Birlea LUKA 3' User manual

4 m
4m
ASSEMBLY INSTRUCTIONS
LUKA 3’ BED FRAME
Vendor: S000238
!
f
You
Tube
www.birlea.com Page 1 of 5
IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR
USING YOUR LUKA 3’ BED FRAME.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
HEALTH & SAFETY:
DO NOT jump on this bed frame.
DO NOT use this bed frame if any parts are missing, damaged or worn.
DO NOT use this bed frame unless all fixings are secured.
Always use on a level, even surface.
WARNING: If this bed is placed on a non-carpeted floor you must place some protection under all legs to stop
the bed frame from moving. If this is not adhered to there is no guarantee if the bed frame collapses.
CARE & MAINTENANCE:
Periodically check all screws & fixings to ensure they are secure.
DO NOT push the bed frame as this will damage the legs.
Always lift the bed with two people to reposition.
Keep any sharp objects away from the frame.

HARDWARE LIST
Part Item Qty
30mm dowel
30mm Screw
80mm Bolt
Half moon nut
A
D
GB
E
C
F
14
8
24
6
4
4
40mm dowel
70mm Bolt
Page 2 of 5
Recycle
2m
01 2 345 6 7891 0
mm 1 1 1 2 1 3 1 4 1 5 1 6
Part Item Qty
H2
Spacer
1
Allen key
1Headboard post x 2
(85 x 4.5cm)
2Left footboard post
(38 x 4.5cm)
3Right footboard post
(38 x 4.5cm)
Slat x 12
(91.2 x 6.5cm)
4
5Side rail x 2 (190 x 11.2cm)
Top headboard rail x 2 (88.8 x 6.5cm)
Footboard panel (888.8 x 9.2cm)
Hardware Kit x 1
1
Glue
6
7
8
9
J
You will need a screwdriver and
small mallet (not provided).
Centre headboard rail x 2 (88.8 x 6.5cm)
Vendor: S000238

Vendor: S000238
Step 1: Insert hardware part B to the side rails (5) using a small mallet (not provided).
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
Page 3 of 5
B
B
2x
5
A
A
A
A
A
A
2x
J
7
7
2x
8
6
Step 2: Insert hardware part A to the top headend rails (6) and footend panel (8) using a small mallet (not provided).
Step 3: Insert hardware part A and J to the centre headend rails (7) using a small mallet (not provided).

Page 4 of 5
Vendor: S000238
Step 4: Attach the headend post (1) to the centre headend rails (7) using hardware parts J.
Attach the headend post (1) to the top headend rails (6) using hardware parts D and G and.
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
Step 5: Attach the left footend post (2) and right footend post (3) to the footend panel (8) using hardware parts D and G.
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
1
1
6
7
6
7
D
D
D
D
D
G
J
J
J
J
1
J
2
2
3
G
D
D
D
8

Vendor: S000238
Step 6: Attach the side rails to the headend posts at the same time using hardware parts E, F and G.
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
Page 5 of 5
E
G
F
Step 7: Fix slats (4) to the side rails using hardware parts C and H with a screwdriver (not provided).
Make sure to start from the ends and work towards the middle.
DO NOT use any power tools as this may damage the frame and will invalidate any claim
Additional Information:
• For complete product information, images and dimension diagrams please visit the website www.birlea.com
• If you have any issues with your item please contact the retailer directly you purchased it from who will be
able to resolve any issues with Birlea.
• Why don’t you send us photos of your assembled furniture to [email protected] to be
shared in our #birleahome feature on Instagram.
b:
a:
H
C
C
4
4
4
4
H
4
4
F
E
G
6
8
8
6
