BIRD ES4-800RN User manual
ES4-800RN E-Scooter
User’s Manual
In order to ensure the safety of yours and others around you, you must
thoroughly read and understand this manual before starting to ride.
Please email Consumer Mobility Services at
Contents
Safety Warnings
Assembling Your E-Scooter
Charging
Diagram
Riding
Safety Warning
Maintenance
Specifications
Certifications
01
02
03
04
05
06-07
08
09
10
01
Packing List
Neck: Base:
User Materials:
QUICK START
GUIDE
USER MANUAL WARRANTY
Hardware:
Battery Charger
with AC Cable
Short Screw
with Washers x 2
Long Screw x 2 Wrench
Riser Lock
02
Assembling Your E-Scooter
Battery pack
faces the rider
1
2
1 2 3 4 5
1. Connect the 5wires securely to their matching
color/port connections (otherwise the unit will NOT
turn on):
1 Blue single-pin connector
2Yellow single-pin connector
3 Brown single-pin connector
4Six-pin connector
5Four-pin connector
2. Slide the handlebar post into the base (the battery
pack must be facing the rider). Install the 4screws
halfway before tightening them completely:
1From the front side of the post, the two screws
that come with washers should be used.
2On the rider’s side of the post, align the two
remaining long screws through the Riser Lock.
NOTE:
For the easy connection of wires, lay the base
of the unit and the handlebar’s post, next to
each other, on a flat surface.
03
Charging
Charging step tips:
Charging = RED
Charging completed = GREEN
1. Locate and open
the charging port
on the stem.
2. Insert the charger
plug into the
scooters
charging port.
3. When done
charging,
close the charging
port cover.
Charger LED indicator:
Charging port
04
Diagram
Rear Fender/Foot Brake
Tail Lights (Left & Right)
Underglow Lights
Dashboard & Power button
Electronic throttle
Kickstand
Hub Motor
Headlight
Bell
Electronic Brake
Power button
(multi-functional)
Speedometer
Battery level
mph
Charging port
05
Riding
1 Wear an appropriate helmet and other
protective gear.
2 Turn on the power and check the scooter’s
display to view battery level (If it is low, charge
the E-scooter).
3 Stand on the deck with one foot and use your
other foot to thrust/push off to gain
momentum.
4 Once you gain some speed, make sure you
bring both feet onto the deck and keep them
stable. Once secured and balanced, press the
black throttle (on the right side of the
handlebar).
5 To slow down, just release the throttle. To
make a more abrupt stop, use the red
thumb-brake (on the left handlebar), and/or
use the foot brake on the rear fender.
6 Shift your body weight and direct the
handlebars to turn.
NOTE:
As a precaution, the motor will not engage until
the scooter reaches 1.8 mph (3 km/h).
06
Safety Warnings
01. Like with any electric scooter, there are always risks of injuries, loss of control, accidents, etc. By riding this
electric scooter (“product”), you acknowledge and accept any and all responsibilities of all risks associated
with riding this product. Be aware that your lack of experience and practice in the riding the product, and lack
of attention to this manual and the Quick Start Guide, can cause major injuries, which you are solely
responsible for.
02. You MUST wear a CPSC-approved helmet, knee pads, elbow pads, and be at least 18 years of age, before
riding this product.
03. You must first practice riding the product in a very slow speed, in an area that is free from any objects, i.e.
pedestrians, curbs, trees, etc.
04. You must always follow the rules and regulations for riding an electric scooter in areas where you plan to ride
the product. You need to always exercise good judgment when riding this product.
05. Riding on a fast speed will require a longer braking distance. Sudden braking on any surface can lead to
slipping wheels, and falls. Accordingly, you must always keep a safe distance between yourself and
people/objects/vehicles, etc.
06. Do not let anyone ride your product if he/she has not read the instructions in this manual, and/or does not
have experience in riding electric scooters.
07. Do not ride this product if you are injured or not in normal health.
08. Do not ride this product if you are under the influence of alcohol or drugs.
09. Do not ride the product if you have problems with balancing.
10. Do not ride this product if you weigh over 220 pounds.
11. Do not ride this product if you do not have a 20/20 vision.
12. Do not ride this product if you are in an area that does not allow you to clearly see your surroundings.
13. Do not ride this product if you are in an area with roads that are not suitable for riding the product. Only ride
this product in areas with no bumps.
14. Do not use any charger or accessory that is not approved to be used by this product.
15. Do not charge or ride the product under rainy conditions.
16. Do not charge the product if the charging port is wet.
17. Do not use the product for carrying objects.
18. Do not service the product on your own.
19. Do not place the product in fire, or close to a hot object.
20. Do not place the product in water, or any liquids.
21. Immediately unplug the product from electricity and/or turn off the product if the unit emits a smell, is too
hot and looks abnormal.
22. Power off your product and unplug the charging cable before assembling, mounting accessories, or
cleaning the mainframe.
23. Do not ride the product while it is being charged.
24. Do not pierce the battery.
25. In order to maintain your balance, wear flat shoes.
26. Do not continue charging the battery if you notice that recharging is not effective.
27. Maintain a moderate distance between yourself and others.
28. Do not ride the product if you are sleepy or tired.
29. Do not make sharp turns at high speeds.
30. Do not ride the product in crowded areas.
31. Do not ride the product while using your cell phone, laptop, or any other portable devices.
32. Before cleaning the product, make sure the unit is in OFF position, the unit is not plugged into AC, and the
charging port’s cap is firmly in place.
33. Do not press the throttle when walking the product.
07
01. Like with any electric scooter, there are always risks of injuries, loss of control, accidents, etc. By riding this
electric scooter (“product”), you acknowledge and accept any and all responsibilities of all risks associated
with riding this product. Be aware that your lack of experience and practice in the riding the product, and lack
of attention to this manual and the Quick Start Guide, can cause major injuries, which you are solely
responsible for.
02. You MUST wear a CPSC-approved helmet, knee pads, elbow pads, and be at least 18 years of age, before
riding this product.
03. You must first practice riding the product in a very slow speed, in an area that is free from any objects, i.e.
pedestrians, curbs, trees, etc.
04. You must always follow the rules and regulations for riding an electric scooter in areas where you plan to ride
the product. You need to always exercise good judgment when riding this product.
05. Riding on a fast speed will require a longer braking distance. Sudden braking on any surface can lead to
slipping wheels, and falls. Accordingly, you must always keep a safe distance between yourself and
people/objects/vehicles, etc.
06. Do not let anyone ride your product if he/she has not read the instructions in this manual, and/or does not
have experience in riding electric scooters.
07. Do not ride this product if you are injured or not in normal health.
08. Do not ride this product if you are under the influence of alcohol or drugs.
09. Do not ride the product if you have problems with balancing.
10. Do not ride this product if you weigh over 220 pounds.
11. Do not ride this product if you do not have a 20/20 vision.
12. Do not ride this product if you are in an area that does not allow you to clearly see your surroundings.
13. Do not ride this product if you are in an area with roads that are not suitable for riding the product. Only ride
this product in areas with no bumps.
14. Do not use any charger or accessory that is not approved to be used by this product.
15. Do not charge or ride the product under rainy conditions.
16. Do not charge the product if the charging port is wet.
17. Do not use the product for carrying objects.
18. Do not service the product on your own.
19. Do not place the product in fire, or close to a hot object.
20. Do not place the product in water, or any liquids.
21. Immediately unplug the product from electricity and/or turn off the product if the unit emits a smell, is too
hot and looks abnormal.
22. Power off your product and unplug the charging cable before assembling, mounting accessories, or
cleaning the mainframe.
23. Do not ride the product while it is being charged.
24. Do not pierce the battery.
25. In order to maintain your balance, wear flat shoes.
26. Do not continue charging the battery if you notice that recharging is not effective.
27. Maintain a moderate distance between yourself and others.
28. Do not ride the product if you are sleepy or tired.
29. Do not make sharp turns at high speeds.
30. Do not ride the product in crowded areas.
31. Do not ride the product while using your cell phone, laptop, or any other portable devices.
32. Before cleaning the product, make sure the unit is in OFF position, the unit is not plugged into AC, and the
charging port’s cap is firmly in place.
33. Do not press the throttle when walking the product.
08
Maintenance
1. Do not use a hose to clean your product…simply use a soft, wet cloth. Do not use alcohol or ammonia-based
cleaning solutions. Do not spray any liquids on any parts of the product.
2. The product needs to be stored in a place with temperatures between 0° to 100° Fahrenheit. Do not store
the product in areas that are subject to extreme temperature fluctuations.
3. In order to save battery, turn off the product while not in use.
4. At least, once a month, recharge the product, otherwise the battery can get fully discharged, thus affecting
the product from getting charged in the future and damaging the battery.
5. The battery range and performance is best when the product is used at 70° Fahrenheit. Using the product at
higher or lower temperatures would result in lower range and performance.
6. Do not attempt to take out the battery.
7. Follow your recycling and disposal’s local ordinances and regulations.
8. Store the product in a cool, dry place. Do not store it outdoors for extended periods of time.
09
Specifications
[1] Typical Range: tested while riding under full power,165 lbs (75 kg) load, 77°F (25°C), 60% of max. speed on average on pavement.
Dimensions Length x Width x Height 40x17x45” (102×43×113cm)
Weight Net 30 lbs (16.3 kg)
Rider Payload 55–220 lbs (25–100 kg)
Recommended Age 18+ years
Required Height 3’11”–6’6” (120–200 cm)
Scooter Parameters Max. Speed 18.6 (30 km/h)
Typical Range [1] 28 miles (45 km)
Max. Slope 15%
Traversable Terrain asphalt/flat pavement;
obstacles < 0.4 in (1 cm);
gaps < 1.2 in (3 cm)
Operating Temperature 14–104°F (-10–40°C)
Storage Temperature -4–122°F (-20–50°C)
IP Rating IP54
Battery Nominal Power 36 VDC
Max. Charging Voltage 42 VDC
Charging Temperature 32-104°F (0–40°C)
Nominal Capacity 374 Wh
Battery Management System Over-heating;
Short circuit;
over-current;
over-charge protection
Motor Nominal Power 300 W
Max. Power 800 W
Charger Output Power 71 W
Input Voltage 100-240 VAC
Output Voltage 42 VDC
Output Current 1.7 A
Duration of Charging 3.5 h
Features Shock Absorber Front
Brake Light LED rear light
10
Certification
This product has been tested to and passed ANSI/CAN/UL-2272.
The battery complies with UN/DOT 38.3.
Federal Communications Commission (FCC) Compliance Statement for USA:
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
NOTE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following measures:
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and receiver
— Connect the equipment into an outlet on acircuit different from that to which the receiver is connected.
— Consult the dealer or an experienced radio/TV technician for help.
This product complies with FCC radiation exposure limits set forth for an uncontrolled environment.
Industry Canada (IC) Compliance Statement for Canada. This device complies with Industry Canada license-ex-
empt RSS standard (s). Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including interference that may cause undesired
operation of the device.
CAN ICES-3 (B)/NMB-3(B)
Vendor is NOT responsible for any changes or modifications not expressly approved by vendor. Such modifications
could void the user's authority to operate the equipment.
Batteries or packaging for batteries are labeled in accordance with European Directive 2006/66/EC concerning
batteries and accumulators and waste batteries and accumulators. The Directive determines the framework for
the return and recycling of used batteries and accumulators as applicable throughout the European Union. This
label is applied to various batteries to indicate that the battery is not to be thrown away, but rather reclaimed upon
end of life per this Directive.
11
12
13
Table of contents
Other BIRD Scooter manuals
