BIRO EMG-32 User manual

Item No. EMG92099
Form No. EMG32MAN-4-18-12 B
IMPORTANT NOTICE
This Manual contains important
safety instruction which must
be strictly followed when using
this equipment.
Model EMG-32
Ergonomic Mixer-Grinder/Chopper
Operating Manual and Parts List

TABLE OF CONTENTS:
NOTICE TO OWNERS AND OPERATORS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PAGE
SAFETY TIPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GROVE GEAR REDUCER REPLACEMENT & LUBRICATION . . . . . . . . . . . . . . . . . . . . . . . . .
ELECTRIC FOOTSWITCH PARTS LIST & DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CLEANING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MIXER DRIVE SHAFT SEAL REPLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1
2
3
13-15
16
17
20
OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
GRINDER KNIFE & PLATE DO’S & DON’TS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6
FOOD HANDLING TO PREVENT CONTAMINATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
TO PROCESS PRODUCT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
GRINDER BOWL INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7
LUBRICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
CHAIN TENSION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8-9
OPERATOR’S NOTES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
OPTIONAL EAGLE DRIVE BELT TENSIONING INSTRUCTIONS . . . . . . . . . . . . . . . . . . . 10-11
OPERATOR’S NOTES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
MIXING PADDLE: INSTALLATION; S/N’s 6001 to 6057 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
18
MIXING PADDLE HISTORY BY SERIAL NUMBER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
19
ELECTRICAL SCHEMATIC WITH ELECTRIC FOOTSWITCH . . . . . . . . . . . . . . . . . . . . . . . . . 21-22
PNEUMATIC FOOTSWITCH PARTS LIST & DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
ELECTRICAL SCHEMATIC WITH PNEUMATIC FOOTSWITCH . . . . . . . . . . . . . . . . . . . . . . . 24-25
ELECTRICAL SUBPLATE COMPONENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
PARTS LIST, NOT SHOWN PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
FASTENERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28-32
BELT DRIVE OPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
JOURNAL BOX ASSEMBLY PARTS DIAGRAM- RIGHT HAND HINGE ASSEMBLY . . . . . . . . . 33
STANDARD EQUIPMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
34
SAFETY LABEL LOCATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TANDEM OPERATION ILLUSTRATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
OPERATOR SIGNATURE PAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
37
LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
38
34-35

NOTICE TO OWNERS AND OPERATORS
BIRO’s products are designed to process food products safely and efciently. Unless the opera-
tor is properly trained and supervised, however, there is the possibility of a serious injury. It is the
responsibility of the owner to assure that this machine is used properly and safely, strictly following
the instructions contained in this Manual and any requirements of local law.
Warnings related to possible damage are indicated by:
BIRO also has provided warning labels on the equipment. If any warning label, instruction label
or Manual becomes misplaced, damaged, or illegible, please contact your nearest Distributor or
BIRO directly for a replacement.
Remember, however, this Manual or the warning labels do not replace the need to be alert and to
use your common sense when using this equipment.
- NOTE -
“A copy of this manual is included with each MODEL EMG-32 MIXER-GRINDER.”
“The descriptions and illustrations contained in this manual are not binding.
The manufacturer reserves the right to introduce any modication without updating
the manual.”
1
No one should use or service this machine without proper training and supervision. All operators
should be thoroughly familiar with the procedures contained in this Manual. Even so, BIRO cannot
anticipate every circumstance or environment in which its products will be used. You, the owner
and operator, must remain alert to the hazards posed by the function of this equipment
particularly the ROTATING GRINDING AUGER and the ROTATING MIXING PADDLE, which
can severely injure an inattentive operator amputating ngers and limbs. No one under eighteen
(18) years of age should operate this equipment. If you are uncertain about a particular task, ask
your supervisor.
This Manual contains a number of safe practices in the SAFETY TIPS section. Additional warn-
ings are placed throughout the Manual. Warnings relate to your personal safety are indicated by:
This Manual applies to all BIRO Ergonomic Mixer Grinder/Choppers.
or

SAFETY TIPS
ROTATING GRINDING AUGER &
ROTATING MIXING PADDLES
TO AVOID SERIOUS PERSONAL INJURY
• NEVER Touch This Machine without Training and Authorization by Your Supervisor.
2
• NEVER Place Hands into Machine Input or Output Openings.
• NEVER Open Machine During Operation.
• ONLY Use a Qualied Electrician to Install According to Local Building Codes: Machine MUST Be
Properly Grounded.
• ALWAYS Connect to Proper Voltage & Phase.
• ONLY Install on Level, Non-Skid Surface in a Clean, Well-Lighted Work Area Away from
Children and Visitors.
• ALWAYS Lock Machine Castors After Moving This Machine.
• NEVER Use This Machine For Non Food Products.
• NEVER Operate Machine With Product Mixer Safety Cover Open or Removed or Magnetic
Interlock Switch By-Passed.
• ALWAYS Turn Off, Unplug Machine From Power Source and Perform Lockout/Tagout
Procedure to this Machine BEFORE Attempting to Unjam or Unclog, Cleaning or Servicing.
• NEVER Leave Machine Unattended While Operating.
• NEVER Alter This Machine From its Original Form as Shipped From Factory. DO NOT
Operate Machine With Missing Parts.
• PROMPTLY REPLACE Any Worn or Illegible Warning Labels.
• ALWAYS Read Operation and Service Manual BEFORE Operating, Cleaning, or Servicing.
• USE ONLY BIRO Parts and Accessories Properly Installed.

INSTALLATION
TO AVOID SERIOUS PERSONAL INJURY, PROPERLY INSTALL
EQUIPMENT IN ADEQUATE WORK AREA
3
• ALWAYS Connect to Proper Voltage & Phase.
• NEVER Operate Machine With Product Mixer Safety Cover Open or Removed or Magnetic
Interlock Switch By-Passed.
• ALWAYS Use Qualied Technician and Electrician for Installation.
• ALWAYS Install Equipment in Work Area with Adequate Light and Space Away From Children
and Visitors.
• ONLY Operate on a Solid, Level, Non-Skid Surface.
• ALWAYS Lock Machine Castors After Moving Machine to Operating Location.
• NEVER Bypass, Alter, or Modify This Equipment in Any Way From Its Original Condition.
• NEVER Operate Without all Warning Labels Attached and Owner/Operator Manual Available to
the Operator.
• USE ONLY BIRO Parts and Accessories Properly Installed.
UNCRATING AND SET UP
1. Read this Manual thoroughly before installation and operation. Do not proceed with installation and
operation if you have any questions or do not understand anything in this Manual. Contact your local
Distributor, or BIRO rst.
2. After removing shipping carton, all banding, and all equipment from inside the tub.
Remove screws from cradle structure, remove cradle structure from under machine. Fold down hinged
ramp, unlock casters, and carefully roll machine off of pallet.
3. This machine is shipped with the adjustable legs fully retracted. The legs allow for a height adjustment
from the oor to centerline of bowl 32” minimum to 38” maximum.
4. This machine weighs approximately 730 pounds. To avoid accidents block up and support machine after
raising to desired operating height.
5. The adjustable legs can be unbolted and lowered to the oor. Replace bolts and nuts and tighten securely.
To the nearest adjustment height, conrming all legs are of equal height.
6. Install machine on a level, non-skid surface in a well-lighted work area away from children and visitors.
7. This machine is complete except for knife and plate. There is a bowl shipping plug (cardboard)
placed in the output end of the grinding bowl to retain the grinding auger during shipment. REMOVE
THE BOWL SHIPPING PLUG AND THE GRINDING AUGER.
8. After checking and making sure the power supply is correct, plug in your machine. NEVER OPERATE
MACHINE WITH PRODUCT MIXER SAFETY COVER OPEN. (Machine will not run with cover
open.) ROTATION MUST ONLY BE CHECKED WITH THE GRINDING AUGER REMOVED,
otherwise serious irreparable damage may occur to the grinding components.
9. Machine must be properly grounded. Use qualied electrician to install according to local building codes.

MOTOR WIRING AND ELECTRICAL REQUIREMENTS
1. Interchange of current is made in motor outlet box. Leads are properly marked. Changing instructions are
on the motor plate or motor outlet box.
NOTE TO OWNER AND ELECTRICIAN: IF THIS MACHINE IS NOT CORD
AND PLUG CONNECTED TO THE ELETRICAL SUPPLY SOURCE, THEN IT
SHOULD BE EQUIPPED WITH, OR CONNECTED TO, A LOCKABLE,
MANUALLY-OPERATED DISCONNECT SWITCH (OSHA 1010.147)
GRINDER MOTOR
HP KW VOLTS HZ PH AMPS
7.5 5.6 208/230 60 3 24/22
7.5 5.6 380/415 50 3 12.7/11.6
7.5 5.6 460 60 3 11
7.5 5.6 575 60 3 9.1
.75 .56 208/230 60 3 3.1/2.8
.75 .56 380/415 50 3 1.7/1.6
.75 .56 460 60 3 1.4
.75 .56 575 60 3 1.1
MIXER MOTOR
4
2. All mixer-grinder/choppers are wired 208 volts unless otherwise specied. Be sure motor specications
(voltage, cycle, phase) match power supply line. Be sure line voltage is up to specication.
3. Electrical connections to be in accordance with safety codes and National Electrical Code.
4. Rated voltage of the unit shall be identical with full supply voltage.
5. Voltage drop on the supply line shall not exceed 10% of full supply voltage.
7. The feederline conductor shall only be used for the supply of one unit of the relevant horsepower. For
connections of more than one unit on the same feederline, a local electrician will have to be consulted to
determine the proper conductor size.
6. The feederline conductor size in the raceway from the branch circuit to the unit must be correct to assure
adequate voltage under heavy starting and short overload conditions.
8. The size of the electrical wiring required from the power source to the mixer-grinder/chopper is a
MINIMUM OF No. 10 WIRE.
9. The BIRO Manufacturing Company is not responsible for permanent wiring, connection or installation.
MOTOR SPECIFICATIONS

For best results, use knife and plate as a set. Do not operate machine for any period of time
without product in the grinding bowl. This will cause heating and dulling of the knife and plate.
OPERATION
5
10. Two sets of green and red pushbuttons are located at the front of the machine that activate the magnetic
contacts that control the mix and grind motors. The time delay product mixer safety cover interlock
switch is mounted in the motor compartment. The product mixer safety cover cannot be opened
until the time delay interlock switch times out (which will be after the grinding auger comes to a
complete stop.)
12. If machine runs clockwise(backwards), it must be rewired to correct rotation, otherwise serious
irreparable damage may occur to the grinding components. The grinding auger must operate in the proper
direction.
13. Check operation of optional footswitch if equipped. Plug footswitch cord into tting at bottom of
contactor box. Turn toggle selector to foot. The machine will operate with pressure on the footswitch
treadle. Releasing the treadle stops the machine. The footswitch operates both the mix and grind together.
14. Insert grinding auger assembly into the bowl and fully engage the auger into the drive shaft. Place knife
rst (sharp edges out) then grinding plate into end of grinding bowl. The grinding plate slides over the
knife drive pin, and is held from rotating during operation by three pins in the grinding bowl. Install the
end retaining ring.
ONLY HAND TIGHTEN END RETAINING RING
15. Check placement of all warning labels and Manual. Machine is now ready for trained operators to process
product.
16. Use meat deector attached to grinding bowl to eliminate meat splatter.
17. Contact your local Distributor or BIRO directly if you have any questions or problems with the installation
or operation of this machine.
TO AVOID SERIOUS PERSONAL INJURY
• NEVER Place Hands into Machine Input or Output Openings.
• ONLY Properly Trained Personnel Should Use This Equipment.
11. With the grinding auger removed from the machine, push the green start button for grind. CHECK THE
ROTATION OF THE AUGER DRIVE SHAFT; ROTATION MUST BE COUNTER-CLOCKWISE
as indicated by the rotation decal afxed to the grinding bowl. ROTATION MUST ONLY BE
CHECKED WITH THE GRINDING AUGER REMOVED, otherwise serious irreparable damage
may occur to the grinding components.

FOOD HANDLING TO PREVENT CONTAMINATION
6
OPERATION (Continued)
• NEVER Open Machine During Operation.
• NEVER Operate Machine With Product Mixer Safety Cover Open or Removed or Magnetic
Interlock Switch By-Passed.
• ALWAYS Turn Off, Unplug Machine From Power Source and Perform Lockout/Tagout
Procedure to this Machine BEFORE Attempting to Unjam or Unclog, Cleaning or Servicing.
• NEVER Operate Without all Warning Labels Attached and Owner/Operator Manual Available to
the Operator.
• DO NOT Wear Gloves While Operating.
• DO NOT Tamper With, Bypass, Alter, or Modify This Equipment in Any Way From Its Original Condition.
• NEVER Leave Machine Unattended While the Grinder is Running.
DO’s DON’Ts
• Always keep knife & plate as matched set.
• Always keep the knife & plate sharp.
• Always install the knife & plate in correct
sequence, knife 1st, then plate.
• Always inspect the plates making sure all holes
are clear - that there are no cracks.
• Always keep knives & plates lubricated in storage
and when starting machine.
• Always check for straightness by laying the knife
on the plate before inserting in machine.
• Always use coolant when sharpening plates.
• Never, never mix different knives to different plates.
• Never, never over tighten the bowl retaining ring
on the machine.
• Never, never hit the plate against anything to
clean the holes.
• Never, never run the grinder without product.
Product is a natural lubricant. Heat can build up so
fast that cold product could crack the plate.
• Never, never throw the knives & plates.
1. ALWAYS wash hands thoroughly with warm soap and water before and after handling raw sh, poultry or
meats.
2. ALWAYS clean and sanitize all utensils and surfaces that have been in contact with raw products.
3. ALWAYS store cold foods at or below 45° F (7.2 ° C).
TO PROCESS PRODUCT
1. Before starting the mixer-grinder, have a container for receiving ground product at the output end of the
grinding bowl.
2. FIRST GRIND
3. SECOND GRIND
4. Unplug machine from power source and perform lockout/tagout procedures.
a. Fill product hopper (maximum 150 pounds), close product mixer safety cover.
b. Push the mix green start button only.
c. After the desired mix, press green grinder start button to operate the grinding auger and grind out
the product.
b. Push both grind and mix green start buttons to feed rst grind. It is recommended to use a breaker plate
with a ⅜” diameter or larger holes.
c. Push both grind and mix red stop buttons when product has been ground out.
a. Fill product hopper (maximum 150 pounds), Before this mix operation seasonings may be added if
desired. Close product mixer safety cover.
d. Push both grind and mix red stop buttons when product has been ground out.

MAINTENANCE
A. GRINDING BOWL INSTALLATION
1. Mount the grinding bowl on the two threaded studs on the front of the machine. Tighten in position with
provided nuts.
2. Place the grinding auger in the grinding bowl and fully seat rear drive tang into auger drive shaft.
3. Install knife, breaker plate, and end retaining ring.
ONLY HAND TIGHTEN RETAINING RING
B. LUBRICATION
1. MOTOR: The grinder motor has pre-lubricated, sealed motor bearings.
2. ROLLER CHAIN AND DRIVE SPROCKETS: The main drive chain has been pre-lubricated at the factory
to protect it against dirt and moisture. Chain life will vary appreciably depending upon lubrication. The
better the lubrication, the longer the chain life.
Lubrication effectiveness will vary with the amount of lubricant and frequency of application. Ideally, a
luricant lm should always be present between the working parts. Manually lubricate the chain as often as
is needed (possibly once a week). NEVER exceed three months without lubricating.
Lubricating just the outside of the chain does little good. Apply lubrication on the inside of the chain span
so that it will work through the moving parts and joints by centrifugal force as the chain rotates and reaches
the area where one surface “scrubs” another.
7
ROTATING GRINDING AUGER
TO AVOID SERIOUS PERSONAL INJURY
• ALWAYS Turn Off, Unplug Machine From Power Source and Perform Lockout/Tagout
Procedure to this Machine BEFORE Attempting to Unjam or Unclog, Cleaning or Servicing.
• NEVER Touch This Machine without Training and Authorization by Your Supervisor.
• NEVER Place Hands into Machine Input or Output Openings.
• NEVER Bypass, Alter, or Modify This Equipment in Any Way From Its Original Condition.
• PROMPTLY REPLACE Any Worn or Illegible Warning Labels.
• USE ONLY GENUINE BIRO Parts and Accessories Properly Installed.
4. When the bowl assembly is mounted and tight, there should be approximately ⅛” gap between the back
inside wall of the grinding trough and the back of the auger. The bowl ring wrench which is provided with
each grinder is used for REMOVAL of the end retaining ring for cleaning purposes or for changing knife
and breaker plate.

B. LUBRICATION continued
3. BEARING HOUSING: The main bearings are housed in an enclosed and sealed journal box. Re-lubricate
semi-annually with a good grade of bearing grease. Do not over-grease.
4. MIXER TRANSMISSION: Oil in the mixer transmission should be changed after the rst four (4) weeks
of operation. This is to remove the “run-in” oil and also any small metal shavings that may have been
generated during the mating of the gears. After the intial oil change, subsequent changes should be
performed every six (6) months. After draining the oil, rell the unit to the “level” plug on the back side
of the transmission with petroleum-based #8 gear oil.
5. PROCEDURE FOR REPLACING OIL IN WINSMITH MIXER TRANSMISSION:
a. Unplug mixer/grinder from power source and perform lockout/tagout procedures.
b. Remove rear drive or access cover.
c. Remove breather plug from top of transmission and oil level plug from back side of transmission.
e. When all oil has drained, clean the drain plug and replace in the transmission.
f. Rell transmission with petroleum-based #8 gear oil or equivalent until oil appears at bottom of oil
level hole. For applications that involve severe ambient temperature extremes, Winsmith recommends
the use of Synthetic Lubricants such as: Texaco Vanguard 460, Mobile SHC 630, and Mobile SHC 634.
These gear reducers contain 0.9 QT. of lubricant.
d. With a container in place to catch old oil, remove the drain plug from the bottom of the transmission.
g. Replace breather and oil level plugs.
h. Reinstall rear drive or access cover.
C. MIXER DRIVE CHAIN TENSION
1. Unplug mixer/grinder from power source and perform lockout/tagout procedures.
2. Remove rear drive or access cover.
3. Loosen the four bolts holding the ¾ HP motor and transmission to its mounting plate.
4. Slide transmission to the right.
5. When approximately ⅛” total chain ex has been attained, retighten transmission bolts.
6. Reinstall rear drive cover or access cover.
D. MAIN DRIVE CHAIN TENSION
5. To Loosen Chain Tension. Turn motor adjusting studs counterclockwise. Grasp motor and pull toward
adjusting stud. Be sure to turn both adjusting studs the same amount and evenly. Total chain ex should be
⅛ to ⅜”. Be sure to keep motor shaft parallel with auger drive shaft.
8
a. Unplug mixer/grinder from power source and perform lockout/tagout procedures.
b. Remove rear drive or access cover.
c. Spray or brush lubricant on inside of chain, slowly and carefully turning the large sprocket by hand.
d. Reinstall rear drive cover.
Recommended types of chain lubricant are those with Molybdenum Disulphide or Graphite added. Also
bonded lubricants such as Dow Corning Molykote 321R or equivalent are excellent for open chains. The
lubricant should be of a viscosity whereby it will “ow” somewhat and penetrate the internal working
surfaces. Thick stiff greases are of little value because they cannot work into moving parts of the chain.
1. Unplug mixer/grinder from power source and perform lockout/tagout procedures.
2. Remove rear drive or access cover.
3. Loosen the four bolts that hold the motor to the frame of the machine.
4. Loosen the lock nuts on the motor adjusting stud.

9
To Tighten Chain Tension. Turn motor adjusting studs clockwise. Be sure to turn both adjusting studs the
same amount and evenly. Total chain ex should be ⅛ to ⅜”. Do not overtighten chain as this will put
excessive and damaging pressure on the motor bearings. Be sure to keep motor shaft parallel with auger
drive shaft.
6. Retighten motor mounting bolts.
7. Retighten motor adjusting stud lock nuts.
8. Reinstall rear drive cover or access cover.
D. MAIN DRIVE CHAIN TENSION (Continued)
- OPERATOR’S NOTES -

10
OPTIONAL EAGLE BELT DRIVE SYSTEM
FORCE TABLE #1-7
7-1/2 HP (5.6 kw)
new 15.3 lb (6.9 Kg)
used 11.2 lb (5.1 Kg)

11
“EAGLE” DRIVE SYSTEM
Tensioning Instructions
1. Place a straight edge on top of the belt and across both sprockets as shown in the diagram.
2. Set the large O-Ring at the 1st Graduation (⅛” line) on the Tension Tester,
Item No. H384-EAGL-TSTR.
3. Set the small O-Ring on the deection force scale to ZERO.
4. Place the tension tester squarely on the belt at the center of the belt span (see Diagram).
c. Retighten the motor mounting bolts.
Do not rely on “feel” for the proper belt tension as this typically results in belts that are
under-tensioned.
Loose belts will fail due to “ratcheting” (jumping a tooth), tooth shearing, and breakage.
5. Apply a force to the plunger until the large O-Ring is even with the bottom of the straight edge which has
been laced across both sprockets (⅛” belt deection).
6. Remove the tension tester and read the force recorded from the bottom of the small O-Ring on the force
scale.
7. The force should be equal to the value indicated in the force table #1-7 depending on the “HP” of the
grinder, and if the belt is “new” or “used.”
8. If the force values do not equal those shown in table #1-7, increase the tension as follows:
a. Loosen the 4 motor mounting bolts slightly.
A
b. Advance the jacking screw ¼ turn each (be sure to advance both screws an equal amount).
B
d. Re-check the belt tension according to the above procedure.
Note- The “Eagle” drive belts do not stretch. However, there is a “break-in” period where the teeth in the
belt “mesh” with the teeth of the sprockets during the 1st few hours of operation.
The belt should be re-tensioned after 1 week of operation, according to this tensioning procedure.
No further maintenance is required after this initial adjustment.

12
- OPERATOR’S NOTES -

13
INSTALLATION INSTRUCTIONS
ALTERNATE
GROVE GEAR REDUCER
Mixer Paddle Gear Reducer Retro-Fit
Effective with Model EMG-32; Serial No. 6988, April 2007
The Mixing Paddle Gear Reducer, Item No. EMG20301 (Winsmith) has been replaced with an
alternate Gear Reducer, Item No. EMG20301G (Grove)
If an old style Winsmith Gear Reducer, #EMG20301, should need replacing, a “Retrot Kit” will be
supplied incorporating the new Grove Reducer, Item No. EMG20301G (see drawing):
Procedure for EMG-32 Gear Reducer
Replacement:
Perform lockout/tagout on the power supply.
Disconnect wiring from the mixer motor.
Loosen check nut, Item No. HN30S and back
out adjuster bolt, Item No. HHS093S.
Loosen four (4) reducer mounting bolts.
Slide the unit to the left and remove the chain.
Loosen and remove sprocket, Item No. EMG62012
and Key, Item No. EMG62197 from the reducer.
Remove the reducer mounting bolts and take the
motor/reducer unit from the machine.
Remove the motor from the reducer and the motor key
from the reducer.
New reducer will arrive with the adaptor plate,
Item No. EMG62020G installed on the reducer from
the factory with two (2) ⅜-16 x 1 at head screws,
Item No. FHS58S.
Install mixer motor and key onto the new reducer with
the original hardware. Remove ll plug in top hole,
backside of reducer, and install vent plug supplied
with the gear box. Install sprocket with key on the reducer. Set the unit on the machine. Use two
(2) ⅜-16 x 1½ long bolts, Item No. HHS080S with two (2) ⅜ lock washers, Item No. LW20S,
two (2) at washers, Item No. FW083S and two (2) spacers bushings, Item No. EMG20302 in
the two holes closest to the chain and sprocket.
Use two (2) ⅜-16 x 1 long bolts, Item No. HHS070S with two (2) ⅜ lock washers, Item No. LW20S,
two (2) at washers, Item No. FW083S and two (2) spacers, Item No. EMG20302 in the two holes away
from the chain and sprocket.
Mount chain on reducer sprocket. Use adjusting bolt to set chain tension to ⅛” total ex.
Tighten the four (4) mounting bolts on the reducer. Check the sprocket alignment and tighten set screws.
Install electrical supply to mixer motor. Test for proper operation and rotation synchronization with the auger.
Install the rear cover.
REPLACING
MORSE GEAR REDUCER
EMG20301G-R
GROVE GEAR
REDUCER ONLY
EMG62020G
ADAPTER PLATE
EMG20302 (4 REQ'D)
SPACER BUSHING
FW083S (4 REQ'D)
FLAT WASHER
LW20S (4 REQ'D)
LOCK WASHER
HHS080S (2 REQ'D)
3/8-16 X 1-1/2
HHS070S (2 REQ'D)
3/8-16 X 1
FHS58S (2 REQ'D)
3/8-16 X 1
EMG20301G
GROVE GEAR REDUCER ASSEMBLY
RETROFIT KIT

14
LUBRICATION FOR GROVE GEAR REDUCER
1. Factory Filling
The speed reducers are oil lled at the factory to the proper level for the standard mounting position. The oil level
should be checked and adjusted (if necessary) prior to operation, using the oil level plug provided and while the unit is
oriented in its operating position.
2. Oil Changing
OIL SHOULD BE CHANGED MORE OFTEN IF THE
REDUCER IS USED IN A SEVERE ENVIRONMENT
(i.e., DUSTY, HUMID)
Therefore, when changing to a different oil, it is recommended that the housing be completely drained and thoroughly
ushed with a light ushing oil prior to relling with the appropriate lubricant. The oil level should be rechecked
after a short period of operation and adjusted, if necessary.
A. Initial Oil Change
The oil in a new speed reducer should be changed at the end of 250 hours of operation. (30 days for 8 hour per day
service, 15 days for 16 hour service, 10 days for 24 hour service.)
All standard reducers ordered from the factory are lled with lubricant to operate within a 30° to 100° F ambient
temperature range.
B. Subsequent Oil Changes
Under normal conditions, after the initial oil change, the oil should be changed after every 2500 hours of operation,
or every six months, whichever occurs rst. Under severe conditions (rapid temperature changes, moist, dirty, or
corrosive environment) it may be necessary to change oil at intervals of one to three months. Periodic examination
of oil samples taken from the unit will help establish the appropriate interval.
C. Synthetic Oils
3. Overlling or Underlling
If a speed reducer is overlled with oil, the energy in churning the excessive oil can result in overheating. If this occurs,
shut down the drive, remove the oil level plug and allow oil to drain until oil ceases to drain from the level hole,
reinstall the oil level plug and restart the drive. If the speed reducer is underlled, the resultant friction can cause
overheating and possible damage. If this occurs, ll the speed reducer to the oil level plug hole and check the gearing
for excessive wear. NOTE: Oil capacity is 1¾ pints.
4. Oil Seals
A. When installing a new seal, cover the keyway and any other surface discontinuity with smooth tape to protect the
seal lip from being damaged.
B. A sealant should be used between the O.D. of the seal and the I.D. of the bore into which the seal is installed. The
seal bore should also be free of any burrs, nicks, or scratches.
C. Be sure that the seal is not cocked in the bore. The outer face of the seal should be ush with the surface into which
it is mounted.
WHEN CHANGING OIL FOR ANY REASON,
DO NOT MIX DIFFERENT OILS IN THE REDUCER.
OILS SHOULD BE COMPATIBLE WITH
VITON SEAL MATERIAL.
®
Synthetic lubricants can be advantageous over mineral oils in that they generally are more stable, have a longer life,
and operate over a wider temperature range. These oils are appropriate for any application but are especially useful
when units are subjected to low start-up temperatures or high operating temperatures. Use of synthetics can cause
problems if they are not compatible with the seals or the conventional lubricants they replace. For continuous duty
at normal ambient temperatures (-10° to 105°F) we recommend the use of Mobile SHC 634 which is compatible
with the standard compounded oil shipped in our product and the Viton seal material used through size 252.
®
Although the speed reducer uses high quality oil seals and precision ground shafts to provide a superior seal contact
surface, it is possible that circumstances beyond the speed reducer’s control can cause oil seal leakage (damage during
shipment or installation, etc.) When replacing a shaft oil seal, using the following suggestions will help to insure leak-
free operation and long seal life:

15
EMG20301G-R GROVE GEAR REDUCER
LUBRICATION AND MAINTENANCE
AFTER SERIAL No. 6987
LUBRICANTS FOR EMG20301G-R GROVE GEAR WORM REDUCER
The precision-made gears and bearings in Grove Gear Speed Reducers require high-grade lubricants
of the proper viscosity to maintain trouble-free performance. For best results, use lubricants on the
following chart for worm gear reducers.
Standard factory-installed lubricant is Mobile Oil Corp. 600 W Super Cylinder Oil (AGMA7).
Some gear lubricants contain E.P. additives that can be corrosive to gear bronze material. Avoid
lubricants that are compounded with sulfur and/or chlorine.
Manufacturer 30° to 100°F Ambient Temperature
AGMA Compounded No. 7
50° to 125°F Ambient Temperature
AGMA Compounded No. 8
Amoco Oil Co.
Chevron USA, Inc.
Exxon Co. USA
Gulf Oil Co.
Mobile Oil Corp.
Shell Oil Co.
Sun Oil Co.
Texaco
Union Oil Co. of CA
Worm Gear Oil
Cylinder Oil #460X
Cylesstic TK-460
Senate 460
600 W Super Cylinder
Valvata Oil J460
Gear Oil 7C
Honor Cylinder Oil
Steaval A
Cylinder Oil #680
Cylinder Oil #680X
Cylesstic TK-680
Senate 680D
Extra Hecla Super
Valvata Oil J680
Gear Oil 8C
650T Cylinder Oil
Worm Gear Lube 140

16
#53953, MIXER DRIVE SHAFT SEAL REPLACEMENT
l. Clean the inside of the groove of the mixer drive shaft seal and mating contact surface of the tub wall
thoroughly with scotch-bright or a roughing pad.
2. Dispense a small amount of #454 Loctite adhesive to both these areas - assure even coverage.
3. Wipe away excess adhesive.
4. Slide the “Pressing Rings” #ST90 and #ST91 over the ends of the mixer drive shaft.
5. Apply “even” pressure to the Rings by installing the paddles and Bearing End Assemblies.
6. Wait 20 minutes Cure-Time.
7. Remove the “Pressing Rings.” The seals will be rmly attached to the tub wall.
NOTE: Part Number for 454 Loctite is #53953A-1

17
CLEANING
TO AVOID SERIOUS PERSONAL INJURY
• ALWAYS Turn Off, Unplug Machine From Power Source and Perform Lockout/Tagout
Procedure to this Machine BEFORE Attempting to Unjam or Unclog, Cleaning or Servicing.
• ONLY Use Recommended Cleaning Equipment, Materials, and Procedures.
• NEVER Spray Water or Other Liquid Substances Directly at Motor, Power Switch or any Other
Electrical Components.
• ALWAYS Thoroughly Clean Equipment at Least Daily.
CLEANING THE EMG-32 MIXER-GRINDER
l. Disconnect mixer grinder from power-source and perform lockout/tagout procedures.
2. Remove grinding bowl end ring, breaker plate, knife and grinding auger.
3. Remove mixing paddles by rst loosening the wing nuts locking the mixing paddle from hubs. Turn the
front hubs clockwise and remove from front of machine. Slide mixing paddles forward off the drive shafts
and remove the mixing paddles from the machine.
DO NOT POWER SPRAY DIRECTLY AT ELECTRICAL COMPONENTS
4. Machine is now ready to be cleaned using warm soapy water and rinsed with clean water. Machine may be
cleaned by power spray washing, taking care not to spray directly at any electrical controls.
5. The grinding bowl can be removed for cleaning if desired. This is accomplished by removing the three nuts
on the ange of the grinding bowl.
6. After machine has been cleaned and allowed to air dry, all exposed metal surfaces should be coated with a
good food grade light oil or grease.
7. Never wash the clear product mixer safety cover with any type of abrasive cleaners. Use a soft cloth and
warm soapy water only, rinse with clear water, let air dry.
8. CLEANING PROCEDURE FOR THE POLYCARBONATE SAFETY COVER:
By using compatible cleaners, coupled with proper maintenance techniques will signicantly improve the
material’s service life.
A. Rinse with water to remove excess dust and dirt.
B. Wash with soap or mild detergent using a sponge or soft cloth.
C. Rinse thoroughly with clean water.
D. Dry with a soft cloth or chamois to prevent water spots.
COMPATIBLE CLEANERS: Formula 409, Palmolive liquid - 3, Tob Job, Joy - 2, Windex with Ammonia D-4.
1. Do not use abrasive cleaning materials, such as brillo pads or metal scrapers. Tin is a soft metal and should
be cleaned with a soft cloth and dried.
2. Do not use a cleaning agent containing a high percentage of free alkali or acid.
3. Do not use a detergent containing a high percentage of tri-sodium phosphate or meta-silicate.
Tin is reactive to both.
4. Rinse well and dry thoroughly after washing to remove agents that may be reactive to tin.
5. If sterilizing agent containing chlorine is used, the tinned surface must be thoroughly rinsed.
Chlorine is corrosive to tin.
6. Dry thoroughly after rinsing and store in a dry environment.
7. If water is exceptionally hard, drying will be necessary to prevent spotting.

18
MIXING PADDLE INSTALLATION
S/N’s 6001 to 6057
The Mixing Paddles ARE NOT INTER-
CHANGEABLE, however they are timed to
allow for proper mix action.
PADDLE INSTALLATION:
Install the corresponding mixer paddles by
matching the male and female hub drives with
the respective female and male paddle hubs.
Reinstall the paddle lock arms and
tighten the locking wing bolts.
PADDLE REMOVAL:
Removing mixing paddles by rst loosening
the paddle lock knobs (wing bolts located on
front of the machine). Then turn the lock arms
clockwise approx. ¼ turn to unlock the paddle
shafts and remove them from the hopper.
