Bitspower TITAN X User manual

Parts List
..............1 set
Backplane assembly
— 1—
Bitspower reserves the right to change the product design and
interpretations. These are subject to change without notice. Product
colors and accessories are based on the actual product.
English
TITAN X_AMD 1.2 Installation Guide
CPU Water Block
A
B-1 B-2 B-4 B-5 B-6
A-1 A-2
B-3
※The allowable variance in tube length is ± 2mm
..........1 pc
BPTA-CPUMS-V2-SKA
A-1
A-2
Fittings
B
...............4 pcs
BPTA-DOTFH1622
B-1
...................................2 pcs
TA-F61
B-2
..............................2 pcs
BPTA-F95
B-3
...........................2 pcs
BP-RIGOS5
B-4
..................................2 pcs
TA-F60
B-5
..................................2 pcs
TA-F40
B-6
Accessory
C
..............................2 pcs
Hard tube
C-1
....................1 pc
Fitting + soft tube
C-2
A
B
C
CPU set
C-3
Hard Tube
C-1
Fitting + soft tube
C-2
V4
SCM3FL20
SPRING
SCM3F6
1mm Spacer
Back Pad
Paste Pad
Metal Backplane
M3x32mm Screw

I. AMD Motherboard system
— 2—
SCM3FL20
CPU Block
SPRING
1mm SPACER
96 90
48
54
AMD SOCKET AM4 AMD SOCKET AM3 / AM3+ AMD SOCKET AM2 / AM2+ AMD SOCKET FM1 / FM2+
AMD SOCKET 939 / 754 / 940
AMD SOCKET AM4
AMD SOCKET AM3 / AM3+
AMD SOCKET AM2 / AM2+
AMD SOCKET FM1 / FM2+
Installation
DRGB LED
IN
OUT
DRGB PIN on Motherboard or other equipment.
 
Motherboard
Fan and DRGB RF Remote
Controller Hub (Not included)
BPTA-RFCHUB
M3x32mm SCREW
(for Intel)
1mm SPACER
Back Pad
3M Paste Pad
Metal Backplane
SCM3FL20
SPRING
CPU Block
1mm SPACER
SCM3F6
EX.
Do not over-tighten the thumb screws
(SCM3FL20). The springs should be
slightly compressed, with visible gaps
in the spring coils. Over-tightening
may result in poor contact between the
water block and CPU.
Use an appropriate amount
of Thermal Compound, - high-end
Bitspower cooling products are now
available at microcenter.com.
The CPU water block has a DRGB cable, which
can be connected to the DRGB extension
cable of the radiator fans.
Bitspower Fan and DRGB RF Remote Controller Hub
(Not included) are now available at microcenter.com
(Pre-installed with
ASUS X570-E
AM4 Motherboard)
ASUS X570-E AM4 Motherboard and
EVGA 850 Watt Power Supply has
been Installed on TITAN X A1.2.
Check your AMD Accessory box for original
Motherboard brackets and screws.
This step has already
been assembled for
AMD Motherboard
installation.

— 3—
Model Brand
1 ROG STRIX B450F GAMNG ATX ASUS
2 PRIME X470-PRO AM4 ASUS
3 TUF GAMING X570-PLUS WIFI ASUS
4 ROG STRIX X570-E GAMNG ASUS
CPU TUBE
Motherboard
AMD 48x263 mm 48x263 mm
Installation 1
Installation 2
Model Brand
1 B450 TOMAHAWK AM4 ATX MSI
2 B450 AORUS PRO WIFI AM4 GIGABYTE
3 X570 AORUS ELITE WIFI GIGABYTE
CPU TUBE
Motherboard
AMD 48x263 mm 48x263 mm
B-4
B-1
C-1
C-1
B-4
B-1
B-6
PUMP HEADER
②FULL SPEED
AIO_PUMP
PUMP HEADER
① PWM CONTROL
CPU_FAN
II. AMD Chipset Installaiton
How to install tubes for CPU

Pour the coolant into the reservoir via the water filling hole. Once the reservoir is 90% full,
turn on the power supply for the pump to run and let the air exit the loop. Turn off the
power supply when the reservoir is near empty. Repeat until all the air has exited the loop.
Notice : Do not turn on the pump if the reservoir is empty.
Bitspower recommends that consumers add the Bitspower coolant or
purified water for their water-cooling liquid. If the consumer chooses
different water-cooling liquids , the resulting impurities may cause
peeling of the coating on some of the hardware, water channels block-
age by built-up residue, improper operation of the water pump, water
tank tube breakage, and o-rings deformation leading to leakage. Any
issues related to the use of inappropriate water-cooling liquid will be
the responsibility of the consumer.
BPTA-EFW
It is recommended to install the water-exhaust
fitting at the lowest point of the water cooling
system.
Step 1
Unscrew the top of the water-exhaust fitting.
AIO_PUMP
PUMP HEADER
① PWM CONTROL
CPU_FAN
PUMP HEADER
②FULL SPEED
AIO_PUMP
① PWM CONTROL
CPU_FAN
A Negative electrode -
B positive electrode +
C Speed signal
A B C D
Step 2
Replace with the water-exhaust part. When
screwing in the part, water will start to
discharge, it is recommended to connect
tubing beforehand to control the water outflow.
— 4—
III. BPTA-O11D-AK
Water filling hole
backplate / control panel / top cover
90% full
Pump Spec.
Rated voltage：12V DC
Power consumption：8.4W
Maximum flow：460±15%L/h
Noise：≦24dBA
PWM：Yes
MTBF：≦15,000 hours
Warranty：2 years
BP-BB2WP-P02
Before installing the water cooling parts
for the graphics card, please cut the soft
tube as shown in the figure and remove
the BP-BB2WP-P02.
