Bifinett KH 3460 User manual

Kompernaß Handelsgesellschaft mbH
Burgstr. 21 • D-44867 Bochum
www.kompernass.com
ID-Nr. KH3460/07-04V2
UK

 Operating Instructions

















GB
3
Professional Meat Grinder
Bifinett KH 3460
Contents
1. Intended use .............................. 3
2. Technical data ............................ 3
3. Delivery contents ...................... 3
4. Safety instructions .................... 4
5. Assembly.................................... 5
6. Operation .................................. 7
7. Troubleshooting.......................... 9
8. Cleaning .................................... 9
9. Storage .................................... 10
10. Disposal.................................... 10
11. Warranty and service ................10
1. Intended use
This appliance is meant to be usedfor
processing foods in small quantities,
enough for private households.
•Mincing fresh meat,
•Making sausages with natural or
artificial sausage skin,
•Grating vegetables
•Crushing fruit with seeds as well as
seedless fruits.
•Making shortbread cookies
This appliance is not meant to be
used for processing frozen foods or
other hard foodstuffs, e.g. bones or
nuts. It is not to be used for commer-
cial or industrial purposes.
2. Technical Data
Voltage ....................: 230 V / ~50 Hz
Power consumption : 550 W max.
Weight ....................: 4,57 kg approx.
Dimensions (mm) ....: 325x160x317
3. Delivery Contents
Motor block
Meat grinder casing
Transport screw
Cross blade
cutting discs for coarse
and fine grinds
Ring clamp
Feeding tray
Round stodger
Sausage disc
Sausage attachment
Kubbe attachment
Grater funnel
Square stodger
Coarse grater attachment
Fine grater attachment
Cutter attachment
Shortbread cookies attachment
Keep this manual for future reference and pass it on with the device to any future
users!

GB
4
4. Safety Instructions
To avoid life-threatening electric
shocks:
•Make sure that the cable is not
damaged. Protect the cable from
heat and make sure that it does
not get stuck or clamped.
•If the cable or the electric plug
is damaged, get it replaced by
customer service, before you con-
tinue using the appliance.
•Use the appliance only in a dry
areas, and not outdoors.
•Never immerse the motor in
water or other liquids! You might
suffer from a life-threatening elec-
tric shock.
Warning!
Never use the appliance for any
other purposes other than those
listed here. There is a major possi-
bility of accidents if you mistakenly
happen to turn off the safety device
of the appliance!
4. Safety Instructions
To avoid the risk of accidents and
injuries:
•Never put your hand into the
openings of the appliance. Do
not insert any objects through
the openings – except for the
appropriate stodger and the food-
stuff to be processed. Otherwise,
there are chances of a serious risk
of accidents!
•Unplug the appliance, before
attaching or removing the acces-
sories.
•Do not leave the appliance unsu-
pervised, when it is ready for use.
Always unplug the appliance after
use or during breaks in order to
avoid it from being turned on acci-
dentally.
•Only use original accessories,
which are meant for this appli-
ance. Other parts may probably
not meet the safety requirements.
•Do not allow children and elderly
people to handle the appliance
without supervision, since they
may not always be able to assess
potential hazards.

GB
5
5. Assembly
All accessories are coated with a thin
oil film to protect them from corrosion.
Therefore clean all the parts carefully
before using the appliance for the first
time, in accordance with the detailed
instructions found under “8 Cleaning”.
a) Assembling the meat grinder
Unfold the fold out. There you will find
the step-by-step illustrations for
assembling the appliance.
•Place the transport screw with
the hexagonal axle in the mincer
casing .
Ensure that the metal washer
remains on the hexagonal axle.
Without the washer, the screw
would close too fast.
•Now place the cross blade so
that the sharp side is facing the
cutting disc . Warning - the
blade is very sharp!
Attention: the device can get dam-
aged if the cross blade is wrongly
inserted in the opposite direction!
•Choose the appropriate cutting
disc – You can find the discs in the
small recess at the top of the
device (Fig. D).
For this push the cover upwards
and take out the required disc.
•Insert both the edges of the chosen
disc into the slots in the mincer
casing .
•After everything has been assem-
bled correctly, screw on the ring
clamp tightly.
5.
Assembly
•The assembled meat grinder is con-
nected by a bayonet joint to the
motor block :
- Insert the meat grinder into the
motor block. The arrow on the
mincer casing should be on the
symbol “offen” (open) (Fig. A).
- Press in the meat grinder lightly.
Turn the stuffing funnel of the
meat grinder upwards till it is ver-
tical (Fig. B).
- To take it out, once again press
down the meat grinder lightly and
turn the stuffing funnel in the
direction of the symbol ”offen“
(Fig. A). Now you can pull out the
meat grinder.
•Finally place the feed tray  on
top on the stuffing funnel.
b) Fixing the sausage stuffer
attachment
Once the meat grinder has been
assembled as described under a):
•Turn open the ring clamp and ...
•Replace the cutting disc with
the sausage disc . This can be
found in the small recess (Fig. D)
on the top of the device. Fix this in
as described in a).
•Now place the sausage stuffer
attachment  in front of the
sausage disc, ...
•before screwing on the ring clamp
tightly.

GB
6
c) Fixing the kubbe attachment
Once the meat grinder has been
assembled as described under a):
•Turn open the ring clamp and ...
•Replace the cutting disc  with the
two plastic parts of the kubbe
attachment . Fix these as
described in a).
•When everything has been
attached correctly, screw on the
ring clamp tightly.
d) Fixing the grater and cutter
attachments
When the meat grinder has been
removed from the motor block:
•First select the appropriate attach-
ment. You can choose from...
- a coarse grater ,
- a fine grater ,
- a cutter attachment .
•Fix the grater or cutter attachment
in the provided round recesses in
the grater funnel. .
•Place the grater funnel in the motor
block in such a way that the arrow
of the grater funnel points to the
symbol ”open“.
Press in the grater funnel lightly
and turn it upwards till it is in a ver-
tical position.
•To remove once again press in the
grater funnel lightly and turn it in
the direction of the symbol "open“
(Fig. A). Now you can take out the
grater funnel.
e) Fixing the shortbread cookie
attachments
Once the meat grinder has been
assembled as described under a):
•Turn open the ring clamp and ...
•take out the cutting disc and the
cross blade .
•Remove the pattern strips from the
shortbread cookie attachment 
and ...
•place the shortbread cookie
attachment in the mincer casing
.
Insert both the edges of the short-
bread cookie attachment into
the slots in the mincer casing .
•When everything has been
attached correctly, screw on the
ring clamp tightly and ...
•once again attach the pattern
strips to the front part of the short-
bread cookie attachment.
•To remove you must again remove
the pattern strip first, before turn-
ing open the ring clamp and
taking out the shortbread cookie
attachment .

GB
7
6. Operation
Attention: In the case of foods, which
need to be processed at high speeds,
the appliance should not be run for
longer than 10 seconds (!) at a
stretch. Let there be a break of 30
seconds before switching it on again,
to prevent the motor from overheating.
One can tell that the machine is being
overused when the sound of the motor
changes and slows down.
a) Operating the appliance
Once the appropriate attachments
have been fixed:
•Place the appliance in such a way
that it is absolutely stable and
cannot fall off the table or into
water (due to vibrations or if it gets
caught in the cable). . The machine
will inevitably vibrate when it is run-
ning.
Warning: Never touch a machine,
which is plugged in or is operational
when it happens to fall or land in
water – or in the case of other
emergencies!
First unplug the appliance in all
emergency situations! Otherwise
one runs the risk of serious injury or
loss of life!
•
Place the food, which is to be
processed in the feeding tray
and
place a vessel to collect the
processed food in front under the
opening.
6. Operation
•First press the OFF button, to
ensure that the appliance is off.
Then plug in...
and set it to ON , to switch it on.
•Now push in the food with the
round or square stodger in
the feeding tube - never with one’s
fingers, forks, spoons or similar
objects. This could lead to injury
and also damage the appliance.
Attention: Do not ever press so
hard that the motor gets audibly
slower. This could put the machine
under pressure and damage it.
b) Processing meat
•Only use meat pieces, which are
not larger than 2 cm. Check that
the meat does not have any bones
and is not stringy.
•Caution: Mincemeat is prone to
decay. Therefore take care to main-
tain good hygiene when processing
meat.
•When you have read all the instruc-
tions on the topic ”Meat“, you can
use the appliance as described
under 6.a).

GB
8
c) Processing sausage meat
•Put the meat through the meat
grinder twice before using it as
sausage stuffing.
•To make the sausage stuffing, add
some chopped onions, spices and
other ingredients to the mincemeat
as per your recipe, and knead the
mixture. Refrigerate this for 30 min-
utes before processing it further.
•Put the sausage skin (natural or
artificial sausage skin) on the
sausage stuffer attachment10 and
knot up the other end. For 1 kg of
the filling, you will need approxi-
mately 1.60 m of sausage skin.
Tip: Soak the natural sausage skin
in lukewarm water for about 3
hours before using it and then
wring out. Natural sausage skin will
thus get more elastic.
•The sausage mixture will be
pressed into the sausage skin by
the sausage stuffer. When it is long
enough switch off the device and
press together the sausage at the
end and turn it around its longitudi-
nal axis.
Tip: Sausage meat tends to
expand when cooked or frozen.
Therefore it is best not to overstuff
the sausage to prevent it from
splitting.
•After you have read all the instruc-
tions about the topic “Sausage“,
you can use the machine as
described under 6 a).
d) Grating and cutting
After you have placed the food to be
grated into the feeding tray:
•Push them with the square stodger
into the feeding tube .
•If some food is stuck on the grating
attachments: Switch off the
device before removing the
attachments or reaching in to
clean them. Otherwise there is the
risk of getting injured.
•After you have read all the instruc-
tions about the topic “Grating and
cutting“, you can use the machine
as described under 6 a).
e) Using the kubbe attachment
With the kubbe attachment foodstuffs
can be processed to form hollow rolls
of meat or vegetables, which can then
be stuffed as desired.
•Put the meat through the meat
grinder twice before pressing it
through the kubbe attachment.
•After you have read all the instruc-
tions about the topic “Kubbe
attachment“, you can use the
machine as described under 6 a).
f) Making shortbread cookies
After you have made the shortbread
dough according to your recipe, and
after having fixed the shortbread cookie
attachment:
•Line a small baking tray with
greaseproof paper and place or
hold it directly under the opening in
the front of the appliance.

GB
9
•Press dough evenly into the feed-
ing tube – the transport screw
pushes it through the design on the
pattern strip of the shortbread
cookie attachment .
•After you have read all the instruc-
tions about the topic ”shortbread
cookie attachment“, you can use the
appliance as described under 6 a).
Warning:
Never open the casing of the
motor block– There are no operat-
ing parts to be found there. If the
casing is opened there exists the
possibility of a life-threatening
electric shock.
7. Troubleshooting
If the smooth running of the appliance
is hampered by excessive or stuck
food:
•Keep the REV key pressed. The
machine will now run in the reverse
direction. This will enable you to
dislodge the food, which has got
stuck, and the machine will once
again run smoothly.
•If you do not succeed by doing so,
clean the machine as described
under 8.
If the motor stops suddenly, it could
be due to the internal overload warn-
ing device, which automatically turns
off the machine when overloaded. This
is supposed to protect the motor.
•Switch off the device and let it cool
down for approximately 15 minutes
before using it again.
•In case this does not work, wait for
a further 15 minutes.
•If it still does not function at the
end of this period, this indicates a
technical problem. In this case,
contact the service centre.
If themains cable is damaged or or
the accessories are visibly damaged:
•Switch off the device by pressing
the OFF button!
•if this is not safely possible unplug
the appliance.
•Get the parts be repaired by cus-
tomer service, before reusing the
appliance again.
8. Cleaning
Pull out the plug from the socket,
before cleaning the appliance.
In this way accidents caused by the
unexpected switching on of the
machine and electric shocks can be
prevented.
a) Cleaning the Motor block
•Clean the external surfaces and
the power cord with a slightly
damp cloth. Always dry the device
well before using it again.
•Warning: Never immerse the motor
block in water or any other liquid!
Otherwise one could get a life
threatening electric shock, if mois-
ture, which has crept in, touches
the electrical wiring.

GB
10
•Never use any cleansers, abrasive
substances or solvents. These
could damage the device.
b) Cleaning accessories
•Wash all the accessories that can
come in contact with food, ...
- by hand only, the accessories
are not dishwasher safe.
- with hot water and a household
cleaning liquid suitable for food-
stuff surfaces
•Caution: The cross blade and the
shredder attachments are very
sharp!
•Dry all parts thoroughly, before
reusing the appliance.
9. Storage
•Wind the mains cable under the
bottom part of the appliance. In
this way, it is protected from dam-
age.
•Store the discs in the small recess
(Fig. D) on top of the machine.
•Store the appliance in a dry place.
•After drying the metal attachments
rub them lightly with a little cooking
oil, if you are not going to use the
device immediately. This will pro-
tect them from corrosion.
•Keep the machine away from chil-
dren and elderly people. They may
not always be able to assess
potential dangers of the heating
elements of such devices.
10. Disposal
Tip: Care for the environment.
If you wish to dispose of the device,
dispose of it at a collection site for
recycling of electronics.
Make the appliance unusable by
removing the plug before disposing of
the appliance, in order to prevent acci-
dents caused by children playing with
the appliance.
Ensure that sharp parts (cross blade,
shredder attachments) are removed to
protect children.
11. Warranty and service
The warranty conditions and service
centre address can be found in the
enclosed warranty slip.
