Better Bathrooms Mojave BeBa 25341 User manual

Multi-person assembly
Tools required
We always recommend using professional
tradespeople to install your product
V2_21.07.21
BeBa_25341 to BeBa_25348
BeBa_27940 to BeBa_27948
Mojave Horizontal Radiator
Please note: Image is for illustrative purposes only and may differ slightly to the
actual product

2
Congratulations on your purchase
And welcome to our growing gang of savvy shoppers
We're on a mission to bring you extraordinary bathroom products, for less. From modern
to traditional style ceramics, plus the gorgeous fixtures, fittings and furniture to match. So,
you can fall in love with your space every single day.
As one of the UK's largest independent bathroom stores, we've received countless
awards; including the National Business Awards UK, the Digital Entrepreneur Awards and
being placed on The Sunday Times Fast Track 100.
We hope your new product exceeds your highest expectations. However, if you
experience any problems, please:
call our friendly UK call centre on 0330 390 3062 (9am-7pm Monday to Friday, or
10am-4pm Saturday and Sunday), or
send us a message via [email protected].uk
Important information
Please read these instructions thoroughly and retain for future reference
Manufactured to BS EN 442-1 Radiators and convectors
Please ensure that the product is checked for damage prior to installation, any
damage reported after installation will not be covered.
The pipework must be flushed out to remove any debris which can affect the
function of this product.
A corrosion inhibitor should be used in your installation.
BTU & Wattage info-
Product Code BTU Wattage Product Code BTU Wattage
BeBa_25341 1198 351 BeBa_27940 1809 530
BeBa_25342 1429 444 BeBa_27941 5242 1536
BeBa_25343 2145 628 BeBa_27942 5874 1721
BeBa_25344 2394 702 BeBa_27943 5874 1721
BeBa_25345 1516 444 BeBa_27944 6852 2008
BeBa_25346 1809 530 BeBa_27945 7831 2295
BeBa_25347 1682 493 BeBa_27946 2781 815
BeBa_25348 1890 554 BeBa_27947 3823 1121
BeBa_27948 5561 1630

3
Parts
A. 1 x Radiator
B. 1 x Air Vent (Bleed Valve)
C. 1 x Blanking Cap
D. 8 x Wall Plug
E. 4 x Wall Bracket
F. 8 x Washer
G. 8 x Wall screw
H. 4 x Wall Bracket Cover
Please note that Parts are for illustrative purposes only and may differ slightly to
the actual product
Tools required
Spanner
Flathead screwdriver
Philips screwdriver
Tape measure
Drill and 8mm drill bit
Spirit Level
Pencil
Sealing tape

4
Installation
Please note: Before starting any installation, turn off the water supply.
Please note: Before commencing any installation, the desired location should be checked
before drilling, that no pipes or wires can be damaged.
First, prepare the water supply pipes to match up with the towel radiator and valve
dimensions being used. Fit the radiator valve tail and nut into the radiator (at both sides)
and using sealing tape, tighten into position, then follow the installation below.
1. Insert the blanking cap and air vent in the top of the radiator at either side, (add a
little sealer tape to secure) and tighten using the spanner, be sure not to
overtighten.
2. Set the position of the wall hanging brackets (on the wall) in relation to the size of
your radiator, the brackets should be located between the last bar and the second
bar in, as shown. Mark these positions on the wall in the required location and use
a spirit level to ensure that these are horizontally and vertically aligned.

5
3. Using the drill and 8mm drill bit, drill into the marked positions then insert the wall
plugs and tap flush to the finished wall surface.
Please note: If drilling into tile, it is recommended to tape the wall to prevent the drill from
slipping.
4. Next, position the wall brackets and screw into place using the screws provided
(securing each with a washer) with the Philips screwdriver. Then place the bracket
covers over the curved section of the bracket which sits between the radiator and
the bracket.
5. Once all brackets are secure, hang the radiator until fixed firmly into place and
adjust so that the radiator aligns with the pipework.
Please note: You may need two people to hang the radiator, depending on the model
purchased.

6
6. Finally, fit the radiator valves to the pipework and connect to the radiator valve tail
and tighten all connections.
IMPORTANT! The product is supplied un-filled.
The radiator should be filled with a water (80%) and glycol (20%) mixture if NOT being
connected to the central heating system, also allow 5% air gap.
After installation
After the above installation, turn on the water supply and using the flathead
screwdriver, open the air vent via the central screw, open the inlet valve and let the
water rush into the radiator. Check all connections for leaks.
Once water overflows from the air vent, this means that there will be no air bubbles
present.
Use a screwdriver to close the air vent and then the radiator is ready to use.
Cleaning
This radiator is made from steel with a painted finish. To maintain the surface of your
product, wipe with a clean damp cloth and wipe dry.
Do not use abrasive cleaning agents or materials which can strip and scratch the surface;
the use of these agents or materials can invalidate your guarantee.
It is recommended to wipe and dry on a regular basis.
