Birlea LISBON 4' BED FRAME User manual

4 m
4m
ASSEMBLY INSTRUCTIONS
LISBON 4’ BED FRAME
Vendor: S000238
!
f
You
Tube
www.birlea.com Page 1 of 6
IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR
USING YOUR LISBON 4’ BED FRAME.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
HEALTH & SAFETY:
DO NOT jump on this bed frame.
DO NOT use this bed frame if any parts are missing, damaged or worn.
DO NOT use this bed frame unless all fixings are secured.
Always use on a level, even surface.
WARNING: If this bed is placed on a non-carpeted floor you must place some protection under all legs to stop
the bed frame from moving. If this is not adhered to there is no guarantee if the bed frame collapses.
CARE & MAINTENANCE:
Periodically check all screws & fixings to ensure they are secure.
DO NOT push the bed frame as this will damage the legs.
Always lift the bed with two people to reposition.
Keep any sharp objects away from the frame.

HARDWARE LIST
Part Item Qty
30mm dowel
16mm Screw
30mm Screw
Nut
50mm Bolt
80mm Bolt
Half moon nut
Code: S000238
A
D
G
L
B
E
J
M
C
F
K
44
8
48
8
2
2
8
4
4
40mm dowel 70mm Bolt
Page 2 of 6
Recycle
2m
01 2 345 6 7891 0
mm 1 1 1 2 1 3 1 4 1 5 1 6
Part Item Qty
32mm Bolt 2
H
N
Metal bracket 2
2
Spacer
1
Allen key
1Headboard post x 2
(85 x 4.5cm)
2Left footboard post
(38 x 4.5cm)
3Right footboard post
(38 x 4.5cm)
Slat x 24
(61 x 6.5cm)
4
Headend rail x 9
(25 x 4.5cm)
5
Support leg x 2
(28.3 x 6.5cm)
6
Side rail x 2 (190 x 11.2cm)
7
8Centre rail (190 x 6.5cm)
9Top headboard rail x 2 (119.8 x 6.5cm)
10 Bottom headboard rail (119.8 x 6.5cm)
11 Footboard panel (119.8 x 9.2cm)
12 Hardware Kit x 1
You will need a screwdriver, small mallet and M11 spanner (not provided).
1
Glue
O

Vendor: S000238
Step 1: Join the support legs (6) to the centre rail (8) using hardware G and M.
Insert hardware part B to the side rails (7) using a small mallet (not provided).
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
Page 3 of 6
M
A
A
A
A
A
A
Step 2: Insert hardware part A to the top headend rails (9), bottom headend rail (10) and footend panel (11)
using a small mallet (not provided).
9 10 11
2x
B
B
G
G
G
6
7
8
6
2x
5
9
9
5
5
Step 3: Insert hardware part A and O to the headend rails (5). Attach the headend rails (5) and top headend rails (9).
A
A
O
5
O
5
9x
9

Vendor: S000238
Page 4 of 6
H
M
Step 4: Attach the headend post (1) to the top headend rails (9)
and bottom headend rail (10) using hardware parts H and M.
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
Step 5: Attach the left footend post (2) and right footend post (3) to the footend panel (11) using hardware parts H and M.
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
H
H
H
H
H
H
1
1
10
9
9
H
H
H
M
2
3
11
2

Vendor: S000238
Step 7: Attach the side rails to the headend posts at the same time using hardware parts J, K and M.
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
Step 6: Fix hardware part L to the headend rail (10) and footend panel (11) using hardware
part C and a screwdriver (not provided).
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
Page 5 of 6
C
L
L
10
11
L
11
10
11
J
M
K
J
M
10
K

Vendor: S000238
Step 8: Fix the centre rail (8) using hardware parts E and F and a spanner (not provided).
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
Page 6 of 6
Step 9: Fix slats (4) to the side rails and centre rail using hardware parts D and N with a screwdriver (not provided).
Make sure to start from the ends and work towards the middle.
DO NOT use any power tools as this may damage the frame and will invalidate any claim
Additional Information:
• For complete product information, images and dimension diagrams please visit the website www.birlea.com
• If you have any issues with your item please contact the retailer directly you purchased it from who will be
able to resolve any issues with Birlea.
• Why don’t you send us photos of your assembled furniture to [email protected] to be
shared in our #birleahome feature on Instagram.
b:
a:
N
D
D
4
44
4
4
4
N
4
4
E
E
F
E
8
8
