Bird-X SOLAR YARD GARD Programming manual

Bird-X, Inc. has been recognized
worldwide as the bird and pest control
experts for more than 50 years.
WHY CONTROL PESTS?
Droppings are unsightly, unhealthy, and
potentially fatal.
Droppings cost money and time. “Cleaning up”
represents costs unrecoverable by revenues.
Pests are destructive and deface property.
USDA, OSHA, health boards and other
organizations can cite, fine or shut down
companies for pest mess problems.
PEST MANAGEMENT PROGRAM
A. Survey the pests and their entry, exit and
feeding habits.
B. Inspect your property. Discover what the pests
find attractive about your area, and if the same
conditions prevail in neighboring properties.
C. Remove inducements. Clean the area of all
evidence of pests and the residual scent.
Because pests and their droppings can cause
many diseases, use extreme caution when
removing them. Do not breathe or come into
direct contact with them. If you have questions
about how to do this safely, consult an expert.
Remove food spillage, garbage, nesting
material and other appealing items.
D. Maintain a clean and changing environment.
For maximum effectiveness, periodically repeat
C) above and relocate or reposition the unit,
vary the output, or turn it off for a short time.
E. Install early. It is always best to install the Solar
Yard Gard before “pest season” begins; as it is
easier to discourage them than to rout them out
once they have already established a pattern.
F. Consider alternate locations. Make educated
guesses as to where the pests will go when
they leave their current infestation area, and
consider purchasing units to cover these areas
as well.
MANUFACTURER’S WARRANTY
The Solar Yard Gard is warrantied against defects
in materials and workmanship for a period of six
months from the shipping date. At the option of Bird-
X, Inc., we will either replace or repair the defective
unit. Prior authorization and a returned goods
authorization (RGA) number will be necessary from
Bird-X, Inc.
NOTE: RETURNS ARE ACCEPTED ONLY WITH
AUTHORIZATION FROM OUR CHICAGO OFFICE.
SYNERGY AND OTHER PRODUCTS
For best results, Bird-X, Inc. always recommends
the Solar Yard Gard be used in conjunction with one
or more other products. The combination of different
types of control methods has proven to maximize
the effectiveness of pest animal control programs.
Two or more ifferent kinds of devices (Solar Yard
Gard plus netting and/or taste or smell aversion) will
produce a synergistic effect and will yield much
greater effectiveness than any single product alone.
Visit www.bird-x.com for more information on
companion products.
Copyright 2017 by Bird-X, Inc. All rights reserved.
Chicago, IL USA
www.bird-x.com s[email protected]
BIRD-X
SOLAR YARD GARD
Ultrasonic Pest Chaser
INSTRUCTIONS & PEST
MANAGEMENT GUIDE
PLEASE READ CAREFULLY TO OBTAIN THE
BEST RESULTS FROM YOUR UNIT.

How it Works
The Solar Yard Gard Ultrasonic Repeller with
optional flashing LED is easy to use. Simply install
the 3 AA NiMH rechargeable batteries (included)
and then place the unit in your garden, with an
unobstructed view of the area you want to protect.
Two adjustable buttons for distance and frequency
target different types and sizes of pest animals. The
built-in motion sensor detects the pest entering the
area and emits a piercing, high-decibel alarm that
startles the pest and frightens it away. Since the
sound is ultrasonic, you and your neighbors cannot
hear it.
Unlike pest deterrents that operate continuously, the
Solar Yard Gard ultrasonic unit waits for the animal
to come into its range before activating, making the
function unpredictable and therefore more effective.
Specifications
This Ultrasonic Repeller automatic outdoor animal
deterrent is constructed of durable, weather-
resistant materials, and has been designed to
provide many years of reliable service.
Infrared sensing angle (motion detector): 80
degrees.
Detection range: 9-10 Meters, depending on
body size of animal. Larger animals are
detected at greater distances.
Rechargeable Battery life: up to 2,000
activations (10 per day = 200 days)
Power supply: (included) 3 pcs (1.2V/pc) 2mA
with Rechargeable Non-Crystalline silicon
battery (3.6V) OR use 3 x AA (1.5V) Battery
(DC4.5V)
Static current: 200uA; Running current: 150mA
Unit on time when activated: 4-6 seconds.
Output frequency: sweeping from 10-50 KHZ.
Sensoring angle: approx. 80 degrees
Water resistant
Features
Blue LED: indicates when the unit is activated.
Flashing Strobe: option for enhanced night-time
effectiveness
Zinc stake: includes one stake for versatile
mounting (ground level, approximately 4” above
ground).
Left button: adjusts sensitivity of motion sensor.
Turn clockwise for greater sensitivity. To detect
small animals, turn all the way to the right (furthest
clockwise).
Right button: Frequency control. Clockwise =
higher frequency. The smaller the pest, typically the
higher frequency setting should be selected to
target them.
Animal type/setting:
SMALL ANIMALS: Insects, Rodents, Squirrels
etc. –Highest frequency (H) 25-50KHZ
MEDIUM-SIZED ANIMALS: Raccoons, Possum,
Cats, Skunks, etc. –Middle range (M) 20-40KHZ
LARGE ANIMALS: Deer, Feral pigs, Javelina,
etc. –Lowest frequency (L) 10-25KHZ
L+, M+, H+: extra strobe of flashing LED will be
turned on to repel animal that is afraid of strong
flashing lights
Off: not sending out frequencies and LED is off
USB charging: 5V, USB port, charging current:
<50MA
LED: In regular working condition, LED will flash
blue when working. When voltage is below 3V, LED
will flash red, which indicates you need to charge
the batteries or replace with new batteries. During
charging with USB cable, LED will flash blue.
To set up the Ultrasonic Repeller
1. Remove the battery cover (being careful not to
press on the lens or speaker). Install 3 AA
batteries and replace battery cover. The light
stays on for 2 seconds indicating that the unit
has been triggered. (If this light does not come
on, replace the batteries)
2. Position the Ultrasonic Repeller (for example, in
the flowerbed, or against the wall) pointed
towards the area that you want to protect.
3. Do not aim the product into neighboring
yards or public areas, or at caged or leashed
animals. The Solar Yard Gard is intended for
use on your own property only.
4. To mount the Solar Yard Gard unit in the
ground, push the mounting stake into the soil
and attach the Ultrasonic Repeller.
5. To mount to a post or fence, secure with a nylon
zip-tie.
SUCCESSFUL LONG-TERM
BEHAVIOR MODIFICATION
Solar Yard Gard success takes time to build. Pest
habits may take several days or weeks to break.
Follow all suggestions for maximum efficacy.
"Instant" tests on pets do not replicate natural
conditions and give no indication of the unit's
success with wild or visiting domesticated pests.
