BIS ASC User manual

COUNTING SCALE
ZÄHLWAAGE
BALANCE COMPTEUSE
BILANCIA CONTAPEZZI
ASC
USER MANUAL
BEDIENUNGSHANDBUCH
MODE D’EMPLOI OPERATEUR
MANUALE UTENTE
ASC_1.008_13.02_EN_DE_FR_IT
BIS S.r.l.
Via Trieste, 31
20080 Bubbiano MI – Italia
Tel.: [phone]
Fax: [phone]
e-mail: [email protected]
P.IVA e C.F.: 03774900967
www.BilanceOnLine.it

2
LANGUAGES
SPRACHEN
LANGUES
LINGUE
ENGLISH ...................................................................................................3
DEUTSCH................................................................................................19
FRANÇAIS...............................................................................................35
ITALIANO.................................................................................................51

3
ENGLISH
INDEX
ENGLISH .................................................................................................................................................................................................. 3
1. INTRODUCTION................................................................................................................................................................................... 4
2. MAIN TECHNICAL SPECIFICATIONS................................................................................................................................................. 4
3. INSTALLATION..................................................................................................................................................................................... 4
3.1 POWER SUPPLY AND START-UP................................................................................................................................................ 5
3.2 BATTERY POWERED................................................................................................................................................................... 5
4. FRONT PANEL KEYS AND INDICATORS........................................................................................................................................... 6
4.1 FUNCTION OF THE KEYS............................................................................................................................................................ 6
4.2 FUNCTION OF THE INDICATORS ............................................................................................................................................... 7
5. DESCRIPTION OF THE LCD DISPLAYS............................................................................................................................................. 7
6. OPERATION ......................................................................................................................................................................................... 7
6.1 AUTOMATIC ZERO UPON START-UP ......................................................................................................................................... 7
6.2 SCALE ZERO................................................................................................................................................................................ 7
6.3 TARE FUNCTION.......................................................................................................................................................................... 8
6.4 OVERLOAD MESSAGE................................................................................................................................................................ 8
6.5 COUNTING PIECES ..................................................................................................................................................................... 8
6.5.1 COUNTING PROCEDURE ................................................................................................................................................ 8
6.5.2 ENTRY OF THE KNOWN AVERAGE PIECE WEIGHT...................................................................................................... 8
6.5.3 AVERAGE PIECE WEIGHT MEMORY .............................................................................................................................. 8
6.5.4 OPTIMISATION OF THE APW........................................................................................................................................... 9
6.6 TOTALISATION OF THE WEIGHT AND PIECES.......................................................................................................................... 9
6.6.1 TOTALIZATION .................................................................................................................................................................. 9
6.6.2 MANUAL OR AUTOMATIC TOTALIZATION....................................................................................................................... 9
6.6.3 TOTAL OPERATION .......................................................................................................................................................... 9
6.7 CHECKING OF THE WEIGHT OR PIECES.................................................................................................................................. 9
6.7.1 SETTING THE CHECK ON THE WEIGHT OR THE PIECES AND OF THE WEIGHT THRESHOLDS............................. 9
6.7.2 ACOUSTIC ALARM IN CORRESPONDENCE OF THE CHECK ..................................................................................... 10
6.8 FUNCTION OF AUTOMATIC TURN-OFF ................................................................................................................................... 10
7. SET-UP ENVIRONMENT.....................................................................................................................................................................11
SET-UP ENVIRONMENT BLOCK DIAGRAM.....................................................................................................................................11
“F1” - CALIBRATION (*)......................................................................................................................................................................11
“F2” - SCALE DIVISIONS (*) ..............................................................................................................................................................11
“F3” - SCALE CAPACITY (*).............................................................................................................................................................. 12
“F4” - A/D CONVERTER POINTS ..................................................................................................................................................... 12
“F5” - SETTING TOTALISATION AND TRANSMISSION MODE....................................................................................................... 12
“F6” - ZERO TRACKING (*)............................................................................................................................................................... 12
“F7” - SETTING PASSWORD SETUP............................................................................................................................................... 12
“F8” - SPEED SETTING ADC CONVERTER READING SPEED...................................................................................................... 13
“F9” - AUTO SWITCH-OFF................................................................................................................................................................ 13
“F10” - GRAVITY ZONE OF USE (*).................................................................................................................................................. 13
“F11” - ACOUSTIC ALARM................................................................................................................................................................ 13
“F12” - RESET (*) .............................................................................................................................................................................. 13
8. CALIBRATION.................................................................................................................................................................................... 13
PROCEDURE WITH DEFINED SAMPLE WEIGHTS........................................................................................................................ 13
PROCEDURE WITH FREE SAMPLE WEIGHT ................................................................................................................................ 14
9. SERIAL OUTPUT................................................................................................................................................................................ 14
9.1 TRANSMISSION PROTOCOLS.................................................................................................................................................. 14
9.2 PRINTER CONNECTION............................................................................................................................................................ 15
9.3 FORMAT OF THE SERIAL COMMANDS.................................................................................................................................... 16
10. SEALING ACCESS TO THE BALANCE SETTINGS ....................................................................................................................... 16
11. ERROR MESSAGES ........................................................................................................................................................................ 17
RECYCLING INSTRUCTION.................................................................................................................................................................. 17
DECLARATION OF CONFORMITY ....................................................................................................................................................... 18
WARRANTY............................................................................................................................................................................................ 18

4
1. INTRODUCTION
This manual was created to help you install and learn all about the functional possibilities of the ASC scale.
WARNINGS
The scales should be sited in a location that will not degrade the accuracy.
Avoid extremes of temperature. Do not place in direct sunlight or near air conditioning vents.
Avoid unsuitable tables. The tables or floor must be rigid and not vibrate. Do not place near vibrating machinery.
Avoid unstable power sources. Do not use near large users of electricity such as welding equipment or large motors.
Avoid high humidity that might cause condensation. Avoid direct contact with water. Do not spray or immerse the scales in
water.
Avoid air movement such as from fans or opening doors. Do not place near open windows.
Keep the scales clean.
Do not stack material on the scales when they are not in use.
2. MAIN TECHNICAL SPECIFICATIONS
Model
Plate
dimensions
mm
Capacity
kg
Standard
Division
g
Internal
sensitivity
g
Min. APW
recommended
g
CE-M
Division
g
ASC6
230 x 300
6
0,1
0,02
0,1
1/2
ASC15
230 x 300
15
0,2
0,05
0,2
2/5
ASC30
230 x 300
30
0,5
0,1
0,5
5/10
Stabilisation Time
2 Seconds typical.
Operative Temperature:
0°C - 40°C / 32°F - 104°F.
Power supply:
with fitted 240 Vac mains power adapter or with fitted battery
Battery life:
up to 70 hours of continuous use.
Recharge time:
12 hours.
Parameter Setup:
Calibration fully digital and programmable from the keyboard.
Display :
3 LCD backlit with 6 digits.
Case:
ABS Plastic.
Zero range:
+/- 2 % of max load capacity.
Auto zero at start-up:
+/- 10 % of max load capacity.
3. INSTALLATION
a) Unpack then product.
b) If present (depending on the model), it is necessary to unscrew and remove the locking screw for the transportation
placed under the scale, as shown in the figure below:

5
c) Level the platform by adjusting the adjustable feet until the bubble is in the centre of the level. The stability of the
platform is very important.
ALL THE CORNERS MUST REST IN A UNIFORM WAY. Carefully check that all feet fully rest on the ground and that the
platform, loaded on the corner, is not unstable (if a corner is not resting on the ground its relative foot is easier to turn).
3.1 POWER SUPPLY AND START-UP
The indicator can be powered with a fitted 240 Vac external power adapter or just with the fitted battery.
NOTE: it is advisable to completely recharge the battery (12 hours) with the first installation of the instrument.
TO POWER the instrument through the 240 Vac mains put the AC/DC power plug in the appropriate socket under the
scale and the power adapter in the 240 Vac mains socket.
TO TURN ON the instrument press downwards the button under the scale until it turns on, then and release it.
TO TURN OFF the instrument press upwards the button under the scale until it turns off, then release it.
3.2 BATTERY POWERED
The weighing indicator can be operated from the battery if desired.
When the battery needs charging the symbol on the weight display will turn on. The battery should be charged
when the symbol is on. The scale will still operate for about 10 minutes after which it will automatically switch off to protect
the battery.
To charge the battery simply plug into the mains power. The scale does not need to be turned on.
The battery should be charged for 12 hours for full capacity.
You can find the “Charge”LED at the right of display to indicate the status of battery charging. When the scale is
plugged into the mains power the internal battery will be charged. If the LED is green the battery has a full charge. If it is
Red the battery is nearly discharged and yellow indicates the battery is being charged.
As the battery is used it may fail to hold a full charge. If the battery life becomes unacceptable then contact your distributor

6
4. FRONT PANEL KEYS AND INDICATORS
4.1 FUNCTION OF THE KEYS
- Clears the displayed gross weight if it’s within the + / - 2% of the
total capacity.
- A secondary function of "Escape" key when setting parameters or
other functions.
- If pressed for an instant it executes the semiautomatic tare.
- A secondary function of "Confirm" key when setting parameters or
other functions.
- If pressed for an instant it adds the value to the accumulation
memory if the accumulation function is not automatic.
- It recalls the total accumulated weight and pieces.
- If pressed for an instant it allows to set the thresholds for the
CHECK OF WEIGHT OR PIECES function (see section 6.7).
- It is used to store average piece weight and recall it from memory
(see section 6.5.3).
- Allows executing the reference operation (see section 6.5.1).
- Allows to quickly enter the average piece weight (see section 6.5.2).
-A secondary function of incrementing the active digit when setting a
value for parameters or other functions.
- Allows clearing the average piece weight (section 6.5).
- In the numeric input phase, it quickly zeros the current value.
- Entry of digits.

7
4.2 FUNCTION OF THE INDICATORS
INDICATOR
FUNCTION
CHARGE
Indicates that the battery is going to recharge (see section 3.2).
5. DESCRIPTION OF THE LCD DISPLAYS
WEIGHT DISPLAY
The weight on the plate is shown in this display.
AVERAGE PIECE WEIGHT DISPLAY
The entered or calculated average piece weight is shown in this display.
COUNT DISPLAY
The current number of pieces is shown in this display.
FUNCTION OF THE SYMBOLS
The LCD displays have symbols which show the indicator’s functioning status; you will find the description for each symbol
below.
6. OPERATION
6.1 AUTOMATIC ZERO UPON START-UP
The indicator has an “auto zero at start-up” function: in other words it means that if at start-up a weight within + / - 10%
of the capacity is detected, it will be zeroed; if the weight is not within this tolerance, the display shows “Err 4” and with
a non approved instrument the present weight after a few instants, while with an approved instrument “Err 4” is shown
continuously.
6.2 SCALE ZERO
You can press the ZERO key at any time to set the zero point from which all other weighing and counting is measured,
within + / - 2% of power up zero. This will usually only be necessary when the platform is empty. When the zero point
is obtained the display will show the indicator for zero.
SYMBOL
FUNCTION
Indicates that the battery is low (see section 3.2)
W1
The instrument is in the first weighing range.
W2
The instrument is in the second weighing range.
NET
Indicates that the displayed weight is a net weight.
~
The weight is unstable.
0
Indicates that the weight detected by the weighing system is near zero.
LOW-PCS
Indicates that there are an insufficient number of samples in order to determine an accurate count (see
section 6.5).
LOW-APW
Indicates that the average piece weight is insufficient in order to determine an accurate count (see section
6.5).
M+
Indicates that the total weight is greater than 0.

8
The scale has an automatic rezeroing function to account for minor drifting or accumulation of material on the platform
(see “F5”step, section 7). However you may need to press the ZERO/ENTER key to rezero the scale if small amounts
of weight are shown when the platform is empty.
6.3 TARE FUNCTION
Zero the scale by pressing the ZERO key if necessary. The “ZERO” symbol will be on.
Place a container on the platform, a value for its weight will be displayed.
Press the TARE key to tare the scale when the weight is stable. The weight that was displayed is stored as the tare
value and that value is subtracted from the display, leaving zero on the display. The "NET" indicator will be on. As
product is added only the weight of the product will be shown. The scale could be tared a second time if another type
of product was to be added to the first one. Again only the weight that is added after taring will be displayed.
When the container is removed a negative value will be shown.
To remove the tare, unload the scale and press again TARE.
6.4 OVERLOAD MESSAGE
Please do not add item that is over the maximum capacity. When reading “—OL—” and hear beeping sound, remove
the item on the platter to avoid damage to the load cell.
6.5 COUNTING PIECES
Through the reference function it’s possible to use the scale as a piece counter.
6.5.1 COUNTING PROCEDURE
The operations to be carried out are the following:
1) Place the empty container on the scale and press TARE to tare it.
2) Check that the zero is on the display and put the quantity of pieces chosen for the SAMPLE on the scale
3) With the keyboard type the number of pieces on the scale.
4) Press PCS; the displays will indicate SAMPL and the indicator will calculate the Average Piece Weight (A.P.W.).
After a few instants the “COUNT” display will indicate the quantity selected put on the platform.
5) Add the rest of the items to count in the container and whose value will appear on the “COUNT” display.
6) Unload the scale; the APW will remain stored in memory for the next counting of similar pieces, without having to
repeat the REFERENCE operation.
7) To cancel the reference, press the C key.
8) To execute a new reference operation repeat the operations as described from point 1).
6.5.2 ENTRY OF THE KNOWN AVERAGE PIECE WEIGHT
To enter the known average piece weight type the value with the keyboard (including the decimal point) and press
APW.
The “A.P.W.” display indicates the entered average piece weight while the “PCS”display shows the number of pieces
on the scale.
The operation can be made with a loaded or unloaded platform.
In any case, the entry of a new average piece weight cancels and substitutes the previous one.
6.5.3 AVERAGE PIECE WEIGHT MEMORY
The scale can store 10 sets average piece weight (A.P.W.).
SAVE THE AVERAGE PIECE WEIGHT
Hold the PLU key for 3 seconds after you key in the A.P.W., it will show “SAVE PoS 00” , press numeric key
0~9 to select which memory location you want to use. After you do, the A.P.W. is stored in the scale.

9
LOAD THE AVERAGE PIECE WEIGHT
If you want to use the A.P.W. stored in the scale, press PLU key, the scale will shows “LoAd PoS 00”, press
numeric key 0~9 to select which memory location’s price you want to use, current A.P.W. will change to the
value stored in the memory.
6.5.4 OPTIMISATION OF THE APW
After having carried out the REFERENCE operations (section 6.5.1), if one adds to the reference quantity another
amount of pieces as long as it is on the scale and greater than one, the instrument automatically updates the
A.P.W.
To lock the unit weight and prevent Auto-update, press APW after REFERENCE operations (section 6.7.1).
6.6 TOTALISATION OF THE WEIGHT AND PIECES
6.6.1 TOTALIZATION
The scale can be set to accumulate manually the weight and the number of pieces on the scale by pressing the M+
key (see charter 7.3).
The displayed values will be stored in memory when the M+ key is pressed and the weight is stable.
When a totalisation is made, the “A.P.W.” display will show "- 01-", the “WEIGHT” display will show the accumulated
total net weight and the “PCS” display will show the accumulated total number of pieces. After 2 seconds the displays
return to the normal viewing.
Remove the weight, allowing the scale to return to zero and put a second weight on. Press M+; the “A.P.W.” display
will show “- 1-”, the “WEIGHT” display will show the new total net weight and the “COUNT” display will shows the new
total number of pieces.
Continue until all weights or pieces have been added.
6.6.2 MANUAL OR AUTOMATIC TOTALIZATION
The operation of accumulation, normally done manually with key M+, can be done automatically when the weight is
stable. To printout the data relatives to the totalized weight, unload the weight from the scale. In regards to the choice
of the totalisation execution mode see section 7.
6.6.3 TOTAL OPERATION
To view and print the total weight and the total number of pieces in memory press MR key
To return normal weighing mode when total values are shown:
- press ZERO key if you don’t want clear memory or
- press TARE key, to clear also the memory.
NOTE:
- The automatic totalisation functions with a minimum weight of 20d.
- The maximum number of totalisations is 99 while the maximum total value which may be accumulated is 999999.
Once reached these limits, one should clear the total; by pressing M+ the message “AdErr” will appear on the
display.
- The total values will be cleared when it’s turned off.
6.7 CHECKING OF THE WEIGHT OR PIECES
The scale is fitted with the quantity check function with 2 thresholds. An acoustic alarm is enabled on the basis of the
set thresholds and the weighing result.
6.7.1 SETTING THE CHECK ON THE WEIGHT OR THE PIECES AND OF THE WEIGHT THRESHOLDS
Each time the Ckey is pressed at length in weighing phase the scale change the type of the control. The “A.P.W.”
display will show the type of control selected in the available types, in this order: control on the net weight (nEt),
control on the pieces (Cnt) or disabled control.

10
Press +/- key:
-The “WEIGHT” display shows “Hi Cnt” while The “A.P.W.” display shows “000.000”. In this step one configures
the upper threshold for pieces check.
-Use the numeric keys to enter the desired value
-Confirm the entered value with TARE or press ZERO to exit without confirming.
-The “WEIGHT” display shows “Lo Cnt” while The “A.P.W.” display shows “000.000”. In this step one configures
the lower threshold for pieces check.
-Use the numeric keys to enter the desired value
-Confirm the entered value with TARE or press ZERO to exit without confirming.
-The “WEIGHT” display shows “Hi nEt” while The “A.P.W.” display shows “000.000”. In this step one configures the
upper threshold for weight check.
-Use the numeric keys to enter the desired value
-Confirm the entered value with TARE or press ZERO to exit without confirming.
-The “WEIGHT” display shows “Lo nEt” while The “A.P.W.” display shows “000.000”. In this step one configures
the lower threshold for weight check.
-Use the numeric keys to enter the desired value
-Confirm the entered value with TARE or press ZERO to exit without confirming.
-The thresholds are configured and the indicator returns to weighing.
6.7.2 ACOUSTIC ALARM IN CORRESPONDENCE OF THE CHECK
One can decide if the acoustic alarm should enable when the weight is within the threshold or when the weight is out
of the threshold. To choose the alarm enabling mode, see step F11 section 7.
Put a weight on the plate of the scale, the alarm will enable depending on which method has been configured:
WITH ALARM METHOD SET TO “OK” (within the limits)
-The alarm will turn on when the detected weight is between the LOWER THRESHOLD and the UPPER
THRESHOLD.
-The alarm will turn off when the detected weight exceeds the UPPER THRESHOLD and when is less than the
LOWER THRESHOLD.
WITH ALARM METHOD SET TO “NG” (out of the limits)
-The alarm will turn on when the detected weight exceeds the UPPER THRESHOLD and when is less than the
LOWER THRESHOLD.
-The alarm will turn off when the detected weight is between the LOWER THRESHOLD and the UPPER
THRESHOLD.
WITH ALARM METHOD SET TO “LOW” (under low limit)
-The alarm will turn on when the detected weight is lower than the LOWER THRESHOLD.
-The alarm will turn off when the detected weight exceeds the LOWER THRESHOLD.
WITH ALARM METHOD SET TO “HIGH” (over high limit)
-The alarm will turn on when the detected weight exceeds the UPPER THRESHOLD.
-The alarm will turn off when the detected weight is lower than UPPER THRESHOLD.
NOTES
-The check function is enabled when the limit values are entered. To disable the function one should set the limit
values at zero.
-The function is not valid when one enters a lower limit greater than the upper limit.
-The check is enabled with a weight greater than the minimum weight (20d).
6.8 FUNCTION OF AUTOMATIC TURN-OFF
The scale is fitted of a programmable automatic turn-off function, which allows to save energy in case of not using it
temporarily; the automatic turn-off starts functioning when the scale is unloaded (gross weight = 0) for the time (in
minutes) programmed in F9 step, see section 7.
The values vary among:
00 DISABLED
03 3 minutes

11
05 5 minutes
15 15 minutes
30 30 minutes
7. SET-UP ENVIRONMENT
The scale has various parameters that can be configured in the SET-UP environment.
To enter in the SET-UP environment press during the start-up the TARE key during the countdown.
One is asked to enter the password. The default password is 0000. If one forget the password, insert 9999. To enter the
menu:
- Enter the password and press the TARE key:
- The display will show the first function, "F1":
- Pressing the APW key will cycle through the other functions.
- Pressing TARE will allow you to set the function.
- Use APW key or set a value using the numeric keys,
- Press TARE key to enter the value or use the ZERO key to leave a parameter unchanged or to escape set-up
environment.
SET-UP ENVIRONMENT BLOCK DIAGRAM
SETUP
ENVIRONMENT
F1 CAL
F3 CAP
F5 AU
F2 rES
F7 Pin
F4 A-D
COUNTS
F8 SPd 7.5, 15, 30, 60
Pin
3000, 6000,
dUaL, 15000,
30000, 60000
3, 6, 15, 30
F12 rSt
F10 GrU
En, it, ES,
Fr, DE
9,XXXXX
tPUP, LP50
b 600, b 1200,
b 2400, b 4800,
b 9600
AU off, AU on,
P ASk,P Cont,
Ser rE,
F6 AZn 0.5d, 1d,
2d, 4d
F9 oFF 0, 3, 5, 15, 30
F11 bEEP HiGH, ok,
Low, nG
In the parameter description:
- The METRIC parameters are shown with the (*) symbol, and, with approved instrument, these are read only. See
section 10.
“F1” - CALIBRATION (*)
See section 8.
“F2” - SCALE DIVISIONS (*)
By pressing the APW key one selects one of the scale divisions:
Value Divisions
3000 3000
6000 6000
dUAL 3000 + 3000

12
15000 15000
30000 30000
60000 60000
“F3” - SCALE CAPACITY (*)
By pressing TARE one selects the total capacity of the scale.
Press APW key to select one of these capacities: 3, 6, 15, 30 kg.
“F4” - A/D CONVERTER POINTS
By pressing TARE the instrument shows the A/D converter points relative to the weight on the scale.
By pressing ZERO one zero the value.
Press TARE to exit the step.
“F5” - SETTING TOTALISATION AND TRANSMISSION MODE
P ModE TOTALIZATION AND TRANSMISSION MODE
Press the APW key to select one of the suggested values:
AU oFF Manually through the M+ key.
AU on Automatically upon weight stability.
P Cont continuous transmission with P Cont. protocol
SEr rE continuous transmission with SEr rE. protocol
For the description of the transmission protocol refer to section 9.1.
P bAUd TRANSMISSION SPEED
Press the APW key to select one of the possible speeds : 600, 1200, 2400 4800, 9600.
Confirm with TARE.
PtYPE PRINTER TYPE
Press the APW key to select one of the possible values:
tP enables the printing with ASCII printer (for example TPR).
LP50 Non used in this application.
Confirm with TARE.
LANG PRINTING LANGUAGE
Press the APW key to select one of the suggested values: En, it, ES, Fr, DE.
Confirm with TARE.
“F6” - ZERO TRACKING (*)
By pressing the TARE key one sets the divisions' number for the zero tracking, in other words, scale’s thermal drift
compensation parameter; the set value corresponds to the number of divisions which is cleared.
Select one of the suggested divisions by pressing the APW key: 0.5d, 1d, 2d, 4d.
“F7” - SETTING PASSWORD SETUP
By pressing TARE key, the “WEIGHT” display shows “Pin1” and the instrument is ready for entering the password, made up
of up to 4 digits; at the end of the entry confirm with TARE.
The “WEIGHT” display shows “Pin2”; enter again the same password and confirm with TARE.
The A.P.W. display shows “PASS” if the password is correctly repeated or “FAiL” if it isn’t.

13
“F8” - SPEED SETTING ADC CONVERTER READING SPEED
By pressing TARE one sets the reading speed of the ADC converter; the set value corresponds to the number of readings
made in a second.
Press A.P.W. to select one of the suggested reading speeds: 7.5, 15, 30, 60.
“F9” - AUTO SWITCH-OFF
By pressing TARE one sets the minutes of not being used for the auto switch-off (see section 6.10).
Press the APW key to select one of the possible values:
0(disabled)
3 (3 minutes of not being used)
5(5 minutes of not being used)
15 (15 minutes of not being used)
30 (30 minutes of not being used)
“F10” - GRAVITY ZONE OF USE (*)
Through this step one selects the acceleration value of use of the instrument:
Manual entry of the g value: one may manually enter the gravitational acceleration value; one must modify the 6 decimal
digits of the gravitational acceleration.
In case one enters a wrong g value: the minimum decimal value is suggested (9,75001); a wrong value is any decimal
number that is not between 9,75001 and 9,84999 (inclusive).
“F11” - ACOUSTIC ALARM
OK acoustic alarm when the value is in the limit range.
Low acoustic alarm when the value is lower than the low limit
NG acoustic alarm when the value is out of the limit range
High acoustic alarm when the value is higher than the high limit
“F12” - RESET (*)
For use of the manufacturer.
8. CALIBRATION
Premise: The unit of measure of the calibration is fixed at kilogram (“kg”).
It’s possible to calibrate the scale by using two defined sample weights or by manually entering a sample weight (can be
useful if one does not have defined sample weights).
IN CASE THE ZONE OF USE IS DIFFERENT FROM THE CALIBRATION ZONE ONE SHOULD:
1) Carry out the calibration as following described.
2) Set the gravity acceleration value for the ZONE OF USER, see step F10, section 7.
PROCEDURE WITH DEFINED SAMPLE WEIGHTS
-Enter in the setup environment by typing the ”9999” password then enter in the F1 CAL step.
-The display shows the acceleration value set: enter the gravitational acceleration value of the calibration zone if different
from the use zone and press the TARE key to confirm. One must modify all the 6 digits of the gravitational
acceleration. The value will be set also in the F10 step.
-The display shows “LOAD 0”;
-Empty the platter, wait for the weight stability and press TARE key to confirm;
-The display shows “LOAD X” in which X is the value of the first sample weight to be used;
-Put the first sample weight, defined in the table below, on the scale, wait for the weight stability and press TARE;
-The display shows “LOAD X” in which X is the value of the second sample weight to be used;
-Put the second sample weight, defined in the table below, on the scale, wait for the weight stability and press TARE;
-The indicator returns to weighing.

14
CALIBRATION WEIGHTS
MODEL
ASC6
ASC15
ASC30
1° weight
2 kg
5 kg
10 kg
2° weight
6 kg
15 kg
30 kg
PROCEDURE WITH FREE SAMPLE WEIGHT
-Enter in the setup environment by typing the password set in the SETUP (default:”0000”) then enter in the F1 CAL step.
-The display shows the acceleration value set: enter the gravitational acceleration value of the calibration zone if
different from the use zone and press the TARE key to confirm. One must modify all the 6 digits of the gravitational
acceleration. The value will be set also in the F10 step.
-The display shows “UNLOAD”;
-Empty the platter, after Stable indicator on, press TARE key to confirm;
-The display shows “LOAD”; set the value of the mass weight through the numeric keyboard and confirm the entered
value with TARE;
-Put the mass on platter, wait for the weight stability and press TARE key to confirm;
-The indicator returns to weighing.
9. SERIAL OUTPUT
Specifications
RS-232 output for the transmission of the weight data
ASCII code
Baud 4800 (selectable from 600 - 9600)
data bits 8 –n –1
No Parity
Connector: 9 pin (female)
Pin 2: RECEPTION
Pin 3: TRANSMISSION
Pin 5: GND
9.1 TRANSMISSION PROTOCOLS
The transmitted data format varies depending on the selected transmission mode (see step F5, section 7).
“AU ON” AND “AU OFF” MODE
In the normal weighing operations when one is accumulating the weight the data format is the following:
When the totals are recalled from the storage (see section 6.6.3) the data format is the following:
Progressive of totalisations

15
Furthermore it’s possible execute the transmission upon request through the serial commands (see section 9.3)
“P CONT”MODE
In this transmission mode the instrument transmits continuously the following data format:
SEr rE MODE
In this transmission mode the instrument transmits continuously the following data format:
9.2 PRINTER CONNECTION
TPR
STANDARD
CABLE
ASC (9 Pin connector)
GND
Black
GND
CTS
Yellow
-
RX
Grey
TRANSMISSION
TPR printer power supply
STANDARD
CABLE
POWER SUPPLY
+VP and +VC
Red and Orange
+V (5V / 5A)
GND and GND
Black and Black
- V
NOTES:
- Set the following parameters in the ASC (see section 7):
P ModE >> Print >> AU oFF or AU on
P baud >> 9600
PtYPE >> tP
ST,GS,XXX.XXXXkg<CR><LF>
PCSXXXXXXXXXXXpcs<CR><LF>
<CR><LF>
GS for gross weight, NT for net weight
Number of pieces
ST,GS,XXX.XXXXkg<CR><LF>
<CR><LF>
GS for gross weight, NT for net weight
Progressive of totalisations

16
9.3 FORMAT OF THE SERIAL COMMANDS
COMMAND
FUNCTION
T<CR><LF>
Automatic tare, tares the weight on the scale.
Z<CR><LF>
Clears the gross weight.
M+<CR><LF>
Executes the totalisation with printing.
MR<CR><LF>
Executes the printing of the total
MC<CR><LF>
Clears the accumulated totals and the totalisation progressive.
Uxxx.xxx<CR><LF>
Entry of APW (in grams if the unit is “kg” or pounds if the unit is “lb”) in which xxx.xxx is
the apw to be entered. If the APW is not valid the command clears the eventual APW.
C<CR><LF>
To Clear the average piece weight.
10. SEALING ACCESS TO THE BALANCE SETTINGS
For legal for trade applications, the balance must be sealed to prevent access to the metrological parameters.
To seal the balance, press the recessed Lock switch at the bottom of the balance, momentarily during power up (the
message “LEGAL” appears an instant), then cover the Lock switch access hole. A cover seal and paper seal may be
installed as shown.
To regain access to the locked balance settings, break the seal and press the recessed Lock switch
momentarily during power up (the message “HIRES” appears an instant).

17
11. ERROR MESSAGES
ERROR MESSAGES
DESCRIPTION
RESOLUTION
- - oL - -
Over range
Remove weight from the scale.
Err 4
Zero Setting Error
Upon start-up or when the ZERO key is pressed, the weight on the
scale exceeds the percentage programmed on the max. capacity.
Remove the excess weight and retry.
Err 5
Keyboard error
The keyboard could be damaged.
Err 6
Input signal greater
than 3mV/V
Indicates that the A/D converter value is greater than the maximum
value:
- Remove the weight from the scale if it’s exceeding.
- The load cell or the electronics could be damaged.
RECYCLING INSTRUCTION
The crossed-out wheeled bin on the product means that at the product end of life, it must be taken to
separate collection or to the reseller when a new equivalent type of equipment is purchased. The
adequate differentiated refuse collection in having the product recycled, helps to avoid possible
negative effects on the environment and health and supports the recycling of the materials of which
the equipment is made. The unlawful disposal of the product by the user will entail fines foreseen by
the current regulations.

18
DECLARATION OF CONFORMITY
This device conforms to the essential standards and norms relative to the
applicable European regulations. The Declaration of conformity is available in the
web site www.scalehouse.it.
WARRANTY
Scale House products are guaranteed for a period of twelve months from delivery,
excluding the parts classified as expendable materials such as mechanical printing
heads, batteries, electric motors and wheels. The warranty for these expendable
materials is three months. The warranty refers to breakdowns resulting from any
construction defect or material defect of the product supplied and covers the cost
of labor and spare parts. The product must be returned to the Seller address in its
original packaging with shipping paid by the sender. The warranty does not apply
to breakdowns due to improper use or non-observance of the operating
instructions, electrical phenomenon, unauthorized repair attempt, connection to
other equipment or removal of any product identification elements (serial number,
label, etc.). This warranty does not provide for any compensation for damages,
direct or indirect, incurred by the user due to complete or partial failure of
instruments, even during the warranty period. The warranty for the load cells
excludes the damages caused by knocks and overloads.
AUTHORISED SERVICE CENTRE STAMP

19
DEUTSCH
INHALTSVERZEICHNIS
1. EINLEITUNG.....................................................................................................................................................................20
2. TECHNISCHE HAUPTEIGENSCHAFTEN .......................................................................................................................20
3. INSTALLATION.................................................................................................................................................................20
3.1 STROMVERSORGUNG UND INBETRIEBNAHME ...................................................................................................21
3.2 BATTERIEBETRIEB...................................................................................................................................................21
4. TASTEN UND ANZEIGEN AUF DEM FRONTPANEEL....................................................................................................22
4.1 TASTENFUNKTIONEN ..............................................................................................................................................22
4.2 FUNKTION DER KONTROLLEUCHTEN...................................................................................................................23
5. SYMBOLE DER LCD ANZEIGE .......................................................................................................................................23
6. FUNKTIONEN...................................................................................................................................................................23
6.1 AUTOMATISCHE NULLSTELLUNG BEIM EINSCHALTEN.......................................................................................23
6.2 NULLSTELLUNG DER WAAGE.................................................................................................................................24
6.3 TARA FUNKTIONEN..................................................................................................................................................24
6.4 ÜBERLAST- WARNUNG............................................................................................................................................24
6.5 STÜCKZÄHLUNG......................................................................................................................................................24
6.5.1 ABLAUF ZÄHLUNG.........................................................................................................................................24
6.5.2 EINGABE DES BEKANNTEN MITTLEREN STÜCKGEWICHTES..................................................................24
6.5.3 DATENSPEICHER (PLU = Product Look up) ..................................................................................................25
6.5.4 AUTOMATISCHE REFERENZOPTIMIERUNG ...............................................................................................25
6.6 SUMMIERUNG DES GEWICHTS UND DER STÜCKANZAHL..................................................................................25
6.6.1 SUMMIEREN...................................................................................................................................................25
6.6.2 MANUELLE ODER AUTOMATISCHE TOTALISIERUNG................................................................................25
6.6.3 ABRUFEN DES GESAMTWERTS ..................................................................................................................25
6.7 KONTROLLE DES GEWICHTS UND DER STÜCKANZAHL.....................................................................................26
6.7.1 EINSTELLEN DER GEWICHTS- UND STÜCKANZAHLKONTROLLE UND DER SCHWELLENWERTE......26
6.7.2 AKUSTISCHER ALARM BEIM GEWICHTS-CHECK.......................................................................................26
6.8 AUTOMATISCHE ABSCHALTUNG ............................................................................................................................27
7. SETUP- UMGEBUNG.......................................................................................................................................................27
BLOCKSCHALTBILD DER SETUP-UMGEBUNG............................................................................................................27
“F1” - KALIBRIERUNG (*) ................................................................................................................................................28
“F2” - TEILUNGEN DER WAAGE (*)................................................................................................................................28
“F3” - WÄGEBEREICH (*)................................................................................................................................................28
“F4” - A/D KONVERTERPUNKTE ....................................................................................................................................28
“F5” - EINSTELLEN DER SUMMIERUNG UND DES ŰBERTRAGUNGSMODUS..........................................................28
“F6” – NULL- NACHFÜHRUNG (*)...................................................................................................................................28
“F7” - PASSWORTEINGABE ...........................................................................................................................................29
“F9” - AUTOMATISCHE ABSCHALTUNG ........................................................................................................................29
“F11” - AKUSTISCHES SIGNAL.......................................................................................................................................29
8. KALIBRIERUNG...............................................................................................................................................................29
VERFAHREN MIT DEFINIERTEN MUSTERGEWICHTEN..............................................................................................30
VERFAHREN MIT FREIEN MUSTERGEWICHT .............................................................................................................30
9. SERIELLE AUSGÄNGE ...................................................................................................................................................30
9.1 AUSGANGSDATENFORMAT.....................................................................................................................................30
9.2 DRUCKERVERBINDUNG..........................................................................................................................................31
9.3 FORMAT DER SERIELLEN BEFEHLE......................................................................................................................32
10. ZUGRIFF AUF DIE WAAGENEINSTELLUNGEN VERSIEGELN...................................................................................33
11. FEHLERMELDUNGEN ...................................................................................................................................................33
ANWEISUNGEN ZUM RECYCLING ....................................................................................................................................33
KONFORMITÄTSERKLÄRUNG...........................................................................................................................................34
GARANTIE............................................................................................................................................................................34

20
1. EINLEITUNG
Diese Beschreibung erklärt Ihnen den Einsatz und die Funktionen der ASC Waage.
HINWEISE
Die Waage sollte an einem Ort eingesetzt werden, welcher die Genauigkeit nicht beeinträchtigt.
Extreme Temperaturen vermeiden. Nicht in direktem Sonnenlicht oder bei Ventilatoren betreiben.
Achten Sie auf eine stabile Auflage. Tisch oder Boden muss eben und frei von Vibrationen sein. Nicht in der Nähe von
vibrierenden Maschinen betreiben.
Achten Sie auf ein sauberes Netz. Nicht an der gleichen Steckdose mit großen Geräten oder Motoren anschließen.
Nicht bei hoher Luftfeuchtigkeit betreiben und direkten Kontakt mit Wasser vermeiden. Nicht in Wasser eintauchen oder
ansprühen.
Vermeiden Sie Zugluft von offenen Fenstern oder Ventilatoren. Nicht in der Nähe von Türen platzieren.
Halten Sie die Waage sauber.
Stapeln Sie keine Waren auf die unbenutzte Waage.
2. TECHNISCHE HAUPTEIGENSCHAFTEN
Version
Schale
(Abmessungen
mm)
Wägebereich
kg
Ziffernschritt
[g]
Interne
Auflösung in
g
Mind.
empfohlenes
M.S.G. in g
CE-M
Ziffernschritt
g
ASC6
230 x 300
6
0,1
0,02
0,1
1/2
ASC15
230 x 300
15
0,2
0,05
0,2
2/5
ASC30
230 x 300
30
0,5
0,1
0,5
5/10
Stabilisierungszeit:
2 Sekunden.
Umgebungstemperatur:
0°C - 40°C / 32°F - 104°F.
Stromversorgung:
Mit 240 V~ Netzteil oder mit interner Batterie
Betriebszeit Batterie:
Bis zu 70 Stunden ununterbrochene Anwendung.
Ladezeit:
12 Stunden.
Parameter Setup:
Digitale Kalibrierung und programmierbar über Tastatur.
Display :
3 hintergrundbeleuchtete LCD-Displays mit 6 Zeichen.
Gehäuse:
ABS Plastic.
Nullstellbereich:
+/- 2 % des Max. Wägebereich.
Nullstellung beim Start:
+/- 10 % des Max. Wägebereich.
3. INSTALLATION
a) Die Verpackung öffnen.
b)Man muss die für die Beförderung Feststellschraube, die vom Modell abhängend unter der Waage zu finden sind,
abschrauben und entfernen. Siehe Bild unten.
