Teknik 5412885 User manual

Something to write
home about.
www.teknikoffice.co.uk
Writing Table Cinnamon Cherry
| Model 5412885
Teknik

Table of Contents Assembly Tools Required
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
No. 2 Phillips Screwdriver
Tip Shown Actual Size
3
4
5-15
16-18
19-21
22
23
Skip the power trip.
This time.
Page 2

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
Now you know
our ABCs.
A END (2)
B RIGHT UPRIGHT (1)
C LEFT UPRIGHT (1)
D TOP (1)
E DRAWER BOX FRONT (1)
F RIGHT DRAWER SIDE (1)
G LEFT DRAWER SIDE (1)
H DRAWER BACK (1)
I DRAWER BOTTOM (1)
J BACK (1)
K RIGHT FRONT (1)
L LEFT FRONT (1)
M STRETCHER (2)
N RIGHT FRONT/LEFT REAR LEG (2)
O LEFT FRONT/RIGHT REAR LEG (2)
P DRAWER FRONT (1)
A
B
C
D
E
K
H
I
A
F
G
J
L
M
M
N
N
O
O
P
Page 3www.sauder.com412885

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
Page 4
HIDDEN CAM - 13
1CAM SCREW - 13 2WOOD DOWEL - 20 3
BLACK 2" FLAT HEAD SCREW - 16
11 BLACK 1-1/2" FLAT HEAD SCREW - 4 12
BLACK 1-1/8" PAN HEAD SCREW - 12
13 BLACK 1" PAN HEAD SCREW - 3 14
BLACK 3/4" MACHINE SCREW - 2
15 BLACK 1/2" FLAT HEAD SCREW - 14 16
SCREW COVER
CARD - 1
5
CAM COVER
CARD - 1
4
PULL - 1
6LEFT CABINET RAIL - 1
18
RIGHT CABINET RAIL - 1
17
LEFT DRAWER SLIDE - 1
20
RIGHT DRAWER SLIDE - 1
19

Step 1
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å Turn thirteen CAM SCREWS (2) into the TOP (D).
2(13 used)
D
Page 5

Step 2
å Insert twenty WOOD DOWELS (3) into the holes in the
edges of the ENDS (A), UPRIGHTS (B and C), BACK (J),
FRONTS (K and L), and STRETCHERS (M).
3
(20 used)
Page 6
J
A
A
L
M
M
K
C
B

Step 3
Page 7
å Fasten the ENDS (A) to the BACK (J). Use two BLACK 2" FLAT
HEAD SCREWS (11).
å Fasten the FRONTS (K and L) to the ENDS (A). Use two BLACK
2" FLAT HEAD SCREWS (11).
å Fasten the UPRIGHTS (B and C) to the BACK (J) and FRONTS (K
and L). Use four BLACK 2" FLAT HEAD SCREWS (11).
J
A
A
L
K
B
C
Finished edge
Finished edge
BLACK 2" FLAT HEAD SCREW
(8 used in this step)
11

Step 4
Page 8
å Push thirteen HIDDEN CAMS (1) into the ENDS (A),
UPRIGHTS (B and C), BACK (J) and FRONTS (K and L).
å Fasten the ENDS (A), UPRIGHTS (B and C), BACK (J)
and FRONTS (K and L) to the TOP (D). Tighten thirteen
HIDDEN CAMS.
å NOTE: Be sure the WOOD DOWELS in the ENDS,
UPRIGHTS, BACK and FRONTS insert into the holes in
the TOP.
D
L
K
B
C
J
A
A
1
2
The arrow in the HIDDEN
CAM must point toward the
hole in the edge of the board.
Arrow
1
(13 used)

Step 5
Page 9
å Fasten the RIGHT CABINET RAIL (17) to the RIGHT
UPRIGHT (B) and the LEFT CABINET RAIL (18) to the
LEFT UPRIGHT (C). Use eight BLACK 1/2" FLAT HEAD
SCREWS (16) through the exact holes shown below.
BLACK 1/2" FLAT HEAD SCREW
(8 used in this step)
16
Roller end
17
18
B
C
17
18
Use these holes.
Use this hole.
Use these holes.
Use this hole.

Step 6
Page 10
å Fasten two LEGS (N and O) to the ENDS (A). Use two
BLACK 2" FLAT HEAD SCREWS (11).
å NOTE: Be sure the WOOD DOWELS in the ENDS insert
into the holes in the LEGS.
å Fasten the BACK (J) to the LEGS (N and O). Use six
BLACK 1-1/8" PAN HEAD SCREWS (13).
A
A
O
N
BLACK 2" FLAT HEAD SCREW
(2 used for the LEGS)
11
J
BLACK 1-1/8" PAN HEAD SCREW
(6 used for the BACK)
13

Step 7
Page 11
å Fasten the STRETCHERS (M) to the LEGS (N and O).
Use two BLACK 2" FLAT HEAD SCREWS (11).
å NOTE: Be sure the WOOD DOWELS in the
STRETCHERS insert into the holes in the LEGS.
å Fasten the remaining LEGS (N and O) to the ENDS (A)
and STRETCHERS (M). Use four BLACK 2" FLAT
HEAD SCREWS (11).
å NOTE: Be sure the WOOD DOWELS in the ENDS and
STRETCHERS insert into the holes in the LEGS.
å Fasten the FRONTS (K and L) to the LEGS (N and O).
Use six BLACK 1-1/8" PAN HEAD SCREWS (13).
A
M
A
M
O
N
N
O
Unfinished edge
BLACK 2" FLAT HEAD SCREW
(6 used in this step)
11
Unfinished edge
L
K
BLACK 1-1/8" PAN HEAD SCREW
(6 used for the FRONTS)
13

Step 8
Page 12
å Fasten the DRAWER SIDES (F and G) to the DRAWER
BACK (H) as shown in the upper diagram. Use two
BLACK 1-1/2" FLAT HEAD SCREWS (12).
å Slide the DRAWER BOTTOM (I) into the grooves in the
DRAWER SIDES (F and G) and DRAWER BACK (H) as
shown in the lower diagram.
HF
G
HF
GI
Finished surface
Groove
BLACK 1-1/2" FLAT HEAD SCREW
(2 used in this step)
12

Step 9
Page 13
å Fasten the PULL (6) to the DRAWER FRONT (P) as shown in the upper diagram. Use two BLACK 3/4" MACHINE
SCREWS (15) through the DRAWER FRONT and into the PULL.
å Fasten the DRAWER BOX FRONT (E) to the DRAWER SIDES (F and G) as shown in the lower diagram. Use two BLACK
1-1/2" FLAT HEAD SCREWS (12).
å NOTE: Be sure the DRAWER BOTTOM (I) inserts into the DRAWER BOX FRONT groove.
å Fasten the DRAWER FRONT (P) to the DRAWER BOX FRONT (E). Use three BLACK 1" PAN HEAD SCREWS (14).
E
F
G
P
P6
I
BLACK 1-1/2" FLAT HEAD SCREW
(2 used in this step)
12
BLACK 3/4" MACHINE SCREW
(2 used for the PULL)
15
BLACK 1" PAN HEAD SCREW
(3 used for the DRAWER FRONT)
14

Step 10
Page 14
G
19
20
F
Roller end
BLACK 1/2" FLAT HEAD SCREW
(6 used in this step)
16
å Carefully turn your drawer over onto its top edges.
å Fasten the RIGHT DRAWER SLIDE (19) to the RIGHT
DRAWER SIDE (F) and the LEFT DRAWER SLIDE (20) to
the LEFT DRAWER SIDE (G). Use six BLACK 1/2" FLAT
HEAD SCREWS (16).
Use these holes. Use these holes.
19 20

Step 11
Page 15
å Carefully stand your unit upright.
å To insert the drawer into your unit, tip the front of the drawer down and drop the rollers on the drawer behind the
rollers on the unit. Lift the front of the drawer up and slide it into the unit.
å Peel the COVERS from the CAM COVER CARD (4) and stick one onto each visible HIDDEN CAM.
å Peel the COVERS from the SCREW COVER CARD (5) and stick one onto each visible SCREW head.
å NOTE: Please read this back page of the instruction booklet for important safety information.
å This completes assembly. Clean with your favorite furniture polish or a damp cloth. Wipe dry.
5
40 lbs.
40 lbs.
5 lbs.
5 lbs.
Place the roller on the SLIDE
behind the roller on the RAIL.
To make drawer adjustments, loosen
the front SCREWS, make needed
adjustments, then tighten the SCREWS.
To cover visible
SCREW heads
To cover visible
HIDDEN CAMS
4

WARNING
Please use your furniture correctly and safely. Improper use can cause safety hazards,
or damage to your furniture or household items. Carefully read the following chart.
Look out for: What can happen: How to avoid the problem:
• Overloaded drawers or shelves. • Risk of injury.
• Top-heavy furniture can tip over.
• Overloaded drawers or shelves can break.
• Never exceed the weight limits shown in
the instructions.
• Work from bottom to top when loading
shelves and drawers. Place the heavier
items on the lower shelves or in lower
drawers.
• Placing TVs on furniture items that are not
designed to support a television is
hazardous.
• Risk of injury or death. TVs can be very
heavy. Plus the weight and location of the
picture tube tends to make TVs unbalanced
and prone to tipping forward.
• This product is not designed to support a
television.
