Art. 3484
Chain Hoist, Capacity 2 to.
Safety advice
Check the chain hoist before use: Check hook, chain and brake for proper operation and whether the
block has been lubricated, sufficiently. For a safe and secure operation, follow these six simple rules:
1. Never try to lift things that weigh more than the maximum capacity of the chain hoist (2 to.).
2. Never work the chain as a noose.
3. Never use the hoist with a knotted chain.
4. To avoid accidents, never stand under a load while being lifted.
5. In case of the chain being stuck, do not use excessive force but check the hoist block for
sufficient lubrication.
6. Only use the chain hoist for vertical lifting operations. The chain hoist has not been designed for
pulling/dragging heavy loads.
Technical specifications
Maximum capacity: 2000 kg
Maximum stroke length: 2500 mm
Expenditure of energy
under full load: 315 N
Height (min. measurement): 420 mm
Weight: 15 kg

SW-Stahl und Werkzeugvertriebs GmbH Tel. [phone] / 46438-0
F56essartSresukreveL ax +49 (0) 2191 / 46438-40
ed.lhatsws@ofni:liaM-EdiehcsmeR79824-D
Instruction Manual
BGS technic KG
Bandwirkerstr. 3
42929 Wermelskirchen
Tel.: [phone]
Fax.: [phone]
[email protected]
www.bgstechnic.com
Maintenance and service
Clean the chain hoist after each use and store it under dry conditions to avoid corrosion.
Clean the chain block once a year: Bath all parts in kerosene and lubricate them afterwards. It
would be best to have all parts be cleaned and serviced by a qualified expert.
Both “O"-labels on each brake wheel should be aligned to each other.
Mount the wheels of the left and right bearing via its inner raceway to the sprocket wheel
journal. Then, put the bearings’ outer raceway onto the side panels.
While assembling the brake mechanism, keep in mind, that the locking chopper disc’s crooked
teeth and the chopper tooth are engaged. Make sure that the chopper tooth is carefully and
reliably controlled by the spring mechanism. Turn the hand wheel clockwise, after it has been
screwed onto the crank shaft. It needs to push disc and panels against the brake’s base.
When turning the hand wheel counter clockwise you should be able to observe a growing
distance between brake and disc.
The anchor and the right side panel are snug fitted. Be careful to not break them off.
After maintenance and service you should test run the chain block first: Test run the chain
block in idle use first and under heavy to maximum load, secondly. If the chain hoist operates
properly during the test runs, it can be operated as needed.
Keep the rubbing surfaces of the brake mechanism clean, while lubricating or using it. Check
the brake mechanism regularly to avoid unintended braking or possible malfunction of the
brakes: Both can cause the lifted load to be dropped.
During maintenance or disassembly, one link of the chain is always opened for your
convenience.

SW-Stahl und Werkzeugvertriebs GmbH Tel. [phone] / 46438-0
F56essartSresukreveL ax +49 (0) 2191 / 46438-40
ed.lhatsws@ofni:liaM-EdiehcsmeR79824-D
CE-Erklärung
BGS technic KG
Bandwirkerstr. 3
42929 Wermelskirchen
Tel.: [phone]
Fax.: [phone]
[email protected]
www.bgstechnic.com
EU-Konformitätserklärung
EC DECLARATION OF CONFORMITY
DÉCLARATION „CE“ DE CONFORMITE
DECLARATION DE CONFORMIDAD UE
Wir erklären in alleiniger Verantwortung, dass die Bauart der:
We declare that the following designated product:
Nous déclarons sous propre responsabilité que ce produit:
Declaramos bajo nuestra sola responsabilidad que este producto:
Kettenzug ( BGS Art. 3484 )
Chain block / Hoist
Palan à chaîne
Polipasto de cadena
folgenden einschlägigen Bestimmungen entspricht:
complies with the requirements of the:
est en conformité avec les réglementations ci-dessous:
esta conforme a las normas:
Machine Directive 2006/42/EC
Angewandte Normen:
Identification of regulations/standards:
Norme appliquée:
Normas aplicadas:
EN 1494:2000+A1:2008
EN 13157+A1:2009
Registration No. : AM 50170400 0001/HS2t
Report No.: 15020978 002
Wermelskirchen, den 27.02.2014
ppa.
Frank Schottke, Prokurist
