Bestop TrekStep Side-Mount User manual

Installation Instructions
INSTALLATION TIME SKILL LEVEL
1 Hour 1 - Easy
TOOLS
Vehicle Application
17 mm,
13 mm 4 mm,
5 mm
www.bestop.com - We’re here to help! Visit our web site and click on “Ask a Question”. Click here for more TruckAccessories by Bestop.
TrekStep Side–Mount™
•Toyota Tundra Crewmax - Passenger Side
5.5' Bed
2007 – Current
Part Number: 75412-15
17 mm,
14 mm

TrekStep Side-Mount™ – Installation Instructions
Rev. G 0115 75412 pg. 2
Parts List and Hardware Identification
Linkage Assembly,
Part Number 484.89,
Qty - 1
Mounting Bracket, Part
Number 490.56, Qty - 1
M6-1.0 x 20 Socket Cap Screw,
Part Number 470.00, Qty -4
M8-1.25 x 20mm Hex Head Screw,
Part Number 460.96, Qty - 3
M8-1.25 Nylock Nut, Part
Number 470.06, Qty - 3
Side Bracket, Part Number
485.61, Qty - 2
M8 x 30mm Set Screw, Part
Number 489.21, Qty - 1
1/4" Spacer, Part
Number 487.64,
Qty - 2
Locking Block, Part Number
489.23, Qty - 1
M10 Split Lock Washer,
Part Number 481.59,
Qty - 2
Remove Bolt
Remove the rear bolt on the rear cab body mount
with a 14mm open end wrench. Save the screw.
M6 Flat Washer,
Part Number
481.96, Qty - 1
M10-1.5 x 45 mm Hex Bolt,
Part Number 484.94, Qty - 2
.5ml Tube Red
Loctite, Qty - 1, Part
Number 309.83
M8 Washer,
Part Number
470.05, Qty - 2
Front Bed
Body Mount
Slot for M6
Screw Rear Cab
Body Mount
Remove
Bolt
Do Not Remove
this nut at any time
during installation
M6-1.0 x 22 Hex Head Screw,
Part Number 490.02, Qty - 1
Running Board Assembly,
Part Number 514.10, Qty - 1

TrekStep Side-Mount™ – Installation Instructions
Rev. G 0115 75412 pg. 3
Install Mounting Bracket
Locate the slot in the frame below the front
bed body mount. Slide the top hole of the
Mounting Bracket over the stud of the front
bed body mount. Position the front hole of
the bracket over the hole in the cab body
mount. Look at the inside of the frame
rail and line up the tapped M6 hole in the
bracket with the slot in the frame. Put an M6
Washer and drop of Loctite on an M6-1.0 X
22 Hex Head Screw.
Thread the screw through the frame and
into the bracket. Insert the bolt from step 1
through the Mounting Bracket and into the
body mount and tighten securely.
Assemble Side Bracket
Position the two Side Brackets back to back as
shown. Secure them with two M8-1.25 X 20mm Hex
Head Screws and two M8-1.25 Nylock Nuts.
Put a drop of Loctite on the M8 X 30mm Set Screw
and thread it into the Lock Block. Slip the Lock
Block over the front edge of the tab that points down
behind the rear tire. Tighten the screw.
Install Lock Block
Slide one end of the Side Bracket
assembly over the set screw and hold in
place with a M8 Washer and M8 Nylock
Nut. Leave the nut loose. Apply a drop
of Loctite to the M8-1.25 X 20mm Hex
Head Screw. Attach the other end of the
Side Bracket Assembly to the back side
of the Mounting Bracket with a M8 screw
and M8 Washer. Tighten the fasteners on
both ends of the Side Bracket Assembly
securely.
Install Side Bracket
Front
Rear Cab Body
Mount Screw Hole
Mounting
Bracket
M6-1.0 x 22 Hex
Head Screw and
M6 Flat Washer
Mounting
Bracket
Front Bed Body
Mount Screw
Side Brackets
M8-1.25 X 20mm Hex Head
Screws and M8-1.25 Nylock
Nuts
Lock
Block
Rear Tire
M8 X 30mm
Set Screw
Lock
Block
Side
Bracket
M8 Washer and
M8 Nylock Nut
Side
Bracket
M8-1.25 X 20mm Hex
Head Screw and M8
Washer

TrekStep Side-Mount™ – Installation Instructions
Rev. G 0115 75412 pg. 4
Put a drop of Loctite on the threads of the
two (2) M10-1.5 X 45mm Hex Head Screws.
Attach the Linkage Assembly to the bottom
of the Mounting Bracket with the M10
screws and M10 Lock Washers.
Install Linkage Mounting
Bracket Use the M6-1.0 x 20 Socket Head Cap Screws to
mount the Step to the Linkage Assembly.
Install Step
Once the Step is installed on the vehicle, you may
adjust it as desired.
If necessary to adjust the height, use the two (2)
1/4" Spacers provided. Remove the M10-15 x
45mm Hex Bolts installed in Step 4 and place the
1/4" Spacers between the Frame Mount and the
Linkage. Reinstall the Hex Bolts.
When the Step is in the desired position tighten all
nuts.
Step Adjustment
Adjust Step if Necessary
Linkage
1/4" Spacer
Linkage
Assembly M6-1.0 x 20 Socket
Head Cap Screws

TrekStep Side-Mount™ – Installation Instructions
Rev. G 0115 75412 pg. 5
LIMITED WARRANTY
We warrant our product to be free from defects in material and workmanship, for the terms specified below, provided there has been normal
use and proper maintenance. This warranty applies to the original purchaser only. All remedies under this warranty are limited to the repair or
replacement of any item or items found by the factory to be defective within the time period specified. If you have a warranty claim, first you must
call our factory at the number below for instructions. You must retain proof of purchase and submit a copy with any items returned for warranty
work. Upon completion of warranty work, if any, we will return the repaired or replaced item or items to you freight prepaid. Damage to our
products caused by accidents, fire, vandalism, negligence, misinstallation, misuse, Acts of God, or by defective parts not manufactured by us, is
not covered under this warranty.
THE WARRANTY TIME PERIOD ISAS FOLLOWS FOR ALL TrekSteps™ MANUFACTURED BY OUR COMPANY: THREE YEARS / 36,000
MILES FROM DATE OF PURCHASE.
ANY IMPLIED WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR PURPOSE CREATED HEREBYARE LIMITED
IN DURATION TO THE SAME DURATION AND SCOPE AS THE EXPRESS WRITTEN WARRANTY. OUR COMPANY SHALL NOT BE LIABLE
FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGE.
Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of incidental or consequential damages,
so the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights, and you may also have other rights which
vary from state to state.
For further information or request for warranty work, please contact:
Bestop Inc. Customer Service
Toll-Free: [phone]
Main: [phone]
E-mail: [email protected]
Website: www.Bestop.com
Operation
• The TrekStep™ is foot operated and deploys and retracts with a
nudge of your foot.
• To deploy, press down using your foot, on the forward outside corner
of the step pad.
• To retract, gently kick the underside of the step pad.
• Max Load Capacity: 400 lbs.
• Always use appropriate hand holds when stepping up to or down
from your truck’s cargo bed.
Care and Maintenance
The step pad surface and linkage arms should be washed with mild soap and
water using a soft brush or sponge to dislodge any mud, dirt or accumulated
road grime. Rinse with fresh water. After it is dry, lubricate the hinge with 3-IN-
ONE Oil.
To prevent slipping, avoid applying waxes, lubricants or protectants likeArmor
All® to the step surface.
Attention!
TrekStep™ SHOULD ALWAYS BE STOWED IN THE RETRACTED
POSITION WHEN DRIVING.
