Owner’s
Manual
Introduction (Thanks / Warnings / Records)
Quick Start Guide
Features / Benefits
Controls / Diagrams
Initial Setup
(Placement / Settings)
Operations
Maintenance
LCD Reminders
Cleaning
Disassemby / Assembly
Troubleshooting
Consumer Information
Specifications
Warranty Information
MCI
3
2
13
13
13
8
9
11
8
7
5
4
12

Page 2
Copyright © 2017 Best Living Systems | All Rights Reserved
Introduction
Plug the unit in and turn the power “ON”. DO NOT make any initial adjustments. Allow the unit to run on
the *current mode for at least one week before making any adjustments
*The air purifier is doing its job over a period of time based on the size of the environment and the contamination load.
If the air purifier is louder than you desire, lower the FAN SPEED only. This technology will work extremely
well on the lowest setting. It may take a little longer to remove indoor environmental contaminants.
Place the unit in the larger room of your
environment on a shelf, entertainment center,
bookcase or other piece of furniture above six
(6) feet. (The higher the better)
Ideally placed
6 ft. or higher
AWAY MODE
FAN
POWER

Page 3
Introduction
Thanks
Welcome to a better, healthier environment!
The MCI22K is one of the most advanced air
purification systems on the market today.
Incorporating MCI™Multi-Cluster Ionization*
technology, high level negative ionization, and
electrostatic filtration, the MCI22K reduces
particles and inactivates microbes providing
a cleaner, healthier environment for you and
your family.
The MCI22K is designed to provide years of
trouble-free service when properly maintained.
This manual will guide you through proper
operation of the purier as well as maintenance
procedures. When properly cared for, some parts
of the unit will need replaced. Replacement parts
can be obtained from your authorized distributor
or directly from Best Living Systems, LLC (www.
BestLivingSystems.com)
Thank you for purchasing the MCI22K
by Best Living Systems.
*Fed. Reg. 4, 320, 186 04/2013
Warnings
WARNING: Never operate the unit near
a heat source, open ame, or ammable/
combustable uids.
WARNING: Do not operate the unit
unless the following are properly
installed: DBI CELL, REAR FILTER
ASSEMBLIES and the REAR COVER.
CAUTION: The unit should be powered
o and the POWER CORD should
be disconnected whenever cleaning/
disassembling/reassembling/servicing.
Records
Purchase Date: ________________________________________________________________________
Model Number: ________________________________________________________________________
Serial Number: ________________________________________________________________________
Distributor Name: _____________________________________________________________________
Distributor Phone: ____________________________________________________________________

Page 4
Copyright © 2017 Best Living Systems | All Rights Reserved
Features / Benets
The MCI22K is one of the most advanced and
most versatile whole house air purication
systems on the market today.
Using four advanced technologies, the MCI22K
helps to eliminate odors, smoke, pollen, dust,
bacteria, mold, pet dander, viruses, and much
more. Noticeable pollution is eliminated in
as little as 15 minutes, and the most dicult
pollution in as few as 24 hours.
Unlike other air puriers that have only one or
two ways of eliminating pollution, the MCI22K
has four advanced technologies to destroy
pollution from the air, embedded in walls,
ceilings, oors, carpets, furniture, clothing,
on countertops and other surfaces. These
technologies help to sanitize everything in the
house and reduces or eliminates all odors,
including cigarette smoke, mildew, cooking
odors, and more.
The advanced variable frequency drive fan system
of the MCI22K runs quietly. In addition, the
MCI22K is very low maintenance and requires
no lter replacement. You simply clean the
electrostatic honeycomb and mesh lter with
running water! The MCI22K is ideal for any
room in your home where airborne and surface
pollution may be present.
Four Advanced Technologies
1. Advanced Dielectric Barrier Ionization
(DBI) Cell: The DBI technology in the MCI22K
not only destroys biological contaminates traveling
through the cell, but it produces a purifying plasma
which breaks down odors, mold, bacteria and
viruses throughout the home or oce. Dielectric
Barrier Ionization reactors have been proven to
reduce dangerous pathogens by over 99% in 24
hours or less.
2. Needlepoint Ionization: The MCI22K
generates a continuous stream of millions of
negative ions that circulate throughout the home.
These ions charge particles of dust, dander,
bacteria and viruses; causing them to attract
other particles and clump together. As more
and more particles come together, they become
heavier, making them easier to pull into the
home’s furnace lter or just fall to the oor to be
vacuumed up. Unlike HEPA lters that can lter
out particles of .5 microns or larger, the ionizer in
the MCI22K can reduce ultra-ne particles, even
nano-particles, that are much more dangerous than
the larger particles you can see. This means your
family breathes easier with fewer particles in the
breathing space, less exposure to bacteria, mold
and virus particles as well.
3. Electrostatic Filtration: An advanced
electrostatic lter is included with the MCI22K to
help keep the purier clean while at the same time
lter out particles which clump together thanks
to the needlepoint ionization. Unlike expensive
HEPA lters, the electrostatic lter is washable and
can be used over and over again.
4. Advanced Photo Catalytic Oxidation (PCO)
Cell: The PCO technology in the MCI22K not only
destroys biological contaminates traveling through
the cell, but it produces a purifying plasma which
breaks down odors, mold, bacteria and viruses
throughout the home or oce.
Photo Catalytic Oxidation reactors have been
proven to reduce dangerous pathogens by over
99% in 24 hours or less. The process is molecular
disassociation, which doesn’t just cover up the
source, it actually breaks the molecule down. The
result at the end of the breakdown process is
Carbon Dioxide and Water Vapor.
Additional Information
Model: ........................ Whole House
Maximum Coverage Area: ..... 22,000 Cubic. ft.
Standard Warranty: ....................1 Year
Enhanced Warranty: ..................3 Years
www.BLSWarranty.com

Page 5
Controls / Diagrams
Unit Exterior
Unit Front
Power Plug
Ionization
Brushes
Fan
Front Grille
Pow er
Adapter
Control Panel
Rear Panel
Release Tab
Unit Rear
(Closed)

Controls / Diagrams Continued
Power Plug
Power Button
Power Button
Away Mode
Button
Away Mode Button
Fan Speed
Buttons
Fan Speed Buttons
Purication Level Buttons
Purication Plate
Power Connector
Purication
Plate
PCO Cell
PCO Cell
Power Connector
DBI Cell
Unit Rear
(Open)
Remote
Control
Panel
AWAY MODE
FAN
POWER
PURIFICATION
POWER
AWAY
MODE
0
1
2
3
FAN

Page 7
Initial Setup
Ideal Placement
When selecting a place for the unit within the
environment there are some things to keep in
mind. Find a location in the room(s) as far away
from the HVAC air return duct as possible, so
that the purication produced by the unit is
optimally circulated. Place the unit on top of a
bookshelf, shelf, or mounting bracket as high
as possible leaving twelve to twenty-four inches
between the unit and the ceiling. Make sure that
there is as much space as possible in front of the
unit. Never place an operating unit on the oor.
Initial Settings
Before using the unit you will need to determine
the area (cubic footage) of the environment. Take
into account all rooms which have doors that
normally remain open to the environment as the
purication that the unit produces does not ow
readily through closed doors. The unit can cover a
maximum of 22,000 cubic feet. To estimate your
homes cubic footage, multiple the HxWxD.
For example: Suppose you have a 12,000 cubic
foot house. The living room is attached to the
kitchen, three bedrooms, and a laundry room.
The kitchen and three bedroom doors remain
open the majority of the time but the laundry
room and den usually remain closed o from the
rest of the house. Together, the laundry room and
den have a combined area of 4,000 cubic feet.
The area of your environment would be 8,000
cubic feet.
After you have established the placement of your
unit and the area of the environment, connect
the POWER CORD to the POWER ADAPTER.
Connect the POWER ADAPTER PLUG to the
unit, plug the POWER PLUG into the wall outlet,
turn the unit on (See “CONTROLS”), and set
FAN SPEED to the quiet setting.
Lower settings may be desirable if the
environment is relatively free of pollutants.
A lower setting will still have a high level of
purifying power, but it may take longer to work.

Page 8
CAUTION: Never adjust the setting to
exceed the square footage of the ventilated
space being treated.
Turning the Unit On
Press the POWER BUTTON on the CONTROL
PANEL or REMOTE to turn the unit on.
Controlling Fan Speed
Fan speed can be controlled on both the
machine’s CONTROL PANEL as well as with
the REMOTE.
Three speeds are available (Low, Medium,
High) and are adjusted with the FAN UP/
DOWN buttons.
Purication Level
Purication level is controlled on the REMOTE
and adjusts the output of Activated Oxygen (O3).
Four levels are available and will be signied by
varying colors on the CONTROL PANEL.
LEVEL 0 (0 - 250ft2): LED is OFF.
(Level 0 uses only PCO and
Ionizaition Technology.)
LEVEL 1 (250 - 500ft2): LED is GREEN
LEVEL 2 (500 - 1000ft2): LED is YELLOW
LEVEL 3 (1000 - 1500ft2): LED is RED
Away Mode
Away Mode is used to treat the toughest odors
in your space with higher levels of Activated
Oxygen and Ionization. To activate, press the
AWAY MODE BUTTON on the CONTROL
PANEL or REMOTE.
Away Mode is active for 2 Hours before
reverting back to previous settings.
Operations & Maintenance
DBI Cell Replacement
The DBI CELL does wear out and should
be replaced once per year of constant
use or when the blue LED lamp goes out,
whichever occurs first.
PCO Cell Replacement
The PCO CELL does wear out and should be
replaced at least once per year of constant use.
DO NOT use Away Mode in an occupied
space. Prolonged exposure to Activated
Oxygen may result in temporary
respiratory or eye irritation.

Page 9
Disassembly / Assembly
DISASSEMBLY:
You will need a #1 PHILLIPS SCREWDRIVER.
WARNING! Do not operate the unit unless the
following are properly installed: DBI CELL,
REAR FILTER ASSEMBLY (with all three
pieces in place), and the REAR COVER.
CAUTION! The unit should be powered o and the
POWER CORD should be disconnected whenever
cleaning/disassembling/reassembling/servicing.
1. Turn the unit o. (See “CONTROLS”)
2. Removing The Power Cord:
(a) Unplug POWER CORD from wall outlet.
(b) Remove POWER ADAPTER PLUG from
rear of unit.
3. Clean the exterior of the unit if necessary (See
“CLEANING: UNIT EXTERIOR”).
4. Removing The Rear Cover:
(a) Begin by unplugging the POWER
ADAPTER PLUG from the back of the unit.
(b) Press down on the tab above the
POWER ADAPTER and pull back on the
REAR COVER.
5. Removing The Filter Assembly:
(a) After removing the REAR COVER slide each
of the FILTER ASSEMBLIES straight out.
6. Removing The PCO Cell:
(a) Locate the PCO CELL POWER
CONNECTOR on the right of the rear of the
unit. Squeeze the tabs on the left and right of
the PCO CELL POWER CONNECTOR and
gently pull free.
(b) Gently slide the PCO CELL out of the unit.
Clean if necessary (See “CLEANING: PCO
CELL”) and set the PCO Cell aside.
7. Removing The DBI Cell:
(a) Locate the DBI CELL inside the unit at the
front right side of the unit’s interior.
(b) Gently push the DBI CELL into it’s
POWER CONNECTOR and rotate until it
slightly ejects, then remove.
8. Clean the interior of the unit if necessary (See
“CLEANING: UNIT INTERIOR”).
9. Removing The Front Grille:
(a) Locate the four FRONT GRILLE SCREWS
in the four corners of the FRONT GRILLE.
Using your SCREWDRIVER, carefully remove
the four FRONT GRILLE SCREWS. Place the
FRONT GRILLE SCREWS where you will nd
them easily during reassembly.
(b) Remove the FRONT GRILLE carefully
to ensure that the IONIZATION NEEDLE
(in the left center of the front of the unit) is
not damaged. Clean the FRONT GRILLE if
necessary (using compressed air, vacuum
cleaner, a damp cloth, or warm soapy water)
and set the FRONT GRILLE aside. Clean
the IONIZATION NEEDLE if necessary (See
“CLEANING: IONIZATION NEEDLE”).

Page 10
Copyright © 2017 Best Living Systems | All Rights Reserved
Disassembly / Assembly Cont.
Assembly
You will need a #1 PHILLIPS SCREWDRIVER.
WARNING! Do not operate the unit unless the
following are properly installed: DBI CELL,
REAR FILTER ASSEMBLY (with all three
pieces in place), and the REAR COVER.
CAUTION! The unit should be powered o and the
POWER CORD should be disconnected whenever
cleaning/disassembling/reassembling/servicing.
1. Installing the FRONT GRILLE:
(a) Gently put the FRONT GRILLE in place
on the front of the unit, being careful not to
damage the IONIZATION NEEDLE at the left
center of the front of the unit.
(b) Insert the four FRONT GRILLE SCREWS
one at a time until they are in place, but not
tight. After all four FRONT GRILLE SCREWS
are in place tighten them carefully.
2. Installing the PCO CELL:
(a) Gently slide the PCO CELL - warning side
facing towards you - into its slot and push
until it locks into place.
(b) Align the PCO CELL POWER
CONNECTOR to the PCO CELL POWER
CONNECTOR OUTLET and insert gently until
the tabs at the left and right of the PCO CELL
POWER CONNECTOR lock into place.
3. Installing the DBI CELL:
(a) Gently slide the DBI CELL into the
POWER CONNECTOR, located on the front
right edge of the interior, then push and rotate
until it locks into place.
4. Installing the FILTER ASSEMBLY:
(a) Place each of the FILTER ASSEMBLIES
into their slots on the sides with the solid
framed side facing out.
5. Installing the REAR COVER:
(a) Place the REAR COVER into place with the
hinges along the bottom in between the hinges
of the machine.
(b) Push the REAR COVER into place until
the tab at the top snaps into place.
6. Installing the POWER CORD:
(a) Insert the POWER ADAPTER PLUG into
the rear of the unit.
(b) Ensure the POWER CORD is properly
connected to the POWER ADAPTER
(b) Insert the POWER PLUG into a wall outlet.
7. Turn the unit ON. Ensure that the unit’s
settings are adjusted to suit the environment
(See “OPERATIONS”).

Page 11
Cleaning
WARNING! Do not operate the unit unless the
following are properly installed: DBI CELL,
REAR FILTER ASSEMBLY (with all three
pieces in place), and the REAR COVER.
CAUTION! The unit should be powered o and the
POWER CORD should be disconnected whenever
cleaning/disassembling/reassembling/servicing.
Unit Exterior
Wipe down the exterior with a damp cloth or use
compressed air or a vacuum cleaner to remove
dust. A non-abrasive cleaner may be used on
the surfaces of the exterior, but do not let non-
alcohol based cleaners come in contact with the
IONIZATION NEEDLE at the left center of the
FRONT GRILLE.
Filter Assembly
Clean water or compressed air may be passed
through the lter assemblies or through the
individual parts of the lters when they are
disassembled. To disassemble the FILTER
ASSEMBLIES grasp the assemblies by the sides
of the rim around the lter and carefully separate
the rim from the FILTER ASSEMBLY. The three
lters (mesh, foam, and honeycomb) can then
be removed and cleaned separately. If using
water you must allow the lters to dry separately
before reassembly. When reassembling, the
HONEYCOMB FILTER goes in rst, then the
FOAM FILTER, and nally the thin MESH
FILTER. Then simply reattach the rim to the
FILTER ASSEMBLY.
Ionization Needle
Using a cotton applicator (Q-Tip), apply a small
amount of clear alcohol based cleaner (or rubbing
alcohol) to the IONIZATION NEEDLE. You may
also use compressed air to blow o any dust that
may accumulate near the IONIZATION NEEDLE.
Unit Interior
Using a damp cloth, a clear alcohol based cleaner,
or compressed air/vacuum cleaner carefully clean
the walls and components inside of the unit, after
completing the DISASSEMBLY procedures.
PCO Cell
Using compressed air or a vacuum blow/suck the
dust out of the PCO Cell. Do not use any liquid to
clean the PCO CELL.
DBI Cell
Using compressed air or a vacuum blow/suck the
dust out of the DBI Cell. Do not use any liquid to
clean the DBI CELL.

Page 12
Copyright © 2017 Best Living Systems | All Rights Reserved
Troubleshooting
WARNING! Do not operate the unit unless the
following are properly installed: DBI CELL,
REAR FILTER ASSEMBLY (with all three pieces
in place), and the REAR COVER.
CAUTION! The unit should be powered o and
the POWER CORD should be disconnected
whenever cleaning/disassembling/
reassembling/servicing.
Unit Fails to Turn On
1. Verify that the POWER PLUG is plugged into
an operational wall outlet.
2. Ensure that the POWER CORD is properly
connected to the POWER ADAPTER
3. Ensure that the POWER ADAPTER PLUG is
fully seated in the receptacle on the back of
the unit.
4. Verify the POWER BUTTON has been
activated on the CONTROL PANEL.
5. If POWER BUTTON on the CONTROL
PANEL fails, use the POWER BUTTON
on the REMOTE CONTROL. If the unit
activates when using the POWER BUTTON
on the REMOTE CONTROL but not the
CONTROL PANEL the CONTROL PANEL is
inoperational. Contact your distributor or
Best Living Systems, LLC
(www.BestLivingSystems.com).
The PCO Cell is not Lighting Up
1. Ensure the PCO CELL POWER CONNECTOR
is properly seated in the PCO CELL
POWER CONNECTOR OUTLET (See
“DISASSEMBLY/ASSEMBLY”).
2. If the PCO CELL still fails to properly operate,
you will need to replace it. Contact your
distributor or Best Living Systems, LLC
(www.BestLivingSystems.com).
The DBI Cell is not Lighting Up
1. Ensure the DBI CELL is properly seated in the
DBI CELL POWER CONNECTOR
(See “DISASSEMBLY/ASSEMBLY”).
2. If the DBI CELL still fails to properly operate,
you will need to replace it. Contact your
distributor or Best Living Systems, LLC
(www.BestLivingSystems.com).
Ionization Needle Creates an Electrical Arc
The IONIZATION NEEDLE needs cleaned (See
“CLEANING: IONIZATION NEEDLE”). Be sure to
complete all of the cleaning procedures described
in “CLEANING” every 30 days of operation.
Fan Does Not Operate Properly
1. Try adjusting the fan speed using the
CONTROL PANEL or REMOTE CONTROL
2. Remove the FRONT GRILLE (See
“DISASSEMBLY/ASSEMBLY”) and ensure
there are no obstructions to the movement of
the FAN. Clean it thoroughly and also clean
the mount that it sits on.
3. If FAN continues to operate improperly or not
at all, contact your distributor or
Best Living Systems, LLC
(www.BestLivingSystems.com).

Page 13
Consumer Info / Specs / Warranty
Consumer Information
Best Living Systems declines all responsibility for
all damages arising from improper use of the unit
or in case of tampering with the unit.
Specications
Unit
• Size: 6 3/4” high x 6 1/2” wide x 7” deep
• Weight: 3 lb.
• Coverage: Up to 22,000 Cubic Feet *
Power Cord
• Fuyuang Switching Power Supply
• Model: FY 1503000
• Input: 100-240VAC 50/60Hz 2.5A
• Output: 15VDC 3A
• See the power supply label for certications
and warnings.
PCO Cell
• Normal Mode Output: < 0.02 ppm ozone
(ambient room concentration)
DBI Cell
• Normal Mode Output: Multi-Cluster Ionization
Ionization Needle
• 6 KV DC Needle Ion Generator
* Depending on variables such as the severity and
frequency of pollution, flow of air in the environment,
humidity, and temperature.
LIMITED WARRANTY
Your MCI22K Air Purier is warranted to be free from all defects
in material and workmanship in normal household use for a period
of (1) year from date of purchase. The warranty is granted only
to the original purchaser and members of his or her immediate
household. The warranty is subject to the following provisions.
This warranty does not cover parts of the Air Purier that require
replacement under normal use. This includes the rear lter
assemblies. Although the DBI cell requires periodic replacement,
the cell is warranted for the same 1 year period as the purier.
Any damages or malfunctions caused by negligence, abuse, or
use not in accordance with the Owner’s Manual are not covered
by this warranty. Likewise, any defects or damages caused by
unauthorized service or the use of other than Genuine Best Living
Systems parts are not covered.
Best Living Systems will, at its option, repair or replace a defective
Air Purier or part(s) for the Air Purier that is covered by this
warranty. As a matter of warranty policy, Best Living Systems will
not refund the customer’s purchase price.
To obtain warranty service you must return the defective Air
Purier or Air Purier parts along with proof of purchase to
the Best Living Systems Authorized Warranty Station. All
transportation charges on parts, or units, submitted under this
Warranty shall be borne by purchaser. Unless this Warranty
is expressly renewed or extended by Best Living Systems, any
repaired or replaced part of unit shall be warranted to the original
purchaser only for the length of the unexpired portion of the
original warranty.
Further Limitations And Exclusions Are As Follows
Any warranty that may be implied in connection with your
purchase or use of the Air Purier, including any warranty of
merchantability or any warranty for Fitness For A Particular
Purpose is limited to the duration of this warranty. Some states
do not allow limitations on how long an implied warranty lasts, so
the above limitations may not apply to you.
Your relief for the breach of this warranty is limited to the relief
expressly provided above. In no event shall Best Living Systems
be liable for any consequential or incidental damages you may
incur in connection with your purchase or use of the Air Purier.
Some states do not allow the exclusion or limitation of incidental
or consequential damages, so the above limitation or exclusion
may not apply to you.
This Warranty gives you specic legal rights, and you may also
have other rights which vary from state to state.
Registration
Please register your new Best Living Systems Air Purication
product within 10 days of purchase by visiting www.BLSWarranty.
com. Registering your new Best Living Systems product entitles
you to the most up-to-date Best Living Systems product warranty
and promotion information and discounts on replacements parts.

Page 14
Copyright © 2017 Best Living Systems | All Rights Reserved

Page 15
Copyright © 2017 Best Living Systems | All Rights Reserved

Owner’s
Manual
Introduction (Thanks / Warnings / Records)
Quick Start Guide
Features / Benefits
Controls / Diagrams
Initial Setup
(Placement / Settings)
Operations
Maintenance
LCD Reminders
Cleaning
Disassemby / Assembly
Troubleshooting
Consumer Information
Specifications
Warranty Information
MCI
