BetterLiving BL1234 Manual instruction

Unfolding / folding the walking frame Adjusting the height
Press in the brass locking button to disengage,
and turn the leg slightly so the button is no longer
aligned with the holes.
Move the leg up or down to your ideal height setting,
then turn the leg back to align the locking button
with the nearest hole. If unable to achieve an exact
height match, make the walking frame slightly
higher rather than shorter to avoid stooping.
The locking button must be fully engaged and
protruding through the height adjustment hole to
ensure a positive lock. Always test that the lock is
fully engaged before use.
See over for Ideal height and Usage suggestion
Unfold each arm outwards
until the lock clicks into place.
Check both sides of the frame
are firmly locked into position
before use
To fold, press firmly on the
single button located in the
centre of the cross bar to
release the locks.
Then fold each side of the
frame inwards until they rest
flat against the frame.
Ideal for the taller user, this lightweight
aluminium walking frame can assist by
improving balance & stability and helps
improve confidence in walking.
Features height adjustable legs with 125 mm
front wheels and rear skis for easy movement
without lifting. Single button folding
mechanism for ease of transport and storage.
Foam grip handles for added comfort.
Please
read these
instructions
before use
Do not use a
walking frame
to climb stairs or
to travel on an
escalator
Walking Frame, Wheels and Skis
SET-UP AND OPERATION

Regular maintenance
Regularly check the walking frame for damage and wear,
paying special attention to the condition of the skis and
wheels. Replace the skis/wheels immediately if you see
evidence of rips, tears, cracks or other general wear. If the
walking frame is damaged in any way, stop using the walking
frame immediately and contact your authorised dealer or the
manufacturer.
Care & cleaning
To clean the walking frame, wipe with a mild soap and warm
water solution and rinse well. Dry thoroughly with a clean cloth.
Avoid harsh, abrasive cleaning agents or utensils (such as a
wire brush) as these may damage the anodised finish, or plastic
and rubber components.
Warranty
Novis Healthcare Pty Ltd warrants this product for a period
of 12 months. Please refer to our Warranty Statement for
full details. Please contact your authorised dealer or the
manufacturer for a list of available spare parts.
Specifications
CODE BL1234
MAXIMUM USER WEIGHT 180 kg
WEIGHT 3kg
OVERALL WIDTH 640 mm
OVERALL HEIGHT 815 > 990 mm
OVERALL DEPTH 555 mm
DEPTH WHEN FOLDED 115 mm
WIDTH BETWEEN HANDLES 430 mm
WARRANTY 1 year
ARTG 176830
Made in China
Ideal height
To determine ideal height for your walking frame, stand
as straight as possible (preferably wearing an everyday
pair of shoes) and look straight ahead with your arms
relaxed at your sides.
In this position, the top of the
handgrips should sit level with your
wrist bone when the walking frame
is placed in the correct position
around your body. You can measure
the distance from your wrist bone
to the floor as a helpful reference for
height adjustment.
Using the walking frame
With both hands placed firmly around the handgrips at the top
of the walking frame, lift and place the frame to a comfortable
arm’s length ahead of you.
Alternatively, you can lift and place the frame to a comfortable
arm’s length ahead of you, making sure the frame is resting
stably on the ground.
Step in towards the frame, stepping o from your weaker leg
(if applicable). Do not step all the way to the front of the
walking frame; smaller steps are recommended. Always take
small steps when turning.
pressure care and patient handling specialists
novis.com.au /1300 738 885
