THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date 2017-04-24 Rev. 0001-A Factory: KONRIC
Modern Farmhouse Tower
Stock # BH17-084-098-48
# BH17-084-099-97
ADULT ASSEMBLY REQUIRED
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our customer service number and have your instructions
and parts list ready to provide the model name, part name or factory number:
866-942-5362
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
Or visit our web site 24 hours a day, 7 days a week for product assistance at
www.whalenstyle.com
Or e-mail your request to [e-mail]
LOT NUMBER:
DATE PURCHASED: / /

2
MANUFACTURER: Whalen Furniture Manufacturing
CATALOG: Modern Farmhouse Tower
MODEL # BH17-084-098-48 / BH17-084-099-97
MADE IN CHINA
How to adjust the European adjustable hinges on doors
Shipping may cause doors to become out of alignment. If you find that the doors need to be
adjusted slightly, turn the appropriate screw as illustrated below.
1. TO ADJUST THE DOOR FORWARD OR
BACKWARD.
2. TO ADJUST THE DOOR TO RIGHT OR
TO LEFT.
3. TO ADJUST THE DOOR UP OR DOWN.
MAXIMUM RECOMMENDED WEIGHT LOADS
MAXIMUM LOAD 50 lb. (22.6 kg)
THIS UNIT IS INTENDED ONLY FOR USE WITHIN THE MAXIMUM
WEIGHTS INDICATED. USE WITH LOADS HEAVIER THAN THE MAXIMUM WEIGHTS
INDICATED MAY RESULT IN INSTABILITY, CAUSING POSSIBLE INJURY.

3
IMPORTANT
Before you begin: Open, identify and count all parts prior to assembly. Lay out parts on a flat and non-
abrasive surface. You will need the parts identified on page 4 and 5 of this instruction manual.
NOTE: IT IS VERY IMPORTANT TO USE GLUE WITH DOWELS. EXCESS GLUE CAN BE WIPED OFF
WITH DAMP CLOTH.
Insert Dowel at least half way by tapping lightly with a rubber mallet IF NECESSARY.
CAM LOCK SYSTEM OPERATION
HOW THE KNOCK DOWN (KD) ASSEMBLY SYSTEM WORKS
1. Screw Cam Bolt into the pre-drilled small holes on panel. Connect both panels together; making sure Cam
Bolt goes into pre-drilled hole on the end of panel with Cam Lock.
2. Insert Cam Lock into pre-drilled large hole on panel. Make sure arrow on Cam Lock is pointed toward
Cam Bolt.
3. Once Cam Bolt is connected inside Cam Lock, take a Phillips screwdriver and tighten Cam Lock clockwise.
4. Plug Cam Cap into the cross slot of the Cam Locks to conceal the cam.
You are now ready to assemble the KD unit.
XX
FINAL
1 2 43
p

4
Parts and Hardware List
Please read completely through the instructions and verify that all listed parts and hardware are present
before beginning assembly.
A- Top Panel B- Left Upper Side Frame C- Right Upper Side Frame
(Qty. 1) (Qty. 1) (Qty. 1)
D- Fixed Shelf (Qty. 1) E- Left Lower Side Frame (Qty. 1) F- Right Lower Side Frame (Qty. 1)
G- Bottom Panel (Qty. 1) H- Top Front Stretcher (Qty. 1) I- Middle Back Stretcher (Qty. 1)
J- Bottom Front Stretcher (Qty. 1) K- Upper Adjustable Shelf (Qty. 3) L- Lower Adjustable Shelf (Qty. 1)
M- Door (Qty. 1) N- Upper Back Panel (Qty. 1) O- Lower Back Panel (Qty. 1)

5
Parts and Hardware List
Please read completely through the instructions and verify that all listed parts and hardware are present
before beginning assembly.
(1) Cam Lock (2) Cam Bolt (3) M8 x 30 mm Wood Dowel
(Qty. 22+1 extra) (Qty. 22+1 extra) (Qty. 26+1 extra)
(4) M4 x 38 mm Screw (5) M3.5 x 15 mm Flat Head Screw (6) M3.5 x 15 mm Washer Head Screw
(Qty. 3+1 extra) (Qty. 2+1 extra) (Qty. 34+1 extra)
(7) Door Stopper (Qty. 1) (8) Shelf Pin (Qty. 16+1 extra) (9) Cam Lock Cover (Qty. 32+1 extra)
(10) #3 x 5/8” Zinc Screw (Qty. 8+1 extra) Glue (Qty. 1)
Touch-up Pen (Qty. 1) Tipping Restraint Hardware Kit (1)
(Included in plastic bag)
Tools required: Phillips screwdriver and hammer (not provided).

6
Assembly Instructions
1. Unpack the unit and confirm that you have all the hardware and required parts listed. Assembly the unit
on a carpeted floor or the empty carton to avoid any scratch.
2. Securely screw the Cam Bolts (2) into the designated small holes on the Top Panel (A), the Upper Side
Frames (B and C), the Lower Side Frames (E and F) and the Bottom Front Stretcher (J).
Cam Bolt
(13 used in this step)
②
2
B
C
A
E
F
J

7
Assembly Instructions
3. Securely screw the Cam Bolts (2) into the designated small holes on the Fixed Shelf (D) at both sides.
4. With the pilot holes as a guide, fasten the Door Stopper (7) to the Fixed Shelf (D) using two 15 mm Flat
Head Screws (5).
Cam Bolt
(9 used in this step)
②
Door Stopper
(1 used in this step)
⑦
M3.5 x 15 mm Flat Head Screw
(2 used in this step)
⑤
2
5
7
D
D

8
Assembly Instructions
5. Insert two Wood Dowels (3) into the large holes on the front edge of Top Panel (A). Tap in with a
rubber mallet, if necessary. Make sure that you use a small amount of glue with both ends of all dowels.
6. Align the drilled holes on the Top Front Stretcher (H) with the inserted Wood Dowels (3) on Top Panel
(A), and then press them together. Secure the Top Front Stretcher (H) in place with three 38 mm Screws
(4) using a Phillips screwdriver.
Wood Dowel
(2 used in this step)
③
M4 x 38 mm Screw
(3 used in this step)
④
3
3
4
A
H

9
Assembly Instructions
7. Attach the Bottom Front Stretcher (J) to the Bottom Panel (G) with two 30 mm Wood Dowels (3) and
one Cam Lock (1).
J
G
3
31
M8 x 30 mm Wood Dowel
(2 used in this step)
③
Cam Lock
(1 used in this step)
①

10
Assembly Instructions
8. Attach the Bottom Panel assembly between the Lower Side Frames (E and F) with six 30 mm Wood
Dowels (3) and six Cam Locks (1).
3
3
1
1
F
G
E
J
Wood Dowel
(6 used in this step)
③
Cam Lock
(6 used in this step)
①

11
Assembly Instructions
9. Glue four Wood Dowels (3) into the top inner holes of the Lower Side Frames (E and F).
10. Position the Fixed Shelf (D) onto the inserted Wood Dowels (3) and attach it into place by engaging
four Cam Locks (1).
Wood Dowel
(4 used in this step)
③
Cam Lock
(4 used in this step)
①
3
1
F
E
D

12
Assembly Instructions
11. Attach the Middle Back Stretcher (I) between the Upper Side Frames (B and C) with two 30 mm Wood
Dowels (3) and two Cam Locks (1).
Wood Dowel
(2 used in this step)
③
Cam Lock
(2 used in this step)
①
1
C
B
I
3

13
Assembly Instructions
12. Combine the side frame assemblies together with six 30 mm Wood Dowels (3) and five Cam Locks (1).
Wood Dowel
(6 used in this step)
③
Cam Lock
(5 used in this step)
①
1
3
C
B
D
I

14
Assembly Instructions
13. Glue four Wood Dowels (3) into the top inner holes of the Side Frames (B and C).
14. Position the Top Panel (A) onto the inserted Wood Dowels (3) and attach it into place by engaging four
Cam Locks (1).
Wood Dowel
(4 used in this step)
③
Cam Lock
(4 used in this step)
①
3
1
C
B
A

15
Assembly Instructions
15. Now, go back and securely tighten all the Cam Locks and Wood Screws. Make sure all the parts are
tight and there are no gaps between the parts. This will help keep the unit square.
16. Unfold the Back Panels (N and O) and lay them to the back of the assembled unit. Make sure the
margins along all edges of Back Panels are equal. Screw the 15 mm Washer Head Screws (6) into the
pre-drilled small holes on the Back Panels (N and O).
NOTE: We recommend attaching back panels with the screws at the corners first.
M3.5 x 15 mm Washer Head Screw
(34 used in this step)
⑥
6
C
F
A
D
N
O
N
O

16
Assembly Instructions
17. Stand the assembled unit upright.
18. Pick up the Door Panel (M) and fasten the Hinge Bases to the hinge supports with four 5/8” Zinc
Screws (10) in each. DO NOT fully tighten the screws.
19. Open and close the door to make sure it is aligned and shut correctly. If necessary, adjust the screws for
a good fit. Refer to the hinge sticker on the door for adjustment.
EF
M
10
#3 x 5/8” Zinc Screw
(8 used in this step)
⑩

17
Assembly Instructions
20. Insert the Shelf Pins (8) into the desired holes in the side frames (B, C, E and F). Make sure that you
place the four Shelf Pins in the same level so the shelf is not tilted. Tilt and rest the Adjustable Shelves
(K and L) onto the Shelf Pins.
21. Plug the Cam Lock Covers (9) onto the visible cams locks to conceal the cams.
Shelf Pin
(16 used in this step)
⑧
K
K
K
L
8
8
9
EF
BC
Cam Lock Cover
(32 used in this step)
⑨

18
Assembly Instructions
Tools required: Phillips screwdriver, power drill, 3/8” drill bit and rubber mallet.
22. Ask for assistance to position the tower at the desired location against a wall. If necessary, adjust the
pre-attached floor levelers at the bottom of the tower to level the unit. Now, follow the instructions
printed on the plastic bag containing the tipping restraint Hardware to attach the tip-over restraints to
the unit and the wall.
NOTE: Young children can be seriously injured by tipping furniture. You must install the Tipping
Restraint Hardware with the unit to prevent the unit from tipping, causing any accidents or damage. The
tipping restraint is intended only as a deterrent, they are not a substitute for proper adult supervision.
The tipping restraint is not an earthquake restraint. If you wish to add the extra security of earthquake
restraints, they must be purchased and installed separately.
23. The tower is now ready for use.

19
Care and Maintenance
Use a soft, clean cloth that will not scratch the surface when dusting.
Use of furniture polish is not necessary. Should you choose to use polish, test first in an inconspicuous area.
Using solvents of any kind on your furniture may damage your furniture’s finish.
Never use water to clean your furniture as it may cause damage to the finish.
Always use coasters under beverage glasses and flowerpots.
Liquid spills should be removed immediately. Using a soft, clean cloth, blot the spill gently. Avoid rubbing.
Always use protective pads under hot dishes and plates. Heat can cause chemical changes that may create
spotting within the furniture finish.
Stains or marks from crayons or ink markers will be difficult to remove.
In the event that your furniture is stained or otherwise damaged during use, we recommend that you call a
professional to repair your furniture.
Check bolts/screws periodically and tighten them if necessary.
Further Advice about Wood Furniture Care
It is best to keep your furniture in a climate-controlled environment. Extreme temperature and humidity
changes can cause fading, warping, shrinking and splitting of wood. It is advised to keep furniture away from
direct sunlight as sun may damage the finish.
Proper care and cleaning at home will extend the life of your purchase. Following these important and helpful
tips will enhance your furniture as it ages.
A touch-up pen has been provided to repair any small nicks or scratches that may occur during
assembly or shipping.
We hope you enjoy your purchase for many years.
Thank you for your purchase!
QUALITY GUARANTEE
We are confident that you will be delighted with your Whalen Furniture purchase.
Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace
it for up to one (1) year from date of purchase. Every Whalen Furniture product is designed to meet your
highest expectations. We guarantee that you will immediately see the value of our fine furniture.
This warranty gives you specific legal rights and you may also have other rights which vary from State to State.
Customer Service: 866-942-5362
8:30 a.m. - 4:30 p.m., PST, Monday to Friday
www.whalenstyle.com
