Bionic Body NS-1009 Installation and operating instructions

NOTE:
Please read all
instructions carefully
before using this product
Table of Contents
Safety Notice
Hardware Pack
Assembly Instruction
Parts List
Warranty
Ordering Parts
Model
NS-1009
Retain This
Manual for
Reference
170315
ASSEMBLY &
OWNER'S
MANUAL
COMPACT ELLIPTICAL
TRAINER
NS-1009
IMPEX®INC.
2801 S. Towne Ave, Pomona, CA 91766
Tel: [phone] Fax: [phone]
www.MarcyPro.com
[e-mail]

©IMPEX INC. www.MarcyPro.com1
TABLE OF CONTENTS
BEFORE YOU BEGIN...................................................................................…. 1
IMPORTANT SAFETY NOTICES..................................................................…. 2
WARNING LABEL PLACEMENT……………………………………………………. 3
HARDWARE PACK……….....…....................................................................…. 4
ASSEMBLY INSTRUCTIONS........................................................................…. 6
EXPLODED DIAGRAM……………………………………………………………… 8
PARTS LIST...................................................................................................… 9
CARE, MAINTENANCE, AND STORAGE………………………………………… 10
COMPUTER…………………………………………………………………………… 11
EXERCISE GUIDELINES……………………………………………………………. 12
WARRANTY.................................................................................................…. 14
ORDERING PARTS.....................................................................................….. 14
BEFORE YOU BEGIN
Thank you for selecting the Bionic Body Compact Elliptical Trainer NS-1009 by
IMPEX®INC. For your safety and benefit, read this manual carefully before using the
equipment. As a manufacturer, we are committed to provide you complete customer
satisfaction. If you have any questions, or find there are missing or damaged parts,
we guarantee you complete satisfaction through direct assistance from our factory. To
avoid unnecessary delays, please call our TOLL-FREE customer service number. Our
Customer Service Agents will provide immediate assistance to you.
Toll-Free Customer Service Number
1-800-999-8899
Mon. - Fri. 9 a.m. - 5 p.m. PST
www.MarcyPro.com
support @impex-fitness.com

©IMPEX INC. www.MarcyPro.com2
IMPORTANT SAFETY NOTICE
PRECAUTIONS
This exercise machine is built for optimum safety. However, certain precautions apply
whenever you operate a piece of exercise equipment. Be sure to read the entire manual
before you assemble or operate your machine. In particular, note the following safety
precautions:
1. Keep children and pets away from the machine at all times. DO NOT leave
children unattended in the same room with the machine.
2. Only one person at a time should use the machine.
3. If the user experiences dizziness, nausea, chest pain, or any other abnormal symptoms,
STOP the workout at once. CONSULT A PHYSICIAN IMMEDIATELY.
4. Position the machine on a clear, leveled surface. DO NOT use the machine near water
or outdoors.
5. Keep hands away from all moving parts.
6. Always wear appropriate workout clothing when exercising. DO NOT wear robes or
other clothing that could become caught in the machine. Running or aerobic shoes are
also required when using the machine.
7. Use the machine only for its intended use as described in this manual. DO NOT use
attachments not recommended by the manufacturer.
8. Do not place any sharp object around the machine.
9. Disabled person should not use the machine without a qualified person or physician in
attendance.
10. Before using the machine to exercise, always do stretching exercises to properly warm
up.
11. Never operate the machine if the machine is not functioning properly.
12. Read all warnings posted on the equipment.
13. Inspect the equipment for worn or loose component prior to use. Tighten/replace any
loose or wore components prior to use.
14. Care should be taken in mounting or dismounting the equipment.
15. This equipment is for consumer and home use only.
CARE AND MAINTENANCE
1. Lubricate moving parts with WD-40 or light oil periodically.
2. Inspect and tighten all parts before using the machine.
3. The machine can be cleaned using a damp cloth and mild non-abrasive detergent.
DO NOT use solvents.
4. Assembled dimension: 27"x20"x12.5"
WARNING: BEFORE BEGINNING ANY EXERCISE PROGRAM, CONSULT YOUR
PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE
OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL
INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. IMPEX INC. ASSUMES
NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE
SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT.
SAVE THESE INSTRUCTIONS.

©IMPEX INC. www.MarcyPro.com3
WARNING LABEL PLACEMENT
The Warning Labels and Caution Label shown here have been placed on the Rear Stabilizer.
If the labels are missing or illegible, please call customer service at 1-800-999-8899 for replacement. Apply the
labels in location shown.

©IMPEX INC. www.MarcyPro.com4
HARDWARE PACK
NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size.
No. Description Qty Identifier
# 27 Allen bolt M8 x ⅝" 6
# 33 Curved washer ⅝" 2
# 3 Allen bolt M6 x ½” 5
# 45 Rubber Feet 5
Allen key 6# 1
Allen key 5# 1

©IMPEX INC. www.MarcyPro.com5
COMPONENTS FOR ASSEMBLY
1 2 32
48 26L/26R 51

©IMPEX INC. www.MarcyPro.com6
ASSEMBLY INSTRUCTION
STEP-1
1. Attach the base board (#2) to the front of the main frame (#1) securing with five sets of allen
bolts (#3) and rubber feet (#45).
2. Attach the rear stabilizer (#32) to the rear of the main frame (#1) securing with two sets of allen
bolts (#27) and flat washers (#33).
27
33 32
2
1
3
45

©IMPEX INC. www.MarcyPro.com7
STEP 2
1. Attach left pedal (#26L) to the left pedal of main frame (#1), secure using two allen bolts (#27).
Repeat for right pedal (#26R) installation.
2. Attach the Rear Stabilizer Cover (#51) to the rear of the main frame (#1) securing with two Self-
tapping screws (#13).
3. Attach the resistance tubes (#48) onto the anchors on the rear stabilizer (#32).
51
26L
48
48
1
26R
27 27
13
13
32

©IMPEX INC. www.MarcyPro.com8
EXPLODED DIAGRAM

©IMPEX INC. www.MarcyPro.com9
NS-1009 PARTS LIST
Part No. Description Q’ty Part No. Description Q’ty
1 Main frame 1 29 End cap for Main frame cover 2
2 Base board 1 30 Flange nut 2
3 Allen bolt M6 x ⅝" 5 31
End cap for front stabilizer ( L
/R)
1/1
4 Clamp spring 2 32 Rear stabilizer 1
5 Bearing 2 33 Flat washer Ø ⅜" 2
6 Flywheel 1 34 Roller Axle 2
7 Magnet assembly 1 35 Nylon nut M6 3
8 Screw M5 x ⅝" 5 36 Axle for belt pulley 1
9 Hex Nut M6 2 37 Belt pulley 1
10 Hex Bolt M6 x 1⅛" 1 38 Allen bolt M6 x ⅝" 5
11 Axle for flywheel 1 39 Clamp spring 2
12 Chain cover ( L/R ) 1/1 40 Bearing 2
13 Self-tapping screw ¾” 12 41 Sensor bracket 1
14 Self-tapping screw ⅝" 11 42 Computer 1
15 Support holder 2 43 Tension knob 1
16 Main frame cover 2 44 Joint screw assembly 2
17 Allen Bolt M6 x ⅝" 2 45 Rubber Feet 5
18 Bearing 4 46 Belt 1
19 Roller 2 47 Sensor wire 1
20
Pedal tube（L/R）
1/1 48 Tension belt 2
21 Bushing for pedal tube 4 49 Cover for Pedal tube(L) 2
22 D type washer 2 50 Cover for Pedal tube(R) 2
23 Washer Ø ⅜" 2 51 Cover for Rear stabilizer 1
24 Spring washer 2 52 Anchor Bracket 2
25 Hex Bolt M8 x ¾” 2 53 Anchor Ring 2
26 Pedal ( L /R) 1/1 54 Anchor limiter 2
27 Allen bolt M8 x ¾” 6 55 Bushing 2
28 Washer 2 56 Screw M5*15 8

©IMPEX INC. www.MarcyPro.com10
CARE, MAINTENANCE AND STORAGE
1. Inspect and tighten all parts each time you use the machine. Replace any worn parts
immediately.
2. This equipment can be cleaned using a damp cloth and mild non-abrasive detergent. Do not
use solvents.
3. Store the equipment IN-DOORS. Excess moisture and water would cause rust on the frame.
4. The equipment shall be placed at least 24 inches away from the wall or/and any other object
such as furniture to provide safe access to and passage around the machine.
5. To avoid possible injury, the help of two or more people are needed when moving the machine
around.
6. Disposal Instructions – The equipment can be safely disassembled and disposed without
unreasonable hazards. Call your local recycle agency regarding details of recycling.

©IMPEX INC. www.MarcyPro.com11
COMPUTER
FUNCTIONAL BUTTON:
MODE/RESET
Push button to select functions.
Hold the button for 4 seconds to "reset".
FUNCTION:
SCAN Automatically cycles through time, count, calories and total count;
each will be displayed for 4 seconds.
TIME Automatically accumulates workout time when exercising.
COUNT Automatically accumulates the number of Steps when exercising .
CALORIES Automatically accumulates calories burnt when exercising
TOTAL COUNT Automatically accumulates the Total number of steps performed for all
exercise sessions.
REPLACE BATTERY:
1. Remove the battery cover on the back of the computer.
2. Replace one 1.5V (AAA) battery.
3. Make sure the batteries are installed correctly and the polarities are correct.
4. The battery life is approx. 3 months under normal usage.
5. When the batteries are removed, all functional values will reset to zero.

©IMPEX INC. www.MarcyPro.com12
EXERCISE GUIDELINES
Using your Compact Elliptical Trainer will provide you with several benefits, it will improve
your physical fitness, tone muscle and in conjunction with calorie controlled diet help you lose
weight.
1. The Warm Up Phase
This stage helps get the blood flowing around the body and the muscles working properly. It will
also reduce the risk of cramp and muscle injury. It is advisable to do a few stretching exercises as
shown below. Each stretch should be held for approximately 30 seconds, do not force or jerk your
muscles into a stretch - if it hurts, STOP.
2. The Exercise Phase
This is the stage where you put the effort in. After regular use, the muscles in your legs will
become more flexible. Work to your targeted heart rate but it is very important to maintain a
steady tempo throughout. The rate of work should be sufficient to raise your heartbeat into the
target zone shown on the graph below.
This stage should last for a minimum of 12 minutes though most people start at about 15-20
minutes
SIDE BENDS OUTER THIGH
INNER THIGH
FORWARD
BENDS
CALF / ACHILLES

©IMPEX INC. www.MarcyPro.com13
3. The Cool Down Phase
This stage is to let your Cardio-vascular System and muscles wind down. This is a repeat of the
warm up exercise e.g. reduce your tempo, continue for approximately 5 minutes. The stretching
exercises should now be repeated, again remembering not to force or jerk your muscles into the
stretch.
As you get fitter you may need to train longer and harder. It is advisable to train at least three times
a week, and if possible space your workouts evenly throughout the week.
MUSCLE TONING
To tone muscle while on your Compact Elliptical Trainer you will need to have the
resistance set quite high. This will put more strain on our leg muscles and may mean you cannot
train for as long as you would like. If you are also trying to improve your fitness you need to alter
your training program. You should train as normal during the warm up and cool down phases, but
towards the end of the exercise phase you should increase resistance making your legs work
harder. You will have to reduce your speed to keep your heart rate in the target zone.
WEIGHT LOSS
The important factor here is the amount of effort you put in. The harder and longer you work
the more calories you will burn. Effectively this is the same as if you were training to
improve your fitness, the difference is the goal.

©IMPEX INC. www.MarcyPro.com14
IMPEX®INC.
LIMITED WARRANTY
IMPEX Inc. ("IMPEX®") warrants this product to be free from defects in workmanship and material, under normal use
and service conditions, for a period of two years on the Frame from the date of purchase. This warranty extends only
to the original purchaser. IMPEX's obligation under this Warranty is limited to replacing or repairing, at IMPEX's option.
All returns must be pre-authorized by IMPEX. Pre-authorization may be obtained by calling IMPEX Customer Service
Department at 1-800-999-8899. All freights for products return to IMPEX must be prepaid by the customer. This
warranty does not extend to any product or damage to a product caused by or attributable to freight damage, abuse,
misuse, improper or abnormal usage or repairs not provided by an IMPEX authorized service center or for products
used for commercial or rental purposes. No other warranty beyond that specifically set forth above is authorized by
IMPEX.
IMPEX is not responsible or liable for indirect, special or consequential damages arising out of or in connection with the
use or performance of the product or other damages with respect to any economic loss, loss of property, loss of
revenues or profits, loss of enjoyments or use, costs of removal, installation or other consequential damages or
whatsoever natures. Some states do not allow the exclusion or limitation of incidental or consequential damages.
Accordingly, the above limitation may not apply to you.
The warranty extended hereunder is in lieu of any and all other warranties and any implied warranties of merchantability
or fitness for a particular purpose is limited in its scope and duration to the terms set forth herein. Some states do not
allow limitations on how long an implied warranty lasts. Accordingly, the above limitation may not apply to you.
This warranty gives you specific legal right. You may also have other rights which vary from state to state. Register
on-line www.MarcyPro.com
IMPEX®INC.
2801 S. Towne Ave.
Pomona, CA 91766
ORDERING REPLACEMENT PARTS
Replacement parts can be ordered by calling our Customer Service Department toll-free at 1-800-999-8899 during our
regular business hours: Monday through Friday, 9 am until 5 pm Pacific standard time.
support @impex-fitness.com
When ordering replacement part, always give the following information.
1. Model
2. Description of Parts
3. Part Number
4. Date of Purchase
