SelfPoweredBike MA01
User Manual
BEYOND MOTOR TECHNOLOGIES, INC

2/ 18
CONTNTS
Introduction:................................................................................................................................................ 3
Purpose of the manual: ........................................................................................................................... 3
Components of the bike: ........................................................................................................................ 4
Getting Started:.......................................................................................................................................... 5
Maintenance and Care:............................................................................................................................ 6
Charging Guidelines ................................................................................................................................. 7
Troubleshooting......................................................................................................................................... 8
Safety Guidelines ....................................................................................................................................... 8
Appendix ....................................................................................................................................................11
Main Technical Specifications: ........................................................................................................11
Dashboard Operation:.......................................................................................................................12
I、Function and display.........................................................................................................12
II、Operation Setting...........................................................................................................13
III、System Settings.............................................................................................................. 15
Installation Diagram:..........................................................................................................................16

3/ 18
Introduction:
Thank you for choosing the SelfPoweredBike electric assist bicycle. Our bike features
an AI-based electromechanical system that intelligently determines the current road
conditions and rider status to provide power assist as needed, making your ride
easier while conserving energy and increasing the bike's range.
With our efficient magnetic power generation technology and intelligent power
regenerative system, the front wheel generates electricity to recharge the battery
without adding any resistance or reducing the bike's efficiency. This helps to
maintain the battery's charge level and extend the bike's range.
The power assist has five levels ranging from 0 to 5, with level 0 being no power
assist and level 5 being the highest power assist. The higher the power level, the
more energy is consumed. If the power assist level is set to 0 or the battery level
drops below 30V, the electric assist system will be turned off, and the front wheel's
rotational energy will be stored in the battery without being consumed.
The bike also features a fully electric mode, allowing the bike to be powered entirely
by the battery without pedaling. However, this mode will consume the battery's
charge more quickly.
Safety is a top priority for us, and the bike's power safety system automatically cuts
off the power when the brakes are applied. In this manual, you will learn how to use
the SelfPoweredBike electric assist bicycle correctly and safely.
Purpose of the manual:
This manual is intended to provide you with essential information on how to operate
and maintain your SelfPoweredBike electric assist bicycle safely and correctly. The
manual explains the components of the bike and their functions, how to start and
use the electric assist, how to maintain and care for the bike, how to troubleshoot
common problems, legal information, and an appendix with additional details.
By following the instructions in this manual, you can ensure that your
SelfPoweredBike electric assist bicycle operates correctly and safely, and you can
extend the life of the bike and its components. Please read this manual carefully
before using the bike for the first time and keep it for future reference.

4/ 18
Components of the bike:
The following are the components of the bike.
⚫Dashboard: displays information such as speed, distance traveled, battery level,
and power assist level selection.
⚫Light and horn switch: controls the headlights and horn on the electric bike.
⚫Throttle: When the throttle is engaged, it activates the motor, which propels the
bicycle forward without the need for pedaling.
⚫Seat: provides a place for the rider to sit.
⚫Fenders: protect the rider and bike from mud and water.
⚫Rear wheel: provides the driving force for the electric bike and is powered by the
motor.
⚫Motor: provides power to the electric bike and assists the rider's pedaling effort.
⚫Pedals: used by the rider to pedal the electric bike.
⚫Power control box: houses the electronic components that control the motor,
battery, and other systems.
⚫Front wheel: provides steering and support for the electric bike.
⚫Generator: Generating electricity for the entire electric-assisted bicycle,
including the lighting, horn, and motor.
⚫Light and horn: used to increase visibility and signal other riders or pedestrians.

5/ 18
Getting Started:
Congratulations on your purchase of the SelfPoweredBike electric-assisted bicycle.
Before you get started, please take a few minutes to read this guide to ensure proper
and safe operation.
Power on and off:
To power on the bicycle, press and hold the power button on the dashboard until the
power indicator light turns on. To power off the bicycle, press and hold the power
button again until the power indicator light turns off.
Assist mode selection:
The electric assist mode has 5 levels, with 1 being the lowest power level and 5 being
the highest power level. Each time the bicycle is powered on, it will automatically
return to the last assist mode setting (user can also set it). To switch between the
assist modes, press the up or down button on the dashboard. Assist mode 0 means
turning off the electric-assist function.
Riding in electric assist mode:
Once the assist mode is selected, pedal the bicycle as normal, and the electric-assist
system will automatically provide power according to your needs. The electric-assist
system is intelligent and can judge the road conditions and the rider's situation in
real-time, and provide the appropriate assist power to ensure a more comfortable
and efficient riding experience. Please note that the higher the assist power level,
the more power it will consume.
Riding in fully electric mode:
The SelfPoweredBike can also be ridden in fully electric mode without pedaling.
Simply rotate the throttle to start the electric motor. Please note that riding in fully
electric mode will consume the battery power faster than in electric assist mode.
Charging:
The electric bike has a high-efficiency magnetic power generation technology,
coupled with an intelligent power recharge system, which can recharge the battery
while cycling without increasing pedaling resistance or reducing efficiency. In normal
usage conditions, users can almost not rely on external chargers to charge the bike.
However, the charger can be used if necessary. When the charger's input and output
terminals are connected, the charger's red indicator light will light up. The charger
has an overcurrent protection device. Long-time charging (usually not more than 18
hours) will not affect the battery and charger's lifespan.

6/ 18
Safety:
The electric safety system will automatically cut off the power when the brakes are
applied.
Battery status:
When the battery voltage is lower than 30V or the assist mode is set to 0, the
electric-assist system will be disabled, and the bike will run like a regular bike. The
bike's AI system is designed to optimize power consumption to increase the bike's
mileage.
We hope that this guide has been helpful to you and wish you a safe and enjoyable
riding experience.
Maintenance and Care:
Economic Riding:
To save energy, try to maintain a steady speed while riding and avoid frequent
braking and starting.
Avoid Overloading:
Do not overload the bike or apply the brakes while twisting the throttle, as this can
overload the motor and damage other components.
Overload Protection:
The controller is equipped with overload protection. If the system detects an
overload, it will automatically shut down to prevent damage to the motor.
Charging:
Charging is generally not necessary if the bike is used conservatively. However, the
bike can be charged using the charger provided. The charger has overcurrent
protection, and charging time should not exceed 18 hours to avoid damage to the
battery and charger.

7/ 18
Charging Guidelines
To ensure the safe use of your electric-assist bicycle and optimize battery
performance, we provide you with the following charging guidelines. Please make
sure to comply with them:
1. Initial Charging:
When charging your bicycle for the first time, ensure that you use the provided
original charger and follow the instructions in the product manual. To ensure that the
battery charges quickly, the product is set to fast charging mode for the first three
charging cycles after leaving the factory.
2. Pedal-Assisted Power:
One unique feature of the electric-assist bicycle is the ability to supplement battery
power by pedaling. This method not only promotes environmental friendliness but
also extends the battery's usage time. We encourage you to make full use of pedal-
assisted power to reduce reliance on the charger.
3. Charging Frequency:
To ensure battery stability and longevity, it is recommended to avoid frequent
charging with the charger. The product system is designed to utilize fast charging
mode for the first three charging cycles to ensure the battery charges quickly.
Afterward, the charging mode will automatically switch to slow charging to protect
the battery and minimize risks.
4. Charging Time:
Regarding the charging time for the electric-assist bicycle's battery, as the product
system sets the first three charges to fast charging mode, it is advisable to ensure
the battery is fully charged during these cycles. Subsequent charges will
automatically switch to the system's default charging mode. Generally, it takes
approximately 10-12 hours to fully charge the battery. Please observe the charging
status indicator during use and follow the instructions in the product manual.
5. Safety Environment:
During charging, ensure that the surrounding environment is dry, well-ventilated, and
free from moisture or potential sources of ignition. Additionally, avoid exposing the
charger to high temperatures or extreme temperature conditions.
Please note that the above charging guidelines are intended to ensure the safety of
your electric-assist bicycle and optimize battery performance. If you have any
questions or require further guidance, please refer to the contact information in the
product manual or consult a qualified professional.

8/ 18
Troubleshooting
In this chapter, we will provide some troubleshooting tips for common problems you
may encounter while using your SelfPoweredBike electric assist bicycle.
Problem: The bike won't start
Solution: Make sure the power button on the dashboard is pressed and the battery
is charged. If the battery is low, you may need to charge it before the bike will start.
Check that the battery is properly installed and that all connections are secure.
Problem: The electric assist is not working
Solution: First, check that the electric assist is turned on. If it is on and still not
working, check that the power level is set to a value greater than zero. If the battery
charge is low, the electric assist may not work properly. In this case, charge the
battery and try again. If the problem persists, contact our customer support team.
Problem: The bike is making strange noises
Solution: Inspect the bike for any loose or damaged components. Check the brakes,
pedals, wheels, and chain. Tighten or replace any loose or damaged parts as needed.
If the problem persists, take the bike to a qualified technician for further inspection.
Problem: The battery does not hold a charge
Solution: Check that the battery is properly installed and that all connections are
secure. If the battery is old or has been exposed to extreme temperatures, it may
need to be replaced. You can purchase a replacement battery from our website or
contact our customer support team for assistance.
Safety Guidelines
The following important instructions must be followed by users of the
SelfPoweredBike electric assist bike. Failure to follow these instructions may result
in damage to the bike, injury, or other hazards. By using the bike, the user agrees to
assume all responsibility for any consequences arising from their use of the bike.
1. Temperature Effects on Battery Performance:
Almost all types of batteries are affected by the environment. Generally, a higher
temperature improves the battery's discharge performance, while temperatures
below 0℃ may cause the battery's power to decrease by more than one-third.
Therefore, in winter or in cold regions, the range of a single charge may decrease,
which is normal. When the temperature rises above 20℃, the function of the battery

9/ 18
will naturally recover.
2. Caution When Handling Battery:
When pulling the battery assembly, do not insert metal objects (such as wires, keys,
etc.) into the battery charging port or touch the positive and negative contacts of
the battery output with metal objects to avoid short circuits, fires, and other safety
issues.
3. Avoid Water Damage:
This bike is resistant to rain and snow but not waterproof. When the water level
submerges the controller, wire circuits, or motor hub, it will cause a short circuit and
damage the electrical components. Please be sure to pay attention to this.
4. Use Only Authorized Chargers and Accessories:
Do not use chargers and accessories that are not authorized by the manufacturer. If
an accident occurs as a result, the manufacturer is not responsible.
5. Prohibited Modification of the Bike:
Unauthorized modification or alteration of the bike is prohibited. The manufacturer
will not be responsible for any damage caused by such modifications, and it may also
invalidate the warranty. If there are internal malfunctions, please contact the local
dealer or designated repair center.
6. Restriction on User Age:
Minors, pregnant women, and elderly people should not use electric bicycles.
7. Do Not Modify the Bike Body:
Unauthorized disassembly and modification of the bike body may cause safety
hazards and danger to the rider.
8. Caution When Riding Downhill:
Do not ride downhill at excessive speeds, and do not use the front brake first when
braking at high speeds to avoid danger caused by forward weight shift.
9. Do Not Lubricate the Brake Parts:
Do not add oil to the brake parts, as it may cause the brakes to fail and create danger.
10. Safety Check Before Riding:
Before riding, always check the safety and reliability of the brakes, saddle, frame,
handlebars, and wheels to avoid accidents.
11. Avoid Rough Roads:
Avoid riding on uneven, muddy, stony roads or stairs to prevent tire punctures, wheel
deformation, damage to the electric bike, and accidents.

10 / 18
12. Do Not Hang Objects on the Handlebars:
Do not hang objects on the handlebars while riding to avoid losing control and
causing accidents.
13. Battery Safety:
The battery should not be placed near a fire source, or any flammable, explosive, or
corrosive gases.
14. Prohibition of Battery Disassembly:
Do not disassemble the battery or the battery box, as it may damage internal
components. Do not damage the labels on the battery or the battery box cover;
otherwise, the warranty will be invalidated.
15. One Rider Only:
The electric bike is designed for one rider only. Do not carry passengers to avoid
imbalance, instability, and danger.
16. Avoid Short Circuits:
Do not short-circuit the positive and negative terminals of the battery with wires or
conductors to avoid danger and battery damage.
17. Handle the Battery with Care:
The battery should be handled with care, to avoid collisions, falls, and drops that may
damage the casing and cause accidents.
18. Please note that electric bicycles are not suitable for long-distance travel.
The final interpretation of all the terms and conditions in this manual belongs to the
company.

11 / 18
Appendix
Main Technical Specifications:
I. Main Technical Parameters of the Electric Vehicle:
Overall weight: 32kg
Payload capacity: 80kg
Recommended speed: 15km/h
Gradeability: 30°
Rated power: 250W
Energy consumption per 100km: 1.08 KWH
II. Main Technical Parameters of the Battery:
Type: Maintenance-free lithium iron battery
Capacity: 36V/20AH
Rated working voltage: DC36V
Charging time: 6-7 hours
Energy consumption per 100km: 1.08KWH
III. Main Technical Parameters of the Electric Motor:
Type: 36V motor
Rated continuous output power: 250W
Rated voltage: 36V
Rated current: 7A
Motor efficiency: 90%
IV. Main Technical Parameters of the Controller:
Type: 36V controller
Undervoltage protection value: 32V±1V
Overcurrent protection value: 15A±1A

12 / 18
Dashboard Operation:
Before using the dashboard, please read this operating manual carefully. The manual
will guide you in the correct use of the dashboard and enable you to access various
control and status display functions.
I、Function and display
1
Up
11
Km/H
Real-time riding speed (metric)
2
Power ON/OFF
MPH
Real-time riding speed (imperial)
3
Down
MXS
Single maximum riding speed display
4
ASSIST
Assist level
AVS
Single average riding speed display
5
Remaining power display
12
Km
Cycling Mileage (Metric)
6
CRUISE
cruise function
Mil
Cycling mileage (imperial)
7
PAS
Assist function
DST
Single ride mileage display
8
TM
Single ride time
ODO
Cumulative mileage display
TTM
Cumulative riding time
display
VOL
Battery real-time voltage display
9
THROTTLE
Rolling handle turn on
13
brake sign
10
6Km/H assist rolling
14
Backlight on sign

13 / 18
II、Operation Setting
1. Power on and off: Press and hold ，power on，then press and hold
again，power off. When the bike is stopped cycling and the dashboard is not
been operated for 5 consecutive minutes, the dashboard will automatically shut
down and turn off the power of the electric bike.
2. User Interface 01
Press and hold ，power on, access to the User Interface
01
2.1 Turn on the backlight and headlights
long press turns on the backlight and lights; then long
press again to turn off the backlight and lights.
2.2 Switching of ASSIST Gear
short press or switch gears from 1-5 ，1
presents the lowest power level, 5 presents the highest. Each
time you start the machine, the gear will be automatically
restored to the last shutdown position (the user can set it
separately). No power assist in gear 0.
2.3 6km/h assist rolling function
Hold , then flashing，bike rolls at a speed of no
more than 6km/h. Release ， the function is cancelled.
2.4 Throttle
If the throttle is turned, this THROTTLE indicator will be
displayed.

14 / 18
2.5 PAS
When pedaling the bicycle and triggering the system to provide
assistance for riding, this PAS indicator will be displayed.
2.6 CRUISE
if the riding speed is more than 7km/h, press and hold , to
activate the Cruise function, deactivate if take brake or press any
key.
2.7 Single data display and clear
After start the system in 5 seconds, press and at the
same time, single ride time (TM) and single ride mileage (DST)
flash. Press shortly to clear both contents. If the button
is not pressed within 5 seconds, it will automatically return to
the display interface 01 after 5 seconds, and the original
content will be retained.
3. User Interface 02
In User Interface 01, press the key briefly to enter User
Interface 02. In riding state, after 5 seconds, User Interface
02 will automatically return to User Interface 01.
4. User Interface 03
In User Interface 02, press the key briefly to enter User
Interface 03. In riding state, after 5 seconds, displaying the
single maximum speed (MXS), it automatically returns to the
real-time riding speed (Km/H) display.
At the bottom of this User Interface 03, the displayed
information is VOL: battery voltage.
In User Interface 03, press the key briefly to enter User
Interface 01.

15 / 18
III、System Settings
1. Set the maximum riding speed
Within 5 seconds after turning on the power, press the
and keys at the same time, and the maximum riding
speed Km/H will flash. Press the or key briefly
to set the maximum riding speed value (default 25Km/H).
Press the key briefly to switch to the next parameter
setting.
2. Set the wheel diameter
After setting the maximum riding speed, set the wheel
diameter, and the wheel diameter specification flashes. Press
the or key briefly to set the wheel diameter
specification. The selection range is 6, 8, 10, 12, 14, 16, 18, 20,
22, 24, 26 and 28 inches. Press the key briefly to
switch to the next parameter setting.
3. Set metric/imperial units
After completing the wheel diameter setting, the next step is to set the unit of
measurement to metric or imperial. At this time, the symbols for km/h and km
will flash. Press the or button briefly to synchronously select the
unit of measurement for speed and distance traveled.
4. After completing the unit setting, the symbols “Km/h" and "Km" will stop flashing.
Press the button again to enter the maximum riding speed setting
interface, or press and hold the button to exit the regular system
settings and save the settings, and return to the User Interface 01.
5. After each of the three Regular System Settings is completed, if you long-press
the button, you can exit the setup environment and return to User
Interface 01, and the settings will be saved. In each setting interface, if there is
no button operation for more than 1 minute, it will automatically return to User
Interface 01 and the current setting will be invalid.

16 / 18
Installation Diagram:

17 / 18

18 / 18
