BetterLiving Euro Lightweight Wheeled Walker User manual

Euro Lightweight Wheeled Walker
USER GUIDE
136 kg
1
YEAR
WARRANTY

2
User Guide Euro Lightweight Wheeled Walker
The Euro Lightweight Wheeled Walker is designed for general indoor and outdoor use with a lightweight
aluminium frame and 8 inch (200 mm) wheels for easy operation and manoeuvrability on smooth surfaces.
The moulded handgrips with soft touch brakes are ideal for people with limited strength or mobility.
Handle height can easily be adjusted, with an overall extension range of 815-945 mm.
Includes the added convenience of a removable shopping bag that can be used with or without a shoulder strap.
The wheeled walker has an easy-fold mechanism for compact convenient transportation or compact
storage.
Intended Use
This wheeled walker is designed primarily for
general indoor and outdoor use as a walking
aid and a temporary seat. If used outside, it is
recommended for smooth or sealed surfaces.
It is not designed to be used as a wheelchair.
The maximum occupant weight is 136 kilograms,
as stated on the manufacturer’s label.
The wheeled walker should only be used and
maintained in accordance with the instructions in
this User Guide.
Overview
Important Notice
Before operating this medical equipment, it is
important to read this manual and understand the
operating instructions and safety precautions.
Failure to do so could result in patient injury and/or
damage to the product.
Therapeutic devices and/or medical equipment
should only be used in accordance with
manufacturer’s instructions and under the
consent, supervision and management of a
suitably qualified health professional.
Definitions of Symbols Used
Important information
Caution
Electrical hazard
Infection control
Do not...
Class II equipment
Type B Applied part
Novis Healthcare has a policy of continuous
product improvement and reserves the right to
amend specifications presented in this guide.
Information correct at time of production
(April 2018) .
© 2016 Novis Healthcare. All rights reserved.

3
Euro Lightweight Wheeled Walker User Guide
Overview 2
Set Up 4
Operation 6
Transportation and Storage 7
Safety and Maintenance 8
Cleaning and Specifications 9
Warranty 10
Index
Removable
shopping bag
Handle with lever brake
Brake cable
Handle height adjustment button
Detachable
walking stick holder
8inch
(200 mm) wheels
Backrest

4
User Guide Euro Lightweight Wheeled Walker
Unfold the Wheeled Walker
Remove the protective covering from all four
wheels. Remove cardboard from between the rear
wheels and brake latches.
Place the wheeled walker on a stable surface.
Unfold by spreading the frame while pushing down
on the side braces, making sure each brace locks
horizontally in place.
Adjust Handle Height
Adjust the handle height by pushing the button and
sliding the tube up or down. The height will adjust
one hole at a time. Ensure that both handles are
adjusted to the same height.
Set Up
Box Contents and Inspection
Carefully remove all components from the box and
check items against the list below. Any damaged
or missing component should be reported to your
authorised dealer or manufacturer.
Prior to use, remove all packaging and plastic
wrapping and check the wheeled walker for any
damage that may have occurred in transit, paying
particular attention to:
⬡Any damage to the wheels, handles or frame.
⬡Damage to the seat or backrest.
⬡Any missing or loose screws or wheelnuts.
Wheeled Walker
Shopping bag
with shoulder
strap
User Guide (this document)
Initial set up may require each handle to be
pulled upwards firmly, in order to expose the
height adjustment button.
Detachable
walking stick holder

5
Euro Lightweight Wheeled Walker User Guide
Attach the Shopping Bag
Attach the side loops of the shopping bag into
the designated protruding handles in front of the
walker.
Attach the Walking Stick Holder
If required, the detachable walking stick holder can
be slid onto the mounting bracket located on the
leg support on the left hand side of the Wheeled
Walker.
Check Brake Function
Check the brake cables are running outside the
frame and adjust the cable guides to store cables
neatly against the frame.
Make sure the brakes are working properly
before using the wheeled walker (refer to page 6
“Operating the brakes” for a description of brack
function)
Ideal Handle Height
A series of holes are placed 25 mm apart along the handle, allowing
handle height to be adjusted to suit the user. Ideal handle height is
set when the top of the handle aligns with the user’s wrist.
Set Up

6
User Guide Euro Lightweight Wheeled Walker
Using as a Walking Aid
When using the wheeled walker as a walking aid,
it is recommended both hands be placed firmly on
the handles, with fingers curled around the brake
levers so that the walker can be stopped
Operating the Brakes
To stop the wheeled walker, gently squeeze the
brake levers until the walker comes to a complete
stop.
Locking the brakes (park brake function)
The brakes should be locked whenever using the
walker as a temporary seat, or when leaving the
walker unattended.
To lock the brakes, push down on the brake levers
until they click. Always check the brake lock is
activated before sitting on the seat.
To release the brake lock, pull up on the brake lever
until the lock disengages. Never release the brake
lock while sitting on the seat.
Using as a temporary seat
Before using the wheeled walker as a temporary
seat, ensure the wheeled walker is parked on a
safe, level surface.
immediately in case of an emergency.
The ideal walking technique is to push the walker
forward to a comfortable arm’s length, then step in
towards the walker, and repeat.
Brake on
Park Brake on
Before sitting, lock both brake levers and
ensure the lock is properly activated or
serious injury may result.
Operation

7
Euro Lightweight Wheeled Walker User Guide
Removing the
Shopping
Bag
To remove the
shopping bag,
detach the side
loops. Use the
handles to lift out
the shopping bag.
Transportation and Storage
Folding the Wheeled Walker
To fold the walker, pull up firmly on the strap
located on the seat. This will disengage the side
braces and collapse the frame. Push the frame
together for a compact fold.
Tilt Assist
The tilt-assist pedal helps to tilt the wheeled walker
backwards when negotiating obstacles. The pedal
is located beside the right rear wheel.
To use, place one foot on the pedal and gently
press downwards while pulling backwards on
the handles to lift the front wheels clear of the
obstacle.
Be very careful to maintain balance while the front
wheels are lifted.

8
User Guide Euro Lightweight Wheeled Walker
General Safety Precautions
Do not use the wheeled walker to transport a
person while seated.
⬡A risk assessment should always be carried
out to ensure the product is suitable.
⬡Before use, the user should read these
instructions and familiarise themselves with
the wheeled walker. Ensure all components are
properly and securely installed.
⬡Ensure the user has sucient strength to
safely operate and control the wheeled walker
and hand brakes.
⬡Before sitting on the wheeled walker ensure
the brake locks are firmly applied.
Do not release brakes until user is standing.
⬡Do not exceed the maximum recommended
working load.
⬡Avoid storing the wheeled walker in direct
sunlight; seat or parts exposed to sunlight will
heat up and may cause injury to the skin.
⬡Do not place more than 4.5 kilograms of
shopping or other items into the designated
shopping bag.
⬡When seated, do not attempt to reach for
objects by leaning forward on the seat or by
reaching down between your knees. Do not lean
over the backrest to reach objects behind you as
this may cause the wheeled walker to tip over.
⬡Use only on designated footpaths or walkways;
do not use on roads, streets or highways.
⬡Do not use the wheeled walker on any incline
greater than 9 degrees, or on a slope with
water, ice or snow covering.
⬡Use caution when traversing kerbs or
obstacles as this may cause the wheeled
walker to tip over and cause harm or damage
to the walker or the user.
Keep a safe distance between moving and
stationary parts, it may cause injuries.
Regular Maintenance
Professional inspection of the
wheeled walker is recommended
at least once a year.
Any service or repairs, especially to the
brakes, must be performed by a trained
professional. Any unauthorised repairs or
service may void your warranty.
⬡Regularly check the wheeled walker for
damage and wear, paying special attention
to the workings of the brakes and the
condition of the wheels. If the wheeled
walker is damaged in any way, stop using the
wheeled walker immediately and contact your
authorised dealer or the manufacturer.
⬡Check handle grips do not twist on the
handles.
⬡Check the brake levers are firm; if loose or
worn they must be replaced before use.
⬡Check the eciency of the braking system
to ensure rear wheels do not move when the
brakes are engaged or locked.
With brakes released, there should be no drag
on the wheels and the wheeled walker should
move easily.
If you notice an unfamiliar braking sensation
or any abnormalities, stop using the wheeled
walker immediately and contact your
authorised dealer or the manufacturer.
⬡Check all screws and wheelnuts are firmly
secured.
Safety and Maintenance

9
Euro Lightweight Wheeled Walker User Guide
Cleaning and Specifications
Cleaning
Do not use high pressure cleaners, steam
cleaners or harsh, caustic chemicals for
cleaning.
Frame
Wipe the wheeled walker frame with a damp cloth.
For more stubborn dirt, use a mild detergent
solution up to 40 °C. Dry thoroughly before use to
avoid corrosion.
Clean the wheels using a damp brush with plastic
bristles (do not use a wire brush or you may
damage the rubber or painted finish).
Bag and seat
Regularly clean the padding materials using a
mild detergent solution up to 40 °C, or wash with
alcohol-based disinfectants if necessary.
Dry thoroughly before use.
Specifications
NAME Euro Lightweight
Wheeled Walker
CODE BL0062
COLOUR Gun Metal Grey
PRODUCT WEIGHT 6.8 kg
OVERALL HEIGHT 815 > 945 mm
OVERALL WIDTH 615 mm
OVERALL DEPTH 780 mm
SEAT HEIGHT 540 mm
SEAT WIDTH 450 mm
SEAT DEPTH 250 mm
FOLDED WIDTH 270 mm
WHEELS 8” (200 mm)
FRAME Aluminium
SAFE WORKING LOAD 136 kg
ARTG 176830
CONFORMS TO ISO11199-2:2005
WARRANTY 1 Year

10
User Guide Euro Lightweight Wheeled Walker
WarrantyWarranty
This warranty is provided by
Novis Healthcare (ABN 45 102 735 491)
of Unit 11/12 Mars Road Lane Cove West
New South Wales 2066.
Novis Healthcare (Novis)
products are manufactured to the
highest quality standards and are
thoroughly tested and inspected
before leaving our factory. In
addition to any statutory rights
and remedies you may have,
Novis warrants all of its products
sold directly or via an Authorised
Novis Australia Dealer against
defective workmanship and
faulty materials from the date of
purchase by the end user for a
period of twelve months unless
otherwise specified for that
product and its components.

11
Euro Lightweight Wheeled Walker User Guide
Limited Liabilities
Our liability under this manufacturer’s warranty
is subject to us being satisfied that a defect
was caused by faulty parts, manufacture or
workmanship, and was not caused or substantially
contributed to by other factors or circumstances
beyond our control, including (but not limited
to) defective installation, maintenance or repair,
product modification or alteration, any neglect,
misuse, or excessive use, normal wear and tear or
failure to follow manufacturer’s instructions.
IMPORTANT NOTICE FOR
AUSTRALIAN CONSUMERS:
Our goods come with guarantees that cannot
be excluded under the Australian Consumer
Law. You are entitled to a replacement or refund
for a major failure and for compensation for any
other reasonably foreseeable loss or damage.
You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a major
failure. To obtain compensation, you will need
to provided documentary evidence of the loss
or damage suered and documentary evidence
that such loss or damage was a reasonable
foreseeable consequence of a failure Novis
Healthcare to comply with a consumer guarantee
under the Australian Consumer Law. Subject to
the provisions of the Australian Consumer Law,
Novis Healthcare excludes, to the fullest extent
permitted by law, all liability in respect of loss of
profit or other economic loss, direct to indirect or
consequential, special, general or other damages
or other expenses or costs which may include
negligence.
Warranty Claims
To claim under this warranty, please contact Novis
Healthcare and have your receipt or proof of
purchase available. Novis Healthcare may need to
assess the defect before determining any claim,
and additional information may be requested
to process your claim. Claims without proof of
purchase may not be able to be processed.
Novis Healthcare may at its option inspect the
goods on site or require them to be returned to its
premises or one of its Authorised Service Agents in
person or freight prepaid by you.
Novis will undertake at its option, to repair or
replace, free of charge, each product or part
thereof on the condition that:
⬡The product found on examination, to be
suering from a manufacturing defect;
⬡The product or relevant part has been serviced
regularly by Novis or one of its Authorised
Service Agents and has not been subjected
to misuse, neglect or been involved in an
accident;
⬡The repairs are not required as part of normal
wear and tear.
At our option
⬡Goods repaired may be replaced by
refurbished good of the same type rather than
being repaired.
⬡Refurbished parts may be used to repair
goods.
Novis Healthcare will not be held responsible for
any repair other than those carried out by it or one
of its Authorised Service Agents.
Warranty repairs do not extend the length of the
warranty period.

pressure care and patient handling specialists
novis.com.au /1300 738 885
