Bestway H2OGO! JUMP AND SOAR User manual

53395E
www.bestwaycorp.com

WARNING:
• Failure to follow the installation and operating instructions present a risk of serious injury or death.
• Place the inflatable device on level ground, not less than 3m (10ft) in any direction from any structure or
obstruction such as a fence, garage, house, overhanging branches, laundry lines, or electrical wires.
• Do not install inflatable device over concrete, asphalt, packed earth, carpet or any other hard surface. A fall onto a
hard surface can result in serious injury to the user.
• To be used on soft ground only, the impact absorbing material (eg. Rubber mulch, engineered wood fiber (EWF)
etc) shall be at least 2m (6.6ft) from opening in all directions away from the inflatable device.
AIR-BLOWER SAFETY INFORMATION
• READ AND SAVE THESE INSTRUCTIONS
• USE ONLY ON GFCI PROTECTED RECEPTACLES
WARNING - ELECTROCUTION HAZARD: DO NOT USE EXTENSION CORDS
WITH THIS PRODUCT.
• To reduce the risk of fire or electric shock, do not use this air blower with any solid-state speed control device.
• Prevent sharp and hard objects from dropping into and prevent liquid from flowing into the air blower.
• Do not wash the air blower with liquid, you must first unplug it from power source and then wipe it with wet cloth
when you clear it.
• Do not draw and pull motor leads, and do not bump the air blower, you’d better use the air blower between
negative five and fifty centigrade, If you let the air blower be baked in the high temperature, motor leads,
enamelled cables and heating bodies will aging and shorten it’s life.
CAUTION - ELECTRICALLY OPERATED PRODUCT:
NOT RECOMMENDED FOR CHILDREN UNDER14 YEARS OF AGE.
AS WITH ALL ELECTRIC PRODUCTS, PRECAUTIONS SHOULD BE
OBSERVED DURING HANDLING AND USE TO PREVENT ELECTRIC
SHOCK.
KEEP CHILDREN AWAY: Do not allow children to play with or around the unit, in any way, which could result in
injury.
PROTECT POWER CORD FROM DAMAGE: Never operate a unit with a damaged power cord, as this may
lead to electrical or fire hazards. If the power supply cord is damaged, it must be replaced by a cord of the same
type and amperage rating.
Always check the adaptor for any conditions which may result in the risk of fire, electric shock, or injury to persons
and that, in an event such conditions, do not use the product until it was properly repaired.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
• Warning: Any changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
• NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE ASSEMBLING THIS INFLATABLE
DEVICE AND KEEP INSTRUCTIONS FOR FUTURE USE.
FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN
SERIOUS INJURY OR DEATH.
WARNING
WARNING
Electrocution Risk
Keep all electrical lines, radios,
speakers, and other electrical
devices away from inflatable device.
Do not place inflatable device near
or under overhead electrical lines.
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/ TV technician for help.
OPERATION
Place the air blower on a steady net surface where children can be kept away. This air blower is for use on a
nominal 120-volt circuit and has a grounding plug similar to the plug illustrated in sketch (A). Only connect the
product to an outlet having the same configuration as the plug. Do not use an adapter with this product.
KEEP UNIT GROUNDED: Air blower should be grounded. In the event of an electrical short circuit, grounding
reduces the risk of electric shock by providing an escape wire for the electric
current. This product is equipped with a cord having a grounding wire with an
appropriate grounding plug. The plug must be plugged into an outlet that is
properly installed and grounded in accordance with all local codes and ordinances.
WARNING: Improper installation of the grounding plug is able to result in a risk of
electric shock. When repair or replacement of the cord or plug is required, do not
connect the grounding wire to either flat blade terminal.
The wire with insulation having an outer surface that is green with or without
yellow stripes is the grounding wire.
CAUTION: Check with a qualified electrician or serviceman when the grounding
instructions are not completely understood, or when in doubt as to whether the air
blower is properly grounded. Do not modify the plug provided. If it will not fit the
outlet, have the proper outlet installed by a qualified electrician. The appliance
must be positioned so that the plug is accessible. If the supply cord is damaged, it
must be replaced by the manufacture or its service agent or a similarly qualified
person in order to avoid a hazard.
OWNER'S MANUAL
2

GFCI WARNING
WARNING: Risk of electric shock. The GFCI must be tested before each use.
WARNING: Do not use the blower if the GFCI test fails.
RESET
TEST
RESET
TEST
RESET
TEST
1 2 34
GROUNDING METHODS
Grounding Pin
ON/OFF SWITCH
OFF — O
ON — l
WARNING:
• Failure to follow the installation and operating instructions present a risk of serious injury or death.
• Place the inflatable device on level ground, not less than 3m (10ft) in any direction from any structure or
obstruction such as a fence, garage, house, overhanging branches, laundry lines, or electrical wires.
• Do not install inflatable device over concrete, asphalt, packed earth, carpet or any other hard surface. A fall onto a
hard surface can result in serious injury to the user.
• To be used on soft ground only, the impact absorbing material (eg. Rubber mulch, engineered wood fiber (EWF)
etc) shall be at least 2m (6.6ft) from opening in all directions away from the inflatable device.
AIR-BLOWER SAFETY INFORMATION
• READ AND SAVE THESE INSTRUCTIONS
• USE ONLY ON GFCI PROTECTED RECEPTACLES
WARNING - ELECTROCUTION HAZARD: DO NOT USE EXTENSION CORDS
WITH THIS PRODUCT.
• To reduce the risk of fire or electric shock, do not use this air blower with any solid-state speed control device.
• Prevent sharp and hard objects from dropping into and prevent liquid from flowing into the air blower.
• Do not wash the air blower with liquid, you must first unplug it from power source and then wipe it with wet cloth
when you clear it.
• Do not draw and pull motor leads, and do not bump the air blower, you’d better use the air blower between
negative five and fifty centigrade, If you let the air blower be baked in the high temperature, motor leads,
enamelled cables and heating bodies will aging and shorten it’s life.
CAUTION - ELECTRICALLY OPERATED PRODUCT:
NOT RECOMMENDED FOR CHILDREN UNDER14 YEARS OF AGE.
AS WITH ALL ELECTRIC PRODUCTS, PRECAUTIONS SHOULD BE
OBSERVED DURING HANDLING AND USE TO PREVENT ELECTRIC
SHOCK.
KEEP CHILDREN AWAY: Do not allow children to play with or around the unit, in any way, which could result in
injury.
PROTECT POWER CORD FROM DAMAGE: Never operate a unit with a damaged power cord, as this may
lead to electrical or fire hazards. If the power supply cord is damaged, it must be replaced by a cord of the same
type and amperage rating.
Always check the adaptor for any conditions which may result in the risk of fire, electric shock, or injury to persons
and that, in an event such conditions, do not use the product until it was properly repaired.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
• Warning: Any changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
• NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/ TV technician for help.
OPERATION
Place the air blower on a steady net surface where children can be kept away. This air blower is for use on a
nominal 120-volt circuit and has a grounding plug similar to the plug illustrated in sketch (A). Only connect the
product to an outlet having the same configuration as the plug. Do not use an adapter with this product.
KEEP UNIT GROUNDED: Air blower should be grounded. In the event of an electrical short circuit, grounding
reduces the risk of electric shock by providing an escape wire for the electric
current. This product is equipped with a cord having a grounding wire with an
appropriate grounding plug. The plug must be plugged into an outlet that is
properly installed and grounded in accordance with all local codes and ordinances.
WARNING: Improper installation of the grounding plug is able to result in a risk of
electric shock. When repair or replacement of the cord or plug is required, do not
connect the grounding wire to either flat blade terminal.
The wire with insulation having an outer surface that is green with or without
yellow stripes is the grounding wire.
CAUTION: Check with a qualified electrician or serviceman when the grounding
instructions are not completely understood, or when in doubt as to whether the air
blower is properly grounded. Do not modify the plug provided. If it will not fit the
outlet, have the proper outlet installed by a qualified electrician. The appliance
must be positioned so that the plug is accessible. If the supply cord is damaged, it
must be replaced by the manufacture or its service agent or a similarly qualified
person in order to avoid a hazard.
PRODUCT DESCRIPTION
GFCI TEST
Item
53395E
Age
3+
Maximum number of users
3
Maximum weight capacity
250 lbs (113 kg)
Individual weight capacity
83 lbs (37.7 kg)
Critical fall height
62 in. (1.57 m)
Maximum fall height
15 in. (39 cm)
Blower Rating: AC110-120V, 60Hz, 2.8A
3

Placement:
Use on a flat, grassy area only. Do not use on
pavement or hard surfaces. Usage area should be
free of rocks, bumps, holes, sticks, etc. The slide
park setup location should have a minimum
distance of 10ft (305cm) from any free-standing
structures or obstructions. This include: houses,
garages, fences, trees, playground equipment,
large rocks, etc.
SETUP INSTRUCTIONS
ASSEMBLY
WARNING
Follow Anchoring Instructions
User must read and follow anchoring
instructions to ensure the proper:
number of anchors used, soil
conditions, and stake installation.
Yes
Wind Speed Judgement Stake Angle
No Yes No
Place on level ground and firm grass or soil to allow proper use of stakes.
Do not set up the inflatable device on a slope or incline.
Stakes are to be driven straight down until the top of the stake is below ground level. Do not drive stakes at an
angle.
For best holding strength, drive stakes into hard, dry soil. In loose or wet soil, or both, stake holding strength will be
reduced.
Do not use the product if wind speed exceeds 20 mph.
Do not set up in windy or rainy conditions: sudden gust of wind may lift the product off the ground.
Only the blower provided or other manufacturer specified replacement blower should be used for inflation.
Use only with Ground Fault Circuit Interrupter (GFCI) receptacle.
Do not use extension cords with this product and keep the blower and power cord away from water.
Product shall be fully inflated and anchored before use.
ATTENTION: After inflation, the blower should run continuously while children are playing.
5.9ft.(180cm)
5.9ft.(180cm)
safety area
INDOOR USE INSTRUCTION
IMPORTANT
1. The product setup location should have a minimum distance of 5.9ft. (180cm) from any freestanding structures
or obstructions.
2. We recommend adding soft cushions such as rubber, foam and carpet under the product.
3. It is not necessary to use stakes indoors. The product is stable during the usage, and there is no risk of being
lifted by light winds.
10ft.(305cm)
10ft.(305cm)
safety area
4

IMPORTANT: All children must exit the slide park before deflation.
WARNING:
1. Store park in a secure place, away from children, to prevent suffocation. Never leave either the park or the
blower outside when not in use.
2. Please place it the dry and ventilated position where is not sour, not alkali and not corrosive gases. After having
used it in outdoors, you should place it in a dry and ventilated room in time. Do not let water into the air-blower.
1. Turn off the blower motor and unplug it from the outlet.
2. Remove stakes from the park and the blower.
3. Fold the slide park toward the center.
4. Roll up the slide park tightly and compress the fabric to expel all of the remaining air.
5. Slip the carrying bag over the rolled-up inflatable park. Flip the bag and the park over, close the bag, and store
the park and the blower in a dry place.
WARNING
• Constant, competent adult supervision of children and other young users is required at all times in front of the
device where all parts of play areas can be seen.
• Keep the area around the product clean, and clear of objects, to prevent slips and falls.
• Always check all anchors before and during use.
• To prevent electric shock, do not clean the blower with water.
• Children should not wear loose or baggy clothing, scarves, hoods or clothing with drawstrings or long cords while
playing in this product.
• Children must remove helmets, loose clothing, scarves, headgear, shoes and glasses, as well as any sharp or
hard objects from their pockets, as they may puncture the bounding surface.
• Separation of larger children from smaller children. Do not allow children to play together who are unevenly
matched in weight and height.
• Do not allow users to climb or hang on containment walls.
• Do not allow users to do somersaults or rough play.
• Do not allow food, drink or gum inside unit.
• Children must not slide down head first on their stomach.
• Keep pets away from product.
• Do not attach items to the inflatable device that are not specifically designed for use with the inflatable device,
such as, but not limited to, jump ropes, clothesline, pet leashes, cables and chain as they have the potential to
cause a strangulation hazard.
MAINTENANCE OF SLIDE PARK
1. To keep the product clean: wipe the inflatable device using a dry cloth or a cloth dampened with a neutral,
non-flammable, non-toxic cleaning and sanitizing solution or pure water.
2. The inflatable device is subject to wear and deterioration. Inspect for signs of fabric failure; weak or torn surface
must be repaired promptly.
MAINTENANCE OF AIR BLOWER
The source of electrical supply must be disconnected prior to any servicing or cleaning.
1. Use a dry cloth to gently clean all surfaces.
2. Store in a cool, dry place and out of children’s reach.
DEFLATION & STORAGE
REPAIR PATCH INSTRUCTIONS
12
correct
incorrect
or
Replace defective parts in accordance with the instructions.
Please keep for future reference.
5

1. Deflate the item, clean the area and allow to dry thoroughly.
2. Cut a portion of the patch to the size needed and round the corners. (See Fig.1&2).
3. Apply the repair patch:
Option #1: Using the vinyl patch.
Remove the adhesive backing from the patch material, position the patch over the damaged area and smooth out
any bubbles.
Option #2: Using the fabric patch and the glue (not included).
Apply only the amount of glue(not included) needed to cover the repair site and press patch firmly over the puncture.
4. Allow to sit for 30 minutes before re-inflating.
WARNING: Repair patched must be applied by an adult only. Keep out of children.
TROUBLESHOOTING
PROBLEM CAUSE
Motor won’t run
Motor runs but wheel makes a scraping noise
1. Switch not turned on.
2. The circuit is opened or it is poor contact.
3. Electric capacity is damaged.
4. Choked up by hard objects.
1. Screws on the vaned wheel are loose.
2. Foreign objects in air-blower.
1. The voltage is unstable.
2. Motor is affected with damp.
3. Electric capacity is failure.
4. The impeller is loose.
Motor is unable to run normally
1 2 3
001 x 1 002 x 1
005 x 1004 x 8 006 x 1
003 x 2
4
6

5
6
7

303021261637
©2021 Bestway Inflatables & Material Corp.
All rights reserved/Tous droits réservés/Todos los derechos reservados/Alle Rechte vorbehalten/Tutti i diritti riservati
Trademarks used in some countries under license from/
Marques utilisées dans certains pays sous la licence de/
Marcas comerciales utilizadas en algunos países bajo la licencia de/
Die Warenzeichen werden in einigen Ländern verwendet unter Lizenz der/
Marchi utilizzati in alcuni paesi concessi in licenza a
Bestway Inflatables & Material Corp., Shanghai, China
Manufactured, distributed and represented in the European Union by/
Fabriqués, distribués et représentés dans l’Union Européenne par/Fabricado, distribuido y representado en la Unión Europea por/
Hergestellt, vertrieben und in der Europäischen Union vertreten von/Prodotto, distribuito e rappresentato nell'Unione Europea da
Bestway (Europe) S.r.l., Via Resistenza, 5, 20098 San Giuliano Milanese (Milano), Italy
Distributed in North America by/Distribués en Amérique du Nord par/Distribuido en Norteamérica por
Bestway (USA) Inc., 3411 E. Harbour Drive, Phoenix, Arizona 85034, United States of America
Tel: [phone] (For U.S. and Canada)
Distributed in Latin America by/Distribué en Amérique latine par/Distribuido en Latinoamérica por/Distribuído na América Latina por
Bestway Central & South America Ltda, Salar Ascotan 1282, Parque Enea, Pudahuel, Santiago, Chile
Distributed in Australia & New Zealand by Bestway Australia Pty Ltd, Unit 2/98-104 Carnarvon St Silverwater, NSW 2128, Australia
Tel: Australia: ([phone]; New Zealand: 0800 142 101
Distributed in United Kingdom by Bestway Corp UK Ltd. 8 Wentworth Road, Heathfield Industrial Estate, Newton Abbot, Devon, TQ12 6TL
Exported by/Exporté par/Exportado por/Exportiert von/Esportato da
Bestway (Hong Kong) International Ltd./Bestway Enterprise Company Limited
Suite 713, 7/Floor, East Wing, Tsim Sha Tsui Centre, 66 Mody Road, Kowloon, Hong Kong
www.bestwaycorp.com
