LED MIRROR WITH WIRELESS
CHARGING SHELF
BeBa_27008
BeBa_27009
•CONTACTLESS CONTROL
•LED ILLUMINATION
•WIRELESS PHONE CHARGER
•DEMISTER
•IP44 INGRESS PROTECTION

2
CONGRATULATIONS ON YOUR PURCHASE
Our aim at Better Bathrooms is to bring you extraordinary bathroom products, for less.
If you’re after a modern, traditional, or a totally unique style bathroom, we have the fittings
and fixtures to bring your ideas to life, so you can fall in love with your space every day.
We hope you’re happy with your new product. But if you experience any problems, we’re
always here to help.
•Call our friendly UK call centre on 0330 390 3062
(Lines open 9am-4.30pm Monday to Friday, or 9am-2pm Saturday).
•Send us a message via betterbathrooms.com.
CONTENTS
SAFETY
3
BATHROOM ZONES
4
PARTS SUPPLIED
5
TOOLS REQUIRED
5
INSTALLING THE MIRROR
6
PRODUCT OVERVIEW
7
OPERATION
7
CLEANING AND MAINTENANCE
8
TECHNICAL SPECIFICATIONS
8

3
SAFETY
•This mirror should be installed by a qualified electrician.
•This fitting is only suitable for connection to a 220-240V earthed supply
in accordance with current IEE wiring regulations, and should be
installed in accordance with local Building Regulations.
•This is for domestic, indoor use only.
•The fitting should be connected to a dedicated lighting circuit which
must be protected by a 5-amp fuse (or a 6-amp miniature circuit
breaker).
•Before installing the fitting ensure the mains supply is switched off, and
that the appropriate fuse is removed (or appropriate circuit breaker is
switched off) before commencing installation. Ensure that measures
are taken to prevent the supply from being inadvertently reconnected.
•If there is a “Minimum Distance” Label, please do not allow Flammable
Materials to come within that distance from the unit.
•This product may contain delicate parts –be careful during handling
and maintenance to avoid breakage.
•If any modification is made to the fitting it will invalidate the warranty
and may render the product unsafe.
•A defective appliance may cause electric shock. Never switch on a
defective or damaged appliance. Disconnect the appliance from the
mains before seeking assistance.
•This product is IP44 rated, and no part of the installation is allowed to
be within bathroom Zones 0 or 1. Installation is permitted within Zone
2.
•This product must be earthed. Before commencing installation, ensure
that there are no pipes or wires located behind the wall that may be
damaged during drilling.
•Ensure that the hanging location has been decided upon and marked
clearly to avoid unwanted damage in the wall due to incorrect
positioning.
•Check that the mirror is not damaged prior to installation.
•Take care unpacking, do not use a sharp blade to open as this may
damage the mirror and void your warranty.
•Installation must only be carried out by a qualified professional or
electrician.

4
BATHROOM ZONES
Zone 0:
The interior of the bathtub or shower basin.
Zone 1:
The area around the bathtub or shower basin up
to a height of 2.25m above the floor
Zone 2:
The area stretching to 0.6m outside the bath or
shower and above the bath or shower if over
2.25m

5
PARTS SUPPLIED
WALL PLUGS (X8)
SCREWS M4 (X8)
PLEASE NOTE: It is the installers responsibility to ensure that the fittings are suitable for the type of wall.
Alternative fittings may be required (Not Supplied). If unsure professional advice should be sought.
TOOLS REQUIRED tool
TAPE MEASURE
SPIRIT LEVEL
ELECTRIC DRILL
SCREWDRIVER
HAMMER
8mm DRILL BIT
PENCIL

6
INSTALLATION
First of all, the mirror should be hung on the wall over the wiring. Once the
mirror is installed, the shelf is added.
1. Looking at the back of the mirror, measure the distance between the fixing
centres of the mounting holes.
2. Using a spirit level and a pencil mark two points on the wall separated by this
distance.
3. Use the drill to make two holes.
4. Insert the wall plugs and screws.
5. Switch off power.
6. Connect the wiring to the lamp as below:
7. Hang the mirror on the screws.
8. Reconnect the power and test the product.
9. Switch the power back OFF.
10. Position the shelf in a suitable position and use a pencil to mark the
corresponding screw hole positions.
11. Drill holes in the marked positions.
12. Insert the wall plugs.
13. Place the shelf over the wall plugs and fix it to the wall with the screws
14. Connect the charger to the wire on the back of the mirror.
15. Turn the power back on and test the function of the charger

7
PRODUCT OVERVIEW
LED lamps
(on rear)
Demister
(on rear)
Infra-red
sensor (on
side)
Wireless phone charger

8
OPERATION
When the mirror is connected and hung securely
onto the wall, turn the mains power back on and the
mirror will be ready to use.
Your mirror has an infrared sensor located on the
side. To activate the light, charger and the demister, move your hand across
the sensor once at a distance of around 5cm.
To turn the light, charger and demister off, move your hand across the sensor
again.
Hold your hand in front of the sensor to change the colour temperature of the
light.
CLEANING AND MAINTENANCE
Never use products containing bleach or abrasive cleaners, as these will have a
detrimental effect on the appearance and lifespan of the product.
Use a clean micro fiber cloth to clean the mirror.

9
TECHNICAL SPECIFICATION
Model
BeBa_27008 (white)
BeBa_27009 (black)
LxHxW (mm)
500x500x150
Net Weight (Kg)
4.5
Power Cord length (cm)
53
Rated Power
8W (demister) 16W (LEDs)
IP Rating
IP 44
Input
220 V - 240 V 50 Hz
DISPOSAL
Recycling facilities are now available for all customers at which you can
deposit your old electrical products. Customers will be able to take any old
electrical equipment to participating sites run by their local councils.
Please remember that this equipment will be further handled during the
recycling process, so please be considerate when depositing your
equipment. Please contact the local council for details of your local
household waste recycling centres.
At the time of printing the product contains no substances listed within Annex XIV of the
Reach Regulations (EC) 1907/2006. In accordance with Article 59 of the same regulation the
following substances are contained within the product at permitted levels: Cadmium.
As a responsible manufacturer the regulations are monitored to ensure continued
compliance. Further information can be provided upon request.
