Bionaire BASF40B User manual

CLEANING AND MAINTENANCE
•Always unplug the fan before cleaning.
•Do not allow water to drip on or into the fan
motor housing.
FITTING A REPLACEMENT PLUG
FOR U.K. AND IRELAND ONLY
If the plug is not suitable for the socket outlets in
your home, it can be removed and replaced by a
plug of the correct type. Please refer to
"Installation of a plug" below.
Installation of a plug Applicable to U.K.
and Ireland.
WARNING - THIS APPLIANCE MUST BE
EARTHED.
The wires in the mains lead are coloured as such:
GREEN AND YELLOW - EARTH
BROWN - LIVE
BLUE - NEUTRAL
Please note that the colour of these mains wires
may not correspond with the colour markings
that identify the terminals in your plug.
Please proceed as follows:
The wire which is coloured GREEN AND YELLOW
must be connected to the terminal which is marked
with the letter 'E' or by the earth symbol or
coloured GREEN AND YELLOW.
The BROWN coloured wire must be connected
to the terminal, which is marked with the letter
"L" or is coloured RED.
The BLUE coloured wire must be connected to
the terminal, which is marked with the letter "N"
or is coloured BLACK.
NOTE: If the terminals in the plug are not marked
or if you are unsure or in doubt about the installation
of the plug please contact a qualified electrician.
If a 13A 3-pin plug is fitted, it must be anASTA
approved plug, conforming to BS1363 standard.
Replacement 3A fuses must be BSI orASTA
BS1362 approved.
GUARANTEE
PLEASE KEEP YOUR RECEIPTAS THIS WILL
BE REQUIRED FOR ANY CLAIMS UNDERTHIS
GUARANTEE.
•This product is guaranteed for 3 years.
•In the unlikely event of breakdown, please take
it back to the place of purchase, with your till
receipt and a copy of this guarantee.
•The rights and benefits under this guarantee
are additional to your statutory rights which
are not affected by this guarantee.
• Holmes Products Europe undertakes within
the specific period, to repair or replace free of
charge, any part of the appliance found to be
defective provided that:
• We are promptly informed of the defect.
• The appliance has not been altered in
any way or subjected to misuse or
repair by a person other than a person
authorised by Holmes Products
Europe.
• No rights are given under this guarantee to a
person acquiring the appliance second hand
or for commercial or communal uses.
• Any repaired or replaced appliance will be
guaranteed on these terms for the remaining
portion of the guarantee.
THIS PRODUCT IS MANUFACTURED TO
COMPLY WITH THE E.E.C. DIRECTIVES
73/23/EEC, 89/336/EEC AND 98/37/EEC.
Waste electrical products should
not be disposed of with
Household waste.
Please recycle where facilities
exist.
Check on the following website
for further recycling and WEEE
information:
www.bionaire.com or e-mail
[email protected]
3 amp
®
®
9100010006871
BASF40IUK05M1
BASF40
CONTEMPORARY
STAND fan
Holmes Products (Europe) Ltd
1 Francis Grove
London SW19 4DT
England
Fax: [phone]
Email: [email protected]
Website address: www.bionaire.com
UK - Free phone Customer Service Helpline – 0800 052 3615
INSTRUCTION MANUAL
© 2005 JCS/THG, LLC
Bionaire®and the Bionaire logo®are trademarks of JCS/THG, LLC.
BASF40WIUK05EM1.qxd 11/29/05 2:13 PM Page 1

PLEASE READ AND SAVE THESE
IMPORTANT INSTRUCTIONS
When using electrical appliances, basic safety
precautions should always be taken including
the following:
•Use the fan only for purposes described in
the instruction manual.
•To protect against electrical shock, do not
immerse the fan, plug or mains cable in
water or spray with liquids.
•Close supervision is necessary when any
appliance is used by or near children.
•Unplug from the electrical outlet when not in
use, when moving the fan from one location
to another, before putting on or taking off
parts and before cleaning.
•Avoid contact with any moving parts.
•Do not operate in the presence of explosives
and/or flammable fumes.
•Do not place the fan or any parts near an
open flame, cooking or other heating
appliance.
•Do not operate any appliance with a
damaged mains cable, plug, after the
appliance malfunctions, or has been
dropped/damaged in any manner.
•The use of attachments not recommended or
sold by the appliance manufacturer may
cause hazards.
•Do not let the mains cable hang over the
edge of a table or counter, or come into
contact with hot surfaces.
•To disconnect from the electrical supply, grip
the plug and pull from the wall outlet. DO
NOT pull on the mains cable.
•Always use on a dry, level surface.
•Do not operate without the fan grills properly
in place.
•This product is intended for household use
ONLY and not for commercial or industrial
applications.
•Should the appliance stop working, first
check the fuse in the plug (UK only) or
fuse/circuit breaker at the distribution board is
operating, before contacting the manufacturer
or service agent.
•If the supply cord or plug is damaged, it must
be replaced by the manufacturer or its
service agent or a similarly qualified person
in order to avoid hazard.
•The appliance contains no user serviceable
parts and should the product suffer damage
or breakdown it must be returned to the
manufacturer or its service agent.
•Do not use outdoors.
•The fan should not be operated without its
base fitted.
•The fan should not be operated laying on its
side.
•NOTE: Use caution when adjusting the tilt
angle of the fan head to ensure that your
fingers do not get caught.
•Under the environment with electrical fast
transient, the product may malfunction and
require user to reset the product.
MISSING A PART FOR YOUR FAN?
Please call 0800 052 3615 for assistance.
ASSEMBLY INSTRUCTIONS
Please see pictures on inside cover
pages (Fig. 1 - 12)
1. Assembly requires the use of a Phillips head
screwdriver and wrench.
2. In Figure 7, insert Bolt (D) and attach Screw
(K). Thread TiltAdjustment (E) onto the end
of (D). Secure Locking Screw (J) last.
3. Before proceeding with Figure 11, remove the
protective sleeve from the motor shaft.
4. In Figure 12, there are 2 indentations in the
Grill Ring (T). Make sure that the rear grill
sits in the rear indentation and the Clip (W) is
positioned at the bottom of the grill. Slide the
bottom of the Front Grill (S) into the front
indentation of the Grill Ring. Working from
the bottom, snap the Front Grill into the Grill
Ring. Verify that the grills fit evenly into the
indentations in the Grill Ring and tighten
Screw (U).
OPERATING INSTRUCTIONS (See Fig
1A & 1)
Speed Control (X) =
0 - Off
I - Low
II - Med
III - High
ADJUSTMENT INSTRUCTIONS
Tilt Adjustment
Loosen Tilt-Adjustment Knob (E), move fan head
to desired angle, and tighten TiltAdjustment
Knob (E) to lock in place.
Height Adjustment
Loosen Pole Locking Knob (F), adjust Pole (G)
to desired height, and tighten Pole Locking Knob
(F) to lock in place.
Oscillation Adjustment
Press, Pull Oscillation (Y) = start, stop
U.K. and IRELAND
BASF40
3
4
2112
12
1
42
3
Figure 1
Figure 1A
Figure 2
Figure 3
Figure 5 Figure 6
Figure 4
Figure 2A Figure 7 Figure 8
Figure 9
Figure 11 Figure 12
Figure 10
M
R
SQ
TVWU
A
F
G
I
N
P-(2)
ZJ
D
AF
G
E
K
X
Y
H
C
C
B
L
B
C-(4)
E
H
F
A
G
D
C-(4)
C-(4)
K
I
J
G
I
B
H
A
F
G
A
B
J
K
G
D
E
M
P-(2)
N
Z
R
N
Z
R
M
T
S
L
L
Q
Q
