BIXOLON SRP-382II Installation instructions

SRP-380/382II
Command Manual
Ver. 1.00
http://www.bixolon.com

SRP-380/382II
Ver. 1.00 BIXOLON
- 2 -
■ Contents
1. Notice ....................................................................................................................................................................................................... 3
2. Control Commands List in Alphanumeric Order ................................................................................................................................... 4
2-1 Command Description Items ...................................................................................................................................................................... 6
2-2 Details of Control Commands ..................................................................................................................................................................... 7

SRP-380/382II
Ver. 1.00 BIXOLON
- 3 -
1. Notice
This document contains proprietary information of BIXOLON Corporation and its affiliates. You may utilize the information solely
for the purpose of facilitating authorized sales and service of, or developing software and similar products for authorized use with,
BIXOLON products, provided that such proprietary information may not be used, reproduced, or disclosed to any other parties for
any other purpose without the prior written permission of BIXOLON Corporation. BIXOLON has no liability for loss or damage
arising from or relating to your use of or reliance on the information in the document.
We at BIXOLON maintain ongoing efforts to enhance and upgrade the functions and quality of all our products. In following,
product specifications and/or user manual content may be changed without prior notice.

SRP-380/382II
Ver. 1.00 BIXOLON
- 4 -
2. Control Commands List in Alphanumeric Order
No. Command Function No. Command Function
1 HT Horizontal tab 26 ESC R Specify an international character set
2 LF Print and line feed 27 ESC S Select standard mode
3 FF Form feed (in page mode) 28 ESC T Select print direction in page mode
4 CR Print and carriage return 29 ESC V Turn 90° clockwise rotation mode on/off
5 CAN Cancel the print data in page mode 30 ESC W Set print area in page mode
6 DLE EOT Transmit real-time status 31 ESC \ Set relative print position
7 DLE DC4 Generate pulse at real-time 32 ESC a Set position alignment
8 ESC SP Set the character right space 33 ESC d Print and feed n lines
9 ESC ! Set print mode 34 ESC i Partial cut
10 ESC $ Set absolute print position 35 ESC m Partial cut
11 ESC % Select/cancel user-defined character set 36 ESC p Generate pulse
12 ESC & Define user-defined character set 37 ESC t Select character code table
13 ESC * Specify bit image mode 38 ESC v Transmit paper sensor status
14 ESC - Turn underline mode on/off 39 ESC { Turn upside-down print mode on/off
15 ESC 2 Select default line spacing 40 FS p Print NV bit image
16 ESC 3 Set line spacing 41 FS q Define NV bit image
17 ESC = Select peripheral device 42 GS ! Select character size
18 ESC ? Cancel user-defined characters 43 GS $ Set absolute vertical print position in
page mode
19
ESC @
Initialize printer
44
GS ( A
Execute test print
20 ESC D Set horizontal tab positions 45
GS ( L
GS 8 L Select graphics data
21 ESC E Turn emphasized mode on/off 46 GS ( k Specify and print the symbol
22 ESC G Turn double-strike mode on/off 47 GS * Define downloaded bit image
23 ESC J Print and feed paper 48 GS / Print downloaded bit image
24 ESC L Select page mode 49 GS : Start/end macro definition
25 ESC M Select character font 50 GS B Turn white/black reverse print mode on/off

SRP-380/382II
Ver. 1.00 BIXOLON
- 5 -
No. Command Function
51 GS H Select print position of HRI characters
52 GS I Transmit printer ID
53 GS L Set left margin
54 GS V Select cut mode and executes a partial cut
55 GS W Set print area width
56 GS ^ Execute macro
57 GS a Enable/Disable Automatic Status Back (ASB)
58 GS f Select font for HRI characters
59 GS h Set bar code height
60 GS k Print bar code
61 GS r Transmit status
62 GS v 0 Print raster bit image
63 GS w Set bar code width
64 BS M Select device font type
65 BS V Select cut mode and executes a partial/full
cut
66 BS ^ P Set power saving mode

SRP-380/382II
Ver. 1.00 BIXOLON
- 6 -
2-1 Command Description Items
Command
Function: Command function outline
Code: Command format expressed in ASCII, hexadecimal, and decimal codes
Range: Argument value (Setting range) for the command
Default: Initial argument value for the command
Description: Detailed command function description
Remarks: Additional information about using the command
Differences: Variations depending on the printer model

SRP-380/382II
Ver. 1.00 BIXOLON
- 7 -
2-2 Details of Control Commands
HT
Function: Horizontal tab
Code: ASCII HT
Hex 09
Decimal 9
Range: None
Default: None
Description: This command moves the print position to the next
horizontal tab position. If the next horizontal tab position is
not specified, this command will be void.
Remarks: ■ The horizontal tab position is set by <ESC> D.
■ With the underline mode turned on, the underline printing is not applied to the tab space created by this
command.
Differences: None

SRP-380/382II
Ver. 1.00 BIXOLON
- 8 -
LF
Function: Print and line feed
Code: ASCII LF
Hex 0A
Decimal 10
Range: None
Default: None
Description: This command prints the data in the print
buffer and feeds one line based on the current set line spacing in
standard mode.
Remarks: ■ In page mode, the printer does not perform actual printing, but moving only the print position to the next
line.
Differences: None

SRP-380/382II
Ver. 1.00 BIXOLON
- 9 -
FF
Function: Form feed (in page mode)
Code: ASCII FF
Hex 0C
Decimal 12
Range: None
Default: None
Description: This commands prints all data collected in the printer buffer In page mode. A
fter completion of printing, the
printer is returned to standard mode.
Remarks: ■ The printer is returned to standard mode after completion of printing.
■ This command works in page mode enabled by ESC L.
■ If the paper is positioned at the print starting position, this command is ignored, not performing actual paper
feeding operation.
Differences: None

SRP-380/382II
Ver. 1.00 BIXOLON
- 10 -
CR
Function: Print and carriage return
Code: ASCII CR
Hex 0D
Decimal 13
Range: None
Default: None
Description:
This command prints the data. With auto line feed enabled, it performs printing and one line feeding same as
LF.
Differences: None

SRP-380/382II
Ver. 1.00 BIXOLON
- 11 -
CAN
Function: Cancel the print data in page mode
Code: ASCII CAN
Hex 18
Decimal 24
Range: None
Default: None
Description: This command clears the receive buffer and print buffers in page mode.
Remarks: ■ This command is effective only in page mode that is set by ESC L.
Differences: None

SRP-380/382II
Ver. 1.00 BIXOLON
- 12 -
DLE EOT
Function: Transmit real-time status
Code: ASCII DLE EOT n
Hex 10 04 n
Decimal 16 4 n
Range: 1 ≤ n ≤ 4
Default: None
Description: This command enables commands to be operable in real-time.
This command transmits the printer-related status specified by n as follows:
n Function
1 Transmit printer status
2 Transmit off-line status
3 Transmit error status
4 Transmit paper roll sensor status

SRP-380/382II
Ver. 1.00 BIXOLON
- 13 -
■ Printer transmits the following status
n=1: Printer status
Bit Binary Hex Decimal Status
0 0 00 0 Not used. Fixed to Off
1 1 02 2 Not used. Fixed to On
2 0 00 0 Drawer kick-out connector pin 3 is LOW
1 04 4 Drawer kick-out connector pin 3 is HIGH
3 0 00 0 Online
1 08 8 Offline
4 1 10 16 Not used. Fixed to On
5 0 00 0 Not used. Fixed to Off
6 0 00 0 Not used. Fixed to Off
7 0 00 0 Not used. Fixed to Off
n=2: Off-line status
Bit Off/On Hex Decimal Status
0 Off 00 0 Fixed
1 On 02 2 Fixed
2 Off 00 0 Cover is closed
On 04 4 Cover is open
3 Off 00 0 Paper is not being fed by using the paper FEED button
On 08 8 Paper is being fed by the paper FEED button
4 On 10 16 Fixed
5 Off 00 0 No paper-end stop
On 20 32 Printing is being stopped
6 Off 00 0 No error
On 40 64 Error has occurred
7 Off 00 0 Fixed

SRP-380/382II
Ver. 1.00 BIXOLON
- 14 -
n=3: Error status
Bit Binary Hex Decimal Status
0 0 00 0 Not used. Fixed to Off
1 1 02 2 Not used. Fixed to On
2 0 00 0 Not used. Fixed to Off
3 0 00 0 No autocutter error
1 08 8 Autocutter error occurred
4 1 10 16 Not used. Fixed to On
5 0 00 0 Not used. Fixed to Off
6 0 00 0 Not used. Fixed to Off
7 0 00 0 Not used. Fixed to Off
n=4: paper sensor status
Bit Binary Hex Decimal Status
0 0 00 0 Not used. Fixed to Off
1 1 02 2 Not used. Fixed to On
2,3 00 00 0 Paper near end sensor: paper adequate
11 0C 12 Paper near end sensor: paper near end
4 1 10 16 Not used. Fixed to On
5,6 00 00 0 Paper end sensor: paper present
11 60 96 Paper end sensor: paper not present
7 0 00 0 Not used. Fixed to Off
Remarks: ■ T
he status is transmitted to the host upon being requested that can check the printer operational condition
with it and takes appropriate measures accordingly.
■ The real time command is stored into the receive buffer and executed with higher priority than other
commands.
Differences: None

SRP-380/382II
Ver. 1.00 BIXOLON
- 15 -
DLE DC4
Function: Generate pulse at real-time
Code: ASCII DLE DC4 n m t
Hex 10 14 n m t
Decimal 16 20 n m t
Range: n = 1, m=0,1, 1 ≤ t ≤ 8
Default: None
Description: ■ Output the pulse specified by t to connector pin m as following:
m Connector pin
0 Drawer kick-out connector pin 2
1 Drawer kick-out connector pin 5
■ This command generates the drive pulse to connector pin m with pulse width defined by t as following:
• Drawer kick-out connector pin 2 is selected with m=0 while pin 5 chosen for m=1.
• Pulse ON time is [t x100 ms] and OFF time [t x100 ms].
Remarks: ■ Upon receiving this command, the printer outputs the drive pulse to the specified connector pin.
■ The real time command is stored into the receive buffer and executed with higher priority than other
commands.
Differences: None

SRP-380/382II
Ver. 1.00 BIXOLON
- 16 -
ESC SP
Function: Set the character right space
Code: ASCII ESC SP n
Hex 1B 20 n
Decimal 27 32 n
Range: 0 ≤ n ≤ 255
Default: n = 0
Description: ■ This command sets the size of space to right of character.
• Right space = n × [horizontal motion units].
Remarks: ■ In a double width mode, the right space will be doubled.
■ Horizontal motion unit varies depending the printer model.
Differences: Horizontal motion unit:
■ SRP-380II: 0.141mm(1/180 inch)
■ SRP-382II: 0.125mm(1/203 inch)

SRP-380/382II
Ver. 1.00 BIXOLON
- 17 -
ESC !
Function: Set print mode
Code: ASCII ESC ! n
Hex 1B 21 n
Decimal 27 33 n
Range: 0 ≤ n ≤ 255
Default: n = 0
Description: This command selects print mode(s) with bits having following meanings.
Bit Off/On Hex Decimal Function
0 Off 00 0 Character font A selected
On 01 1 Character font B selected
1,2 Off 00 0 Reserved
3 Off 00 0 Emphasized mode not selected
On 08 8 Emphasized mode selected
4 Off 00 0 Double-height mode not selected
On 10 16 Double-height mode selected
5 Off 00 0 Double-width mode not selected
On 20 32 Double-width mode selected
6 Off 00 0 Reserved
7 Off 00 0 Underline mode not selected
On 80 128 Underline mode selected
Remarks: ■ As alternative to this command, ESC M, ESC E and ESC –
can be used for the selection for character font,
emphasized mode and underline mode respectively.

SRP-380/382II
Ver. 1.00 BIXOLON
- 18 -
■ The entire character print width is underlined, but the space skipped by HT is not.
■ If both double width and double height are selected, the characters will be quadrupled.
Differences: None

SRP-380/382II
Ver. 1.00 BIXOLON
- 19 -
ESC $
Function: Set absolute print position
Code: ASCII ESC $ nL nH
Hex 1B 24 nL nH
Decimal 27 36 nL nH
Range: 0 ≤ (nL + nH x 256) ≤ 65535 (0 ≤ nH ≤ 255, 0 ≤ nL ≤ 255)
Default: None
Description: This command specifies the next print starting position in reference to the left edge of the print area. The
printing
start position is calculated using (nL + nH x 256) x (vertical or horizontal motion units).
Remarks: ■ Any setting values that go beyond the printable area is ignored.
■ In standard mode, the horizontal motion unit is used for the calculation.
■ In page mode, the horizontal motion unit is applied when printing start poison is defined to the upper
right or
lower right of print area using ESC T, otherwise, the vertical motion unit is used.
Differences: Horizontal motion unit:
■ SRP-380II: 0.141mm(1/180 inch)
■ SRP-382II: 0.125mm(1/203 inch)

SRP-380/382II
Ver. 1.00 BIXOLON
- 20 -
ESC %
Function: Select/cancel user-defined character set
Code: ASCII ESC % n
Hex 1B 25 n
Decimal 27 37 n
Range: 0 ≤ n ≤ 255
Default: n = 0
Description: ■ This command selects/deselects user-
defined character set that is downloaded by user. To make it valid, the
least significant bit should be defined like following.
• When n=0, the user-defined character set is deselected.
• When n=1, the user-defined character set is selected.
Remarks: ■ The resident character set is enabled and used right after canceling the user defined character set.
Differences: None
