BLUM FLATPAX OFFICE FURNITURE RANGEASSEMBLY GUIDEDESK RETURN 1350mm X 450mm X 575mmDufixMinifix4Plastic Glide BrownD - TopJ - Back PanelF - PartitionG - Fixed ShelfH - Fixed ShelfC - Floor BottomE - Fixed ShelfB - Visible Side LeftA - Visible Side LeftI - Front PanelTOTAL NUMBER OF PANELS: 10HARDWAREPRODUCTQTY36Wooden Dowel72136IMAGE

GSPublisherVersion 241.1.7.100
2TOOLS REQUIREDScrew Driver(Pozidriv Head)Cordless DrillPozi Bit (PZ2) 1. Confirm that all panels (10) are in the package before assembling. 2. Check the white sticker on each panel for the labelling (A, B, C, D, E, F, G, H, I & J). 3. Ensure that the panels are laid on a non-abrasive surface when assembling. 4. Note that all panel connections are done using the system described below.Rubber Mallet8mm Drill Bit2 O'ClockPosition230°PANEL CONNECTION AND FASTENINGGENERAL INSTRUCTIONSDet. 1Det. 2Det. 3IIIIIIIVI - Insert the Minifix (1), Dufix (1) and wooden dowels (2) in the shown positions.Gently knock in the wooden dowels using a rubber mallet where necessary.II - Confirm that the Minifix orientation is as shown in Det. 1 then connect thepanels.III - Using a screw driver, turn the Minifix 230° clockwise to fasten the panelstogether. Refer to Det. 2.IV - See Det. 3 for Minifix orientation when fastened. Reset the Minifixorientation to that shown in Det.1 to disconnect the panels.

GSPublisherVersion 241.1.7.100
STEP 1STEP 2Connect panels G & H to panel I as shown. Refer to the holes on the diagram to determine thepanel orientation.Connect panel J to panels G & H as shown. Refer to the holes on the diagram to determine thepanel orientation.3JGHGHII

GSPublisherVersion 241.1.7.100
STEP 3STEP 4Connect panels G & H to panel F as shown. Refer to the holes on the diagram to determine thepanel orientation.Connect panel E to panels A & B as shown. Refer to the holes on the diagram to determine thepanel orientation.4EHGAFB

GSPublisherVersion 241.1.7.100
STEP 5STEP 6Connect panel E to panel F as shown. Refer to the holes on the diagram to determine the panelorientation.Connect panels A, B, F, I & J to panel D as shown. Refer to the holes the diagram to determine thepanel orientation.5IEFABJGABIFJDE

GSPublisherVersion 241.1.7.100
STEP 7STEP 8Connect panel C to panel A, B, F, I & J as shown. Refer to the holes on the diagram to determinethe panel orientation.Using a rubber mallet, knock in the Plastic Glides in the shown positions on panel C. Refer to theindicated dimensions for positioning. Flip the Desk Return upright to finish.6IEFABJGABFJDECD50 mm50 mm50 mm50 mm10 mm10 mmC
