Beyerdynamic SPACE User manual

PERSONAL SPEAKERPHONE
OPERATING INSTRUCTIONS

Contents
6/14 beyerdynamic SPACE Personal Speakerphone
CONTENTS
SAFETY INSTRUCTIONS ................................ 7
Intended use............................................7
Risk of swallowing.......................................7
Power and connecting cable............................7
Using the batteries......................................7
Environmental conditions ...............................7
ABOUT THIS MANUAL .................................. 7
SCOPE OF DELIVERY ................................... 7
PRODUCT OVERVIEW .................................. 7
FIRST STEPS ........................................... 8
Removing from packaging and oring..................8
Securing your Personal Speakerphone ..................8
Charging the battery....................................8
Displaying the battery charge level .....................8
Using the product with a USB cable connection . . . . . . . . .8
Using the product with Bluetooth® connection...........8
SOFTWARE UPDATE .................................... 8
COMPATIBILITY WITH PLAYBACK DEVICES............... 8
SUPPORTED AUDIO CODECS ........................... 8
OPERATION ........................................... 9
Switching on and o ....................................9
Activating and deactivating the Bluetooth® function . . . . 9
Pairing with a device via Bluetooth® .....................9
Bluetooth® connection with a USB Bluetooth® adapter...9
Connection displays ....................................9
Connecting two speakerphones to
form a ereo pair (for music playback)..................9
Multi-point operation ..................................10
Adjuing the volume...................................10
Using the mute function................................10
Playing media..........................................10
Calling up the personal assiant ......................10
Using Sound-Activated Lighting Mode .................10
Using Business Mode....................................11
Using Stealth Mode .....................................11
Controlling calls.........................................11
Using voice messages...................................11
Resetting to factory settings ............................11
Settings for be sound..................................11
Attaching a Kensington lock ...........................12
Overview of operating functions .......................12
HELP WITH PROBLEMS / FAQ. . . . . . . . . . . . . . . . . . . . . . . . . . . .12
BATTERY LIFE ..........................................13
CLEANING AND MAINTENANCE.........................13
DISPOSAL .............................................13
Battery disposal .......................................13
EU/UK DECLARATION OF CONFORMITY .................13
TECHNICAL SPECIFICATIONS ...........................13
WARRANTY CONDITIONS ..............................13
REGISTERED TRADEMARKS .............................14
THIRD PARTY LICENSES ................................14
FCC / IC REGULATION..................................14

Safety inructions
beyerdynamic SPACE Personal Speakerphone 7/14
Thank you for choosing the beyerdynamic SPACE
Personal Speakerphone.
SAFETY INSTRUCTIONS
►Please read these inructions carefully and completely
before using the product.
►Please observe all inructions given, especially those
concerning the safe use of the product.
►Do not use the product if it is defective.
►The company beyerdynamic GmbH & Co. KG accepts
no liability for damage to the product or injury to
persons caused by careless, improper or incorrect use
of the product, or by use for purposes not specified by
the manufacturer.
Intended use
Only use the product as described in this product
manual. beyerdynamic accepts no liability for damage
to the product or injury to persons caused by careless,
improper or incorrect use of the product, or by use for
purposes not specified by the manufacturer.
beyerdynamic is not liable for damage to USB devices
that do not comply with the USB specifications.
beyerdynamic is not liable for damage resulting from
connection interruptions due to batteries being empty or
too old, or due to exceeding the Bluetooth® transmission
range.
Please also observe the relevant country-specific regula-
tions before using the product.
Risk of swallowing
►Keep small pas, such as product, packaging and
accessories, away from children and pets. They coni-
tute a choking hazard if swallowed.
Power and connecting cable
Use only the cable we supply to connect the device for
both charging and connecting to a laptop.
Using the batteries
Danger from heat, water and mechanical ress
Excessive heat, water and mechanical ress may cause
explosion, heat, fire, smoke or fumes. Injuries and irrevers-
ible damage to the battery may result.
►Do not expose the battery (battery pack or integrated
battery) to excessive heat, direct sunlight or fire.
►Do not open the housing or disassemble the battery.
►Do not use the battery if there is a risk it has come into
contact with water.
Storing the battery
►If the battery is not going to be used for an extended
period, set the charge level to approximately 50% of
the maximum capacity and ore it at temperatures up
to max. 30°C.
Environmental conditions
►Do not expose the product to rain, snow, liquids or
moiure.
ABOUT THIS MANUAL
This manual describes the mo impoant functions of the
beyerdynamic SPACE Personal Speakerphone.
The information in this manual refers to the default settings
of the soware. A newer version may be available.
►You can find information about soware updates
under „Soware update“ on page8.
SCOPE OF DELIVERY
•beyerdynamic SPACE
•USB-C to USB-C cable
•USB-C to USB-A adapter
•Drawring orage bag
•Quick Sta Guide
PRODUCT OVERVIEW
123
4
1 On/o button
2 USB-C po with atus LED display
3 Kensington lock
4 Illuminated control ring with operating and dis-
play elements:
Multifunction button
Mute button (red LED display)
Increase volume (white LED display)
Decrease volume (white LED display)
Hang up (red LED display)
Pick up (green LED display)
Segmented battery atus
(green/yellow/red LED display)
Bluetooth® (blue LED display)
English

Fir eps
8/14 beyerdynamic SPACE Personal Speakerphone
FIRST STEPS
Removing from packaging and oring
►When not in use and for transpo, ore the beyerdy-
namic SPACE Personal Speakerphone and accessories
in the carrying case.
This provides the be protection and prevents damage.
Securing your Personal Speakerphone
The Personal Speakerphone has a 1/4“ threaded hole in
the centre of its underside, which can be used to screw it
onto a tripod, for example.
Charging the battery
We recommend you use only the supplied USB cable to
charge the battery.
1. Use the cable supplied to connect the beyerdynamic
SPACE Personal Speakerphone to any andard-com-
pliant live USB-C socket (e.g. USB power adapter) via
the USB-C po. If necessary, use a USB adapter (see
„Scope of delivery“ on page7).
2. Remove the USB cable aer charging.
Remarks on the life of Li-ion batteries
•When fully charged, disconnect the USB cable from the
charging unit and the beyerdynamic SPACE Personal
Speakerphone.
• CAUTION! High temperatures, especially with a high
charge level, can cause irreversible damage.
•If the battery is not used or is ored for extended
periods of time, it is recommended to charge it to
approx. 50% and ore it at no more than 20°C.
•Switch o the battery-powered product aer use.
Displaying the battery charge level
►Briefly press the button once.
The charge level is displayed via the LED ring.
Using the product with a USB cable
connection
You can operate the beyerdynamic SPACE Personal
Speakerphone with a PC or laptop using a USB cable
connection.
1. Switch on the laptop/PC.
2. Connect the beyerdynamic SPACE Personal Speaker-
phone with the desired computer using the enclosed
USB cable and the USB po.
If necessary, use a USB adapter (USB-C to USB-A, see
„Scope of delivery“ on page7).
3. If the speakerphone has not come on automatically,
switch it on with the on/o switch.
LED display of charge level:
Red*: Battery 0–25 % full
–
Yellow: Battery 25–62.5 % full
–
Green: Battery 62.5–100 % full
–
*) The LED flashes when the charge level is close to zero
Using the product with Bluetooth®
connection
You can operate the beyerdynamic SPACE Personal
Speakerphone via Bluetooth® with a smaphone or PC.
For this, the Bluetooth®function mu be active, and the
speakerphone mu be paired with the output device.
You can find inructions on how to operate the product
under „Operation“ on page9.
SOFTWARE UPDATE
Firmware updates are carried out via USB-HID
using the beyerdynamic Update Hub. The so-
ware for updating the product can be down-
loaded here:
https://byr.li/firmwareupdate
The device has a firmware update function
(DFU) via USB connection to a PC (Windows and
Mac OS).
During the update process, the LED ring flashes
magenta.
COMPATIBILITY WITH PLAYBACK
DEVICES
The beyerdynamic SPACE Personal Speakerphone is
compatible with Bluetooth® playback devices that
suppo the following profiles:
•A2DP (for audio transmission)
•HFP (for phone operation)
All associated functions are only available if they are
suppoed by the playback device.
SUPPORTED AUDIO CODECS
The beyerdynamic SPACE Personal Speakerphone
suppos the audio codec SBC.
Please note that only the Codecs available in the play-
back device can be used for audio transmission.
The playback device and the beyerdynamic SPACE
Personal Speakerphone device automatically select the
be mutually available Codec: In this case SBC.

Operation
beyerdynamic SPACE Personal Speakerphone 9/14
OPERATION
Switching on and o
To switch on:
►Press the on/o button for 1 to 3 sec.
To switch o:
►Press the on/o button again for 1 to 3 sec.
Activating and deactivating the
Bluetooth® function
Activate:
►Press thebutton twice, holding it down the second time.
The LED lights up white: Bluetooth® function is activated
Deactivate:
►Press thebutton twice, holding it down the second time.
The LED is not lit: Bluetooth® function is deactivated.
Pairing with a device via Bluetooth®
Before you can use the beyerdynamic SPACE Personal
Speakerphone, you mu pair it with your mobile phone
or another Bluetooth®-enabled device. The connection
process may dier depending on the device.
►Please refer to the relevant operating inructions of
the device with which you wish to pair the Personal
Speakerphone.
To eablish a connection:
9Ensure the beyerdynamic SPACE Personal Speaker-
phone is switched on.
1. Press and hold the button for 1 to 3 sec.
The Bluetooth® connection mode will sta.
The LED display flashes alternately blue and red.
2. Activate the Bluetooth® function on the playback
device and search for new devices if necessary.
3. In the Bluetooth® menu of the playback device, select
“SPACE” from the available devices and connect both
devices.
Aer a successful connection, the LED lights up blue.
Each time the device is switched on again, the devices
will connect as soon as they are within range of each
other.
Connecting with Google Fa Pair:
Android devices from Android 6.0+ enable a fa connec-
tion via Google Fa Pair.
1. Sta the connection to your beyerdynamic SPACE
Personal Speakerphone as described above.
“beyerdynamic SPACE Personal Speakerphone” is
displayed on the connected device.
2. Select “beyerdynamic SPACE Personal Speakerphone”.
The two devices are connected.
If the Bluetooth® connection has been lo, the LED briefly
flashes blue every 2.5 sec.
Deleting the li of already connected devices:
►Press thebutton for longer than 10sec.
The list of already connected Bluetooth®devices
(maximum eight) is deleted and a connection to the
active Bluetooth®device is established.
A double signal tone confirms success.
Bluetooth® connection with a USB
Bluetooth® adapter
A USB Bluetooth®-Adapter is required to enable a wire-
less Bluetooth® connection to a laptop or desktop PC
while ensuring compatibility and synchronisation of the
corresponding commands from related communication
plaorms such as Microso Teams. The andard laptop
and desktop PC Bluetooth®protocols do not suppo
these commands.
The USB WL Adapter (optionally available) has a pairing
button to be able to connect it to a beyerdynamic SPACE
Personal Speakerphone. It can be ored on the under-
side of the beyerdynamic SPACE Personal Speakerphone.
For more information, please refer to the operating
inructions of your USB Bluetooth®adapter.
Connection displays
LED display of the connection atus:
Bluetooth®:
Pairing/recognition possible
Flashes blue
and red
alternately
Bluetooth®:
Connected
Steady blue
Bluetooth®:
Connectable / connection lo
Flashes blue
Connected to USB Entire LED
ring lights up
white
Connecting two speakerphones to form
a ereo pair (for music playback)
To set up a cascade
1. Press the button and the  button
simultaneously for 1 to 3sec on the fir
SPACE device.
Flashes
red
2. Press the button and the  button
simultaneously for 1 to 3sec on the second
SPACE device.
Flashes
red
The two SPACE devices connect via True
Wireless.
When the two devices are successfully
paired, you will hear “cascade successful”
English

Operation
10/14 beyerdynamic SPACE Personal Speakerphone
To delete a cascade
9Check that both SPACE devices are connected.
►Briefly press the button and the button
simultaneously on both SPACE devices.
The Bluetooth® connection between the two devices
(cascading) is deleted.
Multi-point operation
The beyerdynamic SPACE Personal Speakerphone can be
paired with severalBluetooth®-enabled devices.
In normal mode, up to eight devices can be paired.
In business mode, only one device can be paired.
Active connections are possible with up to two devices at
a time. However, playback of music and phone operation
is only possible with one device at a time. Phone opera-
tion has priority over playback of music, i.e. playback of
music is interrupted during phone calls.
Priority li when using the playback devices (PD):
PRI. Profile Playback devices (PD)
1 HFP (phone operation) PD 1 (device used fir)
2 HFP (phone operation) PD 2 (device used second)
3 A2DP
(playback of music)
PD 1 (device used fir)
4 A2DP
(playback of music)
PD 2 (device used second)
Setting up multi point:
1. Connect the Personal Speakerphone to the fir
device (see „Pairing with a device via Bluetooth®“ on
page9).
2. Deactivate the Bluetooth® connection on the fir
device.
3. Connect the Personal Speakerphone to the second
device (see „Pairing with a device via Bluetooth®“ on
page9).
4. Reactivate the Bluetooth® connection of the fir
device that automatically connects to the product.
Once both devices are paired with the Personal Speak-
erphone, the speakerphone connects to both devices
each time it is switched on.
Using multi point:
9If you have connected the speakerphone with two
devices and have ju activated media playback:
►Briefly press the button once to accept an
incoming call.
9If you have connected the speakerphone to two
devices and have ju ended a call:
►Briefly press the button once to a the media
playback that was la played.
Adjuing the volume
To increase/decrease the volume:
►In ages: Briefly press the / button.
►Continuously: Hold down the / button.
A signal tone sounds when the maximum/minimum
volume is reached.
LED display for volume control:
White: zero*–full volume**
–
*) At a volume close to zero LEDs except one (lit 50%) are
o.
**) At full volume, all LEDs are on (ring illuminated white).
Using the mute function
To switch mute on/o:
►Briefly press the button.
Icon is a steady red when mute.
►Briefly press the button again.
Mute is cancelled.
Playing media
The functions described depend on the playback device
and playback device soware and may not be avail-
able.
To a / pause playback:
►Briefly press the button once.
To play the next / previous track:
►Briefly press the button twice / three times.
Calling up the personal assiant
To call up the personal assiant of your smaphone or
tablet:
►Press the button for 1 to 3sec.
Using Sound-Activated Lighting Mode
When Sound-Activated Lighting Mode is activated, the
LED ring lights up in time with the audio signals.
To switch on the function:
►Press the button and button simultaneously
for 1 to 3sec.
To switch o the function:
►Press the button and button simultaneously
for 1 to 3sec.

Operation
beyerdynamic SPACE Personal Speakerphone 11/14
Using Business Mode
In Business Mode, a maximum of one device can be
paired with the beyerdynamic SPACE Personal Speaker-
phone. The pairing li is automatically deleted when the
speakerphone is disconnected or switched o.
To call up Business Mode:
►Press thebutton and button simultaneously
for 1 to 3sec.
To deactivate Business Mode:
►Press thebutton and button simultaneously
for 1 to 3sec.
Using Stealth Mode
In Stealth Mode, the illumination of the LED ring on the
beyerdynamic Personal Speakerphone can be switched
o without switching o the speakerphone.
Operating in Stealth Mode increases battery life during
operation.
To activate Stealth Mode:
►Press the button and button simultaneously
for 1 to 3sec.
The lighting on the LED ring goes out.
To deactivate Stealth Mode:
►Press the button and button simultaneously
for 1 to 3sec.
The lighting on the LED ring comes on.
Stealth Mode is also deactivated when the speaker-
phone is switched o and on again.
Controlling calls
To accept a call:
►Briefly press the button.
To end a call:
►Briefly press the button.
To reject a call:
►Briefly press the button.
To switch a call or accept a second call:
►Briefly press the button.
LED display for calls:
Incoming call flashes green
flashes red
Call in progress eady green
eady red
Call on hold flashes green
eady red
Using voice messages
To activate voice messages:
►Press the button and button simultaneously
for 1 to 3sec.
To deactivate voice messages:
►Press the button and button simultaneously
for 1 to 3sec.
Resetting to factory settings
All personal data is deleted if the device is reset to the
factory settings!
To reset to factory settings:
►Press thebutton and button simultaneously
for 3 to 4sec.
Settings for be sound
To achieve the be possible sound with your beyerdy-
namic SPACE Personal Speakerphone via Bluetooth®,
please observe the following practical tips:
1. Set the volume to minimum on your beyerdynamic
SPACE Personal Speakerphone and to maximum on the
playback device.
2. Then adju the volume only on your beyerdynamic
SPACE Personal Speakerphone and not on the play-
back device.
This applies only to playback devices that do not auto-
matically synchronise the volume. On playback devices
that automatically synchronise the volume (e.g. iPhone,
iPad, various Android smaphones), the volume on the
speakerphone is always identical to the volume of the
playback device.
3. Deactivate any audio eects that may be present in
the soware of the playback device.
English

Help with problems / FAQ
12/14 beyerdynamic SPACE Personal Speakerphone
Attaching a Kensington lock
To attach and lock the lock
1. Loop the lock cable around a secure anchor and
inse the lock head into the Kensington socket of your
Personal Speakerphone.
2. Lock the lock with the enclosed key.
To open and remove the lock
1. Open the lock with the enclosed key.
2. Pull the lock head out of the Kensington socket and
remove the lock with the lock cable.
Overview of operating functions
Function Operation
To switch on and o ►Press the on/o
button for 1 to 3
sec.
To a/op playback ►Press briefly
Next track ►Briefly press
twice
Previous track ►Briefly press
three times
To call up the personal
assiant
►Press for 1 to
3sec
To mute/unmute ►Press briefly
To increase volume ►Tap to increase
in ages
►Hold to increase
continuously
To decrease volume ►Tap to decrease
in ages
►Hold to
decrease
continuously
To end a call ►Press briefly
To reject a call ►Press briefly
To answer a call ►Press briefly
To switch calls ►Briefly press
twice
To display the battery
atus
►Press briefly
Activate/deactivate
Bluetooth®
►twice, holding
it down the
second time
To pair ►Press for 1 to
3sec
To delete pairing and
pairing li
►Press and hold
for at lea
10sec
To switch on Sound-
Activated Lighting
Mode +
►Press simulta-
neously for 1 to
3sec
Function Operation
To switch o Sound-
Activated Lighting
Mode +
►Press simulta-
neously for 1 to
3sec
To switch on Business
Mode +
►Press simulta-
neously for 1 to
3sec
To switch o Business
Mode +
►Press simulta-
neously for 1 to
3sec
To activate/deactivate
Stealth Mode +
►Press simulta-
neously for 1 to
3sec
To switch on voice mes-
sages +
►Press simulta-
neously for 1 to
3sec
To switch o voice
messages +
►Press simulta-
neously for 1 to
3sec
To reset to factory
settings +
►Press simulta-
neously for 3 to
5sec
To activate/deactivate
cascading1) +
►Press simulta-
neously for 1 to
3sec
1) Can only be used if the second device is detected within 5 m
range and indicated by the Bluetooth®-LEDs.
HELP WITH PROBLEMS / FAQ
beyerdynamic SPACE Personal Speakerphone will not
switch on
Battery is empty or almo
empty.
►Charge the battery.
No audio output.
There is no Bluetooth® con-
nection.
►Connect beyerdynamic
SPACE Personal Speaker-
phone with the playback
device.
The beyerdynamic SPACE Personal Speakerphone does
not appear among the available Bluetooth® devices in
the playback device.
The beyerdynamic SPACE
Personal Speakerphone is
switched o.
►Switch on the beyerdy-
namic SPACE Personal
Speakerphone.
The beyerdynamic SPACE
Personal Speakerphone is
not in connection mode.
►Set the beyerdynamic
SPACE Personal Speak-
erphone to connection
mode.
There is already a Blue-
tooth® connection to
another playback device.
►Disconnect the Blue-
tooth® connection to the
other playback device
and connect the beyer-
dynamic SPACE Personal
Speakerphone to the
desired device.

Battery life
beyerdynamic SPACE Personal Speakerphone 13/14
The sound reproduction is too low, even though set to
maximum on the beyerdynamic SPACE Personal Speaker-
phone
The audio signal being
played back is too quiet.
►Set playback volume on
the playback device to
maximum.
The wireless range is too low, or the connection is
disrupted
There is inteerence with
other devices.
►Keep your diance from
WLAN routers and micro-
wave ovens.
►Do not and between
the playback device and
the beyerdynamic SPACE
Personal Speakerphone.
BATTERY LIFE
•Disconnect the USBconnecting cable from the charging
unit and speakerphone.
•High temperatures, especially with a high charge level,
can cause irreversible damage.
•If the battery is not used or is ored for extended
periods of time, it is recommended to charge it to
approx. 50% and ore it at no more than 20°C.
•Switch o the battery-powered product aer use.
CLEANING AND MAINTENANCE
•Use a so cloth moiened with alcohol cleaner to
clean all pas of the beyerdynamic SPACE Personal
Speakerphone. Make sure that no liquid enters the
housing or the transducer.
•Do not use cleaners containing solvents, as these can
damage the suace.
DISPOSAL
This symbol on the product, in the oper-
ating inructions or on the packaging
means that the electrical and electronic
devices mu be disposed of separately
from household wae at the end of their
life cycle.
►Always dispose of used devices in accordance with
the regulations in force.
►For fuher information, please contact your local
authority or the dealer from whom the product was
purchased.
Battery disposal
►Both disposable and rechargeable batteries mu be
disposed of separately from the product aer use in
accordance with the regulations in force. They mu
not be disposed of in household wae.
►Both disposable and rechargeable batteries mu be
discharged and removed before disposal.
IMPORTANT: Non-deructive removal of either dispo-
sable or rechargeable batteries by the end user is not
possible with this product. Please contact beyerdynamic
or consult independent specialis.
EU/UK DECLARATION OF
CONFORMITY
beyerdynamic hereby declares that this radio
transmission device complies with the EU Directive
2014/53/EU and the UK Directive “The Radio Equipment
Regulations 2017”.
►The full text of the EU/UK declaration of conformity can
be found on the Internet at: www.beyerdynamic.com/
cod
TECHNICAL SPECIFICATIONS
Bluetooth® frequency range 2.400 to 2.4835GHz
Transmitting power up to 4dBm
Maximum loudspeaker output 5 W RMS
Sound pressure level SPL=73.8dBA
(pink noise),
SPLmax=81dB@1kHz
Microphone type 4 x MEMS
Microphone frequency range 100Hz to 10kHz
Loudspeaker frequency range 90Hz~ 15KHz (-10dB)
Suppoed profiles HFP, A2DP
Connection Bluetooth® and USB-C
Bluetooth® version 5.0
Battery technology lithium ion
Battery life typ. 20 hours with
communication
Charging connection USB-C
Time of charge 2.5 hours (5V / 1.5 A)
Firmware update possible yes
Length x width x height (mm) 132x132x40
Weight 354 g
►You can find more detailed information about the
technical specifications online at:
www.beyerdynamic.com/SPACE.html
WARRANTY CONDITIONS
beyerdynamic provides a limited guarantee for the orig-
inal beyerdynamic product you have purchased.
►You can find detailed information about beyerdynam-
ic’s warranty conditions on the Internet at:
www.beyerdynamic.de/service/garantie
English
