Biomorph XO2EL Manual

1
DIRECTIONS FOR USE / ASSEMBLING
IMPORTANT NOTES!
Prior to installment, use and maintenance of the table frame, any installer and any userof the table must study
this assembly and operation manual carefully, so as to gain a complete understanding ofits contents.
EN
WARNING
WARNING: FAILURE TO COMPLY WITH OR OBSERVE ALL
ASSEMBLY, SAFETY AND OPERATION INSTRUCTIONS
AND WARNINGS REGARDING THE USE OF THIS
PRODUCT MAY RESULT IN SERIOUS BODILY INJURY.
No. 312
75
0
.
7
xo2EL
biomorph
®
Questions? call 888 302 3375
Ground Support Equipment (US) Ltd. DBA biomorph, 11 Broadway, New York, NY 10004 Tel: [phone] fax:[phone] [email protected]
www.biomorph.com
Dual and single surface versions

2
TABLE OF CONTENT
1. SAFETY AND WARNINGS
2. USAGE
3. SET UP AND INSTALLATION
4. OPERATION
5. MAINTENANCE AND DEFECTS
6. TECHNICAL DATA
7. PARTS
8. ASSEMBLY DIRECTIONS
9. DECLARATION OF CONFORMITY
1. SAFETY AND WARNINGS
2. USAGE
The electromotive, height-adjustable tables are designed for workstations in dry work environments only.
The table height is infinitely adjustable, so that it can be set to the most ergonomically suitable working
level.
They have not been designed for other purposes than those included in this manual, e.g. they are not to
be used in areas of high humidity or dampness, nor for lifting people.
Any other use is at one’s own risk!
Do not crawl, lie or move around under the table frame, and do not sit or stand on the table
frame.
CHILDREN should only use the table when supervised by adults.
Liability: The manufacturer accepts under no circumstances warranty claims or liability claims for
damages arising from improper use or handling of the table frame other than that described in this
operation manual.
3. SET UP AND INSTALLATION
When the table has been assembled (see assembly instructions chapter 8) the adjustable feet are installed
so that the table is level and does not shift. Then the table is connected to the 110-230 VAC outlet and the
table is ready for use.
Make sure that no cables can get jammed.
Place the table in a safe distance from window frames, radiators, furniture etc. so that people do not get
stuck.
Do not place any objects above 55 cm underneath the table.
When moving the table after it has been assembled, the tabletop needs to be removed. The table
CANNOT be lifted by the tabletop.
4. OPERATION
This table complies with the prescribed safety regulations. Inappropriate use may cause damage to
persons and table.
Please read the operation manual prior to start using the table. It provides you with important
information about safety, use, installation and maintenance of the table, and thus protecting you
and your children and avoiding damage on the table.
Please guard this operation manual and pass it on to any future owner!
UP/DOWN operation:
Push button and UP or DOWN
button must be pressed
SIMULTANEOUSLY.
Push button

3
5. MAINTENANCE AND DEFECTS
The table does not require any maintenance by usage as described in chapter 2 in the directions for use.
The table is only to be maintained with a wrung cloth.
In the event of the occurrence of jarring sounds during operation, STOP using the table and please
contact the dealer.
6. TECHNICAL DATA
Frame, materials and weights: Steel, silver - Weight metal frame ~ 30 kg
W
D
60-160 cm
50-100 cm
H
V (speed)
68 – 120 cm
~28 mm/sek.
FMAX = Max. Load on tabletop: 120 kg
Operation: Rocker switches
Voltage:
Stanby consumption:
220-230 VAC / 50Hz or 110-100 VAC / 60Hz
< 0,15 Watt
7. PARTS (containing 2a, 2b or 2c and 3a or 3b, assembly is similar on all)
F
MAX
W
D
H
a) x 12
c) x 16
e) x 2
1
2a
4
5
d) x 1
g) x 4
2b
2c
3b
3a

4
3
5
8. ASSEMBLY DIRECTIONS
2
1
1
a) x 6
e) x 2
d) x 1
2a
2b
2c
3a
3b
a) x 6

xo2EL
biomorph
®
Frame, materials and weights: Steel, silver - Weight metal frame ~ 30 kg
W
D
60-160 cm
50-100 cm
H
V(speed)
68 – 120 cm
~28 mm/sek.
FMAX = Max. Load on tabletop: 120 kg
Operation: Rocker switches
Voltage:
Consumption:
220-230 VAC / 50Hz or 110-100 VAC / 60Hz
80 Watt
1. Attach V-Foot to bottom of post,
upside down.
4. Slip power supply bracket into slot
in left bracket. 5 Place power supply into bracket and
run power cord through hole in support
bracket.
-
8. Attach control switch to large surface using
pilot holes. Connect cables as per diagram, use
guides to organize cables under surface
.
OPERATION: Press either up or down arrow
and desk will move in the up or down direction.
-
7. Place keyboard surface ontop of
foam packing from frame box, attach
keyboard mech using pilot holes. Push
into slide under main surface, attach
plastic end-cap, rotating keyboard
surface if necessary for access.
2. Turn upright, attach left support bracket.
Run cord through hole.
3. Attach right support bracket.
Ground Support Equipment (US) Ltd. DBA biomorph, 11 Broadway, New York, NY 10004 Tel: [phone] fax:[phone] [email protected]
www.biomorph.com
ASSEMBLY INSTRUCTIONS - In concert with frame instructions QUESTIONS? CALL US AT 888 302 3375
6. If dual surface version, place large
surface ontop of foam from frame
box, and mount keyboard mechanism
slide with included screws. (This step
not necessary for single surface
version) Then flip over and mount
onto frame using screws provided
and pilot holes.
