ELECTRIC HEATER
INSTRUCTION MANUAL
Models: W914-40F, W914-48F, W914-60F
ATTENTION:
1. Find a location for the electric heater that is protected from direct sunlight.
2. Do not plug the electric heater into the power outlet before you read all
instructions.

2
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS FOR FUTURE USE
WHEN USING ELECTRICAL APPLIANCES, BASIC PRECAUTIONS SHOULD
ALWAYS BE FOLLOWED TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK,
AND INJURY TO PERSONS, INCLUDING THE FOLLOWING:
Read all instructions before using this heater. Failure to follow these important safety
instructions may cause fire, electric shock or damage. Following proper safety and operating
instructions is the responsibility of the owner.
1) Grounding (If necessary) - this heater is for use on 120 volts. DO NOT attempt to modify
the plug in any way or use adaptors to defeat the purpose of the grounding feature.
2) This heater is hot when in use. To avoid burns, do not let skin come in direct contact with
hot surfaces. The grill directly in front of the heater outlet becomes hot during heater
operation.
3) Front of fireplace should remain not blocked while in use.
4) CAUTION: Extreme caution is necessary when any heater is used by or near children or
those with disabilities. Never leave the heater operating unattended.
5) Do not operate any heater with a damaged cord or plug or after the heater malfunctions,
has been dropped or damaged in any manner. Take heater to authorized service facility
for examination, electrical or mechanical adjustment or repair.
6) Under no circumstance should this electric heater be modified. Parts having to be
removed for servicing must be replaced by a certified repair center prior to operating this
electric heater again.
7) Do not use outdoors or anywhere it can get wet. This heater is not intended for use in
bathrooms, laundry areas and similar indoor locations. Never locate heater in bathrooms,
laundry areas and similar indoor locations. Never locate this appliance where it may fall
into a bathtub or other water container.
8) Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or similar
coverings. Arrange cord away from traffic area and where it will not be tripped over.
9) To disconnect heater, turn off all controls, then remove plug from outlet.
10)Connect to property grounded outlets only.
11)Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this
may cause an electric shock or fire, or damage the heater.
12)To prevent a possible fire, do not block air intakes or exhaust in any manner. Do not use
on soft surfaces, like a bed, where openings may become blocked.
13)CAUTION: A heater has hot and arcing or sparking parts inside. Do not use it in areas
where gasoline, propane, paint, or flammable liquids are used or stored or where the unit
will be exposed to flammable vapors. The heater should not be used as a drying rack for
clothing. Do not hand any decorations on the heater.
14)Do not modify this heater. Use this heater only as described in this manual. Any other use
not recommended by the manufacturer may cause fire, electric shock, or injury to

3
persons.
15)Avoid the use of an extension cord because the extension cord may overheat and cause a
risk of fire. However, if you have to use an extension cord, the cord shall be No.16AWG
minimum size and rated not less than 1875 watts, and 3-wire cord with grounding type
plug and cord connector.
16)Do not plug this product into a receptacle controlled by a wall switch or dimmer.
17)Always use a certified electrician should new circuits or outlets be required.
18)Always disconnect power before performing any cleaning, maintenance or relocation of
the heater.
19)For off-season storage, keep in a dry place.
NOTE: Procedures and techniques that are considered important enough to emphasize.
CAUTION: Procedures and techniques, which, if not carefully followed, will result in damage to the
equipment or personal property or may cause personal injury.
WARNING: Procedures and techniques, which, if not carefully followed, will expose the user to the
risk of serious injury, illness or death.
WARNING:
This heater and parts become hot when in use. The area directly around and under the heater
must be clear and free of any obstructions.
DO NOT ALLOW CHILDREN TO OPERATE THIS HEATER. KEEP CHILDREN AND PETS
AWAY FROM HEATER AND CONTROLS.
Electrical Parameter
Power supply: 120VAC
Frequency: 60Hz
Power: 1500W
NOTE: If the supply cord is damaged, it must be replaced by the manufacturer, its service agent
or similarly qualified persons in order to avoid a hazard.
Parts list
REF NO
DESCRIPTION
QTY
A
Screw
#8 x 1”
8 PCS
B
Anchor Screw
8 PCS

4
C
Mounting Bracket
1 PC
D
Washer
4 PCS
E
Mounting Screw
2 PCS
F
Log
W914-40F: 8 PCS
W914-48F: 10PCS
W914-60F: 14PCS
G
Crystal
500 g
Product Dimension:
Model
A
B
C
D
E
F
G
H
W914-40F
40”
17.7”
6.2”
35.92”
16.27”
5.94”
33.7”
9.05”
W914-48F
48”
17.7”
6.2”
43.91”
16.27”
5.94”
41.69”
9.05”
W914-60F
60”
17.7”
6.2”
55.88”
16.27”
5.94”
53.7”
9.05”
Installation:
Caution: This heater can be installed in two ways, which can be selected according to your preference.

5
Type 1. Built-in Wall
Clearance: Please allow a minimum of 0.5” spacing from the rear of the unit to a wall.
Wall Opening Dimensions:
Note: Before installing the heater, please confirm the opening size of the wall.
Model
Unit Overall Dimensions
Cutout Dimensions(W*D*H)
W914-18F
18” x 6.2” x 24”
15.75”x 6.313”x 23.625”
W914-26F
26” x 6.2” x17.7”
22.75”x 6.313”x 17.125”
W914-30F
30” x 6.2” x17.7”
26.75”x 6.313”x 17.125”
W914-36F
36” x 6.2” x17.7”
32.75”x 6.313”x 17.125”
W914-40F
40” x 6.2” x17.7”
36.75”x 6.313”x 17.125”
W914-48F
48” x 6.2” x17.7”
44.75”x 6.313”x 17.125”
W914-60F
60” x 6.2” x17.7”
56.75”x 6.313”x 17.125”
Step 1: (1) Find the two mounting screws and remove them. (2) Remove the front cover by pulling it
upward (See Fig. A (1) and Fig. A (2)).
