WARNING
IMPORTANT SAFETY
INSTRUCTIONS
When installing and using this electrical equipment,
basic safety precautions should always be followed,
including the following:
READ AND FOLLOW ALL
INSTRUCTIONS
WARNING - TO REDUCE THE RISK OF
INJURY, do not permit children to use this product
unless they are closely supervised at all times.
WARNING - RISK OF ELECTRIC SHOCK -
Connect only to a grounding type receptacle protected
by a ground-fault circuit-interrupter (GFCI). Contact a
qualified electrician if you cannot verify that the
receptacle is protected by a GFCI.
CAUTION - To reduce the risk of electric shock the
pool must be installed no closer than 6 feet (1.8 m) from
any electrical outlet. Do not place portable appliances
closer than 5 feet (1.5 m) from the pool.
DO NOT BURY CORD. Locate cord to minimize
abuse from lawn mowers, hedge trimmers, and other
equipment.
WARNING - To reduce the risk of electric shock,
replace damaged cord immediately.
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
WARNING - To reduce the risk of electric shock, do not
use extension cord to connect unit to electric supply;
provide a properly located outlet.
CAUTION: This pump is for use with storable pools
only. Do not use with permanently-installed pools. A
storable pool is constructed so that it is capable of being
readily disassembled for storage and reassembled to its
original integrity. A permanently-installed pool is
constructed in or on the ground or in a building such that
it cannot be readily disassembled for storage.
WARNING -This appliance is not intended for use by
persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person
responsible for their safety. Children should be
supervised to ensure that they do not play with the
appliance.
Electric installations should follow national wiring rules,
consult a qualified electrician with any questions.
The pump is to be supplied by an isolating transformer or
supplied through a residual current device (RCD) having
a rated residual operating current not exceeding 30 mA.
Please examine and verify all sand filter components are
present before use. Notify Bestway at the customer
service address listed on this manual for any damaged
or missing parts at the time of purchase.
• THERMALLY PROTECTED MOTOR. CSA
ENCLOSURE 3.
• FOR USE WITH SWIMMING POOLS ONLY.
• CAUTION: TO ENSURE CONTINUED
PROTECTION AGAINST SHOCK HAZARD, USE
ONLY IDENTICAL REPLACEMENT PARTS WHEN
SERVICING.
• WARNING: RISK OF ELECTRIC SHOCK.
CONNECT ONLY TO A GROUNDING TYPE
RECEPTACLE PROTECTED BY A GROUND-FAULT
CIRCUIT INTERRUPTER (GFCI).
• CAUTION: THIS PUMP IS FOR USE WITH
STORABLE POOLS ONLY - DO NOT USE WITH
PERMANENTLY-INSTALLED POOLS.
• CAUTION: CONNECT ONLY TO GROUNDING
TYPE RECEPTACLE PROTECTED BY A CLASS A
GROUND FAULT CIRCUIT INTERRUPTER.
• CAUTION: FOR CONTINUED PROTECTION
AGAINST POSSIBLE ELECTRIC SHOCK THIS UNIT
IS TO BE MOUNTED TO THE BASE IN
ACCORDANCE WITH THE INSTALLATION
INSTRUCTIONS.
SAVE THESE INSTRUCTIONS.
EN
SAND FILTER
OWNER’S MANUAL
Visit Bestway YouTube channel

4
WARNING
IMPORTANT SAFETY
INSTRUCTIONS
When installing and using this electrical equipment,
basic safety precautions should always be followed,
including the following:
READ AND FOLLOW ALL
INSTRUCTIONS
WARNING - TO REDUCE THE RISK OF
INJURY, do not permit children to use this product
unless they are closely supervised at all times.
WARNING - RISK OF ELECTRIC SHOCK -
Connect only to a grounding type receptacle protected
by a ground-fault circuit-interrupter (GFCI). Contact a
qualified electrician if you cannot verify that the
receptacle is protected by a GFCI.
CAUTION - To reduce the risk of electric shock the
pool must be installed no closer than 6 feet (1.8 m) from
any electrical outlet. Do not place portable appliances
closer than 5 feet (1.5 m) from the pool.
DO NOT BURY CORD. Locate cord to minimize
abuse from lawn mowers, hedge trimmers, and other
equipment.
WARNING - To reduce the risk of electric shock,
replace damaged cord immediately.
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
WARNING - To reduce the risk of electric shock, do not
use extension cord to connect unit to electric supply;
provide a properly located outlet.
CAUTION: This pump is for use with storable pools
only. Do not use with permanently-installed pools. A
storable pool is constructed so that it is capable of being
readily disassembled for storage and reassembled to its
original integrity. A permanently-installed pool is
constructed in or on the ground or in a building such that
it cannot be readily disassembled for storage.
WARNING -This appliance is not intended for use by
persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person
responsible for their safety. Children should be
supervised to ensure that they do not play with the
appliance.
Electric installations should follow national wiring rules,
consult a qualified electrician with any questions.
The pump is to be supplied by an isolating transformer or
supplied through a residual current device (RCD) having
a rated residual operating current not exceeding 30 mA.
Please examine and verify all sand filter components are
present before use. Notify Bestway at the customer
service address listed on this manual for any damaged
or missing parts at the time of purchase.
• THERMALLY PROTECTED MOTOR. CSA
ENCLOSURE 3.
• FOR USE WITH SWIMMING POOLS ONLY.
• CAUTION: TO ENSURE CONTINUED
PROTECTION AGAINST SHOCK HAZARD, USE
ONLY IDENTICAL REPLACEMENT PARTS WHEN
SERVICING.
• WARNING: RISK OF ELECTRIC SHOCK.
CONNECT ONLY TO A GROUNDING TYPE
RECEPTACLE PROTECTED BY A GROUND-FAULT
CIRCUIT INTERRUPTER (GFCI).
• CAUTION: THIS PUMP IS FOR USE WITH
STORABLE POOLS ONLY - DO NOT USE WITH
PERMANENTLY-INSTALLED POOLS.
• CAUTION: CONNECT ONLY TO GROUNDING
TYPE RECEPTACLE PROTECTED BY A CLASS A
GROUND FAULT CIRCUIT INTERRUPTER.
• CAUTION: FOR CONTINUED PROTECTION
AGAINST POSSIBLE ELECTRIC SHOCK THIS UNIT
IS TO BE MOUNTED TO THE BASE IN
ACCORDANCE WITH THE INSTALLATION
INSTRUCTIONS.
SAVE THESE INSTRUCTIONS.

5
SPECIFICATIONS
Filter Diameter:
Effective Fiter Area:
Max. Operating Pressure:
Working sand filter pressure:
Max. Water Temperature:
Sand:
Sand Size:
Sand Capacity:
254 mm
0.05 m2(0.54 ft2)
0.83 Bar(12 PSI)
<0.45 Bar(6.5 PSI)
35°C
Not included
#20 silica sand,0.45-0.85 mm
Approximately 9 kg
254 mm
480 mm
528 mm
PARTS REFERENCE OVERVIEW
Before assembling the sand filter, take a few minutes to
become familiar with all the sand filter parts.
