Response
6 ADJUSTING LIMITS
SEC SECS S
5 5
Approx. Approx.
The bottom limit should be set ~ 1.38 in. (35mm) below the Ultra-Lock to disengage the auto lock mechanism when the shade is raised.
IMPORTANT
OR
OR

16 Adjusting Your Shade’s Limits and Favorite Position
Adjusting the Lower Limit
Don’t attempt to move the lower limit to a position lower
than the preset limit—that could damage your shade.
If your remote currently controls a group of shades, you’ll first need
to put the shades you do not wish to program to into Sleep Mode.
To do that, perform the following steps first.
1. To enter Sleep Mode, hold the P1 button on the motor head for
approximately 6 seconds.
Before You Start
1. Hold DOWN and STOP on
controller for approximately
5 seconds until the shade
jogs once.
2. Move shade to the desired
lowest position by pressing
the DOWN button.
3. To save lower limit,
hold DOWN and STOP for
approximately 5 seconds
until the shade jogs twice.
ROLLEASE ACMEDA Automate™ Programming Instructions | Li-ion Tubular Motors | 9
SEC
SEC
S
S
5
5
Adjust upper limit
Adjust lower limit
6.1
6.2
Hold UP and STOP on
controller.
Hold DOWN and STOP
on controller.
Move shade to the desired
lowest position by pressing
the UP or DOWN button.
Move shade to the desired
highest position by pressing
the UP or DOWN button.
To save upper limit, hold UP
and STOP.
To save lower limit, hold
DOWN and STOP.
Approx.
Approx.
Motor Response
Motor Response Motor Response
Motor Response
6 ADJUSTING LIMITS
SEC SECS S
5 5
Approx. Approx.
The bottom limit should be set ~ 1.38 in. (35mm) below the Ultra-Lock to disengage the auto lock mechanism when the shade is raised.
IMPORTANT
OR
OR
ROLLEASE ACMEDA Automate™ Programming Instructions | Li-ion Tubular Motors | 9
SEC
SEC
S
S5
5
Adjust upper limit
Adjust lower limit
6.1
6.2
Hold UP and STOP on
controller.
Hold DOWN and STOP
on controller.
Move shade to the desired
lowest position by pressing
the UP or DOWN button.
Move shade to the desired
highest position by pressing
the UP or DOWN button.
To save upper limit, hold UP
and STOP.
To save lower limit, hold
DOWN and STOP.
Approx.
Approx.
Motor Response
Motor Response Motor Response
Motor Response
6 ADJUSTING LIMITS
SEC SECS S
5 5
Approx. Approx.
The bottom limit should be set ~ 1.38 in. (35mm) below the Ultra-Lock to disengage the auto lock mechanism when the shade is raised.
IMPORTANT
OR
OR
4. If you need to adjust another
shade’s lower limit, go back
to the Before You Start
section and repeat the steps.
Adjust the Lower Limit
ROLLEASE ACMEDA Automate™ Programming Instructions | Li-ion Tubular Motors | 9
SEC
SEC
S
S5
5
Adjust upper limit
Adjust lower limit
6.1
6.2
Hold UP and STOP on
controller.
Hold DOWN and STOP
on controller.
Move shade to the desired
lowest position by pressing
the UP or DOWN button.
Move shade to the desired
highest position by pressing
the UP or DOWN button.
To save upper limit, hold UP
and STOP.
To save lower limit, hold
DOWN and STOP.
Approx.
Approx.
Motor Response
Motor Response Motor Response
Motor Response
6 ADJUSTING LIMITS
SEC SECS S
5 5
Approx. Approx.
The bottom limit should be set ~ 1.38 in. (35mm) below the Ultra-Lock to disengage the auto lock mechanism when the shade is raised.
IMPORTANT
OR
OR
2. Repeat step 1 for each shade you want to put into Sleep Mode.
Shades that are in Sleep Mode will retain their current programming.
MOTOR FOR CELLULAR
AND PLEATED SHADES
ROLLEASE ACMEDA Automate™ Programming Instructions | Li-ion Tubular Motors | 7
.
Pair motor with controller
Check motor direction
5.1
5.2
Consult user manual for your
controller for information on
selecting channel.
Damage to shade may occur when operating motor prior to
setting limits. Attention should be given.
Reversing motor direction using this method is only possible
during initial set-up
Hold P1 button on
motor head.
To check travel direction of shade, press UP or
DOWN on controller.
Quick Press = Step
Long Press = Continuous Travel
To reverse shade direction, hold both UP and
DOWN.
Until the motor responds.
Select channel on
controller.
Hold STOP on
controller.
Approx.
Approx.
Motor Response
Motor Response
Motor Response
Motor is now in step mode and ready for setting limits
IMPORTANT
IMPORTANT
IMPORTANT
5 INITIAL SET UP
OR
Approx.
MOTOR FOR SOLAR
AND ROLLER SHADES
P1 Button
P1 Button

17
Adjusting Your Shade’s Limits and Favorite Position
ROLLEASE ACMEDA Automate™ Programming Instructions | Li-ion Tubular Motors | 9
SEC
SEC
S
S
5
5
Adjust upper limit
Adjust lower limit
6.1
6.2
Hold UP and STOP on
controller.
Hold DOWN and STOP
on controller.
Move shade to the desired
lowest position by pressing
the UP or DOWN button.
Move shade to the desired
highest position by pressing
the UP or DOWN button.
To save upper limit, hold UP
and STOP.
To save lower limit, hold
DOWN and STOP.
Approx.
Approx.
Motor Response
Motor Response Motor Response
Motor Response
6 ADJUSTING LIMITS
SEC SECS S
5 5
Approx. Approx.
The bottom limit should be set ~ 1.38 in. (35mm) below the Ultra-Lock to disengage the auto lock mechanism when the shade is raised.
IMPORTANT
OR
OR
Adjusting the Favorite Position
If your remote currently controls a group of shades, you’ll first need to
put the shades you do not wish to program into Sleep Mode. To do
that, perform the following steps first.
1. To enter Sleep Mode, hold the P1 button on the motor head for
approximately 6 seconds.
Before You Start
2. Press and release P2
on the controller. The
shade will jog once
in response.
1. Move shade to the desired position
by pressing the UP or DOWN button
on the controller.
3. Press and release STOP on the
controller. The shade will jog
once in response.
10 | Automate™ Programming Instructions | Li-ion Tubular Motors ROLLEASE ACMEDA
Using P2 Button on existing controller to add a new controller or channel
Using a pre-existing controller to add or delete a controller or channel
7.1
7.2
A = Existing controller or channel (to keep)
B = Controller or channel to add or remove
A = Existing controller or channel (to keep)
B = Controller or channel to add or remove
Press P2 on
controller A.
Press P2 on
controller A.
Press P2 on
controller A.
Press P2 on
controller A.
Press P2 on the
controller B to remove
it.
Press STOP on an new
controller to add it.
Motor Response
Motor Response
Motor Response
Motor Response
Motor Response
Motor Response
7 CONTROLLERS AND CHANNELS
Consult user manual for your controller or sensor
Consult user manual for your controller or sensor
IMPORTANT
IMPORTANT
ROLLEASE ACMEDA Automate™ Programming Instructions | Li-ion Tubular Motors | 9
SEC
SEC
S
S
5
5
Adjust upper limit
Adjust lower limit
6.1
6.2
Hold UP and STOP on
controller.
Hold DOWN and STOP
on controller.
Move shade to the desired
lowest position by pressing
the UP or DOWN button.
Move shade to the desired
highest position by pressing
the UP or DOWN button.
To save upper limit, hold UP
and STOP.
To save lower limit, hold
DOWN and STOP.
Approx.
Approx.
Motor Response
Motor Response Motor Response
Motor Response
6 ADJUSTING LIMITS
SEC SECS S
5 5
Approx. Approx.
The bottom limit should be set ~ 1.38 in. (35mm) below the Ultra-Lock to disengage the auto lock mechanism when the shade is raised.
IMPORTANT
OR
OR
4. Press and release STOP on
the controller. The shade will
jog twice in response.
ROLLEASE ACMEDA Automate™ Programming Instructions | Li-ion Tubular Motors | 9
SEC
SEC
S
S
5
5
Adjust upper limit
Adjust lower limit
6.1
6.2
Hold UP and STOP on
controller.
Hold DOWN and STOP
on controller.
Move shade to the desired
lowest position by pressing
the UP or DOWN button.
Move shade to the desired
highest position by pressing
the UP or DOWN button.
To save upper limit, hold UP
and STOP.
To save lower limit, hold
DOWN and STOP.
Approx.
Approx.
Motor Response
Motor Response Motor Response
Motor Response
6 ADJUSTING LIMITS
SEC SECS S
5 5
Approx. Approx.
The bottom limit should be set ~ 1.38 in. (35mm) below the Ultra-Lock to disengage the auto lock mechanism when the shade is raised.
IMPORTANT
OR
OR
OR
2. Repeat step 1 for each shade you want to put into Sleep Mode.
Shades that are in Sleep Mode will retain their current programming.
MOTOR FOR CELLULAR
AND PLEATED SHADES
ROLLEASE ACMEDA Automate™ Programming Instructions | Li-ion Tubular Motors | 7
.
Pair motor with controller
Check motor direction
5.1
5.2
Consult user manual for your
controller for information on
selecting channel.
Damage to shade may occur when operating motor prior to
setting limits. Attention should be given.
Reversing motor direction using this method is only possible
during initial set-up
Hold P1 button on
motor head.
To check travel direction of shade, press UP or
DOWN on controller.
Quick Press = Step
Long Press = Continuous Travel
To reverse shade direction, hold both UP and
DOWN.
Until the motor responds.
Select channel on
controller.
Hold STOP on
controller.
Approx.
Approx.
Motor Response
Motor Response
Motor Response
Motor is now in step mode and ready for setting limits
IMPORTANT
IMPORTANT
IMPORTANT
5 INITIAL SET UP
OR
Approx.
MOTOR FOR SOLAR
AND ROLLER SHADES
P1 Button
P1 Button

18 Pairing Your Remotes and Shades
We preprogrammed your remotes to operate your shades.
However, you might decide to adjust the pairing—for example,
you might lose a remote and need to pair a new one, or you
might buy an additional remote after you buy your shades. This
section shows you how to pair remotes and shades for a variety
of control scenarios.
PAIRING YOUR REMOTES
AND SHADES

19
Pairing Your Remotes and Shades
ROLLEASE ACMEDA Automate™ Programming Instructions | Li-ion Tubular Motors | 9
SEC
SEC
S
S
5
5
Adjust upper limit
Adjust lower limit
6.1
6.2
Hold UP and STOP on
controller.
Hold DOWN and STOP
on controller.
Move shade to the desired
lowest position by pressing
the UP or DOWN button.
Move shade to the desired
highest position by pressing
the UP or DOWN button.
To save upper limit, hold UP
and STOP.
To save lower limit, hold
DOWN and STOP.
Approx.
Approx.
Motor Response
Motor Response Motor Response
Motor Response
6 ADJUSTING LIMITS
SEC SECS S
5 5
Approx. Approx.
The bottom limit should be set ~ 1.38 in. (35mm) below the Ultra-Lock to disengage the auto lock mechanism when the shade is raised.
IMPORTANT
OR
OR
Pairing a Remote
Pair a New Remote Using an Existing Remote
This method of pairing will copy all shades paired with the
currently selected channel on an existing remote.
Multiple remotes can be paired to each shade using this method.
These steps apply only to the new remote or shade.
1. Press P2 on the EXISTING
remote. The shade will jog
once in response.
2. Press P2 on the EXISTING
remote. The shade will jog
once in response.
3. Press P2 on the NEW remote.
The shade will jog twice
in response.
10 | Automate™ Programming Instructions | Li-ion Tubular Motors ROLLEASE ACMEDA
Using P2 Button on existing controller to add a new controller or channel
Using a pre-existing controller to add or delete a controller or channel
7.1
7.2
A = Existing controller or channel (to keep)
B = Controller or channel to add or remove
A = Existing controller or channel (to keep)
B = Controller or channel to add or remove
Press P2 on
controller A.
Press P2 on
controller A.
Press P2 on
controller A.
Press P2 on
controller A.
Press P2 on the
controller B to remove
it.
Press STOP on an new
controller to add it.
Motor Response
Motor Response
Motor Response
Motor Response
Motor Response
Motor Response
7 CONTROLLERS AND CHANNELS
Consult user manual for your controller or sensor
Consult user manual for your controller or sensor
IMPORTANT
IMPORTANT
ROLLEASE ACMEDA Automate™ Programming Instructions | Li-ion Tubular Motors | 9
SEC
SEC
S
S
5
5
Adjust upper limit
Adjust lower limit
6.1
6.2
Hold UP and STOP on
controller.
Hold DOWN and STOP
on controller.
Move shade to the desired
lowest position by pressing
the UP or DOWN button.
Move shade to the desired
highest position by pressing
the UP or DOWN button.
To save upper limit, hold UP
and STOP.
To save lower limit, hold
DOWN and STOP.
Approx.
Approx.
Motor Response
Motor Response Motor Response
Motor Response
6 ADJUSTING LIMITS
SEC SECS S
5 5
Approx. Approx.
The bottom limit should be set ~ 1.38 in. (35mm) below the Ultra-Lock to disengage the auto lock mechanism when the shade is raised.
IMPORTANT
OR
OR
10 | Automate™ Programming Instructions | Li-ion Tubular Motors ROLLEASE ACMEDA
Using P2 Button on existing controller to add a new controller or channel
Using a pre-existing controller to add or delete a controller or channel
7.1
7.2
A = Existing controller or channel (to keep)
B = Controller or channel to add or remove
A = Existing controller or channel (to keep)
B = Controller or channel to add or remove
Press P2 on
controller A.
Press P2 on
controller A.
Press P2 on
controller A.
Press P2 on
controller A.
Press P2 on the
controller B to remove
it.
Press STOP on an new
controller to add it.
Motor Response
Motor Response
Motor Response
Motor Response
Motor Response
Motor Response
7 CONTROLLERS AND CHANNELS
Consult user manual for your controller or sensor
Consult user manual for your controller or sensor
IMPORTANT
IMPORTANT
ROLLEASE ACMEDA Automate™ Programming Instructions | Li-ion Tubular Motors | 9
SEC
SEC
S
S
5
5
Adjust upper limit
Adjust lower limit
6.1
6.2
Hold UP and STOP on
controller.
Hold DOWN and STOP
on controller.
Move shade to the desired
lowest position by pressing
the UP or DOWN button.
Move shade to the desired
highest position by pressing
the UP or DOWN button.
To save upper limit, hold UP
and STOP.
To save lower limit, hold
DOWN and STOP.
Approx.
Approx.
Motor Response
Motor Response Motor Response
Motor Response
6 ADJUSTING LIMITS
SEC SECS S
5 5
Approx. Approx.
The bottom limit should be set ~ 1.38 in. (35mm) below the Ultra-Lock to disengage the auto lock mechanism when the shade is raised.
IMPORTANT
OR
OR
10 | Automate™ Programming Instructions | Li-ion Tubular Motors ROLLEASE ACMEDA
Using P2 Button on existing controller to add a new controller or channel
Using a pre-existing controller to add or delete a controller or channel
7.1
7.2
A = Existing controller or channel (to keep)
B = Controller or channel to add or remove
A = Existing controller or channel (to keep)
B = Controller or channel to add or remove
Press P2 on
controller A.
Press P2 on
controller A.
Press P2 on
controller A.
Press P2 on
controller A.
Press P2 on the
controller B to remove
it.
Press STOP on an new
controller to add it.
Motor Response
Motor Response
Motor Response
Motor Response
Motor Response
Motor Response
7 CONTROLLERS AND CHANNELS
Consult user manual for your controller or sensor
Consult user manual for your controller or sensor
IMPORTANT
IMPORTANT

20 Pairing Your Remotes and Shades
Pair a New Remote with a Shade Using
the Motor Program Button
This method of pairing will add individual shades to the currently selected
channel on a new remote.
Multiple remotes can be paired to each shade using this method.
ROLLEASE ACMEDA Automate™ Programming Instructions | Li-ion Tubular Motors | 9
SEC
SEC
S
S
5
5
Adjust upper limit
Adjust lower limit
6.1
6.2
Hold UP and STOP on
controller.
Hold DOWN and STOP
on controller.
Move shade to the desired
lowest position by pressing
the UP or DOWN button.
Move shade to the desired
highest position by pressing
the UP or DOWN button.
To save upper limit, hold UP
and STOP.
To save lower limit, hold
DOWN and STOP.
Approx.
Approx.
Motor Response
Motor Response Motor Response
Motor Response
6 ADJUSTING LIMITS
SEC SECS S
5 5
Approx. Approx.
The bottom limit should be set ~ 1.38 in. (35mm) below the Ultra-Lock to disengage the auto lock mechanism when the shade is raised.
IMPORTANT
OR
OR
ROLLEASE ACMEDA Automate™ Programming Instructions | Li-ion Tubular Motors | 9
SEC
SEC
S
S
5
5
Adjust upper limit
Adjust lower limit
6.1
6.2
Hold UP and STOP on
controller.
Hold DOWN and STOP
on controller.
Move shade to the desired
lowest position by pressing
the UP or DOWN button.
Move shade to the desired
highest position by pressing
the UP or DOWN button.
To save upper limit, hold UP
and STOP.
To save lower limit, hold
DOWN and STOP.
Approx.
Approx.
Motor Response
Motor Response Motor Response
Motor Response
6 ADJUSTING LIMITS
SEC SECS S
5 5
Approx. Approx.
The bottom limit should be set ~ 1.38 in. (35mm) below the Ultra-Lock to disengage the auto lock mechanism when the shade is raised.
IMPORTANT
OR
OR
1. Press and hold P1 on the motor.
The shade will jog once in response.
2. Press and hold STOP on the new
remote to add it. The shade will jog
twice in response.
MOTOR FOR CELLULAR
AND PLEATED SHADES
ROLLEASE ACMEDA Automate™ Programming Instructions | Li-ion Tubular Motors | 7
.
Pair motor with controller
Check motor direction
5.1
5.2
Consult user manual for your
controller for information on
selecting channel.
Damage to shade may occur when operating motor prior to
setting limits. Attention should be given.
Reversing motor direction using this method is only possible
during initial set-up
Hold P1 button on
motor head.
To check travel direction of shade, press UP or
DOWN on controller.
Quick Press = Step
Long Press = Continuous Travel
To reverse shade direction, hold both UP and
DOWN.
Until the motor responds.
Select channel on
controller.
Hold STOP on
controller.
Approx.
Approx.
Motor Response
Motor Response
Motor Response
Motor is now in step mode and ready for setting limits
IMPORTANT
IMPORTANT
IMPORTANT
5 INITIAL SET UP
OR
Approx.
MOTOR FOR SOLAR
AND ROLLER SHADES
P1 Button
P1 Button
