Beyerdynamic MPC 23 SE User manual

VERSIONS
MPC 23 sw Half-spherical, black. . . . . . . . Order # 441.562
MPC 23 ws white. . . . . . . . . . . . . . . . . . . . Order # 441.570
MPC 23 SE silver metallic effect,
microphone basket made of
acuraLine®Topmesh
double-layer fine meshed
wire weave . . . . . . . . . . . . . . . Order # 485.963
TECHNICAL SPECIFICATIONS
Transducer type. . . . . . . . . . . . . . . . . . . Condenser
(back electret)
Operating principle. . . . . . . . . . . . . . . . Pressure
Frequency response . . . . . . . . . . . . . . . 50 - 20,000 Hz
Polar pattern . . . . . . . . . . . . . . . . . . . . . Half-spherical
Open circuit voltage
at 1 kHz
(0 dB =
^
1 V/Pa) . . . . . . . . . . . . 16 mV/Pa
Nominal impedance . . . . . . . . . . . . . . . 200 Ω
Load impedance . . . . . . . . . . . . . . . . . . ≥1000 Ω
Max. SPL. . . . . . . . . . . . . . . . . . . . . . . . . 124 dB SPL
Signal-to-noise ratio rel. to 1 Pa . . . . . 60 dB
A-weighted equivalent SPL . . . . . . . . . 26 dB
Phantom power . . . . . . . . . . . . . . . . . . 8 - 52 V
Consumption . . . . . . . . . . . . . . . . . . . . . 3.4 mA
Connector . . . . . . . . . . . . . . . . . . . . . . . . 3-pin XLR male
Dimensions
Length . . . . . . . . . . . . . . . . . . . . . . . . . . . 74/67 mm
Shaft diameter . . . . . . . . . . . . . . . . . . . . M 20 x 1.5 thread
Head diameter . . . . . . . . . . . . . . . . . . . . 30 mm
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . approx. 70 g
Germany
beyerdynamic GmbH & Co. KG
Theresienstr. 8 · 74072 Heilbronn – Germany
Tel. [phone] / 6 17-0 · Fax [phone] / 617-224
[email protected] · www.beyerdynamic.de
United States
beyerdynamic Inc. USA
56 Central Ave. · Farmingdale, NY 11735
Tel. [phone] · Fax [phone]
[email protected] · www.beyerdynamic.com
Great Britain
beyerdynamic U.K. Ltd.
17 Albert Drive · Burgess Hill RH15 9TN
Tel. [phone] / 258 258 · Fax [phone] / 258 444
[email protected] · www.beyerdynamic.co.uk
APPLICATIONS
The MPC 23 acoustical boundary microphone is designed for
mounting into tabletops and ceilings. The half-spherical
polar pattern is picked up in a uniform manner. The high
sensitivity guarantees a constant output level even from long
distance sources. Elastic bearing rings achieve mechanical
isolation from the mounting surface and therefore offer
effective sound isolation of the microphone.
The MPC 23 is designed for applications such as tele/video
conferencing, recording or amplification of round table
discussions and wherever the microphone needs to be as
unobtrusive as possible.
FEATURES
• Omnidirectional characteristic (180°coverage)
• Flat, wide frequency response
• High-quality reproduction of speech
• Unobtrusive design
• Ceiling or tabletop mounting
• Fast and easy installation
SUPPLIED ACCESSORIES
• Elastic bearing rings
INSTALLATION
• Mounting hole with elastic bearing rings: Ø 24 mm (15/16")
• Mounting hole with elastic bearing rings: Ø 20 mm (13/16")
• Max. table- /ceiling thickness: 57 mm (2.25")
MPC 23
Acoustical Boundary Microphone
MPC 23 sw
MPC 23 SE

WIRING DIAGRAM
Positive pressure produces positive voltage on pin 2.
DIMENSIONS
In millimetres (inches in brackets)
FREQUENCY RESPONSE & POLAR PATTERN
This frequency response curve (measuring tolerance ± 2.5 dB) and polar pattern correspond to a typical production sample for this
microphone.
MPC 23
Non-contractual illustrations. Subject to change without notice. E2 / MPC 23 (04.07)
Frequency response ± 2.5 dB 0 dB = 16 mV/Pa MPC 23
