3PC AW WICKER SOFA SET
ASSEMBLY INSTRUCTIONS
ITEM# SW-RK970
SKU# 810503339
DO NOT RETURN THIS PRODUCT TO THE STORE. FOR MISSING PARTS OR QUESTIONS TO THIS PRODUCT PLEASE CALL US
AT 1-888-733-8169 OR EMAIL US AT customerservice [e-mail] OR customerservice [e-mail] OR customerservice [e-mail]
IMPORTANT :
Please read all the instructions and warnings before assembling . In order to make the whole product adjust to the best, please install all the screws on the product
before fully tighten, and note to put the washer to the screw before putting the screw into the screw hole.
WARNING :
Use the correct screws as indicated. All screws should be hand tighten until the complete piece is assembled ( This will make the
assembly process much easier ). Once the piece is fully assembled, then go back and tighten all screws with provided tool.
Keep all children and pets away from assembly area. Children and pets should be supervised when they are in the area of the product construction.
Keep assembly area at leat 6 feet from any obstruction such as a fence, garage, house, overhanging branches, laundry line or electrical wires.
Some parts may contain sharp edges. When assembling and using this product, basic safety precautions should always be followed to reduce the risk of personal
injury and damage to the product. Please read all instructions before assembly and use.
The product is for sitting purpose only. The product is not to be used for standing purposes and will not function as a stool or step-ladder. Use on even surfaces
only.
Sofa and Lounger tested for use at weight of 350 lb (159kg). Ottoman tested for use at weight of 250 lb (113.6kg).
Improper use of this product or failure to use as directed may result in injury. Not intended for commercial use.
CARE & MAINTENANCE
STAIN RESISTANT CUSHIONS CARE —— KEEP THE CUSHIONS IN STORAGE IN RAINING DAY.
SPILLS: Immediately wipe up the spill using a white damp cloth. Repeat process if necessary until stain is gone. Allow cushion to air dry.
FABRIC CARE: Hand wash cold, non-chlorine bleach when needed, lay flat to dry. Cool iron if necessary. Do not dry clean.
ALL WEAHTER WICKER PRODUCT CARE
Before using, clean the product completely with a soft dry towel. When not in use, wipe free of any dirt or loose objects, wash with a mild solution of soap and
water, rinse thoroughly and dry completely. Do not use strong detergent or abrasive cleaners. Screws can be loosen over a peirod of usage, please check the screws
occasionally and re-tighten if necessary.

PARTS LIST
NO. Part Qty Image NO. Part Qty Image
ALeft Arm Board
(With Connector Hole ) 1KWasher 26
BSofa Seat Panel 1LNut 18
C
Sofa Back Panel
(With Connector and
Connector Hole)
1MAllen Wrench 1
DLounger Seat Panel 1NWrench 1
E
Lounger Back Panel
(With Connector and
Connector Hole)
1OPlastic Plug 2
FRight Arm Board
( With Connector ) 1POttoman Cushion 1
GOttoman Seat Board 1QSofa Seat Cushion 1
HOttoman Side Board 2RLounger Seat Cushion 1
IScrew (M6X60MM) 18 SSmall Back Cushion 2
JScrew (M6X35MM) 8TBig Back Cushion 3
Warranty
One-year limited warrantly.
Proof of purchase (dated register receipt) is required for warranty claims.
It remains the customer's responsibility for freight and packing charges to and from the service center.

ASSEMBLING SITTING ARRANGEMENT 1
STEP 1 STEP 2
Secure Sofa Seat Panel (B) to Left Arm Board (A) with 3 Screw (I), 3
Washer (K) and 3 Nut (L) by using Allen Wrench (M) and Wrench (N)
. Do not tighten all screws now.
Secure Sofa Back Panel (C) to Left Arm Board (A) and Sofa Seat
Panel (B) with 5 Screw (I), 5 Washer (K) and 5 Nut (L) by using Allen
Wrench (M) and Wrench (N) . Connect Sofa Back Panel (C) to Left
Arm Board (A) by Connector. Do not tighten all screws now.
STEP 3
Secure Lounger Seat Panel (D) to Sofa Seat Panel (B) with 3 Screw (I), 3 Washer (K) and 3 Nut (L) by using Allen Wrench (M) and Wrench
(N) . Do not tighten all screws now.
STEP 4
Secure Lounger Back Panel (E) to Lounger Seat Panel (D) and Sofa Back Panel (C) with 3 Screw (I), 3 Washer (K) and 3 Nut (L) by using
Allen Wrench (M) and Wrench (N) . Connect Lounger Back Panel (E) to Sofa Back Panel (C) by Connector. Do not tighten all screws now.

STEP 5
Secure Right Arm Board (F) to Lounger Back Panel (E) and Lounger Seat Panel (D) with 3 Screw (I), 3 Washer (K) and 3 Nut (L) by using
Allen Wrench (M) and Wrench (N) . Connect Right Arm Board (F) to Lounger Back Panel (E) by Connector. Do not tighten all screws now.
STEP 6 STEP 7
Insert 2 Plastic Plug (O) to Sofa Seat Panel (B) and Left Arm Board
(A) by hand.
Secure 1 Ottoman Side Board (H) to Ottoman Seat Board (G) 4 Screw
(J) and 4 Washer (K) by using Allen Wrench (M). Do not tighten all
screws now.
STEP 8 STEP 9
Secure 1 Ottoman Side Board (H) to Ottoman Seat Board (G) 4 Screw
(J) and 4 Washer (K) by using Allen Wrench (M). Do not tighten all
screws now.
Verify the alignment and adjust, fully tighten all screws. Put cushions
on assembled sofa set.

ASSEMBLING SITTING ARRANGEMENT 2
STEP 1 STEP 2
Secure Left Arm Board (A) to Lounger Seat Panel (D) with 3 Screw
(I), 3 Washer (K) and 3 Nut (L) by using Allen Wrench (M) and
Wrench (N) . Do not tighten all screws now.
Secure Lounger Back Panel (E) to Left Arm Board (A) and Lounger
Seat Panel (D) with 3 Screw (I), 3 Washer (K) and 3 Nut (L) by using
Allen Wrench (M) and Wrench (N) . Connect Lounger Back Panel (E)
to Left Arm Board (A) by Connector. Do not tighten all screws now.
STEP 3
Secure Sofa Seat Panel (B) to Lounger Seat Panel (D) with 3 Screw (I), 3 Washer (K) and 3 Nut (L) by using Allen Wrench (M) and Wrench
(N) . Do not tighten all screws now.
STEP 4
Secure Sofa Back Panel (C) to Sofa Seat Panel (B) and Lounger Back Panel (E) with 5 Screw (I), 5 Washer (K) and 5 Nut (L) by using Allen
Wrench (M) and Wrench (N) . Connect Sofa Back Panel (C) to Lounger Back Panel (E) by Connector. Do not tighten all screws now.

STEP 5
Secure Right Arm Board (F) to Sofa Seat Panel (B) and Sofa Back Panel (C) with 4 Screw (I), 4 Washer (K) and 4 Nut (L) by using Allen
Wrench (M) and Wrench (N) . Connect Right Arm Board (F) to Sofa Back Panel (C) by Connector. Do not tighten all screws now.
STEP 6 STEP 7
Insert 2 Plastic Plug (O) to Sofa Seat Panel (B) and Right Arm Board
(F) by hand.
Secure 1 Ottoman Side Board (H) to Ottoman Seat Board (G) 4 Screw
(J) and 4 Washer (K) by using Allen Wrench (M). Do not tighten all
screws now.
STEP 8 STEP 9
Secure 1 Ottoman Side Board (H) to Ottoman Seat Board (G) 4 Screw
(J) and 4 Washer (K) by using Allen Wrench (M). Do not tighten all
screws now.
Verify the alignment and adjust, fully tighten all screws. Put cushions
on assembled sofa set.
