BetterLiving Ultra Compact Wheeled Walker User manual

Ultra Compact Wheeled Walker
USER GUIDE
136 kg
1
YEAR
WARRANTY

2
User Guide Ultra Compact Wheeled Walker
The Ultra Compact Wheeled Walker oers all the strength, design and integrity of a regular
Wheeled Walker with the added versatility of a compact folding design that allows it to be
easily transported or neatly packed away when not in use.
It is designed for indoor and outdoor use with a lightweight aluminium frame and
8 inch (200 mm) wheels for easy operation and manoeuvrability on smooth surfaces.
The moulded handgrips with soft touch brakes are ideal for people with limited strength or
mobility. Handle height can easily be adjusted with an overall extension range of 785 – 935 mm.
Included is the added convenience of a removable shopping bag that can be used with or
without a shoulder strap.
Intended Use
This wheeled walker is designed primarily for
general indoor and outdoor use as a walking
aid and a temporary seat. If used outside, it is
recommended for smooth or sealed surfaces.
It is not designed to be used as a wheelchair.
The maximum occupant weight is 136 kilograms,
as stated on the manufacturer’s label.
The wheeled walker should only be used and
maintained in accordance with the instructions in
this User Guide.
Overview
Important Notice
Before operating this medical equipment, it is
important to read this manual and understand the
operating instructions and safety precautions.
Failure to do so could result in patient injury and/or
damage to the product.
Therapeutic devices and/or medical equipment
should only be used in accordance with
manufacturer’s instructions and under the
consent, supervision and management of a
suitably qualified health professional.
Definitions of Symbols Used
Important information
Caution
Electrical hazard
Infection control
Do not...
Class II equipment
Type B Applied part
Novis Healthcare has a policy of continuous
product improvement and reserves the right to
amend specifications presented in this guide.
Information correct at time of production
(April 2018) .
© 2018 Novis Healthcare. All rights reserved.

3Ultra Compact Wheeled Walker User Guide
Overview 2
Set Up 4
Operation 8
Transportation and Storage 10
Cleaning 11
Safety and Maintenance 12
Specifications 13
Warranty 14
Index
Large portable
shopping bag
Handle with lever brake
Brake cable
Seat clasp
Handle height adjustment knob
Temporary seat
Detachable
walking stick
holder
Quick release
locking mechanism
8 inch
(200 mm) wheels
Padded backrest

4
User Guide Ultra Compact Wheeled Walker
Set Up
Box Contents and Inspection
Carefully remove all components from the box and
check items against the list below. Any damage or
missing components should be reported to your
authorised dealer or manufacturer.
Prior to use, remove all packaging and plastic
wrapping and check the wheeled walker for any
damage that may have occurred in transit, paying
particular attention to:
⬡Any damage to the wheels, handles or frame
⬡Damage to the seat or backrest
⬡Any missing or loose screws or wheel nuts
Attach the Backrest
The Walker is delivered in its compact folded
position with the back rest unattached. The
installation of the backrest is required once only
and does not require any tools.
With the backrest facing upwards (padding on the
inside and embroidery facing upwards), insert the
metal bracket on each side of the backrest into the
reciprocating slot, located at the rear of the brake
housing.
Bolt
Secure the backrest in place on each side with the
provided nut and bolt, being sure that the rounded
nut is positioned on the inside of the handle.
Ensure the brake cables are on the outside
edge of the backrest to avoid obstruction.
Ensure the backrest is installed correctly
before proceeding. The padded section
should face inwards and the embroidery
should be the correct way up.
Wheeled
Walker
Transport
Strap
Nut &
Bolt
Shopping
Bag
Shopping Bag
Shoulder Strap
Detachable
Walking Stick
Holder

5Ultra Compact Wheeled Walker User Guide
Set Up
Unfold the Wheeled Walker
1Lift the Walker upwards using the
handles, until the handle bars are
perpendicular to the support legs.
2To secure the quick release locking mechanism
into the retaining clip, rotate the mechanism
until the flat back of the mechanism faces the
frame and securely slots into the retaining clip.
This symbol is located on one side of the
walker as a guide. When the mechanism
is securely LOCKED, this symbol should be
visible and upright.
Replicate the locking process on opposite side.
3Unhook the seat clasp located on the
seat support.
4Spread the frame apart while pushing
down on the side braces, making sure
each brace locks horizontally in place.
Ensure locking mechanism is securely
in place before use. This can be done
by pushing the handles downwards
and backwards whilst checking for
movement.
RELEASED LOCKED

6
User Guide Ultra Compact Wheeled Walker
Attach the Shopping Bag
Slide the side pockets of the shopping
bag over the protruding brackets
located at the front of the Walker.
Adjust Handle Height
Adjust the handle height by loosening the height
adjustment knob and sliding the tube up or down
to the desired height. The height setting will adjust
one hole at a time and is clearly marked at the rear
of each tube. Be sure to tighten the adjustment
knob once desired height is set.
Set Up
Ideal Handle Height
A series of holes are placed 25
mm apart along the handle,
allowing handle height to be
adjusted to suit the user. Ideal
handle height is set when the
top of the handle aligns with
the user’s wrist.
Secure the hook and loop tabs at
the bottom of the bag on each side
around the frame.

7Ultra Compact Wheeled Walker User Guide
Check Brake Function
Check the brake cables are not obstructed and sit
on the outside of the backrest and shopping bag.
Set Up
Attach the Walking Stick Holder
If required, the detachable walking stick holder
can be slid onto the mounting bracket located
on the leg support on the left hand side of the
Wheeled Walker.
Make sure the brakes are working properly before
using the wheeled walker.

8
User Guide Ultra Compact Wheeled Walker
Using as a Walking Aid
When using the wheeled walker as a walking aid,
it is recommended both hands be placed firmly on
the handles, with fingers curled around the brake
levers so that the walker can be stopped
Operating the Brakes
To stop the wheeled walker, gently squeeze
the brake levers until the walker comes to a
complete stop.
Locking the brakes (park brake function)
The brakes should be locked whenever using the
walker as a temporary seat or when leaving the
walker unattended.
To lock the brakes, push down on the brake levers
until an audible ‘click’ is heard. Always check the
brake lock is activated before sitting on the seat.
To release the brake lock, pull up on the brake lever
until the lock disengages. Never release the brake
lock while sitting on the seat.
immediately in case of an emergency.
The ideal walking technique is to push the walker
forward to a comfortable arm’s length, then step in
towards the walker, and repeat.
Brake on
Operation
Park Brake on

9Ultra Compact Wheeled Walker User Guide
Operation
Tilt Assist
The tilt-assist pedals
help to tilt the wheeled
walker backwards when negotiating obstacles.
The pedals are located beside the rear wheels.
To use, place one foot on the pedal and gently
press downwards while pulling backwards on
the handles to lift the front wheels clear of the
obstacle.
Be very careful to maintain balance
while the front wheels are lifted.
Using as a temporary seat
Before using the wheeled walker as a temporary
seat, ensure the wheeled walker is parked on a
safe, level surface.
Before sitting, lock both brake levers and
ensure the lock is properly activated or
serious injury may result.

10
User Guide Ultra Compact Wheeled Walker
Transportation and Storage
Removing the Shopping Bag
To remove the shopping bag, follow the instructions on page 6 “Attach the Shopping Bag” in the reverse order
3Secure the clasp located on the seat.
4Release the locking mechanism located on each leg:
rotate it upwards a quarter turn before pulling down on
the mechanism, so that when it is loose it points towards
the floor. Gently push and pull on the mechanism to
make sure it is free and loose.
The mechanism should be loose and able to move freely
before the Walker can be folded for transport.
Lower the handle bars down towards the walker legs.
5Secure the transport strap around
the frame to prevent movement.
Folding the Wheeled Walker
1Before folding the walker,
remove the shopping bag.
2Pull up firmly on the strap located on the
seat. This will disengage the side braces and
collapse the frame inwards.
1
2

11 Ultra Compact Wheeled Walker User Guide
Cleaning
Cleaning
Do not use high pressure cleaners, steam cleaners
or harsh, caustic chemicals for cleaning.
Bag and seat
Regularly clean the padding materials using a
mild detergent solution up to 40 °C, or wash with
alcohol-based disinfectants if necessary.
Dry thoroughly before use.
Frame
Wipe the wheeled walker frame with a damp cloth.
For more stubborn dirt, use a mild detergent
solution up to 40 °C. Dry thoroughly before use to
avoid corrosion.
Clean the wheels using a damp brush with plastic
bristles (do not use a wire brush or you may
damage the rubber or painted finish).

12
User Guide Ultra Compact Wheeled Walker
General Safety Precautions
Do not use the wheeled walker to transport a
person while seated.
⬡A risk assessment should always be carried
out to ensure the product is suitable.
⬡Before use, the user should read these
instructions and familiarise themselves with
the wheeled walker. Ensure all components are
properly and securely installed.
⬡Ensure the user has sucient strength to safely
operate and control the wheeled walker and
hand brakes.
⬡Before sitting on the wheeled walker
ensure the brake locks are firmly applied.
Do not release brakes until user is standing.
⬡Do not exceed the maximum recommended
working load.
⬡Avoid storing the wheeled walker in direct
sunlight; seat or parts exposed to sunlight will
heat up and may cause injury to the skin.
⬡Do not place more than 4.5 kilograms of
shopping or other items into the designated
shopping bag.
⬡When seated, do not attempt to reach for objects
by leaning forward on the seat or by reaching
down between your knees. Do not lean over the
backrest to reach objects behind you as this may
cause the wheeled walker to tip over.
⬡Use only on designated footpaths or walkways;
do not use on roads, streets or highways.
⬡Do not use the wheeled walker on any incline
greater than 9 degrees, or on a slope with water,
ice or snow covering.
⬡Use caution when traversing kerbs or obstacles
as this may cause the wheeled walker to tip over
and cause harm or damage to the walker or the
user.
Keep a safe distance between moving and
stationary parts, it may cause injuries.
Regular Maintenance
Professional inspection of the
wheeled walker is recommended
at least once a year.
Any service or repairs, especially to the
brakes, must be performed by a trained
professional. Any unauthorised repairs or
service may void your warranty.
⬡Check locking mechanism regularly before
use. Ensure it is free from dirt and grime
and that it locks in place securely
and releases freely.
⬡Regularly check the wheeled walker for
damage and wear, paying special attention
to the workings of the brakes and the
condition of the wheels. If the wheeled
walker is damaged in any way, stop using the
wheeled walker immediately and contact your
authorised dealer or the manufacturer.
⬡Check handle grips do not twist on the
handles.
⬡Check the brake levers are firm; if loose or
worn they must be replaced before use.
⬡Check the eciency of the braking system
to ensure rear wheels do not move when the
brakes are engaged or locked.
With brakes released, there should be no drag
on the wheels and the wheeled walker should
move easily.
If you notice an unfamiliar braking sensation
or any abnormalities, stop using the wheeled
walker immediately and contact your
authorised dealer or the manufacturer.
⬡Check all screws and wheelnuts are firmly
secured.
Safety and Maintenance

13 Ultra Compact Wheeled Walker User Guide
Specifications
Specifications
NAME Ultra Compact
Wheeled Walker
CODE BL0063
COLOUR Gun Metal Grey
PRODUCT WEIGHT 7.3 kg
OVERALL HEIGHT 785 to 935 mm
OVERALL WIDTH 600 mm
OVERALL DEPTH 690 mm
SEAT HEIGHT 560 mm
SEAT WIDTH 450 mm
SEAT DEPTH 230 mm
FOLDED WIDTH 250 mm
WHEELS 8” (200 mm)
FRAME Aluminium
SAFE WORKING LOAD 136 kg
ARTG 176830
CONFORMS TO ISO 11199-2:2005
WARRANTY 1 Year

14
User Guide Ultra Compact Wheeled Walker
WarrantyWarranty
This warranty is provided by
Novis Healthcare
(ABN 45 102 734 491)
of Unit 11, 12 Mars Road,
Lane Cove West
NSW 2066
Novis Healthcare (Novis) products are
manufactured to the highest quality standards
and are thoroughly tested and inspected before
leaving our factory. In addition to any statutory
rights and remedies you may have, Novis
warrants all of its products sold directly or via
an Authorised Novis Australia Dealer against
defective workmanship and faulty materials from
the date of purchase by the end user for a period of
twelve months unless otherwise specified for that
product and its components.
Warranty Claims
To claim under this warranty, please contact Novis
Healthcare and have your receipt or proof of
purchase available. Novis Healthcare may need to
assess the defect before determining any claim,
and additional information may be requested
to process your claim. Claims without proof of
purchase may not be able to be processed.
Novis Healthcare may at its option inspect the
goods on site or require them to be returned to its
premises or one of its Authorised Service Agents in
person or freight prepaid by you.
Novis will undertake at its option, to repair or
replace, free of charge, each product or part
thereof on the condition that:
⬡The product found on examination, to be
suering from a manufacturing defect;
⬡The product or relevant part has been serviced
regularly by Novis or one of its Authorised
Service Agents and has not been subjected
to misuse, neglect or been involved in an
accident;
⬡The repairs are not required as part of normal
wear and tear.

15 Ultra Compact Wheeled Walker User Guide
Important notice for Australian consumers:
Our goods come with guarantees that cannot
be excluded under the Australian Consumer
Law. You are entitled to a replacement or refund
for a major failure and for compensation for any
other reasonably foreseeable loss or damage.
You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a major
failure. To obtain compensation, you will need
to provided documentary evidence of the loss
or damage suered and documentary evidence
that such loss or damage was a reasonable
foreseeable consequence of a failure Novis
Healthcare to comply with a consumer guarantee
under the Australian Consumer Law. Subject to
the provisions of the Australian Consumer Law,
Novis Healthcare excludes, to the fullest extent
permitted by law, all liability in respect of loss of
profit or other economic loss, direct to indirect or
consequential, special, general or other damages
or other expenses or costs which may include
negligence.
At our option
⬡Goods repaired may be replaced by
refurbished good of the same type rather than
being repaired.
⬡Refurbished parts may be used to repair
goods.
Novis Healthcare will not be held responsible for
any repair other than those carried out by it or one
of its Authorised Service Agents.
Warranty repairs do not extend the length of the
warranty period.
Limited Liabilities
Our liability under this manufacturer’s warranty
is subject to us being satisfied that a defect
was caused by faulty parts, manufacture or
workmanship, and was not caused or substantially
contributed to by other factors or circumstances
beyond our control, including (but not limited
to) defective installation, maintenance or repair,
product modification or alteration, any neglect,
misuse, or excessive use, normal wear and tear or
failure to follow manufacturer’s instructions.

Pressure care and patient handling specialists
novis.com.au /1300 738 885
