bewell connect BW-MyCoach PULSE BW-HB16 User manual

BewellConnect - BWHB16 - User Manual - 092016 BewellConnect - BW-HB16 - User Manual - 092016
1 1
BW-HB16
BW-MyCoach®PULSE
www.bewell-connect.com
Customer Service
+ 33 892 350 366
(0,34€/mn)

BewellConnect - BWHB16 - User Manual - 092016 BewellConnect - BW-HB16 - User Manual - 092016
2 3
Consult instructions for use
Temperature limitation
Batch code
SN
Serial number
Manufacturer
Caution
Humidity Limitation
The device, accessories and the packaging have
to be disposed correctly at the end of the usage.
Please follow local ordinances or regulations for
disposal.
Year Month Day Serial number
SN
SN :
Serial number
BW-HB16
Rating label
A B
1
12
3
4
5
2

BewellConnect - BWHB16 - User Manual - 092016 BewellConnect - BW-HB16 - User Manual - 092016
4 5
BW-HB16
EN
BW-MyCoach®PULSE

BewellConnect - BWHB16 - User Manual - 092016 BewellConnect - BW-HB16 - User Manual - 092016
6 7
Changes or modications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept
any interference received, including interference that may
cause undesired operation.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protec-
tion against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequen-
cy energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio commu-
nications. However, there is no guarantee that interference will
not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment o and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit dierent
from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for
help.
CONTENTS
1. NOTICE 8
2. DESCRIPTION 9
3. INFORMATION 9
3.1 MEASUREMENT OF THE HEART RATE 9
4. USE 10
4.1 PRECAUTIONS BEFORE USE 10
4.2. GETTING STARTED 10
4.3. STARTING UP 11
4.4. DATA MONITORING 11
4.4.1 DAILY DATA MONITORING 11
4.4.2. MONITORING THE HEART RATE 12
4.4.3. SLEEP MONITORING AND ANALYSIS 13
4.4.4. DAILY GOALS 13
4.4.5. MODE SPORT 13
4.4.6. FIND PHONE & ANTILOST FUNCTIONS 14
4.4.7. ALARM MODE 15
4.4.8. NOTIFICATIONS 15
4.4.9. INACTIVITY 15
4.4.11. WRIST SENSE 16
4.5. BATTERY LIFE  RECHARGING 16
4.6. SYNCHRONIZATION 16
5. CLEANING AND MAINTENANCE 17
6. TECHNICAL SPECIFICATIONS 17
6. TROUBLESHOOTING GUIDE 19
Learn how to install and use the BewellConnect® application by
logging onto our website www.bewell-connect.com/install
The manufacturer reserves the right to modify the product
specications without prior notice.

BewellConnect - BWHB16 - User Manual - 092016 BewellConnect - BW-HB16 - User Manual - 092016
8 9
Dear Customer,
You have just purchased a BW-MyCoach®, the connected activity,
sleep and heart rate tracker by BewellConnect® and we thank you
for your condence. We hope you will enjoy using it and recom-
mend that you carefully read this instruction leaet.
The manufacturer reserves the right to modify the technical cha-
racteristics of the product without any prior notice.
1. NOTICE
Although your BW-MyCoach®activity tracker is designed to be
worn at all times, improper use could damage its electronic com-
ponents. Please read the safety instructions and warnings to ensu-
re correct operation and maintenance.
- Use this device only for its intended purpose as described in this
leaet.
- This device can be used for personal use at home.
- Use this device in an ambient temperature range between 10 and
40°C.
- Do not expose this device to conditions of extreme temperature
> 60°C or < -20°C.
- Do not use this device in relative humidity greater than 85%.
- This device must always be placed in a clean, dry place.
- Do not expose this device to direct sunlight or water.
- Do not expose this device to electric shock.
- Never drop the device.
- Follow the maintenance instructions described in this leaet.
- Do not attempt to open the device. In the event of a problem,
contact your dealer.
- Do not leave this device within reach of children.
- Stop using the device in the event of a fault or malfunction.
- This device is not intended to be used by persons (including child-
ren) with reduced physical, sensory or mental abilities, nor by per-
sons lacking experience or knowledge, unless they have received
supervision or prior instructions concerning the use of the device
from a person responsible for their security.
2. DESCRIPTION
See A page 2
1
navigation button
2
Display LCD
3
Silicone wristband
4
Contact point (Charging clip)
5
Charging clip
3. INFORMATION
3.1 MEASUREMENT OF THE HEART RATE
The heart rate is the number of heartbeats (contractions) per unit
of time (usually per minute).
AGE HEART RATE
Infant 90 - 190
1-2 years old 70 - 150
3-5 years old 70 - 140
6-12 years old 65 - 125
Adolescent or adult 60 - 80
Elderly person 60 - 70
The pulse of a person in good health and at rest is between 50 (ath-
lete with endurance training) and 80 heartbeats per minute. Du-
ring an eort, the maximum heart rate is theoretically 220 minus

BewellConnect - BWHB16 - User Manual - 092016 BewellConnect - BW-HB16 - User Manual - 092016
10 11
the age of the person (e.g.: 190 at 30 years old)
Biological rhythms (such as digestion, waking/sleep, etc.) and phy-
siological reactions (such as fear, stress, etc.) inuence the heart
rate, which is not constant.
4. USE
4.1 PRECAUTIONS BEFORE USE
BW-MyCoach® is resistant to rain, splashing and sweat. Neverthe-
less, our tracker is not designed to be immersed in water. Be sure
to remove it before any water activity or before taking a shower.
We also recommend you do not wear your activity tracker 24 hours
a day, in order to let your skin breathe. Be sure to dry it when wet.
4.2. GETTING STARTED
How to wear the BW-MyCoach®?
For optimal use and the greatest precision, wear your BW-My-
Coach® on your wrist. You can also put it in your pocket or bag, but
the indicators will not be as precise.
The accuracy of the heart rate is aected by various phenomena,
such as the way the tracker is worn, body movements or the phy-
siology of the wearer. This technology will not provide precise mea-
surements for each activity, but we recommend you follow these
instructions:
- Do not wear your activity tracker too tightly: this can decrease
blood ow and alter the measurement. However, BW-MyCoach®
must be adjusted to your wrist during physical activity.
- During physical activity requiring repeated movements of the
wrists, we recommend you remain still for a few moments (appro-
ximately 10 seconds) in order to improve the measurement signal
and to adjust your BW-MyCoach® on your wrist in relation to your
movements to obtain a reliable measurement.
4.3. STARTING UP
Download the BewellConnect® application
Download the BewellConnect® application from the store
of your smartphone or tablet (App Store for an iOS device,
Play Store for an Android device) or scan the QR code on
the side of the box.
First use – Programming personnal data
Begin by creating your prole or that of the wearer.
Making the measurement
- Before the rst use, charge your BW-MyCoach® activity tracker
with the cable provided for approximately two hours.
- Make sure that the Bluetooth function (Bluetooth Low Energy 4.0
only) of your smartphone is turned on and that the version of the
operating system of your smartphone is up to date (Android 4.3
or iOS 7.1).
- Then synchronize your activity tracker with the BewellConnect®
application (more information in chapter 3.6. Synchronization).
- Once synchronized, your activity tracker is ready for use.
4.4. DATA MONITORING
You can follow your physical activity during the day and monitor
your sleep at night with your BW-MyCoach®.
4.4.1 DAILY DATA MONITORING
Your activity tracker allows you to automatically monitor your daily
activity. Find the following information in the BewellConnect® ap-
plication, as well as on the screen of your activity tracker:
Your heart rate
Calories burned

BewellConnect - BWHB16 - User Manual - 092016 BewellConnect - BW-HB16 - User Manual - 092016
12 13
Distance traveled
Number of steps taken
- To scroll through the dierent measurements on the screen, press
the button located to the left of the screen. The time, date and
battery level is displayed. Press the button again to change the
menu (heart rate, number of steps taken, distance traveled, calo-
ries burned, time of the next alarm, „Find Phone“ function).
6000 120 25.2KM
10:36
07/12 TUE
These measurements are also displayed on the BewellConnect®
application, as well as:
- The heart rate history
- The duration and quality of your sleep.
All your data are saved in the internal memory of your activity tra-
cker for a period of 7 days.
4.4.2. MONITORING THE HEART RATE
67
Your heart rate is automatically measured every
5 minutes. The BewellConnect application al-
lows you to obtain a tracking curve over a 24-
hour period (view in the application).
To manually measure your heart rate, press the
button located to the left of the screen twice to
display the heart rate function.
The measurement is displayed on the screen
after a few seconds.
4.4.3. SLEEP MONITORING AND ANALYSIS
BW-MyCoach® detects when you are asleep (drop in your heart
rate, absence of movement) and automatically switches to Night
mode, in order to analyze the quality of your sleep and its evolu-
tion throughout the night (movements, awakenings and duration).
These data are transferred to your smartphone via the Bewell-
Connect® application to help you analyze the quality of your sleep.
4.4.4. DAILY GOALS
Set your daily goals and save them in the BewellConnect® application.
6000
Set a target number of steps to perform daily
in the application. You can monitor your goals
at any time of the day on your BW-MyCoach®
thanks to the progress bar located below the
number of steps.
You can also set a goal for the duration of sleep per night, in order
to improve your physical condition.
4.4.5. MODE SPORT
- You can monitor a specic sports activity thanks to the Sport
mode. You can measure dierent metrics depending on the acti-
vity (a static activity such as tness training will not measure the
distance traveled).
- To activate the Sport mode, press and hold the button of your
BW-MyCoach® until it vibrates. A screen with the last reading and
the last heart rate registered appears.
- To start the stopwatch, press the button of your tracker twice. Trai-
ning begins when it vibrates.
You can navigate between screens at any time (as in normal mode)
by pressing the button of your tracker. You can view:
- Elapsed time
- Heart rate and heart rate range

BewellConnect - BWHB16 - User Manual - 092016 BewellConnect - BW-HB16 - User Manual - 092016
14 15
- Number of steps taken
- Distance traveled
- Calories burned
- Time
6000 25.2KM
10:36
07/12
120 03:10.6
67
To stop the session, press and hold the button of your BW-My-
Coach® until it vibrates. After synchronization, your data will appe-
ar in the BewellConnect® application.
4.4.6. FIND PHONE & ANTILOST FUNCTIONS
A. FIND PHONE
You can locate your smartphone thanks to your BW-MyCoach®.
Press the button on the tracker until the “FIND PHONE” menu ap-
pears.
- Press and hold the button until the tracker
starts to vibrate. Your smartphone will then
ring or vibrate (depending on the mode ac-
tivated).
Attention: This function will only work if your tracker is located within the
area of Bluetooth coverage of your smartphone and if the BW-MyCoach®
application is open on your smartphone (even in the background).
B. ANTI LOST
Your activity tracker is equipped with an “ANTI-LOST” function. As
soon as your BW-MyCoach® tracker is separated from your smart-
phone by a distance of more than ten meters, it begins to vibrate to
indicate to you that you are moving away from it.
4.4.7. ALARM MODE
- You can program up to 10 daily alarms to trigger reminders
(medication, drink water, do sport, etc.).
- To add, modify, or delete an alarm, open the BewellConnect® ap-
plication and then click on the BW-MyCoach® icon. In the drawer,
click on „Alarms“ and follow the instructions.
4.4.8. NOTIFICATIONS
Over 120 compatible mobile devices allow you to receive notica-
tions on your activity tracker.
Go to http://www.bewell-connect.com/wp-content/
uploads/2015/12/compatible_devices_list.pdf to see if your device
is compatible.
Management of call notication
- To enable or disable notications, go to the BewellConnect® applica-
tion on your smartphone and then click on the BW-MyCoach® icon.
- In the Settings, click on„Notications“ and follow the indications.
Notications
- When you receive a call, text or a message (social networks), it is
displayed on the screen of your BW-MyCoach®.
4.4.9. INACTIVITY
- BW-MyCoach® helps you remain active throughout the day!
Schedule an inactivity alert on your Bewell-
Connect® application. BW-MyCoach® starts
to vibrate and an icon appears on the screen
when it detects prolonged inactivity.
In the drawer, click on „Alarms“ and follow
the instructions.

BewellConnect - BWHB16 - User Manual - 092016 BewellConnect - BW-HB16 - User Manual - 092016
16 17
4.4.10. CONTROLING THE CAMERA
Remotely trigger the camera located in the BewellConnect® appli-
cation by pressing the button of your BW-MyCoach®
4.4.11. WRIST SENSE
The screen of your BW-MyCoach® automatically turns on when it
detects a movement of the wrist similar to the one that you make
to look at a watch dial.
4.5. BATTERY LIFE  RECHARGING
- Your BW-MyCoach® activity tracker is equipped with a lithium-po-
lymer rechargeable battery, which in normal conditions of use
allows you to monitor your activity for approximately 5 days.
- Press the button to the left of the screen to display the battery
level.
- The screen displays in the event of a low battery.
- To recharge your BW-MyCoach®, connect the USB cable to your
computer or to a power adapter and then connect the other end
to the place provided at the rear of the activity tracker (See B page 2 ).
- Allow one to two hours to fully recharge your BW-MyCoach®.
4.6. SYNCHRONIZATION
- Your activity tracker automatically syncs when you open the Be-
wellConnect® application and press the BW-MyCoach® icon.
- To sync manually, go to the menu of the application by clicking
on the icon and then press Synchronize.
- Your activity tracker is congured directly via the application. Re-
member to sync your tracker in the application for new settings to
be taken into account.
5. CLEANING AND MAINTENANCE
Your BW-MyCoach® is designed for daily use. It is important to cle-
an it regularly, including the inner part of the wristband that comes
in contact with your skin.
- Use a soft, dry cloth to clean the device. If necessary, use a cloth
slightly moistened with tap water.
- Do not use alcohol, benzene, thinner or other chemical products
to clean the device.
- This product is not waterproof - avoid any contact with liquids. Be
sure to dry the wristband before wearing it.
It is recommended to regularly clean the activity tracker using a
soft, dry cloth to avoid the accumulation of microscopic dust and
dirt that could aect the reliability of the measurements.
6. TECHNICAL SPECIFICATIONS
PRODUCT NAME BewellConnect® BW-MyCoach®
REFERENCE BW-HB16
SETTINGS MIN. MAX.
Steps 0 99999
Distance (km) 0 9999
Calories (kcal) 0 9999
TIME FORMAT 12/24 hours
NIGHT MODE Automatic
ALARM Up to 10 congurable alarms on
the BewellConnect® application

BewellConnect - BWHB16 - User Manual - 092016 BewellConnect - BW-HB16 - User Manual - 092016
18 19
NOTIFICATIONS
Text messages
Calls
Facebook
Facebook Messenger
WhatsApp
WeChat
Twitter
LinkedIn
Instagram
ALARMS
Inactivity
Anti-Lost
Telephone localization
OTHER FEATURES Wrist Sense
Camera control
CHIPSET Nordic nRF51822
SENSOR Kionix KX022-1020
HEART RATE
SENSOR Silicon labs Si1142
SCREEN OLED 0.49 inch
MEMORY 32KB RAM + 256KB ROM
WRISTBAND TPE / high quality silicone
WRISTBAND
DIMENSIONS 230 x 20 x 13 mm
WEIGHT 81 g
BATTERY 60mAh Lithium Polymer
OPERATING
VOLTAGE 3.6 – 4.2 V
BLUETOOTH BLE 4.0
AUTONOMY 5 - 10 days depending on use
CHARGING TIME
Approximately 2 hours de-
pending on the charging mode
(mains or computer)
DATA STORAGE 7 days
OPERATING
TEMPERATURE
From -20 to 60°C
(from -4 to 140°F)
CHARGING CABLE Charging clip
7. TROUBLESHOOTING GUIDE
Problem Solution
Nothing is displayed on
the screen of the
BW-MyCoach
Recharge the device with
the USB cable provided.
No transfer of data to
your phone / tablet
Bluetooth connection disa-
bled: Enable Bluetooth on your
phone / tablet.
Phone or tablet incompatible:
Check that your phone or tablet
is equipped with Bluetooth 4.0.

BewellConnect - BWHB16 - User Manual - 092016 BewellConnect - BW-HB16 - User Manual - 092016
20 21
The BewellConnect®
application does not
detect the BW-MyCoach®
activity tracker when
pairing.
Check that the Bluetooth
function on your smart-
phone is enabled and that
the version of the operat-
ing system of your smart-
phone is updated (Android
4.3 or iOS 7.1).
Check that your activity
tracker is located within
range of the smartphone
you want to synchronize
with (50 cm maximum).
If the problem persists,
please contact customer
service or your dealer.
You are unable to
connect your BW-My-
Coach® activity tracker
to the BewellConnect®
application.
Activate Bluetooth.
Restart your smartphone.
If the problem persists,
please contact customer
service or your dealer.

BewellConnect - BWHB16 - User Manual - 092016 BewellConnect - BW-HB16 - User Manual - 092016
22 23
WARRANTY

BewellConnect - BWHB16 - User Manual - 092016 BewellConnect - BW-HB16 - User Manual - 092016
24 25
GUARANTEE CARD
Purchase date
Date :.......... / .......... / ..........
Serial number
SN: ...................................................
Retailer’s seal Cachet / Stamp:
EN: Visiomed®will repair or replace this product free of charge in the
case of defective parts or manufacturing defects, in accordance with
the conditions mentioned below as follows:
DURATION: 24 MONTHS RETURN TO WORKSHOP
LIMITS AND EXCLUSIONS: This guarantee concerns only the original
nal purchaser. A purchase invoice, or another proof of purchase, with
this guarantee card will be required to obtain an after-sales service, in
accordance with this guarantee. This guarantee card will not be ex-
tended to another person only the original nal purchaser. This guar-
antee becomes void if the serial numbers on the product are modied,
replaced, illegible, absent, or if repair has been carried out by a service
not approved, including the user.
This guarantee covers only the defects of the material or parts, occur-
ring during normal use of the pro-duct. It does not cover the damage
caused during the transport of the apparatus, causes due to repairs
being carried out by the distributor, by any modications undertaken,
any connection of equipment not approved by Visiomed®, or causes
contrary to those written in the user manual or notice. Moreover, the
present guarantee does not cover damage due to falls, bad handling,
bad installations, damage by re, oods, lightning, or any other natural
disaster. This guarantee does not cover the packing of the material, the
accessories, the defects caused by commercial exposure of the prod-
uct, show room, sale space, demonstration etc... Normal maintenance,
cleaning and the replacement of parts where wear is normal, are not
covered by the terms of this guarantee. Visiomed®and its representa-
tives and agents will not in any case be held responsible for any dam-
age and consecutive damages due to the mishandling of this product.
This guarantee is the only valid one at Visiomed®, any other guarantee
(commercial guarantee) except this one will not be taken into account.
IMPORTANT: During the guarantee period if you are dissatised with the
repairs of this product, please contact the Visiomed
®
customer service.
EN: Disposal of Waste Equipment by Users in Private House-
holds in the European Union.
The symbol on the product or on its packaging indicates that
this product must not be disposed of with your other household
waste. Instead, it is your responsibility to dispose of your waste
equipment by handing it over to a designated collection point for the
recycling of waste electrical and electronic equipment. The separate
collection and recycling of your waste equipment at the time of disposal

BewellConnect - BWHB16 - User Manual - 092016 BewellConnect - BW-HB16 - User Manual - 092016
26 27
will help to conserve natural resources and ensure that it is recycled in
a manner that protects human health and the environment. For more
information about where you can drop o your waste equipment for
recycling, please contact your local city oce or your household waste
disposal service.
© 09/2016 BW-HB16
EN: BewellConnect® is a brand registred by Visiomed Group SA. The
constructor keeps the right to modify the photographs and characteristics
without previous notice. Registred design. The logos and trademarks are
the property of their respective owners.
