Bionaire Breeze BSF152T Manual

ADJUSTMENT INSTRUCTIONS
Height Adjustment: To adjust the height of the fan
remove the lower pole. Insert the upper pole into the top
of the base and secure with base weight nut.
Tilt Adjustment: To adjust the angle of the Fan Head,
loosen the Tilt Adjustment knob, move Fan Head to
desired angle, and firmly tighten the Tilt Adjustment
knob.
CLEANING/MAINTENANCE
INSTRUCTIONS
Follow these instructions to correctly and safely care for
your fan.
• Always unplug the fan before cleaning or
disassembling.
• Be sure to clean your fan with a soft cloth moistened
with a mild soap solution.
• Do not allow water to drip on or enter into the fan
housing.
• Do not use gasoline, thinner, or benzene as a
cleaner.
• Lightly run a vacuum cleaner nozzle over the fan
grill to remove any dust or dirt that may have
accumulated.
Fan Blade Cleaning Instructions.
Make sure the fan is unplugged before disassembling
and cleaning the fan blade. Carefully remove the front
grill from the clips. Wipe the blade with a soft cloth
moistened with a mild soap solution. DO NOT allow any
liquid to drip into or enter the motor housing. Snap the
front grill onto the fan. Make sure all parts are secured
prior to operating the fan.
FAN STORAGE
Your fan should be stored in the off-season in its original
box. It is important to keep it in a safe, dry location.
• Store your fan in the original box or an
appropriately sized box.
• Protect the fan head from dust.
• Store your fan in a dry location.
CLEANING AND MAINTENANCE WARRANTY INFORMATION
5 YEAR LIMITED WARRANTY
Sunbeam Products, Inc. doing business as Jarden Consumer Solutions or if in Canada, Sunbeam Corporation (Canada)
Limited doing business as Jarden Consumer Solutions (collectively “JCS”) warrants that for a period of five years from
the date of purchase, this product will be free from defects in material and workmanship. JCS, at its option, will repair
or replace this product or any component of the product found to be defective during the warranty period.
Replacement will be made with a new or remanufactured product or component. If the product is no longer available,
replacement may be made with a similar product of equal or greater value. This is your exclusive warranty. Do NOT
attempt to repair or adjust any electrical or mechanical functions on this product. Doing so will void this warranty.
This warranty is valid for the original retail purchaser from the date of initial retail purchase and is not transferable.
Keep the original sales receipt. Proof of purchase is required to obtain warranty performance. JCS dealers, service
centers, or retail stores selling JCS products do not have the right to alter, modify or any way change the terms and
conditions of this warranty.
This warranty does not cover normal wear of parts or damage resulting from any of the following: negligent use or
misuse of the product, use on improper voltage or current, use contrary to the operating instructions, disassembly,
repair or alteration by anyone other than JCS or an authorized JCS service center. Further, the warranty does not
cover: Acts of God, such as fire, flood, hurricanes and tornadoes.
What are the limits on JCS’s Liability?
JCS shall not be liable for any incidental or consequential damages caused by the breach of any express, implied or
statutory warranty or condition.
Except to the extent prohibited by applicable law, any implied warranty or condition of merchantability or fitness for
a particular purpose is limited in duration to the duration of the above warranty.
JCS disclaims all other warranties, conditions or representations, express, implied, statutory or otherwise.
JCS shall not be liable for any damages of any kind resulting from the purchase, use or misuse of, or inability to use
the product including incidental, special, consequential or similar damages or loss of profits, or for any breach of
contract, fundamental or otherwise, or for any claim brought against purchaser by any other party.
Some provinces, states or jurisdictions do not allow the exclusion or limitation of incidental or consequential damages
or limitations on how long an implied warranty lasts, so the above limitations or exclusion may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights that vary from province to province,
state to state or jurisdiction to jurisdiction.
How to Obtain Warranty Service
In the U.S.A.
If you have any question regarding this warranty or would like to obtain warranty service, please call
1-800-253-2764 and a convenient service center address will be provided to you.
In Canada
If you have any question regarding this warranty or would like to obtain warranty service, please call
1-800-253-2764 and a convenient service center address will be provided to you.
In the U.S.A., this warranty is offered by Sunbeam Products, Inc. doing business Jarden Consumer Solutions located in
Boca Raton, Florida 33431. In Canada, this warranty is offered by Sunbeam Corporation (Canada) Limited doing
business as Jarden Consumer Solutions, located at 20 B Hereford Street, Brampton, Ontario L6Y 0M1. If you have
any other problem or claim in connection with this product, please write our Consumer Service Department. PLEASE
DO NOT RETURN THIS PRODUCT TO ANY OF THESE ADDRESSES OR TO THE PLACE OF PURCHASE.
© 2008 Sunbeam Products, Inc. doing business as Jarden Consumer Solutions. All Rights Reserved.
Distributed by Sunbeam Products, Inc. doing business as Jarden Consumer Solutions, Boca Raton, Florida 33431.
132134/9100010010548 BSF152T08EM1 Printed In China
If you have any questions regarding your product or
would like to learn more about other Bionaire®
products, please contact our Consumer Service
Department at 1-800-253-2764 or visit our website at
www.bionaire.com.
Instruction Leaflet
16 INCH (40CM) PEDESTAL
STAND FAN
MODEL: BSF152T
Read instructions before operating. Retain for future reference.
breeze
Questions? Comments? Call 1-800-253-2764 in North America
or visit our website at www.bionaire.com.
BSF152T-U_08EM1.indd 1BSF152T-U_08EM1.indd 1 12/22/08 3:49:38 PM12/22/08 3:49:38 PM
All manuals and user guides at all-guides.com
all-guides.com

PLEASE READ AND SAVE THESE
IMPORTANT SAFETY INSTRUCTIONS FEATURES - OPERATIONS FEATURES - OPERATIONS
When using electrical appliances, basic safety precautions
should always be taken including the following:
1. Read all instructions before using this appliance.
2. Use fan only for purposes described in the instruction
manual.
3. To protect against electrical shock do not immerse
unit, plug or cord in water or spray with liquids. Plug
the appliance directly into a 120V AC electrical outlet.
4. Close supervision is necessary when any appliance is
used by or near children.
5. Unplug from outlet when not in use, when moving
fan from one location to another, before putting on
or taking off parts and before cleaning.
6. Avoid contact with moving parts.
7. Do not operate in the presence of explosive and/or
flammable fumes.
8. To avoid fire hazard, NEVER place the cord under
rugs or any parts near an open flame, cooking or
other heating appliance.
9. Do not operate any appliance with a damaged cord
or plug after the appliance malfunctions, or has been
dropped/damaged in any manner. Discard fan or
return to an authorized service facility for
examination and/or repair.
10. The use of attachments not recommended or sold by
the appliance manufacturer may cause hazards.
11. Do not use outdoors.
12. Do not let the cord hang over the edge of a table,
counter or come in contact with hot surfaces or leave
exposed to high traffic areas.
13. To disconnect, grip plug and pull from wall outlet.
Never yank on cord.
14. Always use on a dry, level surface.
15. Do not operate fan until fully assembled with all
parts properly in place.
16. This product is intended for household use ONLY and
not for commercial or industrial applications.
17. WARNING: To reduce the risk of electrical shock
injury to persons, do not use in window.
18. WARNING: This fan is provided with an internal
electronic fan speed control. To reduce the risk of fire
or electric shock, do not use this fan with any other
solid-state speed control device.
INSTALLATION INSTRUCTION
PLEASE READ AND SAVE
THESE IMPORTANT
SAFETY INSTRUCTIONS
ASSEMBLY INSTRUCTIONS
Assembly Time: 5-10 Minutes
NOTE: Check all packaging materials and make sure
that you have all of the parts necessary for assembling
your fan.
1. Insert the threaded end of the Lower Pole into the
Base. Refer to Figure 2.
2. Secure the Base Weight to the threaded end of the
Lower Pole with the Base Weight Nut. Refer to Figure 2.
3. Insert the threaded end of the Upper Pole into the
Lower Pole. Twist clockwise to lock. Refer to Figure 3.
4. Slide Neck of the Motor Housing over the Upper Pole
and secure by tightening the Thumb Screw.
5. Secure the Rear Grill to the Motor Housing by
tightening the Rear Grill Mounting Nut. Refer to
Figure 4 for the correct positioning of the Rear Grill
to the Motor Housing.
6. Secure the Fan Blade to the Motor Shaft by
tightening the Fan Blade Cap. Refer to Figure 5.
7. Secure the Front Grill to the Rear Grill by snapping
the Front Grill into the clips around the perimeter of
the Rear Grill.
OPERATING INSTRUCTIONS
1. Set fan on a dry, level surface.
2. Plug cord into any standard 120 volt AC outlet.
3. The speed/mode is adjustable by pushing the Mode/
Off ( ) button either from the fan housing or the
remote control.
OSCILLATION INSTRUCTIONS:
To turn the oscillation feature off pull the Oscillation
Control Knob ( ) all the way up. To turn the
oscillation feature on push the Oscillation Control Knob
() all the way down.
FCC STATEMENT
Potential for Radio/Television interference
This product has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15
of the FCC rules.
These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. The product generates, uses, and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that the interference will not occur in a
particular installation. If the product does cause harmful
interference to radio or television reception, which can be
determined by turning the product on or off, the user is
encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the product and the
receiver.
• Connect the product into an outlet on a circuit
different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV
technician for help.
Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment.
REMOTE CONTROL
This unit includes two (2) AAA batteries.
Battery Replacement
a) Locate the battery cover on the back of the remote
control handset. Slide the battery cover off with your
thumb.
b) Use the tip of a pen to loosen each battery. Hold the
remote control handset at an angle to allow the
batteries to slide out.
c) Insert two new batteries, pressing them firmly into
their slot.
d) Replace the battery cover.
NOTES:
• Do not mix old and new batteries.
• Do not mix alkaline, standard (carbon-zinc), or
rechargeable (nickel-cadmium) batteries.
• Replace all batteries of a set at the same time.
• Clean the battery contacts and the devices’ contacts
prior to installing the batteries.
• Remove the batteries from the equipment when it is
not being used for an extended period of time.
• Remove the used batteries promptly.
THIS APPLIANCE HAS A POLARIZED PLUG (one blade is wider than the
other). To reduce the risk of electric shock, this plug is intended to fit in
a polarized outlet only one way. If the plug does not fit fully in the
outlet, reverse the plug. If it still does not fit, contact a qualified
electrician to install the proper outlet.
DO NOT ATTEMPT TO MODIFY THIS PLUG OR DEFEAT THIS
SAFETY FEATURE IN ANY WAY.
Figure 2
MK
Figure 6
Figure 4
F
E
Figure 5
CD
Figure 3 I
K
A. Logo Plate
B. Front Grill
C. Fan Blade Cap
D. Fan Blade
E. Rear Grill Mounting Nut
F. Rear Grill
G. Motor Shaft
H. Motor Housing
I. Upper Pole
J. Grill Clips (6)
K. Lower Pole
L. Decorative Cap
M. Base
N. Base Weight
O. Base Weight Nut
P. Oscillation Control Knob
Q. Tilt-Adjustment Knob
R. Thumb Screw
S. Mode/Off button
T. IR Lens
ABCDEFGH
I
L
Q
M
R
Figure 1
P
K
N
O
BSF152T-U_08EM1.indd 2BSF152T-U_08EM1.indd 2 12/22/08 3:49:39 PM12/22/08 3:49:39 PM
All manuals and user guides at all-guides.com
